Paw Brothers PBP89320 User manual

Copyright ©2020, G & G Distribution, Inc. All Rights Reserved
PBP89320/89321 Paw Brothers®
Pro Hydraulic Grooming Table
Service Manual
&
Warranty Information
FB: @Ryanspet IG: @Ryanspetsupplies

Copyright ©2020, G & G Distribution, Inc. All Rights Reserved
2
Your Paw Brothers® Pro Hydraulic Grooming Table features a removable table top for easy cleaning and a “Z” shaped
base that eliminates wobbling and tipping. The all metal frame is strong and long lasting. An antistatic baked epoxy
finish adds style and durability. The removable top is made with Belgian poly-board covered by a premium non-slip
rubber surface. The outstanding quality Italian style hydraulic pump mechanism allows the table to adjust from 19” to
40”, with a maximum lifting capacity of 200 lbs.
In the unlikely event your table should need repair the following replacement parts are available:
Hydraulic Pump
Leg Levelers
Grooming Arm
Removable & Reversible Safe-T Grid™Table Top
Initial Inspection
When your Paw Brothers® Pro Hydraulic Grooming Table arrives, check immediately for signs of shipping damage. If
you notice damage, save the shipping carton for claim purposes, and immediately report the problem to your supplier
and to the shipping company. Also, save the carton for shipping in case your product ever needs repair at a remote
location.
Tools Required for service: #2 Phillips Head Screwdriver
Allen wrench
Set of metric wrenches or sockets
Pliers

Copyright ©2020, G & G Distribution, Inc. All Rights Reserved
3
Pro Hydraulic Grooming Table
Service Instructions
Caution: The hydraulic table is heavy. Two people are be required for these procedures.
Hydraulic Pump Replacement
Step 1: Remove the table top from the frame assembly, and set it aside. Remove the grooming arm. Turn the entire
frame assembly upside down and place it on a protective surface to avoid marring the epoxy finish.
Step 2: Using an Allen wrench, remove the foot lever by loosening the two set screws on either side of the hydraulic
pump. Note the position of the foot lever and how it goes through the slot in the frame assembly.
Arm Clamp Adjustment
Knob Under the Table
Grooming Arm
Hydraulic Pump and
Foot Lever
Removable/Reversable
Safe-T Grid™Table Top
Frame Assembly
Leg Levelers

Copyright ©2020, G & G Distribution, Inc. All Rights Reserved
4
Step 3: Remove the cotter pin and retaining bolt from the frame assembly. See Figure 1.
The cotter pin and retaining bolt
hold the top portion of the hydraulic
pump to the frame assembly.
Step 4: Remove the two bolts from each side of the hydraulic pump holder. See Figure 2.
Step 5: Lift the hydraulic pump up and out of the frame assembly.
Step 6: Remove the screw holding the plastic cover for the hydraulic pump.
Step 7: Remove the four nuts and washers holding the hydraulic pump to the pump holder. Remove the lock washers
located under the holder.
Step 8: Attach the pump holder to the new hydraulic pump, making sure the lock washers are installed under the
holder. Put on the four washers and nuts. Tighten each nut. Re-install the pump cover.
Step 9: Place the hydraulic pump and holder into the frame assembly and re-install the two holder bolts. Note: Make
sure the hydraulic pump is in the correct position for the foot lever to be attached.
Step 10: Re-install the cotter pin and the retaining pin. Turn the table upright, and install the foot lever. Tighten both set
screws for the foot lever. Re-install the table top and the grooming arm.
Figure 1
Figure 2 Figure 3
Pump Cover
Pump Holder
Hydraulic
Pump
Hydraulic
Pump Holder
Bolt

Copyright ©2020, G & G Distribution, Inc. All Rights Reserved
5
Statement of Limited Warranty
Warranty Period
Your hydraulic table is warranted against manufacturing defects in materials and workmanship, to the original
purchaser, after the date of purchase, for six months for parts only. During the warranty period components that do fail
may be repaired or replaced at the discretion of G & G Distribution, Inc. Any warranty claims must be accompanied with
a copy of the original purchase invoice. For warranty service call 1-800-525-7387.
Warranty Exclusions
This warranty does not cover failures or damages resulting from misuse, accidents, modifications, unsuitable physical or
operating environments, acts of nature, transportation damages, or improper maintenance.
Limitation of Liability
Under no circumstances is the supplier liable for third party claims against you for damages, special, inci-dental, or
indirect damages, or for any economic consequential damages, or lost profits, business revenue, goodwill or anticipated
savings. Some states or jurisdictions do not allow the exclusion or limitation of inci-dental or consequential damages, so
the above limitation or exclusion may not apply to you.
