PAWW SoulSound 2 H1010 User manual
1. INTRODUCTION
Congratulations on your purchase of the Paww SoulSound 2 Bluetooth headphones! Please read the
instructions and warnings carefully before use to ensure safe and satisfactory enjoyment of this product.
SAFETY PRECAUTIONS
1. To ensure your safety, please follow the instructions in this manual carefully before operating the
headset.
2. Keep the device away from edges, uneven surfaces, unstable locations, metal parts, accessories and
packaging to prevent any possible damage or malfunction of the device
3. Do not dismantle, disassemble, modify, or attempt to repair at your own discretion, especially battery
mismatch or mishandling, as this may cause fire or explosion, electric shock, or complete damage to the
unit. Doing so will void the warranty of the device.
4. Keep the device away from water, any liquid, moisture, rain, very humid areas or places with excessive
dust environment. Do not use diluents or volatile liquid when cleaning the Bluetooth stereo headphone.
5. If the device is exposed to water, moisture, oil, or other liquids, do not operate to avoid electrical shock
or possibly damage and injury to the device and to yourself.
6. Keep the headset away from fire, heat source, or flammables.
7. Avoid using the headphone in unsafe and dangerous locations.
USAGE WARNING
Listening to high volumes can lead to permanent hearing damage.
2. PACKAGE CONTENT
1 Paww SoulSound 2 Headphones
1 Custom Carry Bag
1 USB Charger Cable
1 Aux-in Cable
1 User Manual
3. CONNECTION DIAGRAM
1. MFB Buttons
Turn on / Turn off
Pairing Mode
Answer Call
Reject Call
End Call
Activate Siri or other Voice system
Play / Pause
2. Charging
3. 3.5mm Audio Jack
Model:H1010
FCC ID: 2AR52-H1010
4. Volume Down / Previous Track
5. Volume Up / Next Track
6. Microphone
7. Notification LED Light
8. Bass Boost Function
4. HOW TO USE
4.1. Quick Usage Guide
Desired Result
Required Action
Turn On & Entering Pairing
Mode
Press the "MFB" button for 3 second while the device is off. The LED
will flash blue and red alternatively and you will hear one beep.
Volume Up
Short press the "+" button for volume up
Volume Down
Short press the "-" button for volume down
Play Previous Track
Long press the "-" button for previous music.
Play Next Track
Long press the "+" button for next music.
Turn Off
Press the "MFB" for 3 seconds while the device is on. The LED will
turn off and you will hear a beep.
Play / Pause
Press the "MFB" button to play music when the device is connected
and to pause when the device is already playing music.
Low Battery Warning
The LED will flash continuously in red.
Charging
Plug the charger into the micro-USB port. The LED will light up in red
indicating that the headset is charging.
Answer Call
Short press the "MFB" button to answer an incoming call.
End Call
Short press the "MFB" button to end a call.
Transfer Voice Call
Press the “MFB” button for 1 second to transfer a voice call between
the mobile phone and the headphones during an ongoing call.
Reject Call
Press the "MFB" button for 2 seconds to reject a call.
Activate Siri or other Voice
assistant
Double press the "MFB" button to activate Siri or other Voice
assistant.
Turn off Siri or other Voice
assistant
Double press the "MFB" button to turn off Siri or other Voice assistant.
4.2. Pairing to a Mobile Phone or Other Device
To pair your SoulSound 2 headphones with a phone or a computer, please follow the steps below.
Once your device is paired to a specific device they will remain paired and will automatically
recognize each other whenever they are within range and Bluetooth is switched on.
Steps for pairing to a Bluetooth-enabled device
1. Turn on your device and activate the Bluetooth mode.
2. Turn on the Paww SoulSound 2 headphones and enter Pairing Mode by pressing the
“MFB” button for 3 seconds.
3. On your Bluetooth-enabled device, scan or search for new devices. Please refer to the
device’s user guide for more information on how to do this.
4. Select SoulSound 2 from the list of new devices available.
5. If asked for a Pass Key or PIN, enter 0000.
6. If asked to confirm the pairing, press Yes.
4.3. Connecting to Two Devices Simultaneously
1. Pair the PureSound headphones to your first device using the steps described in section
4.2.
2. Once paired successfully, turn the headphones and Bluetooth function on the first
device off.
3. Turn on the headphones.
4. Now pair the headphones to your second device using the steps described in section
4.2.
5. Once pairing is successful with the second device, turn Bluetooth on in the first device.
6. Click “SoulSound 2” on the first device, now two devices are connected to the same
headphones.
Note:
1. When reconnecting, the headphones will automatically connect to one of the two devices
automatically. To connect the second device, you will have to go to Bluetooth settings and
select SoulSound 2 from the list of available devices.
2. To switch sources when listening to music, press pause on the device playing the music,
and press play on the second device. There may be a few second gap before the switchover
happens.
4.3. Charging your device
A USB cable is needed to charge the headset and a 5V output DC adapter. Before using the
device, make sure to charge for at least 6 hours prior to initial use. When charging, the LED
indicator will show a solid red light. When the device is fully charged, the LED indicator turns to
blue. Headphones will automatically turn off when charging.
5. Technical Specifications
Parameter
Value
Bluetooth Specification
Bluetooth 4.1
Supported Bluetooth Profiles
A2DP1.2/ AVRCP1.4/ HSP1.2 /HFP1.6
Battery Capacity
500 mAh
Operating Distance
10 m
Frequency Response
20Hz-20KHz
Impedance
32Ω±15%(at 1KHz)
Sensitivity
112dB ±3
Speaker Dimension
40mm
Playback Time
about 17 hours
Charging Time
about 2.5 hours
Dimension (L×W×H)
203×170×94mm
Weight
270g
6. Warranty
The Paww SoulSound 2 headphones ship with a 1-year warranty. If you do encounter any
issues during this time, you can initiate a warranty claim by contacting us via email on
support@mypaww.com or through the Contact Us page on our website
(https://www.mypaww.com/pages/contact-us).
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
