Pearmain PE512X Series User manual

PE512X Universal Keyboard
PE512X series is Universal keyboard to Matrix switcher, DVR and pan-tilt (speed dome),
to offer system program, switch & pan-tilt and lens control, etc. function, with Pelco,
Samsung, etc. protocol, to make PE512X can be compatible to popular platform.
With Marco function, multi-function keys, also it can determine keys according to practice,
it can upload and program firmware of Marco and other function key from PC directly.
PE512X can receive alarm information from matrix to trigger other auxiliary operation or
relay.
3 communication ports to have RS485/RS422/RS232, baud rate can set.
With 10M/100M Ethernet port optional.
Operation keys display on 240x128mm LCD by icon.
LCD indicate system status, operation success indicator, with several tone available,
volume can set.
With 3-D joystick
Technology Specification
Display method: 240mm×128mm LCD
Communication mode: RS-485/RS-422/RS-232/Ethernet 10/100M
Communication speed: can set
Connection method: RJ45
Relay drive: 1A/110VAC or 3A/24VDC
Key quantity: 46
Pan-tilt control: 3 or 4-asis joystick
Power failure protection: 10 years
Working temperature: -10℃～+45℃
Working voltage: 9VDC
Power: 5.0W
Weight: 1.5KG
Dimension: 370（L）×190（W）×55（H）mm
Installation method: desktop
PE512X icons
Lots of icon of PE512X to express functions, we suggest user to know well usual icon.

PE512X Universal Keyboard
System icon
confirm cancel input exit menu
confirm store backlight display set
to indicate command running next page of LCD menu
previous page of menu next page of menu
right page of menu left page of menu
power forbid invalid caution
Silence password set data upload data download
communication port 1 communication port 2
communication port 3 communication port 4
keyboard Lock help matrix
monitor fixed camera receiver/driver
DVR control
Function icon
switch time auto switch program switch
salvo switch right down right
down down left left
top left above top right
Zoomin zoom out iris close iris open
Focus near focus far set run
AUX1 AUX 2 AUX 3 AUX 4
auto scan line scan
left limit of line scan right limit of line scan
preset Tour park action pattern scan
privacy masking privacy set privacy forbid stop
volume increase volume decrease key voice alarm voice
voice set alarm control alarm mention record
play pause stop
speed backward speed forward previous section
next section
signal window window in window 4window
9 window 16window
Inform remind icon
key volume current ID current port
of icon list is same to usual “ENTER”, or usually can replace by ESC.
Inform remind icon maybe is different to sample, e.g. voice increase
： is
current port COM3
Function area instruction
Key area, function area of PE512X is following,

PE512X Universal Keyboard
There is a basic principle of PE512X,
1、usual function can be on main key.
2、LCD OSD menu operation area to run unusual(senior) function and system
parameter set.
Input switch
Main for input value, including camera number to call, monitor number to call, etc.
Function key
To run usual operation, e.g. monitor to call, switch, AUX switch control, call preset, etc., it
also switch to DVR control mode, to have main operation of DVR.
Lens operation
To control IRIS, FOCUS of lens.
Vector joystick
To operate pan-tilt rotate at random, multi-speed switch, zoom function of camera.
Display operation area
F1 ~ F8：real-time function key, F1~F8 can change in real-time, when in condition of
operation all function key, proper function will mention on LCD.
M1 ~ M8：Marco command key, user can program a series of command in advance, just to
press corresponding Marco key, it can run all linked commands, it can save 999 Marco at
most.
Indicator of power, communication and alarm
When power-on, power indicator will be on immediately, communication indicator flashes
to mean normal communication keyboard and wanted device, matrix alarm will enable
alarm indicator.

PE512X Universal Keyboard
Usual operation function
As followings,
0~9 to input numeral
sSITE to call wanted Smatrix (ssite)
mMON To call wanted m monitor（output）
nCAM To switch camera n(input) to wanted monitor
Joystick movement To control direction of pan-tilt, or move cursor in menu
Joystick rotation Zoom in or zoom out
NEAR/FAR Focus Near or Far
CLOSE/OPEN IRIS close or open
ESC to cancel combination operation function or exit to superior
menu.
FUN to make keyboard condition switch during “Master matrix Æ
DVR direct control Æspeed dome direct controlÆmaster
control” switch item set in keyboard parameter in advance
ENTER To confirm input, enter into junior menu
ACK when keyboard alarm is triggered, ACK key to cancel alarm
condition
This function available only matrix set as fixed alarm mode, if in circle alarm mode,
when keyboard clear alarm, it will alarm again.
nAUX ON Auxn of receiver/driver on
nAUX OFF Auxn of receiver/driver off
nPRESET To call preset n
BWD To switch current monitor to previous CAM
FWD To switch current monitor to next CAM
nENTER ON To add camera n to current monitor zone switch
nENTER OFF To delete camera n to current monitor zone switch
xON yOFF To switch camera X to Y on current monitor
mRUN To call program switch m
SALVO BWD to choose previous group of Salvo
SALVO FWD to choose next group of Salvo
nSALVO ON To run Salvo N
nSALVO RUN To call Salvo N
SALVO OFF To stop Salvo
Screen button operation
Parameter set and various high function of matrix, keyboard must do through F1~F8 of
LCD.
LCD interface
During operation, high operation and information remind mainly display by LCD, details as
following diagram,

PE512X Universal Keyboard
Button:
Function button: function transaction key, current function display on screen.
Such as F1 of above diagram to choose pan-tilt.
（ ）
Marco command: Marco transaction key.
Information:
Function item: function of function-key will change according to operation status, which
indicate current function of proper keys.
Sub function: when choosing some function, it will require some function button operation
(just as sub menu), this site to indicate function of current operation item.
As diagram, it is running line scan （ ） of pan-tilt （ ）
It will display opposite color of icon.
System function, confirm, cancel, exit, which will display while log-in, parameter set.
Input, display area: to display current wanted matrix, monitor, camera and input numeral
etc.
Status display: to display current system status.
As diagram, Volume3
（ ）， User 1 log-in （ ）， to use COM2 （ ）， that is
RS422.
It will display opposite color of icon.
Real-time status: to display running operation, e.g. to press MON, to display character
“MON”.
as diagram, joystick is running top-left
（ ） and it also sent command （ ） .
Some key, such as MON repeat pressed, it will not send command, so it will not
display .
Following instruction is according to OSD menu, to explain operation of administrator,
user.

PE512X Universal Keyboard
Power-on
When power-on, it will display manufacturer logo, keyboard model, then it will display user
interface, as followings,
User log-in
In condition of user log-in, it will display function model of current keyboard,
PE5123RS can display “receiver/driver speed dome” or “DVR”
PE5123S also can display “PE40”
、 “PE50” or “PE60”
PE5124S or PE5125 can display “NET keyboard”.
Administrator can set Exact model displayed on keyboard, details will be in following
“ administrator log-inÆkeyboard managementÆKeyboard model available”.
It will require ID and password, as following sheet,
Model Keyboard model ID Password
1 Receiver/driver/speed
dome
2 DVR 1~64
3 PE40
No password required
4 PE50 1~16
5 PE60 User password of matrix
6 NET keyboard 1~32 Set on keyboard by
administrator
This model support 66 ID ， 1~64 is operator, ， 0 and 99 is for administrator, which can
set parameter of keyboard or matrix.
Set of “user password of matrix”, please refer to user manual of matrix.

PE512X Universal Keyboard
Administrator operation
Log-in by administrator to set parameter, when first time log-in.
Administrator ID:0, initialization password is“11111”, administrator ID:99, initialization
password is “99999”, administrator can set new password by “User
managementÆpassword management” .
99 administrator mainly set parameter of PE60 matrix, 0 administrator mainly set
parameter of others.
0 administrator and 99 administrator can not set password each other, but they can
manage other all user password.
Sample by 0 administrator, input ID “0” and password “11111”, enter into management
interface.
Management interface including keyboard management, user management, master menu,
initialization, ID set, character set, language set, etc. 7 items, every item contain its sub
menu.
Relation of management menu as attachment, following explanation is according to
management interface.
Following set will be available once press “store”
（ ）
¾Followings with “to choose wanted matrix ID”
， if keyboard does not set as NET
keyboard, without this item.
1 Keyboard management
Set use environment of keyboard
1.1 Choose Keyboard model
To choose keyboard as direct control DVR, receiver/driver or control PEARMAIN
matrix.
Initialization set is to control “NET matrix”.
1.2 Set FUN
In usual system operation, every time to press FUN, current operation will switch
during “master controllerÆDVR controllerÆspeed dome controllerÆmaster
controller”, it can set FUN invalid here , or just only switch between 2 function.
Initialization set is “matrix
Æ DVR Æ speed dome”
1.3 DVR setup
To set protocol, baud rate etc., communication parameter and to choose
communication port.
1.3.1 To choose Protocol
Current version only with PEARMAIN DVR protocol.
1.3.2 Communication port
Keyboard with COM1, COM 2, COM3 3 ports, to use RS485,RS422 and
RS232 separately, user can choose “modify” to have corresponding port

PE512X Universal Keyboard
according to practice.
Initialization set is “RS232”, that’s COM3.
1.3.3 Baud rate
It can choose baud rate, stop-bit, parity-bit
Initialization set is 9600, 4800,2400,and none.
1.4 Speed dome setup
Similar to “ DVR setup”, besides PEARMAIN protocol, it also can choose Pelco
P/D.
Initialization protocol is “PEARMAIN” protocol.
1.5 Marco setup
It must use attached CD together to set Marco, which is only for keyboard with
Marco, details for Marco set software.
2 User management
To enter ID (1 to 64 or 0) according clew, then it can manage password, site and
DVR of this user.
User management only for keyboard to control “NET master”,all password of
keyboard ID is according to this setup, details for “User log-in”.
To administrator user, It only can manage, can not operate, so it is available of
password item.
ID 99 can manage all ID except ID 0, same to ID 0.
2.1 Password management
To press “modify” key and then input new password, “delete” key to delete this
user, it is available again, if to set new password for this user again.
Initialization password of all 64 ID is “12345”.
2.2 Site management
M1~M4 key for cursor movement, M5、M6 for next page, corresponding
site(NET matrix ID) set as 1, to indicate user can control the matrix of this site, if
not, set as 0, it can set “all modify” to set as 0 or 1.
Initialization set of 64 ID, which can control all matrix.
2.3 DVR management
Similar to “site management”, to corresponding DVR, it can set as 0,1 or 2, 0 is
“can not control”, 2 is ”can control all function”, 1 is “only can have playback,
multi-window, etc. operation, can not record, enter into menu etc. to modify
parameter”.
Initialization set of 64 ID is no any limit to all DVR control function.
3 Matrix menu
To choose ID of wanted matrix, then it can revise menu by page up/ down/left/right
and confirm, cancel, exit and input data etc.
To “NET matrix”, it should check whether in menu or not.
4 Initialization
To choose wanted matrix ID, then it can choose to only matrix initialization or
keyboard initialization.
After matrix or keyboard initialization, it will set all parameter again.
When choose initialization, it will require administrator to confirm.

PE512X Universal Keyboard
5 ID setup
It can set keyboard ID,MAC or IP.
5.1 Keyboard ID
It main use for matrix to judge command source, same matrix can have
multi-keyboard, so it should set ID for different keyboard.
Initialization ID is 0.
5.2 MAC
It should set MAC when Keyboard use for Ethernet, MAC should be different to
other device in Ethernet.
MAC of Initialization is 11-11-11-11-11-11.
5.3 IP
When keyboard in Ethernet, it should set IP, IP of keyboard should be different to
all other device, and it also need to set gateway and subnet mask.
IP of initialization is 192.168.0.1
， subnet mask: 255.255.255.0 ，
gateway:192.168.0.1 。
6 Character setup
To choose matrix ID, Monitor number of wanted character, then it can set title of
camera to display or mask, time display or mask, and joystick to move position of
character.
It also can control “title renew”, it can renew all camera title output from matrix
according to set of matrix menu.
To choose monitor ID “0”, and to operate all monitor output title of matrix.
“Renew title” will take 4 minutes at most, during this period, matrix without
communication, if longer time, it can not recover, restart matrix.
7 Language setup
Current version with Chinese and English, after modification, wanted language will
run immediately.
Initialization set of language is English
User operation
After administrator set parameter, user can operate according to requirement.
Log-in
Please refer to description of “User log-in”, to input ID and
password, e.g.ID:1 and password:12345 to go to “NET
matrix.”
To press M1
（ ） or ENTER to confirm, M2 （ ）
to cancel current input, M3 （ ） or ESC to cancel all
input.
If ID and password can meet setup, it will go to operation
interface immediately, if not, it will remind ”wrong password”,
and require new password.
If in control mode of PE50
、 PE60 ， it must be on base of

PE512X Universal Keyboard
normal communication and correct password.
Basic operation
After correct log-in, basic operation interface will display.
Many function model will display, it can not display on same screen, to press F8 to next
page, all function will display.
F1
F2
F3
F4
F5
F6
F7
F8
M1
M2
M3
M4
M5
M6
M7
M8
SITE：01
MON：001
CAM：0001
ENTER：_ _ _ _
SITE：01
MON：001
CAM：0001
ENTER：_ _ _ _
To press F8（ ）, it will display above two basic interface.
Current diagram to indicate voice volume is 3, user 1log-in, communication port is
COM2.
Press next in this interface, it can have following operation.
1. “usual operation function” listed on above.
2. Function of F1~F8 and junior function, exact function should be according to
attachment “user operation model icon list”.
3. some operation in followings should work with matrix, pan-tilt or alarm etc. device,
which should support by exact function, please refer to proper user manual.
e.g. user want to switch camera 3 of matrix 2 to monitor 4, and also to have image
right of monitor 3（camera 3 can move）, operation should be: 2 SITE 4 MON 3
CAM, then move joystick to right, aim to wanted monitor point.
As followings,
SITE：01
MON：001
CAM：0001
ENTER：_ _ _ 2
SITE：02
MON：001
CAM：0001
ENTER：_ _ _ _
SITE
SITE：02
MON：001
CAM：0001
ENTER：_ _ _ 4
to input 2 to input SITE to input 4

PE512X Universal Keyboard
MON
SITE：02
MON：004
CAM：0001
ENTER：_ _ _ _
SITE：02
MON：004
CAM：0001
ENTER：_ _ _ 3
CAM
SITE：02
MON：004
CAM：0003
ENTER：_ _ _ _
to input MON to input 3 to input CAM
User can see followings,
When input numeral, it will display wanted numeral after “ENTER” ;
When to press function, it will display key name in real-time condition.
When real-time status area display “ ”, to indicate current operation has sent data to
COM2, e.g. to operate CAM and move joystick.
Generally, Camera operation will send data, but if input area indicate no data, to
press CAM directly, it will not appear “ ”, that is invalid.
Generally,, pan-tilt control etc. basic operation will be in user basic interface, if in
superior operation interface, it wants to control pan-tilt or camera switch, or to run
FUN, it should exit and then go to basic interface.
Joystick move to right CAM switch is invalid
Besides usual operation, it can run function by F1~F8 on left basic interface, including
pan-tilt, matrix alarm, DVR, keyboard lock, matrix menu, keyboard voice, backlight,
password change, etc., as followings,
Pan-tilt operation
SITE：02
MON：004
CAM：0003
ENTER：_ _ _ _
SITE：02
MON：004
CAM：0003
ENTER：_ _ _ _
CAM

PE512X Universal Keyboard
To press F1 pan-tilt key , then it can operate further pan-tilt, speed dome, etc. superior
function, as following diagram,
SITE：01
MON：001
CAM：0001
ENTER：_ _ _ _
Line scan
In Lin scan, to press to set left-limit, to set right-limit, ESC to basic interface.
Auto
To press run auto function, to stop auto function.
Preset
Input numeral n, to press , that is to set current camera ID as preset n, to delete
preset n.
Tour
As diagram, input wanted tour n, is to run tour, is to stop tour, is to delete
tour.
To press to begin to set current tour: input swell time t, F3 to confirm input time, input
preset x, F2 to confirm preset input, that is to set a preset of tour.
And it also can not set time t, default time of keyboard is 2 seconds.
After set all preset, to pressF4 to finish set of this tour.
ENTER：_ _ _ _
：001

PE512X Universal Keyboard
“001” on above diagram to indicate to choose tour 1.
Park function
To set park time, it will auto call home position, preset or other park action, or cancel park
function.
Patter scan
To input wanted pattern number, to confirm,
To go to “setup”, then following action of pan-tilt and lens will record as pattern.
When record pattern, generally, it will auto stop record, when record time reach to longest
time, if not, to stop record by manual.
“Run”, just to run current pattern, any command will stop pattern scan.
Menu
to enter into menu, to move cursor by joystick, it can operate to confirm, to
cancel or to exit.
It can run “change, confirm, cancel or exit, etc.” by joystick rotation（zoom in/out）.
Privacy masking
After going to menu of privacy masking, to input wanted privacy number, to confirm.
To press to set masking, after “Start”, then to use joystick to set, “end” to finish setup.
to run current privacy masking（it must be valid）,is set to invalid.
Alarm control
Pan-tilt and speed dome can be with alarm function, this item to control some alarm zone
alarm-on, all alarm-on, all alarm-off, it will clear alarm-remind after alarm.
If alarm of matrix being triggered, followings will run in keyboard,
1. alarm indicator on.
2. alarm –remind voice（set by administrator in advance）.
3. RELAY of matrix will link other device.
After keyboard respond to alarm, to pressACK to recover condition before alarm.
Switch time
To set auto switch time of matrix output（MON）.
Keyboard should require wanted monitor number, then input time(second), then
press F2(time) to confirm.
Matrix alarm function
As following operation,
Alarm-on/off, it can set alarm on/off to individual alarm zone, input alarm zone ID
before operation.
Alarm group on/off, set alarm on/off to a group of alarm zone, input alarm zone group
ID before operation.
Auxiliary function, to control auxiliary switch open/close of alarm unit (connection with
matrix), and it also can set time from On to Off.
Clear, when alarm being triggered, it will be some clew on monitor, even alarm
disappear, clew still will be on monitor, if user doesn’t want it, it can clear.
Please refer to user manual of matrix and alarm unit for above function.
DVR operation

PE512X Universal Keyboard
When it indicates to input DVR ID, which can run usual functions o f DVR, as following
diagram,
Multi-window: single window , 2-window（window-in-window）, 4-window ,
9-window , 16-window ;
To choose designated record channel , stop record ，or previous record , next
record ;
Enter into menu of DVR , move cursor by joystick, numeral input, to confirm, to
cancel.
In this condition, it can control DVR by function keys, such as: RUN
、 BWD 、
FWD 、 SALVO ;
It called DVR 2 in above diagram.
Keyboard lock
It will require user to input password and then lock, user can not operate, it must unlock by
password.
Matrix menu
After to press , if want to control NET matrix, it must input matrix ID, then enter into
menu.
It can operate followings, including Up/down/left/right page, to move cursor by joystick,
input numeral, etc.
Keyboard voice
It can increase or reduce voice volume, and set button tone and alarm tone
, it will tone sound when set.
LCD backlight
It can make character on screen bright, once backlight is on, as with problem of
high-consumption and high-heat, so we suggest to set as auto close backlight when
keyboard unused.
Time to close backlight can set as 2,5,10 or 20 minutes.
Default time is 2 minutes.

PE512X Universal Keyboard
User password change
User can change its password, please operate according to menu, there it will indicate
password has been changed or not.
Exit
It can exit from operation interface and go back user log-in.
FUN operation
After administrator set function of FUN, user can press FUN key to switch current
operation function in user interface.
to control receiver/driver and to control DVR directly
speed dome directly
It is to press repeat FUN key to go to interface of direct control receiver/driver and speed
dome, in fact, it is similar to interface of matrix to control receiver/driver and speed dome,
following operation is difference,
1. When in direct control speed dome, user is nothing to operation, it will display ID
on status.
2. When in direct control receiver/driver, it is nothing to matrix and matrix output, so
it will not display SITE and MON.
3. Usual RS485 port for receiver/driver, RS232 port for DVR, so administrator will
set RS485 and 232 port, just like above diagram, it displayed COM1 and COM3,
administrator can set different parameter according to practice, the port should
be same.
Besides, operation is same to control receiver/driver and speed dome by matrix.
If FUN is set to “master
Æ direct control DVR Æ direct control Speed dome”, FUN will
limit from set.
Other protocol
Administrator can set direct control receiver/driver, speed dome with Pelco D/P protocol,
or other protocol, and it also can control other device via protocol converter.
As function of different front device is not same, so it can not run all function, so user
should be familiar with its front device.

PE512X Universal Keyboard
1. Initialization set of keyboard
1、Default password
Administrator 0: 11111
Administrator 99:99999
It is no Password for User 1~64 control receiver/driver, DVR PE40 matrix.
To control NET master: 12345
（ set in keyboard ）
To control PE50、PE50M、PE60:it is password of corresponding to matrix.
2、Keyboard type: NET master
3、FUN: Matrix
Æ DVR Æ Speed dome
4、DVR set
a) Communication protocol: DVR protocol of PEARMAIN
b) Communication port: RS232
（ COM3 ）
c) Baud rate: 9600,8,2,NONE
5、Speed dome settings
a) Communication protocol: PEARMAIN protocol
b) Communication port: RS485
（ COM1 ）
c) Baud rate: 9600,8,2,NONE
6、User management
a) Password management :password of User 1~64 is 12345
（ to control NET
master
）
b) Site management: User 1~64sets all site is 1.
（ it can control all matrix ）
c) DVR management: all 64users set DVR as 2
（ it can control all DVR ） .
7、ID set
a) Keyboard ID: 0
b) MACID:11-11-11-11-11-11
c) IP: 192.168.0.1
d) Sub mask:255.255.255.0
e) gateway: 192.168.0.1
8、Language: English
9、Voice settings
a) Volume: 2
b) Button tone:1
c) Alarm tone: 1
10、Backlight dwell time: 2 minutes
