Pecron Q Series User manual

User manual for Q Serial
PORTABLE POWER STATION

Content
1.Product introduction
2.Functions
3.Notice for function
4.Warranty service
PORTABLE POWER STATION

1.Product introduction
Thanks for choosing our portable power station which Q serial
is with light weight, high battery capacity and large power
rate. This back-up power device can easily provide power in
the fields of mobile, outdoor areas just like ambulance, fire
rescue and is always applied to outdoor emergency situations,
blackout areas and so on.
Main functions for Q serial:
Please read the manual before using the power pack and
put it together with the power device for future use.
Q2000/Q3000 main functions
Q2000S/Q3000S main functions
220V/50Hz or 110V/60Hz pure sine wave output
UPS
Solar charge
***
12V10A DC output
QC3.0- dual USB output
Intelligent display screen
PORTABLE POWER STATION

Specifications
Model
Q2000
Q3000
Q2000S
Q3000S
AC output voltage
AC220V50Hz or 110V60Hz
Output waveform
AC pure sine wave
Rated power
2000W
Peak power
4000W
Battery capacity
1885.52Wh
(25.9V72.8Ah)
2693.6Wh
(25.9V104Ah)
1885.52Wh
(25.9V72.8Ah)
2693.6Wh
(25.9V104Ah)
Battery type
Lithium-ion battery
Charging voltage
and current
AC100~240V
DC29.4V5A(built-in charger)
DC29.4V10A
DC29.4~40V20A(Solar
charge）
Charging time
15~16H
21~22H
8~9H
11~12H
DC output
QC3.0(5V2A 9~12V1.5A)
DC12V10A
QC3.0(5V2A 9~12V1.5A)
UPS
Yes(8ms)
No
Temp
0℃~45℃(Charge),－20℃~60℃(Discharge)
Protection
Over-voltage, over temperature
overload, short-circuit
Product color
Blue+silver
Black +yellow
Dimension(cm)
L40*W24.5*H27.2
Weight(kg)
23
27
23
27
PORTABLE POWER STATION

2.Functions
Please read the main functions carefully before using the
power unit to avoid unnecessary damage.
Accessories list
NO.
Q2000/Q3000 accessories
Q2000S/Q3000S accessories
Quantity
1
AC Charging cable
Charging adapter
1
2
Car charger
1
3
***
Solar charging cable of optional
1
4
User manual and warranty card
1
PORTABLE POWER STATION

Q2000/Q3000 Panel
56 7 8
12 3 4
56 7 8
PORTABLE POWER STATION

NO.
Q2000/Q3000 features
1
AC input port:main input for AC charging of the UPS unit
2
USB ports*2 : supply power with 5V and output current of 2A.
3
Smart display : showing the battery capacity,percentage,power
and time of charging and discharging.
4
USB Output/Power switch : press this button to view the
remaining power of the power unit. At the same time, the display
will turn on, as same as the USB output.If need to turn off it,
please pressitagain.
5
UPS charging indicator:red light means the power unit is
charging, and green light means that’s fully charged.
6
DC charging ports (1, 2 is positive, 3, 4 is negative):charging
voltage of this port is DC 29.4V20A.
7
UPS AC outputs : supply 220V or 110V output after pressing the
AC switch.
8
AC output switch : AC output will work after pressing it .
PORTABLE POWER STATION

13 14 15
910 11 12
Q2000S/Q3000S Panel
PORTABLE POWER STATION

NO.
Q2000S/Q3000S features
9
DC cigar outlet :12V output with constant voltage; max current
is 10A.
10
USB ports*2 : supply power with 5V and output current of 2A.
11
Smart display : showing the batterycapacity,percentage,power
and time of charging and discharging.
12
USB Output/Power switch : Press this button to view the
remaining power of the power unit. At the same time, the display
will turn on, as same as the USB output.If need to turn off it,
please press it again.
13
DC charging ports charging (1, 2 is positive, 3, 4 is negative):
voltage range of this port is DC 29.4V~40V (solar charge) 20A
14
AC outputs : supply 220V or 110V output after pressing the AC
switch.
15
AC output switch : AC output will work after pressing it .
PORTABLE POWER STATION

3.Notice for usage
Working environment
Power charging:
Please pay attention the power unit when it's charging.Please disconnect
the charger and stop charging when the is fully charged.power pack
Please charge the power unit every six months after no use for a long time.
AC load:
Before use the power unit, please ensure the rated power of load power
is lowers than the rated power. But sometimes the consumed power of
some appliances is greater than its rated power on power-on, the overload
protection will occur and power output will turnoff. For example, the general
starting current for inductive load equipment is up to 3~8 times of its rated
power. And its starting power for energy saving lamp is up to dozens of times
of its rated power; Their starting power is much more than the instant maximum
power that the power can bear, so the load protection works automatically.
Avoid water and other liquid
Shady 0℃~45℃ for charging situation and
-20℃~60℃ for discharging situation
At least 5cm space around the power
pack
Safety Avoid petrol, gas, flammable and
other corrosive gas environments
Ventilation
Dry
PORTABLE POWER STATION

Operating steps:
(1)Turn on the AC load switch
(2)Check the working voltage and frequency of the load.
(3)Check the load power and ensure it’s not higher than the rated power
of the power unit.
(4)Plug in the AC socket of the power unit and turn on the load switch.
(5)Turn off the AC output switch after using it.
(6)Please charge the power unit on time if the battery is run off or lack of
battery so that you can use it conveniently next time!
Note：Please be sure to turn off the switch of AC power when you don't
need to use it. Or it will be in high energy consume mode, consuming the
energy in reserve, which may damage the battery
4.Warranty service
This product is warranted for 12 months. During this time our ,
company will be in charge of the it if there is defects on materials
and manufacturing. And we will offer free repair and main parts
accessories after checking it by our after-sale department.
The warrant does not cover the following cases:
. Take apart the unit privately
. Damage on surface coating and appearance.
.Breakdown due to wrong installation, packing and usage.
Customers should do this according to the manual instruction.
.Breakdown or damage caused by accident, man-made
environment( mis-operation, crash, unsuitable voltage, damp and etc.)
.Breakdown or damage caused by natural hazard beyond control
( earthquake, fire, tsunami and etc.)
.Maintenance is not including package and products accessories
We will offer paid service once warranty period is over.
PORTABLE POWER STATION

Certification
Item:
Inspector:
Date of production:
Warranty Card
Item Product name Purchase date
Factory No. Client Contact
Address Invoice No.
Dealer Address
