Pedigree Technologies OneView Cab-Mate Flex User manual

INSTALLATION MANUAL
PedigreeTechnologies.com | Support: (701)-499-0022
Cab-Mate Flex (from Cab-Mate One)
Document ID:IM-CMF
Last Updated: October 06, 2021
Pedigree Technologies recommends using a professional installer for optimal
results. Please let your Pedigree Technologies representative suggest a provider if
you need help with your hardware installations.

2
INSTALLATION MANUAL
Prerequisites
PedigreeTechnologies.com | Support: (701)-499-0022
Required Information [*needed for nal activation of hardware - see last page]
• Name of asset*(ex: Propane Truck #20)
• Detailed information about the asset*(year, make, model, VIN, license plate, etc.)
• State, area, organization, or group the asset belongs to (ex: North Region, MN tankers, etc.)
• ESN of each device to be installed* (ESN is found on the back of each unit with a barcode)
• Current odometer reading
• Type of diagnostics connector, if possible (6 pin, 9 pin square flange, 9 pin round threaded,
J1962, Type II, etc.)
Required Equipment
Required Tools
• Drill and assorted drill bits (ex. to mount cradle)
• Slotted, Philips, and/or Torx bits (you may need tamper resistant Torx bits)
• Panel removal tool or plastic pry bar (to remove dash panel(s) as needed)
• Small socket set
• Zip Ties (to hold cabling in place)
LMU/Bracket Tablet Cradle
Hardware Pack
In-Cab Readiness Kit
(booklet, stickers, DOT reference card)
(5) #8 Self-tapping Screw 3/4 inch
(5) M4 Screw 12mm
(5) M4 Screw 8mm
(5) M4 Steel Nut
(11) M4 Star Lock Washer
(2) M4 Tamper Resistant Button Head HEX
Screw 20MM

PedigreeTechnologies.com | Support: (701)-499-0022
3
STEP ONE
Unplug the canbus cable from the Cab-Mate One cradle. You will plug this cable into the new
device in future steps.
Before You Begin
TURN TO THE LAST PAGE - WRITE DOWN THE REQUIRED INFORMATION!!!
• Decide where the hardware components will be located. If necessary remove any dash
panels with removal tool.
• Must be within reach of the diagnostic cable to be installed.
• Must be protected from moisture, excessive dust/dirt, heat (away from heater vents) and
unobtrusive to driver operation or eld of view.
• Routing of the cable between the factory diagnostic port and the telematics device does not
cause excessive bending/kinking or areas where vibration may jeopardize the integrity of
the hardware.
• Cabling must not impede function of any rotating or moving parts (ex. Steering
mechanisms, wiper mechanisms, or brake pedal)
• Ensure that the mounting location has enough integrity to accommodate the additional
weight and vibration of the device.
Cab-Mate One to Cab-Mate Flex
Remove Cab-Mate One
Bottom View of Cradle/LMU

PedigreeTechnologies.com | Support: (701)-499-0022
4
Installation Steps, Continued
Assemble Cab-Mate Flex
Cab-Mate One to Cab-Mate Flex
Cradle/LMU
STEP TWO
Detach the ball mount from the back of the cradle by removing the four screws that secure it. It
may be easier to remove the mount by detaching the ball mount section. The ball mount section
will be used in the assembly of the new device.
Ball Mount
STEP THREE
Assemble the new Cab-Mate Flex LMU and cradle. Lay the LMU assembly over the back of the
cradle and line up the four screw holes. Add the ball mount on top, lining up the 4 holes inthe ball
mount and fasten all three pieces together with provided screws.
++

PedigreeTechnologies.com | Support: (701)-499-0022
5
Connect Diagnostics Cable to Cradle
Cab-Mate One to Cab-Mate Flex
STEP FOUR
Plug the canbus cable that you removed from the Cab-Mate One into the 16 pin port on the 3640
LMU (the only open port).
16 Pin Connector
from canbus cable
STEP FIVE
Connect the 6 pin plug (smaller of the two plugs) from the LMU assembly into the matching port
on the back of the cradle.

Testing / Conrmation Steps
PedigreeTechnologies.com | Support: (701)-499-0022
Cab-Mate One to Cab-Mate Flex
Install Conrmation: 701-499-0022
You will be prompted for the following information during the set up process
• Device ESN
• Name of Asset (ex. Service Truck 51)
• Year, make, and model
• VIN #
• License plate #
• Mileage Hours
STEP EIGHT
Call Pedigree Technologies support to conrm installation before replacing any of the dash
panels you may have removed during cable installation.
STEP SIX
Reattach the ball mount/cradle assembly to the mounting bracket by inserting the ball and hand
tighten (not pictured).
STEP SEVEN
Snap the tablet into the cradle assembly.
Cradle/LMU Tablet in Cradle/LMU
