4 Front panel
1. MIC1 (mic input 1).
2. MIC2 (mic input 2).
3. MIC3 (mic input 3).
4. Volume control on MIC1.
5. Volume control on MIC2.
6. Volume control on MIC3 & MIC4.
Note: Rotate the knobs in clockwise/counterclockwise to increase/decrease the volume.
7. IR: IR receiver for remote control.
8. 2.2” LCD colour display panel.
9. MIC: Volume control for master mic.
10. EFFECT: Volume control for master sound effects.
11. MUSIC: Volume control for master music.
Note: Rotate the knobs in clockwise/counterclockwise to increase/decrease the volume (-90 ~ +12 dB),
it will display the corresponded volume on LCD panel.
12. USB 2.0: USB interface for recording the songs.
13. MIC: Press it to enter the [MIC] window, and add/delete/reset/load the preset settings, see MIC for details.
14. ECHO: Press it to enter the [ECHO] window, and add/delete/reset/load the preset settings, see ECHO for
details.
15. REVERB: Press it to enter the [REVERB] window, and add/delete/reset/load the preset settings, see
REVERB for details.
16. MUSIC: Press it to enter the [MUSIC] window, and add/delete/reset/load the preset settings, see MUSIC
for details.
17. RECALL: Press it to enter the [RECALL] recording setting window, see RECALL for details.
18. UP/ESC: Navigation as go back to previous page.
19. MAIN: Press it to enter the [OUTPUT - MAIN] window, and add/delete/reset/load the preset settings, see
MAIN for details.
20. SUB (subwoofer): Press it to enter the [OUTPUT - SUB] window, and add/delete/reset/load the preset
settings, see SUB for details.
21. CENTER: Press it to enter the [OUTPUT - CENTER] window, and add/delete/reset/load the preset settings,
see CENTER for details.
22. SYSTEM: Press it to enter the [SYSTEM] setting window, see SYSTEM for details.
23. SAVE: Press it to enter the [SAVE] save/reset/load/preset/exit setting window, see SAVE for details.
