Pepperl+Fuchs EXTA2 Series User manual

MANUAL
EXTA2-* Keyboard
PROCESS AUTOMATION

With regard to the supply of products, the current issue of the following document is ap-
plicable: The General Terms of Delivery for Products and Services of the Electrical Indus-
try, published by the Central Association of the Electrical Industry (Zentralverband
Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the
supplementary clause: "Expanded reservation of proprietorship"
EXTA2-* Keyboard

EXTA2-* Keyboard
3
1 Safety ........................................................................................... 5
1.1 General .................................................................................................. 5
1.2 Delivery, Transport and Storage ......................................................... 5
1.3 Installation and Commissioning EXTA2............................................. 5
1.4 Keyboard Marking................................................................................ 6
1.5 Repair and Maintenance...................................................................... 7
1.5.1 Maintenance ...................................................................................... 7
1.6 Disposal ................................................................................................ 7
1.7 Intended Use of the EXTA2 Keyboard ................................................ 7
1.8 Used Symbols ...................................................................................... 8
2 Product Specifications............................................................... 9
2.1 Function ................................................................................................ 9
2.2 Technical Data EXTA2-K3 with Trackball, Intrinsically Safe............. 9
2.3 Technical Data EXTA2-K4 with Touchpad, Intrinsically Safe ......... 11
2.4 Technical Data EXTA2-K6 with Joystick, Intrinsically Safe ............ 13
2.5 EXTA2 back view ................................................................................ 14
2.6 Accessories ........................................................................................ 15
3 Installation and Commissioning ............................................. 16
3.1 Mounting the Keyboard Connecting Cable to a PC........................ 16
3.2 Installation of Hazardous-Location EMC Cable Glands ................ 18
3.3 Housing design keyboard ................................................................. 19
3.3.1 Keyboard for Panel mounting (Housing Version -N) ......................... 19
3.3.2 Desktop Keyboard (Housing Version -T, e. g., for VisuNet)............... 20
3.3.3 Keyboard for Wall Mounting (Housing Version -F) ........................... 21
3.3.4 Mounting Option -G for Housing AG-XX00....................................... 22

4
EXTA2-* Keyboard
4 Appendix ................................................................................... 23
4.1 Chemical Resistances........................................................................23
4.1.1 Chemical Resistance of Keyboard Foil ............................................. 23
4.1.2 Chemical resistance of the trackball, keyboard variant EXTA2-K3... 24
4.2 Typecode .............................................................................................25

EXTA2-* Keyboard
Safety
2018-07
5
1
1.1
1.2
1.3
Safety
General
Responsibility for planning, assembly, commissioning, operation, maintenance, and
dismounting lies with the plant operator.
Installation and commissioning of all devices may only be performed by trained and qualified
personnel.
Protection of operating personnel and the system is not ensured if the product is not used in
accordance with its intended purpose.
Laws and regulations applicable to the usage or planned purpose of usage must be observed.
Devices are only approved for proper usage in accordance with intended purpose. Improper
handling will result in voiding of any warrantee ormanufacturer's responsibility.
The Declaration of Conformity, Certificate of Compliance, Statement of Conformity, EC-type-
examination certificate and data sheets are an integral part of this document.
The data sheet contains the electrical data of the Declaration of Conformity, the Certificate of
Compliance and the EC-type-examination certificate.
The documents mentioned are available from http://www.pepperl-fuchs.com or contact your
local Pepperl+Fuchs representative.
Delivery,Transport and Storage
Check the packaging and contents for damage.
Check if you have received every item and if the items received are the ones you ordered.
Keep the original packaging. Always store and transport the device in the original packaging.
Always store the device in a clean and dry environment. The permitted storage temperature
(see datasheet) must be considered.
Installation and Commissioning EXTA2
Prior to mounting, installation, and commissioning of the device you should make yourself
familiar withthe device and carefully read the instruction manual.
Installation in the presence of intrinsically safe circuits
The intrinsically safe circuits of the devices areallowed to be introduced into hazardous areas.
In this case, they must be safely isolated from all non-intrinsically safe circuits.
The intrinsically safe circuits must be installed in accordance with the applicable installation
regulations.
If intrinsically safe field devices are interconnected with the intrinsically safe circuits in
associated devices, the respective maximum values of these field devices and the associated
devices must be complied with in the interests of explosion protection (verification of intrinsic
safety). Account must be taken of EN 60079-14 / IEC 60079-14. Compliance with the "National
Foreword" of DIN EN 60079-14 / VDE 06165 Part 1 must be additionally ensured if the devices
are used in the Federal Republic of Germany.
The identification plate must not be removed.
The device must be free of voltage during installation and maintenance. The keyboard/mouse
must only be connected to the supply voltage after complete mounting and connection.
Individually accessible non-grounded metal parts can become electrostatically charged. The
determined capacitance exceeds the required value according to IEC/EN 60079-0. The
determined capacitance is specified in the technical data.
Information on electrostatic hazards can be found in the technical specification IEC/TS 60079-
32-1.

2018-07
6
EXTA2-* Keyboard
Safety
1.4 Keyboard Marking
EXTA2-*
Pepperl+Fuchs
D-68307 Mannheim
www.pepperl-fuchs.com
Additional label acc. to ATEX
Additional label acc. to IECEx
Additional UL listing—EXTA2-J-T and EXTA2-J-F for K1, K4, K6, K8, and K9 models
Additional UL recognition—EXTA2-J-N for K1, K4, K8, and K9 models
EXTA2-*
Zone 1 and zone 21
BVS 07 ATEX E 163 X
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIB T135°C Db
EXTA2-*
Zone 1 and zone 21
IECEx BVS 08.0022X
Ex ib IIC T4 Gb
Ex ib IIIB T135°C Db

EXTA2-* Keyboard
Safety
2018-07
7
1.5 Repair and Maintenance
The device must not be repaired, changed, or manipulated. In case of failure, always replace
the device with an original device.
1.5.1 Maintenance
Standards, directives, or statutory requirements stipulating regular system tests may exist in
connection with keyboards and mouse devices used as part of a system.
The keyboard functionality should be tested at least twice per year, or more often under heavy-
duty conditions.
Do not use caustic fluids to clean the keyboard.
A dirty keyboard could cause a malfunction or ultimately stop working.
1.6 Disposal
Disposal of devices and their packaging material must be performed in compliance with the
applicable laws and guidelines of the corresponding country.
The devices do not contain any batteries that need to be disposed of separately from the
products.
1.7 Intended Use of the EXTA2 Keyboard
EXTA2 is a PC keyboard with an optional control element for mouse functions (touchpad,
trackball, joystick). The keyboard has USB interfaces for intended use in Zone 1 and Zone 21
hazardous areas according to ATEX Directive 2014/34/EU and IECEx. The USB interfaces of
the keyboard and the control element for mouse functions are separated, intrinsically safe
circuits. Both intrinsically safe circuits are led out either in one or two separate connection
cables. The conncection cable corresponds to type "B" according IEC 60079-14 section
12.2.2.8. The cable has to be secured and effectively protected from damage. The EXTA2
keyboard cannot be installed in locations where corrosive media may be used.
To avoid discharge processes, the keyboard may only be installed in areas where high
electrostatic buildup due to dust is unlikely. To avoid electrostatic charging, the keyboard
cannot be covered or glued with foils.
The keyboard cannot be exposed to direct sunlight, unless it is equipped with the UV-resistant
foil option.
When connecting the EXTA2 keyboard to a VisuNet RM/PC, keep in mind that the USB
connection is not hot swappable. Connect the keyboard cable when there is no voltage
applied.
If circuits with type of protection Ex i are operated with non-intrinsically safe circuits, they must
no longer be used as circuits with type of protection Ex i.

2018-07
8
EXTA2-* Keyboard
Safety
1.8 Used Symbols
Safety-Relevant Symbols
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note!
This symbol brings important information to your attention.

EXTA2-* Keyboard
Product Specifications
2018-07
9
2 Product Specifications
2.1 Function
The EXTA2 is a keyboard/mouse combination with USB interfaces, available in different
versions. The intrinsically safe keyboards integrate different mouse systems. The outside
dimensions are the same for all versions. The keyboards are designed for panel mounting or
for installation in a housing. The EXTA2 comes with an 8-pin connection cable included.
2.2 Technical Data EXTA2-K3 with Trackball, Intrinsically Safe
Technical Data EXTA2-K3
General specifications
Ty p e Keyboard with trackball
Supply
Rated voltage Ex i, via data line
Indicators/operating means
Keyboard 105 short stroke keys
Keyboard layout: US international, German, French, (further
keyboard layouts on demand)
Trackball
Diameter 50 mm
Material Phenolic resin (black)
Driver Microsoft Mouse ®, USB
Interface
Interface type USB or PS/2 (PS/2 via adapter)
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations) ; EN 61000-6-
4:2007+A1:2011
RoHS
Directive 2011/65/EU (RoHS) EN 50581:2012-09
Conformity
Electromagnetic compatibility EN 61000-6-2:2005
Degree of protection IP65 , if trackball is inactive. Undefined during motion.
Ambient conditions
Ambient temperature 0 ... 50 °C (32 ... 122 °F)
Storage temperature -20 ... 70 °C (-4 ... 158 °F)

2018-07
10
EXTA2-* Keyboard
Product Specifications
Relative humidity max. 85 % , non-condensing
Mechanical specifications
Material anodized aluminum , Polyester foil
Mass 1.2 kg
Dimensions 482.6 mm x 177.8 mm x 45 mm
Cut out dimensions 450 mm x 152 mm
Cable length 5 m / 1.8 m, USB
Data for application in
connection with hazardous
areas
EC-Type Examination
Certificate
BVS 07 ATEX E 163 X
Group, category, type of
protection II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIB T135°C Db
Input
Voltage 5.4 V
Current 240 mA
Power 600 mW
Internal capacitance 24 µF
Internal inductance negligible
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013, EN 60079-11:2012
International approvals
UL approval UL listing/recognition: E190294
IECEx approval IECEx BVS 08.0022X
Group, category, type of
protection
Ex ib IIC T4 Gb, Ex ib IIIB T135°C Db
Technical Data EXTA2-K3

EXTA2-* Keyboard
Product Specifications
2018-07
11
2.3 Technical Data EXTA2-K4 with Touchpad, Intrinsically Safe
Technical Data EXTA2-K4
General specifications
Ty p e Keyboard with touchpad
Supply
Rated voltage Ex i, via data line
Indicators/operating means
Keyboard 105 short stroke keys
Keyboard layout: US international, German,
French, (further keyboard layouts on demand)
To u c h p a d
Active Principle capacitive
Resolution 40 Pts./mm
Dimensions 66 x 50
Driver Microsoft Mouse ®, USB
Interface
Interface type USB or PS/2 (PS/2 via adapter)
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations) ; EN
61000-6-4:2007+A1:2011
RoHS
Directive 2011/65/EU (RoHS) EN 50581:2012-09
Conformity
Electromagnetic compatibility EN 61000-6-2:2005
Degree of protection IP66
Ambient conditions
Ambient temperature -20 ... 50 °C (-4 ... 122 °F)
Storage temperature -20 ... 70 °C (-4 ... 158 °F)
Relative humidity max. 85 % , non-condensing
Mechanical specifications
Material anodized aluminum , Polyester foil
Mass 1.2 kg
Dimensions 482.6 mm x 177.8 mm x 45 mm
Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
1
Alt
AltGr
+
Rollen
Num
Einfg
Pos 1
Ende
Entf
/
-
*
!
Druck Pause
S-Abf Untbr
Enter
0
123
456
789
Pos 1
Einfg
Ende
Entf
StrgStrg
234
$
5
%
6789
)
0
Q
ASDF GHJKL
WE R T Z U I O P
§
XCVBNM
, .
NumPower Rollen
,
Y
^
°
<
>
|
µ
€
@
;
:
/
-
_
ÖÄ
}
][
{
Ü*
+
\
#
‘
23
&
(
=
?
ß

2018-07
12
EXTA2-* Keyboard
Product Specifications
Cut out dimensions 450 mm x 152 mm
Cable length 5 m / 1.8 m, USB
Data for application in connection with
hazardous areas
EC-Type Examination Certificate BVS 07 ATEX E 163 X
Group, category, type of protection II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIB T135°C Db
Input
Voltage 5.4 V
Current 240 mA
Power 600 mW
Internal capacitance 24 µF
Internal inductance negligible
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013, EN 60079-
11:2012
International approvals
UL approval UL listing/recognition: E190294
IECEx approval IECEx BVS 08.0022X
Group, category, type of protection Ex ib IIC T4 Gb, Ex ib IIIB T135°C Db
Technical Data EXTA2-K4

EXTA2-* Keyboard
Product Specifications
2018-07
13
2.4 Technical Data EXTA2-K6 with Joystick, Intrinsically Safe
Technical Data EXTA2-K6
General specifications
Ty p e Keyboard with joystick
Supply
Rated voltage Ex i, via data line
Indicators/operating means
Keyboard 105 short stroke keys
Keyboard layout: US international, German, French, (further
keyboard layouts on demand)
Joystick
Driver Microsoft Mouse ®, USB
Interface
Interface type USB or PS/2 (PS/2 via adapter)
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations) ; EN 61000-6-
4:2007+A1:2011
RoHS
Directive 2011/65/EU (RoHS) EN 50581:2012-09
Conformity
Electromagnetic compatibility EN 61000-6-2:2005
Degree of protection IP65
Ambient conditions
Ambient temperature -20 ... 50 °C (-4 ... 122 °F)
Storage temperature -20 ... 70 °C (-4 ... 158 °F)
Relative humidity max. 85 % , non-condensing
Mechanical specifications
Material anodized aluminum , Polyester foil
Mass 1.2 kg
Dimensions 482.6 mm x 177.8 mm x 45 mm
Cut out dimensions 450 mm x 152 mm
Cable length 5 m / 1.8 m, USB

2018-07
14
EXTA2-* Keyboard
Product Specifications
2.5 EXTA2 back view
The EXTA2 comes with an 8-pin connection cable included.
Data for application in
connection with hazardous
areas
EC-Type Examination
Certificate
BVS 07 ATEX E 163 X
Group, category, type of
protection II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIB T135°C Db
Input
Voltage 5.4 V
Current 240 mA
Power 600 mW
Internal capacitance 24 µF
Internal inductance negligible
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013, EN 60079-11:2012
International approvals
UL approval UL listing/recognition: E190294
IECEx approval IECEx BVS 08.0022X
Group, category, type of
protection
Ex ib IIC T4 Gb, Ex ib IIIB T135°C Db
Technical Data EXTA2-K6
Keyboard dimensions back view
470
438
146
292
110
165
48
3
178
483

EXTA2-* Keyboard
Product Specifications
2018-07
15
2.6 Accessories
If you use the EXTA2 as a stand-alone keyboard, an additional barrier is required.
Order Code Description Part Number
KI153 ■Barrier
■2 USB cables to connect
the barrier with the PC
■2 USB PS/2 adapters
256034

2018-07
16
EXTA2-* Keyboard
Installation and Commissioning
3 Installation and Commissioning
3.1 Mounting the Keyboard Connecting Cable to a PC
Connecting the Keyboard to a PC via the Keyboard Connecting Cable
Connect the wires of the keyboard connecting cable as shown in the following table.
Keyboard and Mouse (EXTA2-K*) Core Assignment
Connecting the Keyboard to a PC via Barrier KI153
1. Plug the USB plugs of the keyboard cables into the USB ports of the barrier. Use the USB
ports on the face labeled with "intrinsically safe."
2. Plug the USB plugs of the enclosed USB cables into the USB ports of the barrier. Use the
USB ports on the face labeled with "not intrinsically safe."
3. Plug the USB plugs of the enclosed USB cables into 2 unused PC USB ports. By using the
enclosed USB PS/2 adapters, you have the possibility to use the PC's PS/2 interface
instead of the USB ports.
Note!
For installation and connection in North America, refer to Control Drawing 116-0357B.
Assignment Color coding
Keyboard Ui green
D+ brown
D- grey
GND yellow
Mouse Ui red
D+ white
D- pink
GND blue
Note!
Torque Specifications for Keyboard Lid
After connecting the keyboard, tighten the screws on the EXTA2 lid to a torque of 0.5 Nm (4.4 in
lb).
Ex- Area ATEX II 2G, II 2D
PC
2x CON ADAPT
USB-A-F/PS2
IS
max. 5 m
IS
max. 5 m
KEYBOARD INTERFACE KI153
KEYBOARD INTERFACE KI153
EXTA2-F-T-K4US-U07UA-Z-10-N
2x CBL SET 04
025 PVC 180
2 USB M0480
2x CBL SET 04
025 PVC 180
2 USB M0480
IS
max. 5 m
IS
max. 5 m
PC
USB
USB
EXTA2-F-T-K4US-U07UA-Z-10-N
max. 2 m
max. 2 m

EXTA2-* Keyboard
Installation and Commissioning
2018-07
17
Equipotential Bonding
1. The shielding of the keyboard cable must be connected in the cable gland of the PC/display
(VisuNet) (refer to VisuNet manual). Before doing this, open the cable clip (1) and remove
the cable protective tube (2).
■(1) cable clip
■(2) cable protective tube
2. Install the keyboard in a metal housing that is connected to PE.
Danger!
Explosion Hazard
Risk of fatal injury and severe property damage.
The housing must always be connected to the PE. There are 2 possibilities:
Connection via cable shielding of the connecting cable.
Built into a metal housing that is connected to the PE.
End of the Keyboard Cable (Attached to the Keyboard)

2018-07
18
EXTA2-* Keyboard
Installation and Commissioning
3.2 Installation Instructions for Hazardous-Location EMC Cable Glands
Power supply cables for the Ex e Ethernet and the RS-485 or TTY Ex e data interface, the Ex i
keyboard, and the Ex i scanner must be shielded to ensure sufficient immunity to interference
(EMC). Connect the cable shielding to the VisuNet RM/PC according to the following
installation instructions:
Step 1
■Isolate the cable.
■Expose the braid.
■Remove the braid and insulation little by
little.
■With thin cables, the braid can be folded
back over the insulation sheath.
■Insert the cable into the gland until the
braid reaches the contact point.
■Tighten the cable gland.
Step 2
■Guide the cable through the lock nut.
■Guide the cable into the terminal insert.
■Fold the braid over the insert.
■The braid must overlap the O-ring by about
2 mm
Step 3
■Fit the terminal insert into the intermediate
gland.
■Assemble the cable gland.
Internal view of the assembled cable gland.

EXTA2-* Keyboard
Installation and Commissioning
2018-07
19
3.3 Housing design keyboard
There are different possibilities to mount the keyboards.
1. Panel mounting (Housing version -N)
2. The keyboard is mounted in a desktop housing. (Housing version -T)
3. Wall mounting (Housing version -F)
3.3.1 Keyboard for Panel mounting (Housing Version -N)
Safety Information for Installation in North America
When installed in North America, EXTA2-J-N models are only suitable for use in the following
locations:
■Class I, Division 2, Groups A, B, C, and D
■Class II, Division 2, Groups F and G
■Class III
■Nonhazardous locations
The following safety information applies for installation in North America:
Assembly of the keyboard with cover at the back: Cutout
Danger!
Explosion Hazard
Risk of fatal injury and severe property damage.
Do not substitute components. Substitution of any component may impair suitability for Class I,
Division 2 and Class II, Division 2.
Devices must also be installed in a suitable enclosure.
Warning!
Maximum Air Temperature
Risk of device damage.
Devices are suitable for a maximum surrounding air temperature of 50 °C.
450
146
292
438
469,6
20 x
Ø5
110
164,8
152

2018-07
20
EXTA2-* Keyboard
Installation and Commissioning
3.3.2 Desktop Keyboard (Housing Version -T, e. g., for VisuNet)
■(1) protective earth bolt
Note!
Torque Specifications
Torque the screws for the EXTA2 keyboard and housing interface to 0.4 Nm (3.5 in lb).
Desktop Keyboard Dimensions
265
287
(1)
50
530
80
92
Note!
To simplifiy keyboard mounting, you can remove the cables from the keyboard PCB. After you
have mounted the keyboard, reattach all cables properly—including the PA cable. Tighten
protective earth to a torque of 0.15 Nm (1.3 in lb). Tighten the cable clip to a torque of 0.3 Nm
(2.6 in lb).
