Pepperl+Fuchs IST-HH20 User manual

IST-HH20
HANDHELD (250 KHZ)
FACTORY AUTOMATION
MANUAL

With regard to the supply of products, the current issue of the following document is appli-
cable: The General Terms of Delivery for Products and Services of the Electrical Industry,
published by the Central Association of the Electrical Industry (Zentralverband Elektrotech-
nik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary
clause: "Expanded reservation of proprietorship"
IST-HH20

3
IST-HH20
1 Introduction ................................................................. 6
2 Declaration of Conformity.......................................... 7
2.1 Declaration of Conformity ........................................................................7
3 Safety ........................................................................... 8
3.1 Symbols relevant to safety .......................................................................8
3.2 Intended use ..............................................................................................8
3.3 General notes on safety............................................................................9
4 Product description IST-HH20.................................. 10
4.1 Use and application ................................................................................10
4.2 LED indicators and control keys............................................................ 11
4.2.1 Status LED ................................................................................................12
4.2.2 Display.......................................................................................................12
4.2.3 Key overview .............................................................................................14
4.3 Interfaces .................................................................................................16
4.4 Scope of supply.......................................................................................16
4.5 Accessories .............................................................................................17
4.5.1 Connecting cable.......................................................................................17
4.5.2 Accessories for interfaces .........................................................................17
4.5.3 Handles .....................................................................................................17
4.5.4 Storage batteries .......................................................................................17
4.5.5 Chargers....................................................................................................18
4.5.6 Brackets ....................................................................................................18
5 Installation ................................................................. 19
5.1 Preparation...............................................................................................19
5.2 Handle installation ..................................................................................21

4
IST-HH20
6 Commissioning..........................................................25
6.1 Switching on and off............................................................................... 25
6.2 Basic operation....................................................................................... 26
6.2.1 Navigation through menus ........................................................................ 26
6.2.2 Data entry ................................................................................................. 26
6.3 Operating modes .................................................................................... 27
6.3.1 Wireless operation (batch mode).............................................................. 27
6.3.2 Cable operation: RS 232 .......................................................................... 28
6.3.3 Cable operation: PS/2............................................................................... 29
6.3.4 Cable operation: USB ............................................................................... 30
6.3.5 Operating with Bluetooth .......................................................................... 31
7 Operation....................................................................32
7.1 Read data................................................................................................. 32
7.2 Writing data ............................................................................................. 34
7.3 Editing and entering data manually ...................................................... 36
8 Troubleshooting ........................................................38
8.1 Error message "no tag".......................................................................... 38
8.2 Error message "Connect failed!" .......................................................... 38
8.3 Error message "No stored data" ........................................................... 39
8.4 Error message "No Data to copy"......................................................... 39

5
IST-HH20
9 Software description PF_Ident ................................ 40
9.1 Read/Write menu .....................................................................................40
9.1.1 Read/Write > Data read ...........................................................................41
9.1.2 Read/Write > Data write...........................................................................45
9.1.3 Read/Write > Data copy...........................................................................49
9.1.4 Read/Write > Read fixcode .....................................................................54
9.1.5 Read/Write > Make ICC............................................................................58
9.1.6 Read/Write > Read spec. fix....................................................................61
9.1.7 Read/Write > Read spec. fix....................................................................65
9.1.8 Read/Write > Initialise tag.......................................................................69
9.1.9 Read/Write > Fill tag ................................................................................72
9.2 Storage menu...........................................................................................76
9.2.1 Storage > Options ...................................................................................77
9.3 Settings menu..........................................................................................81
9.3.1 Settings > Tag type..................................................................................82
9.3.2 Settings > Data format ............................................................................83
9.3.3 Settings > Trigger keys ...........................................................................84
9.3.4 Settings > Time stamp ............................................................................85
9.3.5 Settings > Checksum ..............................................................................86
9.3.6 Settings > Prefix/Suffix ...........................................................................87
9.3.7 Settings > Communication .....................................................................88
9.3.8 Settings > Send/Log ................................................................................92
9.3.9 Settings > Language ...............................................................................93
9.3.10 Settings > Date/Time ...............................................................................93
9.3.11 Settings > System....................................................................................94
9.3.12 Settings > Vibrator...................................................................................95
9.3.13 Settings > Buzzer.....................................................................................96
9.3.14 Settings > Default settings .....................................................................97
9.4 Applications menu ..................................................................................99
9.5 About menu ...........................................................................................100
10 Command reference ................................................101
11 ASCII table ............................................................... 104

205267 2007-12
6
IST-HH20
Introduction
1 Introduction
Congratulations
You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops,
produces and distributes electronic sensors and interface modules for the market of
automation technology on a worldwide scale.
Symbols used
This manual contains different symbols that draw your attention to information or instructions.
Action
This symbol marks an acting paragraph.
The following chapters contain the most important instructions:
• Basic operation: see chapter 6.2
• Description of the most important tasks: see chapter 7
• Complete description of all menu entries: see chapter 9
IIf you have any queries regarding the device, accessories or advanced functions, please
contact:
Pepperl+Fuchs GmbH
Königsberger Allee 87
D-68307 Mannheim
Telephone: 0621 776-1111
Fax: 0621 776-271111
e-mail: fa-info@de.pepperl-fuchs.com
Note!
This symbol brings important information to your attention.

IST-HH20
Declaration of Conformity
205267 2007-12
7
2 Declaration of Conformity
This product has been developed and manufactured in accordance with applicable European
standards and directives.
The manufacturer of this product, Pepperl+Fuchs GmbH, in D-68307 Mannheim, Germany, has
a certified quality management system in accordance with ISO 9001.
2.1 Declaration of Conformity
The device has been tested for compliance with FCC regulations Tests confirmed that all valid
FCC rules and regulations have been complied with.
Note!
A Declaration of Conformity can be requested from the manufacturer.
ISO9001
Note!
The device may not be used in the vicinity or in combination with another antenna or a
transmitter in order to meet the requirements stipulated in FCC RF exposure guidelines.

205267 2007-12
8
IST-HH20
Safety
3 Safety
3.1 Symbols relevant to safety
3.2 Intended use
The Handheld was designed for identifying RFID code and data carriers within a defined
frequency range and should be used for this purpose only. Examples of device applications
include manual quality control and verifying maintenance work.
Operating the Handheld in a way different from that described in these instructions may have a
negative effect on the reliability and function of the device and connected systems. Protection
of operating personnel and the overall system is no longer guaranteed if the device is not used
as specified.
Danger!
This symbol indicates a warning about a possible danger.
In the event the warning is ignored, the consequences may range from personal injury to death.
Warning!
This symbol indicates a warning about a possible fault or danger.
In the event the warning is ignored, the consequences may course personal injury or heaviest
property damage.
Caution!
This symbol warns of a possible fault.
Failure to observe the instructions given in this warning may result in the devices and any
connected facilities or systems develop a fault or fail completely.
Caution!
Modified or separate JavaScript programs
Data reading and writing processes may be influenced or disrupted.
• Do not modify the JavaScript programs provided by the manufacturer.
• Check whether the identification function of self-configured JavaScript programs is
affected.

IST-HH20
Safety
205267 2007-12
9
3.3 General notes on safety
Installation and commissioning of all devices must be performed by a trained professional only.
When packing the device for storage or transport, use materials that will protect the device from
bumps and impacts and protect against moisture. The original packaging provides the best
protection. Also take into account the permitted ambient conditions.
Do not open, burn or short-circuit the battery. The battery may ignite, explode, leak or heat up
and become irreparably damaged.
Always charge the battery using approved cables.
The Handheld supports different interfaces such as Bluetooth, USB, RS 232 or PS/2. Always
use correctly configured devices and the recommended original accessories to ensure reliable
communication.
The operating company bears responsibility for observing locally applicable safety regulations.
Independent interventions and separate modifications are dangerous and will void the warranty
and exclude the manufacturer from any liability. If serious faults occur, stop using the device.
Secure the device against inadvertent operation. In the event of repairs, send the device to
Pepperl+Fuchs.
Do not dispose of storage batteries with the household refuse.
Consumers are obliged by law to dispose of used storage batteries in accordance with
regulations. You can hand in your used batteries at public collection points in your area or sales
points where batteries of that particular kind are sold. You can also send your used batteries
directly to us for disposal. Please remember that this service is only available within the scope
of normal use. If you wish to send back your used batteries, please affix sufficient postage
stamps and send to our address. There are no extra charges for disposal.

205267 2007-12
10
IST-HH20
Product description IST-HH20
4 Product description IST-HH20
4.1 Use and application
Handheld
IDENTControl by Pepperl+Fuchs is a proven system designed for stationary RFID applications.
A portable device for process monitoring (reading/writing functions, data carrier initialization) is
provided with this Handheld.
One new feature is the cellphone design with keypad and display for intuitive operation.
Frequently recurring actions can be performed by pressing one of two configurable keys.
JavaScript provides a familiar cross platform programming language to enhance system
functionality for the user.
In addition to a lithium ion storage battery, a large permanent memory and the option of
2.45 GHz band wireless communication based on the Bluetooth standard ensure maximum
mobility.
Data carrier 250 kHz (inductive)
Data carriers from this frequency range achieve a higher reading speed than 125 kHz data
carriers. ICC ... code carriers with a 28 bit fix code and IDC ... data carriers with a memory
capacity of 1 kBit are available in various designs.

IST-HH20
Product description IST-HH20
205267 2007-12
11
4.2 LED indicators and control keys
The device has the following LED indicators and control keys:
1Status LED
2LC display
3Softkeys
4Navigation keys
5Trigger keys
6Keypad
7Interface
8Battery compartment
9Read/write head
4
3
6
1
9
2
5
7
8

205267 2007-12
12
IST-HH20
Product description IST-HH20
4.2.1 Status LED
The status LED indicates the following states:
Meaning of the status LED
4.2.2 Display
The display on the device is divided into different areas:
Status Description
Lights up green • The Handheld has been switched on.
• The interface has been modified.
• Data has been read or written.
Flashing yellow The Handheld has successfully completed a read or write command.
Red flashing The Handheld has unsuccessfully completed a read or write command
and reports an error.
Off Read/Write head is inactive
1Toolbar
2Display
3Softkey bar
1
2
3

IST-HH20
Product description IST-HH20
205267 2007-12
13
The following table lists all the symbols on the toolbar and the functions they perform:
Symbols in the toolbar
Symbol Description
Charging status
The capacity of the battery is between 50 % and 100 %.
The capacity of the battery is between 20 % and 50 %.
The capacity of the battery is between 0 % and 20 %. Recharge the
battery.
Battery is charged.
Connection status
The Handheld is connected to an interface.
RS 232 is selected as the active interface.
PS/2 is selected as the active interface.
USB is selected as the active interface.
Bluetooth is selected as the active interface.
Data transfer
Data transfer in one direction: data is transferred from the Handheld to
the connected computer. A response from the computer is not required.
Data transfer in two directions: data is transferred from the Handheld to
the connected computer. The Handheld then waits for a response from
the computer.
Keyboard mode: the Handheld is connected to the computer via a USB
or PS/2 interface.
Virtual COM port mode: the Handheld emulates an RS 232 interface via
the USB interface allowing communication from the computer to the
Handheld. A response from the computer is not required.
Memory status
0 % to 25 % of the internal memory is occupied.
25 % to 50 % of the internal memory is occupied.
50 % to 75 % of the internal memory is occupied.
75 % to 100 % of the internal memory is occupied.
The internal memory is full. You can no longer store data on the internal
memory.
Batch mode inactive. Data is not buffered in the internal memory.

205267 2007-12
14
IST-HH20
Product description IST-HH20
4.2.3 Key overview
The following table lists all keys on the device and the functions they perform:
Softkeys
Navigation keys
Input mode
Numerical input mode - data entered using the keys appears in the form
of numbers.
Alphabetical input mode - data entered using the keys appears in the
form of letters.
Alphabetical input mode - data entered using the keys appears in the
form of lower case letters.
Symbol input mode - data entered using the keys appears in the form of
symbols.
Symbol Description
Keys Designation
Left softkey
Right softkey
Keys Designation
Up navigation key
Down navigation key
Left navigation key
Right navigation key
Enter navigation key

IST-HH20
Product description IST-HH20
205267 2007-12
15
Trigger keys
Input keys
Keys Description
Left trigger key
Right trigger key
Keys "Numerical" mode
"Alphanumerical
upper case" mode
"Alphanumerical
lower case" mode "Symbols" mode
Switches between "Numerical", "Alphanumerical upper case", "Alphanumerical
lower case" and "Symbols" mode.
1Space, 1 Space, 1 Space
) < _
2A, B, C, 2 a, b, c, 2 ! * = `
3D, E, F, 3 d, e, f, 3 " + > {
4G, H, I, 4 g, h, i, 4 # , ? |
5J, K, L, 5 j, k, l, 5 $ - @ }
6M, N, O, 6 m, n, o, 6 % . [ ~
7P, Q, R, S, 7 p, q, r, s, 7 & / \
Space
8T, U, V, 8 t, u, v, 8 ' : ]
Space
9W, X, Y, Z w, x, y, z ( ; ^
Space
0 0 0 Scrolls through
the different
symbol pages
For data input fields: delete the last character. Otherwise: ESC function (exits
the menu without adopting the current settings.)

205267 2007-12
16
IST-HH20
Product description IST-HH20
4.3 Interfaces
The handheld has the following interfaces:
4.4 Scope of supply
The scope of supply includes:
• Handheld without storage battery or battery compartment cover
• CD with documentation (manual)
18-pin connecting socket
1
Note!
You will require other components in addition to the Handheld included in the scope of supply
to complete assembly of the device. The basic equipment includes: Handheld, battery and
charging station. Missing components can be ordered from Pepperl + Fuchs.

IST-HH20
Product description IST-HH20
205267 2007-12
17
4.5 Accessories
Different connection cables, handles, mounts, storage batteries and a range of accessories for
chargers and interfaces are available for this Handheld.
4.5.1 Connecting cable
The following connecting cables are available as an option:
4.5.2 Accessories for interfaces
The following interfaces are available as optional accessories:
4.5.3 Handles
The following handles are available as an optional accessory:
4.5.4 Storage batteries
The following batteries are available as an optional accessory:
Designation Description
ODZ-MAH-CAB-B14 Connecting cable USB interface, length approx.
180 cm
ODZ-MAH-CAB-R2 Connecting cable RS 232 interface, length approx.
120 cm
ODZ-MAH-CAB-R6 Connecting cable PS/2 interface, length approx.
120 cm
Designation Description
ODZ-MAH-B15 Bluetooth modem (without cable), preset to USB
ODZ-MAH-B15-R2 Bluetooth modem (without cable), preset to RS232
ODZ-MAH-B15-R6 Bluetooth modem (without cable), preset to PS/2
Designation Description
ODZ-MAH-GRIP1 Handle, without battery
ODZ-MAH-GRIP2 Handle, with integrated lithium ion battery, capacity
1950 mAh
ODZ-MAH-GRIP3 Handle, with integrated lithium ion battery, capacity
3900 mAh
Designation Description
ODZ-MAH-BAT Lithium ion battery, capacity 1950 mAh
ODZ-MAH-BLANK Battery blank (for cable operation)

205267 2007-12
18
IST-HH20
Product description IST-HH20
4.5.5 Chargers
The following chargers are available as an optional accessory:
4.5.6 Brackets
The following brackets are available as an option:
Designation Description
ODZ-MAH200-CHARGER Charger for 2 lithium ion storage batteries
ODZ-MAH-CHARGER Battery charging tray for handles with integrated
lithium ion storage battery
ODZ-MAH200-SUPPLY +
ODZ-MAH-CAB-CHARGE
Plug supply unit with cable for direct connection of the
Handheld
ODZ-MAH-CHARGER-SINGLE Charger for I*T-HH20 with integrated battery ODZ-
MAH-BAT
Designation Description
ODZ-MAH300-BRACKET Table bracket for Handhelds with display

IST-HH20
Installation
205267 2007-12
19
5 Installation
5.1 Preparation
Unpacking the unit
1. Check that all package contents are present and undamaged.
If anything is damaged, inform the shipper and contact the supplier.
2. Check that all items are present and correct based on your order and the shipping
documents.
If you have any questions, please contact Pepperl+Fuchs.
3. Keep the original packing material in case you need to store or ship the unit at a later time.
Fitting the battery
Fit the battery as follows:
1. Turn the battery so that you can remove it as shown in the illustration.
2. Slide the plastic tab on the battery into the corresponding recess on the Handheld.

205267 2007-12
20
IST-HH20
Installation
3. Push the locking device upwards and push in the battery.
4. Push the battery in the Handheld, hold in position and release the locking device so that
the battery engages.
Charging battery
Charge the battery as follows:
1. Connect the Handheld, including battery, to an interface cable.
2. Connect the interface cable to the switched-on computer.
When the Handheld is switched on, the symbols displayed in the toolbar indicate the
charging status of the Handheld. Overviewview table "Symbols in the toolbar" on page 13
Note!
If you are operating the handheld via an RS 232 interface, connect the RS 232 interface power
supply unit to the socket to charge the battery.
Note!
Completely discharged storage batteries
If the storage battery is completely discharged, you will have to wait at least 10 minutes before
the Handheld is ready for operation again.
Table of contents
