Performance Tool W16751 User manual

LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These
warranties give specific legal rights. Except where prohibited by local law, the law of the State of Washington
governs all warranties and all exclusions and limitations of warranties and remedies. There may be other rights
which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal
use and service. A defective product may be returned for a free replacement within 90 days from the date of
purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90
days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which
our examination shall disclose to be defective and under warranty. These warranties shall be valid only when a
sales receipt showing the date of purchase accompanies the defective product or defective part (s) being returned.
For part (s) after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to
misuse, neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no
express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes
no implied warranty of merchantability and no implied warranty of fitness for any particular purpose, except that for
goods purchased primarily for personal, family or household use and not for commercial or business use,
PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in
all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in
any manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive
remedy for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on
limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the above
limitations may not apply in all cases.
© Copyright 2016 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
600 PEAK AMPJUMP STARTER
AND POWER BANK
OWNERS MANUAL
Item Number W16751
On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to merchandise which will not be
reflected in this manual. Although we strive to maintain complete and accurate information, it is possible in some instances, that the product may differ slightly
from printed specifications. Illustrations are intended for reference only. Actual merchandise may vary. Wilmar is not responsible for typographical errors.
Please read these instructions carefully and retain them for future use.
TABLET CELL PHONE AUTO/ATV

1. On/Off Switch
2. LED Light
3. Battery Level Indicator
4. 5V/1A USB Port
5. 5V/2.1A USB Port
6. 15V/1A Input Recharge Port
7. 12V Jump Starter Port
Battery Level Indicator
• Presson/offbuttononcetocheckbatterylevel
• Unlit–0%
• 1flashing–10%
• 1solid–25%
• 2solid–50%
• 3solid–75%
• 4solid–100%
• Lightswillflashduringchargingandwillallbelitwhenchargingisfinished.
PRODUCT FEATURES
OPERATION
Recharging the Battery Unit
• Selecteitherthe12Vcaradaptor,120VACadaptor
• Plugselectedchargerintotherechargeport
• Connectthechargertotheappropriatepowersource
CAUTION: To prevent damage or injury, and ensure proper performance be sure
to note the following:
• BesureyourvehicledoesnotrequiremorecrankingAMPsthanthebattery
unit can provide
• Ideallythebatteryunitshouldbefull,butalwaysconfirmitunithasatleast
 2solidlights,or50%charge
• Beforestartingthevehicle,ensureagoodsolidconnectionbetweenthe
cables and the battery unit
• Allowaminimumof10secondsbetweenattemptstostart
• Ifcardoesnotstartafterfirsttry,doublechecktheconnectionsandbesure
car battery terminals are clean.
• Ifcarstillwillnotstartafterseveralattempts,disconnectandinvestigate
other potential problems.
• Storebatteryunitattemperaturesbetween40ºand120ºF.Toavoid
damaging the internal cells, do not expose to excessive heat.
Using The Smart Clamp
1. Connect the smart clamps to the jump starter power bank battery. Check
the indicator LEDs on the smart clamp for the following:
a. If the red indicator LED on the smart clamp lights up, there may be
insufficient change in the jump starter. Recharge power bank and try again.
b. If smart clamps alarm, disconnect the clamps and check connections for
correct polarity. An audible alarm means there is a short circuit or reverse
polarity.
c. In case of any of the above, disconnect the clamps and reconnect properly.
d. If red and green indictor LEDs stay on the vehicle may require more current
that the jump starter can provide. Compare the required amperage of your
vehicle with the jump starter. A larger capacity jump starter may be required.
2. Alternating red and green indicator LEDs on the smart clamp indicate there
is sufficient charge.
3. Once attached, the green indicator on the clamps should stay on, indicating
sufficient charge and proper connection. Your vehicle is ready to jump.
4. After proper connection, smart clamp will shut off automatically after 30
seconds. Reconnect if vehicle still needs to be jump started.
5. Red indicator LED will blink and clamps will alarm after a successful jump.
Jump Starting a Car
WARNING: to prevent damage to the battery unit disconnect the charger
from the battery immediately after the vehicle has been successfully started.
• Besurebatteryunitisatleast50%full.
• Connecttheredclamptothedeadbatteriespositive(+)terminal.
• Connecttheblackclamptothedeadbatteriesnegative(-)terminal.
•
Plug the other end of the cables into the jump starter port on the battery unit.
• Startthevehicle.
• Oncestartedunplugcablesfrombatteryunit,thenremovethered
clamp, followed by the black clamp.
Charging Cell Phones, Tablets and other Portable Electronics
• PlugthedevicesUSB
charging cord directly into the
battery unit.
• Presstheon/offbuttonto
charge device.
1 2
2
4
3
5
1
6
7

SPECIFICATIONS
Size: ............................................. ..............6.75 x 3 x 1.25 in (136*78*16 mm)
Weight:............................................................................... 13.7 oz (388 g)
Output:......................................................................... 12V, 5V @ 2.1A & 1A
Input:.............................................................................................. 15V 1A
Battery Capacity: .....................................................................11100Mah
Full Charging Time: ......................................................................6 hours
Starting Current:...................................................................... 300 AMPs
Peak Current:........................................................................... 600 AMPs
Specifications are subject fo change without notice
Performance Notes
• Batteryunitwillshutoffautomaticallyifnoloadispresentor
charging is complete
• Afullchargewillchargeanaveragesmartphoneapproximately7
times. Charging time is about 1 hour.
• Chargingtimeforalaptopis2-3hoursdependingonlaptopbattery
capacity and charge level.
• Afullchargewillallowuptoapproximately20vehiclejumpstarts.
• Theinternalli-ionbatteryholdsachargefor3-6months.Forbest
results recharge every 3 months when not in use.
3 4
LED Light
• Pressandholdfor3secondstoturnon.
• Pressagainquicklytotogglemodes:On,Flash, S.O.S.
• Pressandholdfor3secondstoturnbackoff.
Read these safety warnings before operation.
WARNING!
• Donotexposedevicetorainorotherliquids,donotsubmerge.• Keep
out of reach of children and pets.
• Donotattempttorepairunityourself.
• Donotplaceunitnearstrongmagneticfields.
• Ifstoringunitinavehicle,besureitisproperlysecuredsoasnottomove
around potentially causing damage or injury.
• Donotexposeunittohighheat,radiation,orfire.Disposeofproperly
accordingtolocal,stateand/orfederale-wastedisposalregulations.Do
not dispose of in standard municipal waste facilities.
• Donotattempttousethisunitasareplacementtoyourvehicle’sbattery.
WARNING: REMOVE CABLES WITHIN 30 SECONDS OF VEHICLE
STARTING. NEVER TOUCH THE CABLES TOGETHER WHEN PLUGGED
IN. ALLOW DEVICE TO COOL BETWEEN JUMP START ATTEMPTS.
• Thisjumpstarterpowerbankisdesignedforjumpstartingsmalltomid-
sized vehicles and charging smaller portable electronics. Do not modify,
alter, attempt to repair or use the tool for any other purpose.
• Protect yourself and others by observing all safety information.
• Failure to comply with instructions could result in personal injury and/or
property damage!
• Always wear ANSI approved goggles when using this product.
• Work Safe. Operate tool a safe distance from yourself and others in the
 workarea.Keepproperfootingandbalanceatalltimes.Donotoverreach,
especially on ladders. Be certain ladders being used are sturdy, stable, on a
firm surface and erected as safe working angles. Do not reach over or
across running machines, hoses, cords, etc.
• Inspect tool before every use; do not use if parts are loose or damaged.
• Do not alter this product in any way.
• Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
• Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained. Follow instructions in the Maintenance section of this
manual. Use of unauthorized parts or failure to follow Maintenance
Instructions may create a risk of shock or injury.
• Maintain labels and nameplates. These carry important safety information.
If unreadable or missing, contact Performance Tool® for a replacement.
IMPORTANT SAFETY INFORMATION

5 6
TROUBLESHOOTING
Unit shows fully charged but unit
is not fully charged
unplug the charging adaptor and
then plug in again.
No response when pressing
power button
Low voltage protection may be
active. Recharge the battery unit.
Battery unit is generating
excessive heat
if charging a laptop, try removing
the laptop battery. If still hot,
disconnect, allow unit to cool and
charge again later.
INDICATOR/ALARM STATUS PROBABLE CAUSE/SOLUTION
Red indicator LED is blinking, fuse
holder alarms 1 long tone and 2
short tones.
Short circuit protection. Check
clamps for proper connection.
Red indicator LED is blinking, fuse
holder alarms, continuous tone.
Reverse connection protection.
Check clamps for proper
connection.
Red indicator LED is on. Over discharge protection. Check
Jump Starter battery indicator
LEDs; battery may be too low;
recharge jump starter. If jump
starter is full, there may be
insufficient amperage in the
vehicle’sbattery,anditmayneed
to be replaced.
The Red indicator LED is blinking
and black fuse holder alarms.
Reverse charge protection.
Disconnect jump starter from
battery.
Red and green indicator LEDs
light up together.
Over current protection. Vehicle
may require additional amperage,
and may not be able to be jumped
by this unit.
• Disconnect the plug from the power source before making any adjustments
or changing accessories. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
• Do not use accessories which are not specifically designed and
recommended by the tool manufacturer. Just because the accessory can
be attached to your power tool, it does not assure safe operation.
• Store idle equipment. When not in use, tools must be stored in a dry
location to inhibit rust. Always lock up tools and keep out of reach of
children and other untrained persons. Switch off all unused electrical tools
when stored. Disconnect battery from unit. Tools are dangerous in the
hands of untrained users.
• Properly dispose of batteries once depleted. Do not dispose of in a fire.
Check local regulations and follow proper disposal.
WARNING: Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities, contains chemicals known [to the State of
California] to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
-Leadfromlead-basedpaints.
-Crystallinesilicafrombricksandcementorothermasonryproducts.
-Arsenicandchromiumfromchemicallytreatedlumber.
• Your risk from these exposures varies, depending on how often you do this
typeofwork.Toreduceyourexposuretothesechemicals:workinawell-
ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.
(California Health & Safety Code § 25249.5, et seq.)
• The warnings, precautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur.
It must be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be supplied by the
operator.
WARNING: BATTERIES CONTAIN ACID AND PRODUCE EXPLOSIVE
GASES. DO NOT OPERATE JUMP STARTER NEAR ANY OPEN FLAME OR
SPARKS. DO NOT SMOKE, EXTINGUISH ANY FLAMES, AND ALWAYS
WORK IN A WELL VENTILATED AREA.
WARNING: This product and its packaging contain a chemical known to the
State of California to cause cancer, birth defects, or other reproductive harm.
