Performance PA6 User manual
6.5” 2-way coaxial speaker
User manual
Content
Welcome
Warranty
General
Declaration of conformity
Included parts
Pre installation
Installation
Running-in time
DLS support
Wiring diagram
Specifications
Dimensions
Product markings
1
1
1
1
2
2
2
3
3
4
5
5
6
DECLARATION OF CONFORMITY
Welcome to DLS!
Thank you for buying a DLS Performance PA6. For us, it’s
all about the sound experience. We care deeply about
sound and construction quality. In order for your experience
to be as optimal as possible, it is important that you read
this manual, preferably before you start your installation.
Keep the manual in a safe and accessible place for future
reference.
Your speakers must be installed correctly in order to work
as intended. Make sure you have all necessary tools nearby
before starting and that you are completely confident in how
to process. If you feel the slightest uncertainty; feel free to
take the help of an experienced installer or a car audio
dealer.
General
Some sound systems may vary in size of the door speaker.
Make sure that your vehicle has the same size as this
speaker, before you start the assembly
DLS Performance speakers for vehicles are
manufactured in accordance with the EU directive
EEC 95/54 (72/245/ EEC) and are marked with the
approval number. They are also marked in
accordance with the WEEE-directive 2012/19/EC.
The products are also produced in accordance
with the EU RoHS directive 2015/863/EU.
Warranty
This coaxial speaker is covered by warranty, depending on
the conditions in the country where it is sold. If the speaker
is returned for service, please include the original dated
receipt with the product.
Winn Scandinavia AB
Elementvägen 15 - SE-702 27 Örebro - Sweden
www.dls.se
DLS speakers are engineered by DLS Sweden,
a part of:
Designed & Sound tuned in Sweden.
PA 6
DLS PERFORMANCE
Included products:
2pcs Coaxial speakers
Included in box:
2pcs Speaker cables 100cm
8pcs V-type clips
8pcs Screws
2pcs Grills
1pcs Manual
Mount the speakers in the door or in the rear shelf of your car.They may fit in the factory pre-made mounting
holes, if not you might have to modify the fitting. If you want to improve the sound reinforcement you can use
a baffle of MDF-board or similar. An installation high up on the door side is to be prefered. For door
placements, there are normally speaker rings that have to be used to make the speaker fit to the door panel.
NOTE! It is important to fasten the speakers properly in order to avoid bad sound or rattling.
Installation
2
Included parts Pre installation
Disconnect Battery
Before you start the process
of replacing speakers,
disconnect and secure the
negative terminal from your
battery/power source. This
will prevent the risk of
damaging yourself or the
products.
Place the disconnected terminal in a secure and
isolated location away from any possible
connection belonging to the battery/power source
system.
Door insulation
DLS recommends using insulation/sound deadening
in the car doors.It lowers the noise from the road/tires
and prevent rattles and other noises from plastic
details in the doors.
If you need help deciding what type of door insulation
you should use, ask your DLS distributor for info and
guidance.
3
Running-in time
For technical assistance, ask your car audio dealer where the product was sold or the distributor in your
country.You can always contact the DLS Helpdesk in Sweden at e-mail: info@dls.se. Information can also
be found on our WEB-site www.dls.se. We follow a policy of continuous advancement in development. For
this reason, all or part of specifications & designs may be changed without prior notice.
DLS support
Allow the speakers to play for at least 15-20 hours in order to perform at its
possibly best. This run-in can be made with tone sweep or with just music.
Start at a moderate volume and increase the volume step by step during the
running in period. After the 15-20 hour run in session the performance and
characteristics will be in the correct condition.
4
Wiring diagram
Woofer 6.5” /165 mm
Basket Steel
Magnet HG Ferrite
Cone Polypropylene
Tweeter 0.51” / 13 mm
Frame ABS
Magnet Neodymium
Cone Mylar
RMS Power 50W
MAX Power 100W
PEAK Power 150W
Impedance 4 Ohm
Sensitivity 86dB 1W/1M
Freq. range 67Hz-20 kHz
Art. no CC-PA6
Ø159mm
Ø80mm
Ø166mm
58mm
Ø144mm
5
Specifications
Dimensions
This product has been granted with the CE certification mark to show that the
product follows the health, safety, and environmental protection standards for
products sold within the European Economic Area (EEA).
DLS products complies with the relevant provisions of the RoHS
Directive for the European Union. In common with all Electrical
and Electronic Equipment (EEE) the productshould not be
disposed of as household waste. Alternative arrangements may
apply in other jurisdictions.
aideMeliboMnaeporuEehtforentraplabolgasiSLD
Association, an organisation that focus on promoting the
custom made mobile media installations to consumers.
Product markings
We follow a policy of continuous advancement in development. For this reason all or part of
specifications & designs may be changed without prior notice. We reserve for possible typos,
factual or numeric errors that may have been printed on any products, package designs,
user manuals and/or other included accessories.
6
The crossed-out wheelie bin symbol means that the product, literature and
packaging included must be taken to separate collection at the end of their
working life. Do not dispose of these products as unsorted municipal waste:
take them for recycling. For info on your nearest recycling point, check with
your local waste authority.
