Performax 241-0916 User manual

Operator’s Manual
18V Lithium-Ion Hammer Drill
241-0916
CHARGE BATTERY
BEFORE FIRST USE
IMPORTANT
WARNING! To reduce the risk of injury, user must read instruction manual.
Safety symbols in this manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warn-
ings do not, by themselves, eliminate any danger, nor are they substitute for
proper accident prevention measures.
This Safety Alert Symbol indicates caution, warning, or danger. Failure to
obey a safety warning can result in serious injury to yourself or others. To reduce
the risk of injury, fire, or electric shock, always follow the safety precautions.
13
15
17
19
21

2
TABLE OF CONTENTS
Safety Symbols ……………..………………………………………......Page 3
Safety Instructions ……………………………….…...............................Page 5
Description …..…………………………………….…............................Page 10
Assembly ……………..………………………………………...............Page 11
Operation……………..……………………………………….........….Page 12
Maintenance ………..…………………………………….....….........…Page 21
Troubleshooting ……..………………………………………..................Page 23
Warranty ……..………………………………………............................Page 24
INTRODUCTION
SAVE THESE INSTRUCTIONS
This hammer drill has many features for making its use more pleasant and
enjoyable. Safety, performance, and dependability have been given top priority
in the design of this product, making it easy to maintain and operate.

3
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers.
The safety symbols and the explanations with them deserve your careful
attention and understanding. The symbol warnings do not, by themselves,
eliminate any danger. The instructions and warnings they give are no
substitutes for proper accident prevention measures.
WARNING: Be sure to read and understand all safety instructions in this
manual, including all safety alert symbols such as “DANGER,” ”WARNING” and
“CAUTION,” before using this tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious personal injury
SYMBOL SIGNAL MEANING
DANGER:
Indicates an imminently hazardous situation,
which, if not avoided, will result in death or
serious injury.
WARNING:
Indicates a potentially hazardous situation,
which, if not avoided, could result in death or
serious injury.
CAUTION:
Indicates an potentially hazardous situation,
which, if not avoided, may result in minor or
moderate injury.
NOTE: (Without Safety Alert Symbol) Indicates a situation
that may result in property damage.
WARNING: To ensure safety and reliability, all repairs should be performed by
a qualified service technician at Authorized Service Center.
WARNING: The operation of any power tool can result in
foreign objects being thrown into your eyes, which can
result in severe eye damage. Before beginning power
tool operation, always wear safety goggles or safety
glasses with side shields and a full-face shield when
needed. We recommend a Wide Vision Safety Mask for
use over eyeglasses or standard safety glasses with
side shields. Always use eye protection which is marked
to comply with ANSI Z87.1

4
SAVE THESE INSTRUCTIONS
Some of these following symbols may be used on this tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to
operate the tool better and more safely.
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
.../min
Alternating Current Type of current
.../min
Direct Current Type or a characteristic of current
noNo Load Speed Rotational speed, at no load
.../min
Class II Construction Double-insulated construction
.../min
Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
.../min
Wet Conditions Alert Do not expose to rain or use in damp locations.
.../min
Read The Operator’s
Manual To reduce the risk of injury, user must read operator’s manual.
.../min
Eye Protection Always wear safety goggles or safety glasses with side
shields, or a full face shield when operating this product.
Safety Alert Precautions that involve your safety.
.../min
No Hands Symbol Failure to keep your hands away from the blade will result in
serious personal injury.
.../min
No Hands Symbol Failure to keep your hands away from the blade will result in
serious personal injury.
.../min
No Hands Symbol Failure to keep your hands away from the blade will result in
serious personal injury.
.../min
No Hands Symbol Failure to keep your hands away from the blade will result in
serious personal injury.
.../min
Hot Surface To reduce the risk of injury or damage, avoid contact with any
hot surface.

5
SAFETY INSTRUCTIONS
GENRAL SAFETY RULES
WARNING: Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term power tool in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
1) WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or grounded surface, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep the cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.

6
3) PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use the tool while tired or under the
influence of drugs, alcohol, or medication. A moment of inattention while
operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure that the switch is in the OFF
position before connecting it to a power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your finger
on the switch or energizing power tools that have the switch on invites
accidents.
Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and
collection facilities, ensure that these are connected and properly
used. Use of these devices can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and more safely at
the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.

7
Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories, tool bits. etc., in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
5) BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of fire
when used with another battery pack.
Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects,
such as paper clips, coins, keys, nails, screws or other small metal
objects that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6) SERVICE
Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
SPECIFIC SAFETY RULES FOR CORDLESS HAMMER DRILL
Use this tool only with the batteries and charger listed below:
Battery pack Charger
252-0900
252-0908 252-0912
Hold power tools by their insulated gripping surfaces when performing
an operation where the cutting tool may contact hidden wiring or its
own cord. Contact with a “live” wire will also make exposed metal parts of
the tool “live” and shock the operator.

8
Use protective gloves when removing the bit from the tool, or first allow
the bit to cool down. The bit may be hot after prolonged use.
Keep your hands away from the motor-housing vents. Hot gas comes
from the vents during operation.
Do not operate the tool at full-load for more than 30 seconds, as this
can cause the motor to become too hot, which may damage the motor.
Release the trigger immediately when the screws are tightened to avoid
breaking the screw.
For best results, your battery tool should be charged in a location where the
temperature is more that 41oF (5oC) but less that 122oF (50oC). Do not store
outside or in vehicles.
SAFETY RULES FOR CHARGER
Warning: Read and understand all instructions. Failure to follow all instruc-
tions listed below may result in electric shock, fire, and/or serious personal in-
jury.
Before using the battery charger, read all instructions and cautionary
markings in this manual and on the battery charger, the battery, and the
product using the battery to prevent misuse of the products and possible
injury or damage.
CAUTION! To reduce the risk of electric shock or damage to the charger and
battery, charge only those rechargeable batteries specifically designated on your
charger’s label. Other types of batteries may burst, causing personal injury or
damage.
Do not use the charger outdoors or expose it to wet or damp
conditions. Water entering the charger will increase the risk of electric
shock.
Use of an attachment not recommended or sold by the battery-charger
manufacturer may result in a risk of fire, electric shock or injury to
persons.
Do not abuse the cord or charger. Never use the cord to carry the charger.
Do not pull the charger cord to disconnect the plug from receptacle. Damage
to the cord or charger could occur and create an electric shock hazard.
Replace damaged cords immediately.
Make sure that the cord is located so that it will not be stepped on,
tripped over, come in contact with sharp edges or moving parts, or
otherwise subjected to damage or stress. This will reduce the risk of
accidental falls, which could cause injury and damage to the cord, which
could then result in electric shock.

9
Keep the cord and charger from heat to prevent damage to the housing or
internal parts.
Do not allow gasoline, oils, petroleum-based products, etc. to come
in contact with plastic parts. These materials contain chemicals that can
damage, weaken, or destroy plastic.
An extension cord should not be used unless absolutely necessary. Use
of an improper extension cord could result in a risk of fire and electric shock.
If an extension cord must be used, make sure that:
The pins on plug of extension cord are the same number, size and shape as
those of the plug on charger.
The cord is properly wired and in good electrical condition
The size is large enough for AC ampere rating of charger as specified below:
The Cord Length (Feet) 25’ 50’ 100’
Cord Size (AWG) 16 16 16
NOTE: AWG = American Wire Gauge
Do not operate the charger with a damaged cord or plug, which could
cause shorting and electric shock. If damaged, have the charger repaired or
replaced by an authorized service technician at Service Center.
Do not operate the charger if it has received a sharp blow, been
dropped, or has otherwise been damaged in any way. Take it to an
authorized service technician at Authorized Service Center for an electrical
check to determine if the charger is in good working order.
Do not disassemble the charger. Take it to an authorized service technician
at an Authorized Service Center when service or repair is required. Incorrect
reassembly may result in a risk of electric shock or fire.
Unplug the charger from the electrical outlet before attempting any
maintenance or cleaning to reduce the risk of electric shock.
Disconnect charger from the power supply when not in use. This will
reduce the risk of electric shock or damage to the charger if metal items
should fall into the opening. It will also help prevent damage to the charger
during a power surge.
Risk of electric shock. Do not touch the uninsulated portion of output
connector or uninsulated battery terminal.
Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you lend this tool to someone else, also lend
these instructions to them to prevent misuse of the product and possible
injury.

10
DESCRIPTION
KNOW YOUR HAMMER DRILL (Fig. 1)
Before attempting to use this hammer drill, familiarize yourself with all of its
operating features and safety requirements.
WARNING: Do not allow familiarity with your hammer drill to make you care-
less. Remember that a careless fraction of a second is sufficient to inflict severe
injury.
PRODUCT SPECIFICATION
Motor 18 Volt DC
Switch VSR (Variable Speed Reversible)
No Load Speed LO: 0-400 RPM / HI: 0-1400 RPM
Hammer LO: 0-5200 BPM/HI: 0-18200 BPM
Clutch 23+1 position
Chuck 1/2” (13mm), single-sleeve keyless
Max torque 350 in. lbs
Charging time 60 min.
Drill Weight (With battery) 3 lb. 2 oz.
Battery Voltage 18 Volt DC
Charger Input 120-Volts, 60 Hz AC only
Optimum Charging Temperature 41°F (5°C) -122°F (50°C)
13
15
17
19
21
Torque adjustment
ring
Keyless chuck
Auxiliary handle
Battery release
button
LED worklight
Battery pack
Hammer/screw/drill
mode selection ring
Two-speed
gearbox switch
Direction-of-Rotation
Selector
Bit storage
Variable-speed
trigger switch
Fig. 1

11
WARNING: The safe use of this product requires an understanding of the
information included on the tool and in this operator’s manual, as well as know-
ledge of the project you are attempting. Before using this product, familiarize
yourself with all operating features and safety rules.
ADJUSTABLE TORQUE
The drill has 23+1 screw-driving positions.
TWO-SPEED GEAR BOX
The two-speed gear box is designed for drilling or driving at LO or HI speeds. A
slide switch is located on top of your hammer drill for selecting the appropriate
speed.
VARIABLE SPEED
The variable-speed trigger switch delivers higher speed with increased trigger
pressure and lower speed with decreased trigger pressure.
KEYLESS CHUCK
The keyless chuck allows you to hand-tighten or hand-release the drill bit in the
chuck jaws.
FORWARD/CENTER LOCK/REVERSE
The direction-of-rotation selector located above the trigger switch changes
the direction of bit rotation. Setting the trigger switch in the OFF (center lock)
position helps to reduce the possibility of accidental starting when not in use.
LED WORKLIGHT
Pressing the trigger switch illuminates the LED worklight, located on the front of
the drill. This feature provides extra light for increased visibility.
BIT STORAGE
The bit is conveniently stored at the back of battery pack.
ASSEMBLY
Warning: If any part is broken or missing, DO NOT attempt to plug in the
power cord, attach the battery or operate the drill until the broken or missing part
is replaced. Failure to do so could result in possible serious injury.
Warning: Do not attempt to modify this hammer drill or create accessories
not recommended for use with this hammer drill. Any such alteration or modi-
fication is misuse and could result in a hazardous condition leading to possible
serious injury.
Warning: To prevent accidental starting that could cause serious personal
injury, always remove the battery pack from the drill when assembling parts.

12
UNPACKING
This product has been shipped completely assembled.
Carefully remove the tool and any accessories from the box. Make sure that
all items listed in the packing list are included.
Inspect the tool carefully to make sure that no breakage or damage occurred
during shipping.
Do not discard the packing material until you have carefully inspected and
satisfactorily operated the tool.
PACKING LIST
Hammer drill, 1pc auxiliary handle, 1pc Lithium-Ion battery pack, 1pc charger,
1pc double end bit and Operator’s Manual
OPERATION
BATTERY PROTECTION
To protect the battery from damage and prolong its life, the battery pack’s
circuitry will turn off the battery pack if it becomes overloaded or if the
temperature becomes too high during use. This may happen in extremely high
torque, binding and stalling situations. The battery pack will begin normal
operation when it cools down.
NOTICE: A significantly reduced run time after fully charging the battery pack
indicates that the batteries are near the end of their usable life and must be
replaced.
COLD WEATHER OPERATION
When the battery pack is very cold, it may “pulse” for the first minute of use to
warm itself. Put the battery pack on a tool and use the tool in a light application.
After about a minute, the battery pack will have warmed itself and will operate
normally.
WHEN TO CHARGE THE BATTERY PACK
The Lithium-Ion battery can be charged at any time and will not develop a
“memory” when charged after only a partial discharge. It is not necessary to
run down the battery pack charge before recharging. Remove the battery pack
from the tool when convenient for you and your job.
You can “top-off” your battery pack’s charge before starting a big job or long
period of use.
Due to Lithium-Ion’s fade-free properties, the only time it is necessary to
charge the Lithium- Ion battery pack is when the pack has reached the end
of its charge. To signal the end of charge, power to the tool will drop quickly.
Charge the battery pack as needed.

13
HOW TO CHARGE THE BATTERY PACK
NOTICE: This Lithium-Ion battery pack is shipped partially charged. Before using
it the first time, fully charge the battery pack.
A fully discharged battery pack will charge about 60 minutes in a surrounding
temperature between 41° F (5oC) and 122° F (50oC).
1. Charge the Lithium-Ion battery pack
with the correct charger.
2. Connect the charger to a power supply.
3. Attach the battery pack to the Charger
by aligning the raised ribs of the
battery pack with the slot in the
Charger. Slide the battery pack onto
the Charger (Fig. 2).
4. The Charger will communicate with
the battery pack’s circuitry to evaluate the condition of the battery pack.
5. During normal charging, the green LED on the charger will flash
continuously.
6. After charging is complete, the green LED on the Charger will be on.
7. The battery pack will fully charge, but will not overcharge, if left on the Charger.
LED FUNCTIONS OF CHARGER (Fig. 3)
LED INDICATOR BATTERY
PACK RED LED GREEN LED ACTION
DEFECTIVE
BATTERY
BATTERY
CHARGING
BATTERY
FULL
HI / LO TEMP. Hot/Cold
battery On Off
Fast charge will begin
when battery returns to
desired temperature.
DEFECTIVE
BATTERY
BATTERY
CHARGING
BATTERY
FULL
HI / LO TEMP.
Defective Flashing Off Battery pack or charger
is defetive
DEFECTIVE
BATTERY
BATTERY
CHARGING
BATTERY
FULL
HI / LO TEMP.
Charging Off Flashing Charging
DEFECTIVE
BATTERY
BATTERY
CHARGING
BATTERY
FULL
HI / LO TEMP.
Fully
charged Off On Charging is complete
CHARGING A HOT BATTERY PACK
If the battery pack is above normal temperature range, the red LED on the
charger will turn on and the green LED will be off. When the battery pack cools
down to approximately 122°F (50°C), the charger will automatically begin fast
charge mode.
WARNI NG!
Li-ion
Model #: 252-0908
Risk of fire, explosion, and burns. Do not
disassemble, crush, heat above 212°F or
incinerate. Keep battery out of reach of children.
Use only with charger 252-0912.
Made in China
100520
Customer Service: 1-866-858-2664
BATTERY CHARGER
Fig. 2

14
CHARGING A COLD BATTERY PACK
If the battery pack is below normal temperature range, the red LED on the
charger will turn on and the green LED will be off. When the battery warms to
a temperature of more than 41°F (5°C), the charger will automatically begin
charge mode.
DEFECTIVE BATTERY
If the charger detects a problem, the red LED will flash and the green LED will
be off (or the red and green LED lights will both be off).
If defective, remove and reinsert the battery pack in the charger. If the LED
status reads the “defective” a second time, try charging a different battery
pack.
If a different battery pack charges normally, dispose of the defective battery
pack (see maintenance section).
If a different battery pack also indicates “defective,” the charger may be
defective.
BATTERY CHARGING
If the battery pack is within normal temperature range, the green LED will begin
flashing and the red LED will be off.
BATTERY FULL
When the battery is fully charged, the green LED Light on the charger will be on.
NOTICE: The battery pack will fully charge, but will not overcharge, if left on the charger.
NOTICE: Charger may warm with several continuous charge cycles. This is part
of the normal operation of the charge. Charge in a well ventilated area.
TO ATTACH BATTERY PACK (Fig. 4)
Lock the trigger switch on the drill by
placing the direction of rotation (forward/
center lock/reverse) selector in center
position
1. Align the raised portion on the battery
pack with the grooves on the bottom
of the drill, and then attach the battery
pack to the drill as shown.
2. Make sure that the latch on the
battery pack snaps into place and the battery pack is secured to the drill
before beginning operation.
CAUTION! When placing the battery pack in the tool, be sure that the raised
rib on battery pack aligns with the groove on the drill and the latches snap into
place properly. Improper assembly of the battery pack can cause damage to in-
ternal components.
Fig. 4
Detach
Attach

15
TO DETACH BATTERY PACK (Fig. 4)
1. Lock the trigger switch on the drill by placing the direction of rotation
(forward/center lock/reverse) selector in center position.
2. Depress the battery release buttons located on the front of the battery pack
to release the battery pack.
3. Pull forward on the battery pack to remove from the tool.
TRIGGER SWITCH (Fig. 5a)
To turn the drill ON, depress the trigger
switch. To turn it OFF, release the trigger
switch.
VARIABLE SPEED (Fig. 5a)
The variable-speed trigger switch delivers
higher speed with increased trigger
pressure and lower speed with decreased
trigger pressure.
DIRECTION-OF-ROTATION SELECTOR
(FORWARD/CENTER LOCK/REVERSE)
(Fig. 5b)
The direction of bit rotation is reversible
and is controlled by a selector located
above the trigger switch.
With the drill held in normal operating
position:
1. Position the direction of rotation
selector to the left of the tool for forward rotation.
2. Position the direction of rotation selector to the right of the tool for reverse
rotation.
3. Setting the switch in the OFF (center lock) position helps reduce the possibility
of accidental starting when the tool is not in use.
NOTICE: To prevent gear damage, always allow the chuck to come to a complete
stop before changing the direction of rotation.
NOTICE: The hammer drill will not run unless the direction of rotation selector is
engaged fully to the left or right.
ELECTRIC BRAKE
To stop the hammer drill, release the trigger switch and allow the chuck to
come to a complete stop. The electric brake quickly stops the chuck from
rotating. This feature engages automatically when you release the trigger
switch.
Fig. 5a
Direction-
of-rotation
selector
Variable-speed
trigger switch
Fig. 5b
FORWARD
REVERSE

16
KEYLESS CHUCK (Fig. 6)
The hammer drill has a keyless chuck to tighten or release drill bits in the chuck
jaws. The arrows on the chuck indicate which direction to rotate the chuck
body in order to GRIP (tighten) or OPEN
(release) the chuck jaws on the drill bit.
WARNING: Do not hold the chuck body
with one hand and use the power of the
drill to tighten the chuck jaws on the drill
bit. The chuck body could slip in your hand,
or your hand could slip and come in con-
tact with the rotating bit. This could cause
an accident resulting in serious personal
injury.
TWO-SPEED GEAR BOX (Fig. 7)
The drill has a two-speed gear box designed for drilling or driving at LO or HI
speeds. A slide switch is located on the top of the drill to select either LO or HI
speed.
When using the drill in the LO speed
range, the speed will decrease and the
drill will have more power and torque.
When using drill in the HI speed range,
the speed will increase and the drill
will have less power and torque. Use
LO speed for high power and torque
applications and HI speed for fast drilling
or driving applications.
Use LO speed for starting holes without
a center punch, drilling metals or plastic, drilling ceramics, or in applications
requiring a higher torque (see below).
HI speed is better for drilling wood and wood composites and for using abrasive
and polishing accessories.
CAUTION! Never change gears while the tool is running. Failure to obey this
caution could result in serious damage to the drill.
NOTICE: Avoid running the drill at LO speed for extended periods of time.
Running at LO speed under constant usage may cause the drill to become
overheated. If this occurs, cool the drill by running it without a load at HI speed.
13 15 17 19
Fig. 6
(Release)
(Tighten)
Keyless
chuck
OPEN
GRIP
Fig. 7
Two-speed gearbox switch

17
SCREWDRIVING/DRILLING/HAMMER DRILLING MODE SELECTION (Fig. 8)
To select the mode, rotate the mode
selection ring until the appropriate icon
aligns with the arrow and clicks into
position.
Screwdriving
Rotate the mode selection ring so the
screw symbol is aligned with the arrow.
Set the torque adjustment ring to the
appropriate number setting for the torque
desired.
NOTICE: The torque adjustment ring may be set on any number; change
between screwdriving and drilling modes using the mode selection ring.
Drilling
CAUTION! When the mode selection ring is in the drill/ hammer drill mode, the
drill will not clutch out regardless of the position of the torque adjustment ring.
Rotate the mode selection ring so the drill symbol is aligned with the arrow.
NOTICE: The torque adjustment ring may be set on any number.
Hammer drilling
Rotate the mode selection ring so the hammer symbol is aligned with the arrow.
ADJUSTABLE TORQUE CLUTCH (Fig. 9)
The torque clutch can be adjusted to 24
different settings. The higher the torque
setting, the more force the drill produces
to turn an object in either LO or HI rotation
speed.
When using the drill for different driving
applications, it is necessary to increase
or decrease the torque in order to help
prevent the possibility of damaging screw
heads, threads, workpiece, etc.
Adjust the torque by rotating the torque-adjustment ring.
The proper setting depends on the job and the type of bit, fastener, and material
you will be using. In general, use greater torque for larger screws, but if the
torque is too high, the screws may be damaged or broken.
For delicate operations, such as removing a partially stripped screw, use a
low torque setting. For operations such as drilling into hardwood, use a higher
torque setting.
13
15
17
19
Fig. 8
Mode selection ring
13 15 17 19
Fig. 9 To decrease torque
To increase torque
Torque
adjustment
ring

18
NOTICE: When adjusting the torque clutch make sure that the speed switch is
completely in either the LO or HI position.
CAUTION! Do not change the torque setting when the tool is running.
LED WORKLIGHT (Fig. 10)
The LED worklight, located on the base of
the drill, will illuminate when the trigger
switch is depressed. The LED worklight
will turn off when the trigger switch is
released. This provides additional light on
the surface of the workpiece for operation
in lower-light areas.
INSTALLING BITS (Fig. 11a, 11b)
1. Lock the trigger switch by placing the
direction of rotation selector in the
OFF (center) position.
2. Open or close the chuck jaws to a
point where the opening is slightly
larger than the bit size you intend to
use.
3. Insert a drill bit.
WARNING: Make sure to insert the
drill bit straight into the chuck jaws. Do
not insert the drill bit into the chuck jaws
at an angle and then tighten the chuck,
as shown in figure 11b. This could cause
the drill bit to be thrown from the drill, re-
sulting in possible serious personal injury
or damage to the chuck.
NOTICE: Rotate the chuck body in the
direction of the arrow marked GRIP to close the chuck jaws. Do not use a
wrench to tighten or loosen the chuck jaws.
4. Tighten the chuck jaws securely on the bit.
REMOVING BITS
CAUTION! Use protective gloves when removing the bit from the tool, or first
allow the bit to cool down. The bit may be hot after prolonged use.
1. Lock the trigger switch by placing the direction of rotation selector in the
OFF (center) position.
Fig. 10
LED worklight
Fig. 11b WRONG!
13 15 17 19
Fig. 11a
(Release)
Tighten
Keyless
chuck
OPEN
GRIP

19
2. Open the chuck jaws.
NOTICE: Rotate the chuck body in the direction of the arrow marked OPEN
to close the chuck jaws. Do not use a wrench to tighten or loosen the chuck
jaws.
3. Remove the drill bit.
USING THE AUXILIARY HANDLE ASSEMBLY
WARNING: To reduce the risk of injury, always use the auxiliary handle
when operating and hold tool with both hands to maximize control.
The auxiliary handle must be tightened sufficiently to resist the twisting
action of the tool if the bit binds or stalls. Be sure to grip the side handle at
the far end to control the tool during a stall.
The auxiliary handle can be attached to either side for left- or right-hand use.
GENERAL DRILLING (Fig. 12)
1. Check the direction of rotation
selector for the correct setting
(forward or reverse).
2. Secure the material to be drilled in a
vise or with clamps to keep it from
turning as the drill bit rotates.
3. Hold the drill firmly and place the bit
at the point to be drilled.
4. Depress the trigger switch to start the drill.
5. Move the drill bit to contact the workpiece, applying only enough pressure
to keep the bit cutting. Do not force the drill or apply side pressure to
elongate a hole. Let the tool do the work.
6. When drilling hard, smooth surfaces, use a center punch to mark the
desired location of the hole. This will prevent the drill bit from slipping off-
center as the hole is started.
7. When drilling metals, use light oil on the drill bit to keep it from overheating.
The oil will prolong the life of the bit and increase the drilling action.
8. If the bit jams in the workpiece or if the drill stalls, stop the tool
immediately. Remove the bit from the workpiece and determine the
reason for jamming.
NOTICE: This drill is equipped with an electric brake. When the brake is
functioning properly, sparks may be visible through the vent slots in the
housing. This is normal and is the action of the brake.
DRILLING MODE OPERATION
1. Select the desired speed to match the planned operation.
Fig. 12

20
2. For wood drilling, use twist bits, spade bits, power auger bits or hole saws.
Begin drilling at a very low speed to prevent the bit from slipping off the
starting point and increase the speed as the drill bit bites into the material.
When drilling “through” holes, place a block of wood behind the workpiece to
prevent ragged or splintered edges on the back side of the hole.
3. For metal drilling, use high speed steel twist drill bits. Begin drilling at a very
low speed to prevent the bit from slipping off the starting point. Maintain a
speed and pressure which allows cutting without overheating the bit. Use
light oil on the drill bit to keep it from overheating; the oil will prolong the
life of the bit and increase the drilling action.
4. If the drill stalls, it is usually because it is being overloaded. Release trigger
switch immediately, remove drill bit from work, and determine cause of stalling.
5. Keep the motor running when pulling the bit back out of drilled hole. This
will prevent jamming.
HAMMER DRILLING MODE OPERATION
1. When hammer drilling, use just enough force on the hammer to keep it from
bouncing excessively. Too much force will cause slower drilling speeds,
overheating and a lower drilling rate.
2. Do not exert side pressure on the bit when drilling, as this will cause
clogging of the bit flutes and reduced drilling speed.
3. If the hammer speed starts to drop off when drilling deep holes, pull the bit
partially out of the hole with the tool still running to help clear debris from
the hole.
4. For masonry, use carbide-tipped bit or masonry bits. A smooth, even flow of
dust indicates the proper drilling rate.
WARNING: Always wear safety goggles or safety glasses with side shields
during power tool operation or when blowing dust. If operation is dusty, also wear
a dust mask.
SCREWDRIVER OPERATION
1. Select the desired speed/torque range to match the planned operation.
2. Attach the desired fastener accessory into the chuck.
3. Make a few practice runs in scrap piece before working.
