Performax 241-9891 User manual

8.5A IMPACT WRENCH
241-9891
Owner’s Manual
PRODUCT SPECIFICATIONS
Rating:
120 V AC, 60 Hz
Amperes:
8.5 A
Speed:
2,600 RPM (no load)
Impact speed:
2,700 BPM
Torque:
440 ft/lbs in reverse
320 ft/lbs in forward
Square drive:
1/2"
Weight:
9 lb 8 oz (4.3 kg)
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665
Technical questions
Replacement parts
Parts missing from package

2
Product specifications ………….…………………………………………………….
1
Table of contents ……………………………………………………………………...
2
General safety warnings ……………………………………………………………..
3–4
Eye, ear & lung protection ……………………………………………………………
3–4
Electrical safety ……………………………………………………………………….
4
Power tool safety ……………………………………………………………………...
5–6
General safety rules …………………………………………………………………..
5
Work area safety ………………………………………………………………….…..
5
Electrical safety ……………………………………………………………………….
5
Personal safety ………………………………………………………………………..
5–6
Power tool use and care .…………………………………………………………….
6
Service …………………………………………………………………………………
6
Specific safety rules …………………………………………………………………..
7
Extension cord safety ………………………………………………………………...
8
Symbols ………………………………………………………………………………..
9
Know your impact wrench ……………………………………………………………
10
Accessories ……………………………………………………………………………
10
Assembly and operation ……………………………………………………………..
11–13
Installing impact sockets ……………………………………………………………..
11
Forward/reverse trigger switch ………………………………………………………
11
Removing fasteners …………………………………………………………………..
11–12
Tightening wheel nuts ………………………………………………………………..
12–13
Maintenance …………………………………………………………………………..
14–15
Removing motor brushes …………………………………………………………….
14–15
Installing new motor brushes ………………………………………………………..
15
Exploded view …………………………………………………………………………
16
Parts list ………………………………………………………………………………..
17–18
Warranty ……………………………………………………………………….………
19
TABLE OF CONTENTS

3
EYE, EAR & LUNG PROTECTION
This instruction manual includes the following:
General Safety Rules
Specific Safety Rules and Symbols
Functional Description
Assembly
Operation
Maintenance
Accessories
!
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if
broken during operation of a power tool.
SAVE THESE INSTRUCTIONS FOR REFERENCE
WARNING: Use hearing protection, particularly during extended
periods of operation of the tool or if the operation is noisy.
!
GENERAL SAFETY WARNINGS
WARNING: Before using this tool or any of its accessories, read this
manual and follow all Safety Rules and Operating Instructions. The
important precautions, safeguards and instructions appearing in this manual
are not meant to cover all possible situations. It must be understood that
common sense and caution are factors which cannot be built into the product.
!

4
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, fire hazards or damage to the
tool, use proper circuit protection.
This tool is wired at the factory for 120 V operation. It must be connected to
a 120 V 15 A time delayed fuse or circuit breaker. To avoid shock or fire,
replace power cord immediately if it is worn, cut or damaged in any way.
GENERAL SAFETY WARNINGS
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
WARNING: Dust that is created by power sanding, sawing, grinding,
drilling, and other construction activities may contain chemicals that are
known to cause cancer, birth defects. or other genetic abnormalities. These
chemicals include:
Lead from lead-based paints
Crystalline silica from bricks, cement, and other masonry products
Arsenic and chromium from chemically-treated lumber
The level of risk from exposure to these chemicals varies according to how
often this type of work is performed. In order to reduce exposure to these
chemicals, work in a well-ventilated area, and use approved safety
equipment, such as a dust mask that is specifically designed to filter out
microscopic particles.
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

5
WARNING: Read all safety warnings
and instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
Work area safety
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of a ground fault
circuit interrupter (GFCI) reduces the risk of
electric shock.
Personal safety
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in
moving parts.
POWER TOOL SAFETY
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

6
Personal safety –cont’d
If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
Hold power tool by insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring or its own cord. Contact with a "live"
wire will make exposed metal parts of the tool
"live" and shock the operator.
Use clamps or another practical way to
secure and support the workpiece to a stable
platform. Holding the work by hand or against
your body leaves it unstable and may lead to
loss of control.
Service
Have your power tool serviced by a qualified
repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
POWER TOOL SAFETY
SAVE THESE INSTRUCTIONS FOR REFERENCE

7
WARNING: Know your impact wrench.
Read the Owner’s Manual carefully. Learn
the tool’s applications and limitations, as
well as the specific potential hazards related
to this tool. Following this rule will reduce the
risk of electric shock, fire or serious injury.
Always wear eye protection. Any
power tool can throw foreign
objects into your eyes and cause
permanent eye damage.
ALWAYS wear safety goggles (not glasses) that
comply with ANSI safety standard Z87.1.
Everyday glasses have only impact resistant
lenses. They ARE NOT safety glasses.
WARNING: Glasses or goggles not in
compliance with ANSI Z87.1 could cause
serious injury when they break.
Always use hearing protection when operating
the impact wrench.
Hold power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring or its own cord. Fasteners contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
Use only impact sockets and accessories that
are designed for use with an impact wrench. Do
not use chrome plated sockets and accessories.
Chrome plated sockets and accessories are
designed for hand use only and MUST NOT be
used with an impact wrench. They may shatter
and possibly cause serious injury.
Before each use, check the impact sockets and
accessories for excessive wear or cracks. Worn
or damaged sockets or accessories may shatter
and possibly cause serious injury. Worn
accessories may allow the socket to come off
during operation of the impact wrench.
Never use the impact wrench as a torque
wrench. Always use a torque wrench to adjust
the fastener to the specified torque.
Keep the impact wrench handle and body clean
and free of oil and grease. Always use a clean
dry cloth when cleaning. Do not use solvents,
brake fluid, gasoline or other petroleum products
to clean the tool. They will damage the tool.
Do not wear neckties or loose clothing.
When wearing gloves, they must be tight fitting
and slip resistant type. Leather gloves offer the
best protection.
Always use two hands when operating the
impact wrench. Use one hand on the handle
and the other on the front of the tool body.
Never place your hand so it is touching the
socket or accessory when the tool is turned ON.
Your hand could be seriously injured.
Always remove the plug from the power source
before installing or removing any socket or
accessory.
Be ready for components to shift when removing
any fastener. The speed of the fastener removal
could cause unexpected shifting of the
components.
SPECIFIC SAFETY RULES
!
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

8
WARNING: Keep the extension cord
clear of the work area. Position the cord so
that it will not get caught on the workpiece, a
tool, or any other obstruction while the power
tool is in use.
If an extension cord is used with this impact
wrench, verify that it is in good condition. When
using an extension cord, be sure to use one that
is heavy enough to carry the current that the tool
will draw. An undersized cord will cause a drop
in line voltage, which will result in a loss of
power and overheating.
The following table shows the correct size to
use according to cord length and the amperage
rating that is listed on the tool's nameplate.
When in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
Verify that the extension cord is properly wired
and in good condition. Replace a damaged
extension cord immediately, or have it repaired
by a qualified electrician before using it. Keep
the extension cord away from sharp objects,
excessive heat, and damp or wet areas.
Use a separate electrical circuit for power tools.
This circuit must consist of not less than 14
gauge wire, and should be protected by either a
15 Amp. time-delayed fuse or a circuit breaker.
Before connecting the power tool to the outlet,
verify that the switch is in the OFF position, and
that the voltage of the power source is the same
as the voltage that is indicated on the tool's
nameplate. Running this impact wrench at lower
voltage will damage the motor.
EXTENSION CORD SAFETY
MINIMUM GAUGE (AWG)
EXTENSION CORDS (120 V use only)
Amperage
rating
Total length
More
than
Not
more
than
25'
(7.5 m)
50'
(15 m)
100'
(30 m)
150'
(45 m)
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

9
WARNING: Some of the following symbols may appear on the impact wrench.
Study these symbols and learn their meaning. Proper interpretation of these symbols
will allow for more efficient and safer operation of this tool.
This symbol designates that this tool is listed
with U.S. requirements by ETL Testing
Laboratories, Inc.
Conforms to UL Std. 60745-1, 60745-2-2.
Certified to CAN/CSA STD C22.2 No.
60745-1, 60745-2-2.
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Litres
kg
Kilograms
H
Hours
N/cm2
Newtons per square
centimeter
Pa
Pascals
Min
Minutes
S
Seconds
Alternating current
Three-phase alternating
current
Three-phase alternating
current with neutral
Direct current
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight construction
Protective grounding at
grounding terminal,
Class I tools
Revolutions or
reciprocations per
minute
Diameter
Off position
Directional arrow
Warning symbol
SYMBOLS
!
JD2173U
3042597

10
AVAILABLE ACCESSORIES
WARNING: Use only accessories that
are recommended for this impact wrench.
Follow the instructions that accompany the
accessories. The use of improper
accessories may result in injury to the
operator or damage to the impact wrench.
Before using any accessory, carefully read the
instructions or the owner’s manual for the
accessory.
Impact sockets
Impact extensions
Impact adapters
Impact nut drivers
Impact screwdriver bits
WARNING: If any part is missing or
damaged, do not plug the impact wrench into
the power source until the missing or damaged
part is replaced.
KNOW YOUR IMPACT WRENCH
ACCESSORIES
½" square
drive
Air vents
Motor end
cap
Handle
Forward/reverse
trigger switch
Air vents
!
!

11
INSTALLING IMPACT SOCKETS
WARNING: Use only impact sockets
and accessories that are designed for use
with an impact wrench. Do not use chrome
plated sockets and accessories. Chrome plated
sockets and accessories are designed for hand
use only and MUST NOT be used with an
impact wrench. They may shatter and possibly
cause serious injury.
WARNING: Always remove the plug from
the power source before changing any sockets
or accessories. You may injure your hand if the
tool is started accidentally.
To install a socket, press the square portion of
the socket (1) onto the square drive (2) of the
impact wrench (Fig. 1).
NOTE: Slide the socket fully onto the square
drive so the socket is held firmly in place.
FORWARD/REVERSE TRIGGER SWITCH
This impact wrench is equipped with a rocker
style forward/reverse switch (1) (Fig. 2).
1. To operate the impact wrench in the
forward direction, press and hold the
bottom part of the switch (2). The socket
will rotate in a clockwise direction to
tighten the fastener.
2. To operate the impact wrench in the
reverse direction, press and hold the top
part of the switch (3). The socket will rotate
in a counter clockwise direction to loosen
the fastener.
REMOVING FASTENERS
One of the most common uses for the impact
wrench is to remove car wheel nuts for rotating
the tires. Car wheel nut removal is used for
illustrative purposes.
DANGER: Before attempting to remove
a car wheel, make sure all jacking, wheel
blocking and wheel removal safety
procedures illustrated in the Owner’s Manual
for your car are followed exactly. Failure to
follow those safety instructions could result
in serious injury or death.
1. Install the correct size of impact socket on
the impact wrench as outlined in Fig. 1
2. Plug the impact wrench power cord into an
appropriate power source.
3. Grasp the impact wrench handle (1) with
one hand and the front housing of the
impact wrench (2) with the other hand
(Fig. 2).
ASSEMBLY AND OPERATION
!
!
!
!
WARNING
For safety reasons, the operator must
read the sections of this Owner’s Manual
entitled “GENERAL SAFETY
WARNINGS”, “POWER TOOL SAFETY”,
“SPECIFIC SAFETY RULES”,
“EXTENSION CORD SAFETY” and
“SYMBOLS” before using this impact
wrench.
Verify the following every time the impact
wrench is used:
1. Safety glasses and hearing
protection are being worn.
2. Socket or accessory is “impact
wrench” rated.
3. Socket or accessory is in good
condition.
Failure to observe these safety rules will
significantly increase the risk of injury.
!
Fig. 1
12

12
REMOVING FASTENERS –cont’d
4. Place impact socket (3) onto the wheel nut.
NOTE: Make sure the socket is fully
engaged with the nut to avoid potentially
damaging the socket or the wheel nut.
5. While holding the tool level with the ground
and with a firm grasp, squeeze the upper
portion of the trigger switch (4).
When removing fasteners, do not operate the
impact wrench for more than 15 seconds unless
the fastener begins to turn. If the fastener fails to
turn within 15 seconds, reverse the direction of
rotation and operate the impact wrench in a
forward direction on the fastener for a few
seconds. Now switch back to reverse direction
and remove the fastener. This procedure will
usually break loose seized or “frozen” fasteners.
WARNING: Operating the impact wrench
for more that 15 seconds at a time on a seized
or “frozen” fastener will place severe stress on
the impact wrench and cause damage. It may
also break the fastener.
NOTE: Once the wheel nut has been removed,
release the trigger switch. The tool will turn
OFF.
TIGHTENING WHEEL NUTS
This impact wrench can be used to tighten
wheel nuts and other fasteners.
1. Install the correct size of impact socket on
the impact wrench (Fig. 1).
2. Place the wheel on the wheel studs and
thread one wheel nut (1) clockwise onto
each wheel stud
(Fig. 3).
NOTE: Thread each wheel nut at least
three full turns onto the wheel stud by hand
to make sure the nuts are NOT cross
threaded. The wheel stud and wheel nut
will be damaged if the nut is cross
threaded.
3. Grasp the impact wrench handle with one
hand and the front housing of the impact
wrench with the other hand.
4. Place the impact socket onto the lower
wheel nut (1) (Fig. 4 & 5).
NOTE: Make sure the socket is fully
engaged with the nut to avoid potentially
damaging the socket or the wheel nut.
5. While holding the tool level with the ground
and with a firm grasp, squeeze the lower
portion of the trigger switch. The impact
wrench will tighten the wheel nut.
!
Fig. 3
1
Fig. 2
1
2
3
4
ASSEMBLY AND OPERATION

13
TIGHTENING WHEEL NUTS –cont’d
NOTE: Release the trigger switch
IMMEDIATELY when the impact mechanism
“rattles”.
6. Proceed with tightening the remaining
wheel nuts as noted above.
WARNING: Tighten the wheel nuts in
the sequence outlined in Fig. 4 for 4 stud
wheel patterns and Fig. 5 for 5 stud wheel
patterns. Following this sequence is
extremely important to avoid potential
distortion of the brake rotors or drums.
7. Use a torque wrench to tighten all wheel
nuts to the manufacturer’s recommended
torque. Follow the same tightening
sequence as noted above.
8. Once the wheel nuts have been tightened,
lower the vehicle so the wheel is firmly in
contact with the ground and verify the
torque of each wheel nut using a
conventional torque wrench.
ASSEMBLY AND OPERATION
!
Fig. 4
Fig. 5

14
GENERAL
WARNING: When servicing, use only
identical replacement parts. Use of any other
part may create a hazard or cause product
damage.
DO NOT use solvents when cleaning plastic
parts. Plastics are susceptible to damage from
various types of commercial solvents and may
be damaged by their use. Use a clean cloth to
remove dirt, dust, oil, grease etc.
WARNING: Do not at any time allow
brake fluids, gasoline, petroleum-based
products, penetrating oils, etc. to come into
contact with plastic parts. They contain
chemicals that can damage, weaken or
destroy plastic.
DO NOT abuse power tools. Abusive practices
can damage the tool as well as the workpiece.
WARNING: DO NOT attempt to modify
tools or create accessories. Any such
alteration or modification is misuse and
could result in a hazardous condition leading
to possible serious injury. It will also void
the warranty.
LUBRICATION
All of the bearings in this tool are lubricated with
a sufficient amount of high-grade lubricant for
the life of the unit under normal conditions.
Therefore, no further lubrication is required.
REMOVING MOTOR BRUSHES
Motor brushes are a normal wear item and will
require replacing periodically depending upon
the amount the tool is used. The following
information outlines the general procedure for
removal of the worn brushes and installation of
the new brushes.
WARNING: Make sure the impact wrench
is unplugged from the power source.
Removing worn brushes
1. Remove 4 screws (1) from the motor end
cap (2) using a #2 screwdriver (Fig. 6).
2. Carefully pry the motor end cap (2) off the
motor housing (3) using a small slot
screwdriver.
NOTE: Be careful not to damage the motor
end cap or the motor housing to ensure
easy re-assembly.
MAINTENANCE
!
!
!
!
Fig. 6
1
2
Fig. 7
23

15
Removing worn brushes –cont’d
NOTE: Pay attention to the position of the
braided copper brush wire (8) (Fig. 8). When the
new carbon brush is reinstalled, the braided
brush wire MUST be placed in exactly the same
position.
3. Use a small slot screwdriver to lift the end
of the coil spring (4) upward and place it on
the edge of the copper brush holder (5).
4. Use small needle nose pliers to pull the top
spade connector (6) from the spade
terminal.
5. Turn the two brush holder screws (7)
counter clockwise about 4 turns using a
#2 screwdriver.
NOTE: Do NOT completely remove the
screws. Back the screws out only far
enough to allow the carbon brush to be
removed from the brush holder.
6. Carefully grasp the braided copper brush
wire (8) and lift the carbon brush (9) from
the brush holder.
INSTALLING NEW MOTOR BRUSHES
7. Once the old carbon brush has been
removed, use a SOFT DRY brush to
carefully remove all grinding dust from the
brush holder and install the new carbon
brush in the reverse order that was used to
remove the worn carbon brush.
8. Reinstall the new carbon brush in reverse
order of paragraphs 1 through 6.
NOTES:
a) Make sure the braided brush wire is routed
EXACTLY the same as the original.
b) Make sure the end of the coil spring is
placed on top of the carbon brush (Fig. 8).
9. Turn the tool over to remove and replace
the second carbon motor brush using the
same procedures noted above.
10. Once both carbon brushes have been
replaced, reinstall the motor end cap and
the motor end cap screws.
MAINTENANCE
Fig. 8
4
5
6
7
8
7
9

16
EXPLODED VIEW
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
23
29
30
31
25
26
27
32
34
33
35
37
36
39
40
42
44
41
2
3
24
38
43
20
22
28
34

17
WARNING: When servicing, use only original equipment replacement parts. The
use of any other parts may create a safety hazard or cause damage to the impact wrench.
Any attempt to repair or replace electrical parts on this impact wrench may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-Free Helpline, at 1-866-349-8665.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
4030090005
ST4.9×50 Screws
4
2
4040030003
5mm Lock washer
4
3
4040010011
5mm washer
4
4
3140100013
Rubber sleeve
1
5
2020050079
Aluminum shell
1
6
3140020017
O-ring
1
7
2010080084
Bushing
1
8
2030020196
Washer
1
9
2040040051
Drive shaft
1
10
4080080002
ball ф6.35mm
2
11
2040200014
Impact block
1
12
4080060001
ф5mm Ball bearing racer
24
13
2030020343
Washer
1
14
2050060240
Torque spring
1
15
2040040113
Intermediate shaft
1
16
2010010132
Planetary gears
3
17
4110010011
Pins
3
18
2030020229
Washer
1
19
4010010084
Bearing 6002 2RS
1
20
4100010015
Circlip
1
PARTS LIST
!

18
Key #
Part #
Part Name
Quantity
21
2010090082
Ring gear
1
22
3140020132
Oil seal ring
1
23
2020020050
Gear box
1
24
3190010023
Felt seal ring
1
25
4010010055
Bearing 6001 2RS
1
26
1010180015
Rotor
1
27
4010010048
Bearing 608 RS
1
28
3140040001
Bearing boot
1
29
3150050094
Air deflector
1
30
4003010122
ST3.9×70 Screws
2
31
3150160214
Stator spacer
1
32
1020180014
Stator
1
33
3120070132
Handle
1
34
4030010106
ST3.9×19 screws
7
35
1062020067
Switch
1
36
1250010002
Terminal block
1
37
3140010061
Strain relief
1
38
1190290015
UL approved power cord
1
39
3011180006
Housing
1
40
1230030032
Carbon brush holder assembly
2
41
2050020030
Brush flat coil tension spring
2
42
4030010146
ST2.9×18 screws
4
43
1230010149
Carbon brushes
2
44
3160010071
Motor end cap
1
PARTS LIST

19
Rev 1.4 16/12/2015
PERFORMAX®IMPACT WRENCH WARRANTY
30-DAY MONEY BACK GUARANTEE:
This PERFORMAX®brand power tool carries our 30-Day Money Back
Guarantee. If you are not completely satisfied with your PERFORMAX®brand
power tool for any reason within thirty (30) days from the date of purchase, return
the tool with your original receipt to any MENARDS®retail store, and we will
provide you a refund –no questions asked.
2-YEAR LIMITED WARRANTY:
This PERFORMAX®brand power tool carries a 2-Year Limited Warranty to the
original purchaser. If, during normal use, this PERFORMAX®power tool breaks
or fails due to a defect in material or workmanship within two (2) years from the
date of original purchase, simply bring this tool with the original sales receipt
back to your nearest MENARDS® retail store. At its discretion, PERFORMAX®
agrees to have the tool or any defective part(s) repaired or replaced with the
same or similar PERFORMAX®product or part free of charge, within the stated
warranty period, when returned by the original purchaser with original sales
receipt. Not withstanding the foregoing, this limited warranty does not cover any
damage that has resulted from abuse or misuse of the Merchandise. This
warranty: (1) excludes expendable parts including but not limited to blades,
brushes, belts, bits, light bulbs, and/or batteries; (2) shall be void if this tool is
used for commercial and/or rental purposes; and (3) does not cover any losses,
injuries to persons/property or costs. This warranty does give you specific legal
rights and you may have other rights, which vary from state to state. Be careful,
tools are dangerous if improperly used or maintained. Seller’s employees are
not qualified to advise you on the use of this Merchandise. Any oral
representation(s) made will not be binding on seller or its employees. The rights
under this limited warranty are to the original purchaser of the Merchandise and
may not be transferred to any subsequent owner. This limited warranty is in lieu
of all warranties, expressed or implied including warranties or merchantability
and fitness for a particular purpose. Seller shall not be liable for any special,
incidental, or consequential damages. The sole exclusive remedy against the
seller will be for the replacement of any defects as provided herein, as long as
the seller is willing or able to replace this product or is willing to refund the
purchase price as provided above. For insurance purposes, seller is not allowed
to demonstrate any of these power tools for you.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free at: 1-866-349-8665 (M-F 8am –6pm)
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
Distributed by: Menard, Inc., Eau Claire, WI 54703
Table of contents
Popular Impact Driver manuals by other brands

Hilti
Hilti SIW 8-22 Original operating instructions

Chicago Pneumatic
Chicago Pneumatic CP7748 Series Operator's manual

King Canada
King Canada 8311 instruction manual

Hitachi
Hitachi WH 14DM Technical data and service manual

Villager
Villager VLN 3420 Original instruction manual

Nordic
Nordic POBA2100 operating manual
