1. INTRODUCTION TO CropVIEW®
The CropVIEW® system is composed of three parts:
1. The main unit; including:
• Cameras and optics (wide/narrow angle)
• Processor, modem, USB port
• SIM card holder,
• UMTS/GPS antenna,
• Holder with pitch angle selector (0°,11°,22°,33, 44°)
• Eyehole pointer
2. Control Unit, which commands the main unit; including:
• Power supply
• Sensor set
3. The FieldClimate platform; including:
• Pictures hosting
• Image processing
• Diseases modeling, weather forecast
• Coming new value adding services
Picture 1: CropVIEW®

CropVIEW®extended user manual 4
CropVIEW® is to be used in all areas covered at least by UMTS (3G) networks. It is equipped with a solar panel
and a battery for all year-round standalone functioning. After installing the unit and setting the recording
interval, CropVIEW® is already fully operational.
Important:
CropVIEW® eld device needs 3G (UMTS) coverage, and will not be operational under 2G (GPRS) services.
Several versions of CropVIEW® are available with dierent levels of output oer. Please contact us for further
information at [email protected].
The CropVIEW® camera uses a set of lenses that should be focused manually. They are delivered already fo-
cused for 2.5m to the objective picture. For a dierent distance, onsite manual focus is essential.
2. SIM CARD
A SIM card from a 3G cellular service provider is needed. To insert or remove a SIM card:
1. Slide the metal part to the right to unlock the holder
2. Open the holder from the left side and insert or remove the SIM card
3. Close the holder
4. Lock the holder by sliding the metal to the left (you should hear a click).
Picture 2: SIM Card holder
2.1 HOW TO DEACTIVATE (DISABLE) PIN REQUEST
This can be done using:
• a GSM handset device or
• directly with the USB <=> PC connection
Attention:
Please always check that the PIN request for the SIM is disabled.

CropVIEW®extended user manual 5
2.2 USING UNUSUAL SIM CARDS
We have prepared an extanded table of Internet connection settings for various cellular service providers
worldwide, which is present in the device memory (we are adding new providers all the time). You can check
if your provider is in the table with sending email to: [email protected].
It might happen that your iMETOS is one of the rst devices set up with a specic provider. In this case, you
will need to set these parameters with your PC via USB port or sending SMS with correct settings to the sta-
tion.
To set new APN settings send a special SMS to the station, with APN settings, its username and its password.
Before sending the SMS insert SIM card into your device. The SMS with APN settings has the following form:
Picture 3: APN
2.3 SIM CARD: PREPAID OR CONTRACT
Prepaid SIM cards may be used temporarily or for service purposes. A contract SIM card will always be more
cost eective.
Every picture has 10±2MB depending in the complexity of the image, so the data plan in your SIM should be
calculated by the following formula:
Monthy data plan= 12(MB per picture) *number of cameras * shootings per day * 30(days per month)
Example:
CropVIEW® with 2 cameras 2 shootings per day will need minimum monthly data plan:
12MB * 2 cameras* 2 shoots per day *31 days per month = 1.5GB/month

CropVIEW®extended user manual 6
3. FOCUSING THE CAMERAS
The quality of the images captured by the camera depends critically on the precision when focusing the lens.
The focus process must be performed in the eld.
To focus the pictures, use the application PI CropVIEW® Focus and follow the process described in coming pages.
Important note:
Correct onsite focusing of the camera is essential for the quality of the pictures and for the current (and fu-
ture) added services provided upon them.
3.1 INSTALLING PI CropVIEW®FOCUS APPLICATION
• Download the installer from our website: Firmware and program download
• Extract the les to a folder
• Open the folder containing the extracted les and select CV_PhotoViewer_Installer.msi le and double click on it
• Installation window will open; click on Next and select appropriate Installation Folder or leave default value
• Conrm installation
• Find the application on the Desktop or in Start > Programs > Pessl Instruments > PI CropVIEW® Focus test
and run it
• Run the application
The application will open in a window with 3 tabs which will be explained on the following page
• Conguration
• Focus
• Image
Picture 4: Focus APP

CropVIEW®extended user manual 7
3.2 CropVIEW®FOCUS APPLICATION: CONFIGURATION TAB
This tab has 5 sections:
• Image selection
• Brightness squares
• Delay between photos
• Camera selection
• Serial com port
3.2.1 IMAGE SELECTION
To speed up the process of focusing, here you can select the resolution and part of the image to use during
the focusing process.
Resolution with 3 options:
• low resolution (3Mpix)
• with medium resolution picture (6Mpix)
• full resolution (12Mpix)
Picture 5: Focus app: images selection
Note:
The resolution selected here does not aect the resolution of the nal pictures. It is only intended to reduce
the data trac between USB and PC until the nal ne focus.
Cameras are delivered focused for an object at 2.5 m, but in most cases the object distance will be much
higher, so you will need to start rotating the lens of the camera counter clockwise.
Tip:
Save time in the focusing process by starting with low resolution for the gross focusing, then repeat the pro-
cess with medium resolution picture to rene it and at last nish with a full resolution to check the result and
to do the nal adjustments.

CropVIEW®extended user manual 8
3.2.2 PART OF THE PICTURE
Speed up the process by using the zoom options which allow you to use a partial frame (1/8) with the com-
plete resolution, you can choose between 5 dierent parts as shown in the image below.
Picture 6: Focus app: Select part of the picture
Tip:
It is recommended to start with the “Zoom Center”
Picture 7: Focus app: part of the picture – Zoom center

CropVIEW®extended user manual 9
3.2.3 BRIGHTNESS SQUARES
Use this feature to select the areas to be used by the auto exposure algorithm to get the right brightness of
the overall picture. Doing so, you can optimize the contrast for the area of interest in pictures with dierences
in illumination. Any of the red squares can be enabled or disabled for the nal exposure.
Picture 8: Brightness squares
3.2.4 OTHER SETTINGS IN CONFIGURATION TAB
Delay between photos:
Use this to insert a time delay of up to 9 seconds between every image USB transmission to the PC.
Camera:
Select the camera to focus: Wide angle or narrow angle camera.
Serial COM Port:
To select the COM port, to which the CropVIEW® device is connected to the PC via USB.
3.3 CropVIEW®FOCUS APPLICATION: FOCUS TAB
To assist you during the focusing, in this mode PI CropVIEW® Focus lters the edges of the image and con-
verts the total amount of edges into a gure that we call “detail level”.
An image with a higher number of edges
is sharper or more focused. Actual detail
level is an indicator of the focus accuracy.
The higher the value, the more focused
the image.
Picture 9: Focus tab

CropVIEW®extended user manual 10
Actual detail level: Displays the detail level of the most recent image.
Last detail level: Displays the detail level of the previously received image, indicates whether you are turning
the camera lens in the right direction.
Best detail level: Displays the highest of all detail levels measured in the process
Reset Detail: Resets the detail level elds.
B/W: Option to display the image in Black & White or in colour.
Connect to Camera: Starts the USB communication between PC and the camera.
Start: Starts the image capturing process.
Stop: Stops the image capturing process.
Status: Here you can see the actual action that the system is performing.
3.4 CropVIEW®FOCUS APPLICATION: IMAGE TAB
Check the actual image without processing.
Tip:
In the next page, you will use “detail level” gure, you will rotate the lens between two consecutive pictures
and keep rotating in the same direction if the “detail level increases”. If the “detail level” decreases change the
direction of rotation (see next page).
3.5 FOCUS PROCESS
3.5.1 CONNECT THE CropVIEW®TO THE PC
1. Unplug control unit from CropVIEW®unit
Picture 10: Connect to PC

CropVIEW®extended user manual 11
2. Connect CropVIEW® unit to your PC with USB cable to mini-USB
Use the mini USB port in the lower left corner of the board.
3. Place the jumper in position J1. If you have access to the internet, USB drivers will be installed automatically.
Attention:
The CropVIEW® device has two mini-USB ports. Use the one labeled as “MAIN-USB” (the other one is only for
service purposes).
USB driver
The PC should recognize automatically the CropVIEW® device once you connect it via the USB and it will install
the needed driver itself with no further intervention. In case of problems or in the case that your rst installa-
tion is oine you can previously download and install the driver from the following link: www.st.com
3.5.2 FOCUSING PROCESS USING THE FOCUS APPLICATION
3.5.2.1 CONNECTING TO THE CAMERA
After selecting the correct port for the CropVIEW®, the image size and location required for your installation,
you should go to the focus window and click on the button “Connect to Camera”. The status should change
from Waiting to CropVIEW®Ready. At this point the camera is ready to start the image transmission.
3.5.2.2 START THE IMAGE TRANSFER
In the Focus tab click on the Start button and the Status will change to Conguring Camera. During this phase
the camera will take a series of images in order to adjust the exposure time with the current light conditions.
After setting the camera parameters, the status will change to Getting a new Photo and nally to Next Photo.
At this point you will see the image on the screen.
Recommendation:
When you are outdoor: check the box labeled B/W (i.e. black and white) to see the image better.
Focusing the camera:
Picture: Focusing the camera

CropVIEW®extended user manual 12
Foucsing the camera- black&white mode:
Picture: Focusing the camera in BW mode
3.5.2.3 FOCUSING
To focus the camera, you should start turning the lenses in one direction, wait one or two images and check
the Actual Detail Level to determine if the value of this gure is increasing (the higher the better), continue
turning in the same direction until it starts to decrease; at this point, change rotation direction slowly looking
for the maximum value of the detail level. Below is a sequence of images of a common focus process:
Picture: Focus process

CropVIEW®extended user manual 13
TIP:
Rotate the lens slowly, focus is very sensitive to small rotations. Remember the direction of your last rotation.
Finalized focus:
Picture: Finalized focus
In order to be sure that the camera is well focused you should use the image tab to verify what the image
looks like:
Picture 15: Image check
3.5.2.4 CHANGING THE CAMERA TO FOCUS THE SECOND CAMERA
If your CropVIEW® has a second camera, procced to focus it. Procced as follows:
• In the Focus window click on Stop
• Wait until the status change to CropVIEW® Ready
• In the Conguration windowselect the camera you want to focus then repeat the process described in the
previous section
3.5.2.5 ENDING THE FOCUS PROCESS
After you are satised with the photos, click on the “Stop” button and disconnect the USB cable.
Attention:
Do not forget to remove the jumper from J1!

CropVIEW®extended user manual 14
4. PREPARATION OF YOUR CropVIEW®UNIT BE-
FORE FIELD INSTALLATION
In order to check the proper operation of the system before going to the eld for installation it is highly rec-
ommended to perform the procedure following on next pages.
Basic requirements:
• PC with terminal application installed
• Type A USB to Mini USB cable
• Jumper
Note:
You can use the terminal program of your choice. Or you can use our specic terminal program which you
can nd at: www.metos.at or contact our support team at [email protected].
4.1 CHECK THE COMMUNICATION
4.1.1 FINAL TEST BEFORE FIELD INSTALLATION
This is recommended to be done in an indoor environment (e.g. your oce).
To correctly connect your CropVIEW® unit to your PC please follow instructions on page Connect the
CropVIEW® to the PC.
Open a terminal window on your computer and select the right serial port associated with the camera in your
system.
Place the jumper in position J1 and you will see the following text in terminal window:
============
USER: \ MAIN MENU
============
(1) SYSTEM
(2) CONTROL UNIT
(3) MODEM
(4) FLASH
(5) CAMERA
Select SYSTEM (press nr. 1 on your keyboard), and in the next menu select QUICK VIEW (again nr. 1). Now you
will see station info and its serial number (0700xxxx), where the 07 indicates that it is a CropVIEW® product.
Press ESC button on your keyboard several times, to return to the main menu. Then Insert the SIM card in the
SIM card holder and x it (you must hear a click when you lock it).
In terminal window select MODEM (3), then select SEND DATA (3) and nally remove the jumper from posi-
tion J1 (in order to set up the spy mode). Now you will see in the terminal window the log information of the
communication process.

CropVIEW®extended user manual 15
You should not see any error messages. In case of errors please check if the SIM card is unlock ed and make
sure that the 3G data service is available (in log of communication process should be indicated that it’s con-
nected through UMTS):
bearer_type=’UMTS’
mcc_current=’232′
mnc_current=’10’
mcc_sim=’232′
mnc_sim=’10’
sim_id=’8943102101104029497′
apn_country=’Austria’
apn=’drei.at’
user=’drei’
passw=”
roaming=’0′
/>
4.1.1 FINAL TEST BEFORE FIELD INSTALLATION
To do a nal test, do the following:
• Unplug the battery and the solar panel from the control unit
• Unplug the USB cable from CropVIEW®unit
• Connect the cable from control unit to the CropVIEW® unit – make sure it is connected in the right way – as
shown on the picture below
Picture: Correct connection

CropVIEW®extended user manual 16
Picture: Unscrew four screws on the control unit box and open it. Once open connect the solar panel cable to the
SOLAR CHARGER connector on the control unit board (marked with red square on the picture). Connect the red
cable to + and black cable to -. After successfully connecting the solar panel, close the control unit box and screw the
four screws.
• Connect the battery to the control unit
• Connect the solar panel to the control unit
• After approximately one or one and a half hour you should see the photos on the web site (it depends on
the quality of the internet connection)
• Unplug the battery and solar panel for transport or storage
• Your CropVIEW® device is ready for eld installation
5. FIELD INSTALLATION OF YOUR CropVIEW®DEVICE
5.1 CAMERA LOCATION
Look for the scene that you want to take pictures of. Identify the best location for the camera – take into
consideration the sun position. We recommend the use of a sun position application for your mobile phone
(Sun Surveyor or something similar), in order to be sure that your CropVIEW® unit will not be facing sun light
directly at the time that photos should be taken.
Tip:
If you install camera inside the rows (for example in an orchard or vineyard) it is very likely that lenses on
camera will get dirty when you spray your plants and the picture quality will decrease. In order to avoid this
problem put some kind of a protection over your CropVIEW® device, when spraying.
5.2 FOCUS THE CAMERAS
Unplug the control unit from the camera and connect the USB cable and the Jumper to position J1 and follow
instructions on how to focus your camera on page Focusing the camera.

CropVIEW®extended user manual 17
Focus both cameras to get the best results based on the actual scene. You can also focus the cameras in your
oce, if you know the exact distance on the eld – from your CropVIEW® unit to the object of interest.
Tip:
Focusing the cameras in the eld: it is recommended to do it in the morning or evening, when the sunlight is
low. Otherwise your laptop screen will be hardly visible.
5.3 CHECK THE FULL FRAME IMAGES USING THE FOCUS APPLICATION
To be sure that the camera captures the image that you want, use the Full resolution option in the Congu-
ration Window and check the result in the Image Window (for more information about how to use the Focus
application see the page Focusing the camera).
5.3.1 FINAL SETUP OF THE SYSTEM
To avoid any initialization problems, please perform the following steps in the given order:
• Unplug the solar panel from the control unit.
• Unplug the battery from control unit.
• Unplug the USB cable.
• Remove the jumper from position J1.
• Connect the cable from control unit to CropVIEW® unit.
• Connect the battery to control unit.
Now you should see the red LED in the control unit turning o and approximately 2 seconds later, you should
see the three LEDs in the CropVIEW® unit turning on and o. At this point we are sure that the system is run-
ning. If the LEDs aren’t turning on, repeat the process.
• Connect the solar panel to the control unit.
• Final check of all connections, LEDs and cables.
• Close the housing.
Note: When the season is over, remove the device from the eld, disconnect the solar panel and the battery
to avoid discharge and store it indoors until the next season.
6. ACCESSING THE PICTURES AND SERVICES FROM
FieldClimate
6.1 USE YOUR CropVIEW®
FieldClimate is the web service you are intended to use your CropVIEW® with. It allows you to see photos
taken by the two cameras. It provides interfaces for picture downloads and it provides a powerful decision
support system for plant protection and irrigation.

CropVIEW®extended user manual 18
6.2 REGISTER YOURSELF AS A USER ON FieldClimate.com
To use the services on FieldClimate.com it is necessary to register as a user rst. Click the plus (+) button to
add a new user.
The registration screen which comes up, asks you for a username and a password and it needs your email
address as well as your postal address and some information about the company. Please note you will have
to enter the real email address. An acknowledge email is send to your inbox and its containing link that has to
be used to activate the newly created user account on FieldClimate.com.
Picture: Register yourself
6.3 ADD THE CropVIEW®TO YOUR ACCOUNT
After you have activated your account you can enter thedocs.metos.at/FieldClimate. To add your CropVIEW®
device, open user menu and then press the “Add/Remove station” button.
Picture: Add/remove station

CropVIEW®extended user manual 19
It will ask you for a Station ID number and a station key. Now the little silver colored sticker which came
with your CropVIEW® has to be used. This sticker contains two keys. Key 1 gives the power to change all the
settings on the CropVIEW® whereas key 2 is only valid to use the data of the system. To be able to set up
the CropVIEW® enter the key 1 here. If you entered the correct key, your station list will be enlarged by this
CropVIEW® and it can be selected.
Picture: Add station
6.4 THE CropVIEW®PAGE
To access the CropVIEW® page, click on the eye icon on the left side of the bar.
Picture: Access CropVIEW®
After clicking on the eye icon a new page with full-scale picture will open. When hovering over this picture
with your mouse, you can use the mouse wheel to zoom in and out.
Below the full-scale picture, you can nd a date selection option and a selection between the two cameras –
wide angle lens and zoom lens. With this you can choose which picture to show in full-scale.

CropVIEW®extended user manual 20
Picture: Camera selection
6.5 SETTINGS FOR YOUR CropVIEW®
Settings menu for your CropVIEW® can be reached from the station settings menu, under conguration.
6.5.1 TIME ZONE AND LOCATION SETTINGS
Be aware that precise location and time-zone settings are essential for proper functioning of weather forecast
and other services.
If your device has a built-in GPS, location and time zone will be acquired automatically. You can also dene
location and time zone manually.
Manually entering the station location:
• You can drag the marker on the map to your location
• You can enter location (by address) into „location search“ box and then click „GO!“ Button
• You can enter coordinates of device location to Longitude, Latitude, Elevation boxes (you can acquire coor-
dinates with help of your mobile phone, if it has built-in gps)
Manually entering the station time zone:
• Select the correct time zone from a drop-down list
When you nish with conguration, do not forget to save new settings that you made (click on „save location“
button)!
6.5.2 TRANSFER SETTINGS
Setup how your CropVIEW® station is sending data.
In Scheduler please select the hours at which you wish your CropVIEW® station to take a picture and send it to
the server.
