Petoneer FSW020 User manual

Model: FSW020
Fresco Smart Fountain Ultra
User Manual
（Please read this manual carefully before using.
Keep the manual in a safe place for future reference.）
www.petoneer.com

Inside the box
Filter
Fountain
5V 2A Power
Supply
Micro USB
Cable 4 Feet
(1.2M)
Meet your Fresco Ultra
Replacement
Foam
Replacement
Pump Filter
Sticker
How sterilization works：The UVC ultraviolet light emitted by the tube at the bottom of the fountain can destroy the
DNA structure of microorganisms such as bacteria, causing the bacteria to die. It works for 3 minutes every interval.
The lighting lasts for 3 minutes every interval killing up to 99.7% bacteria.
Lid
Reservoir
Filter
Filter Tray
Bucket
Main Body
TDS Probes
Germicidal
UV Tube
Pump Helmet
Silicone
Tube
Pump
Silicon Mat
Pump's Screen
Sticker
Wi-Fi LED
Indicator
Reset Hole
LED Status
Panel
Foam

1. Assemble
3. Fill up
Operations
5. Accessories replacing
Please put all parts in the right places according
to the illustration;
Pour water into the bucket. Do not exceed the
max water level.
2. Power on
4. Clean up
Connect the Micro USB cable to the power input
port at the bottom, then connect A/C adapter to
the wall outlet.
Lift the bucket and clean the inside of the bucket.
Quick Setup
It is recommended to replace the filter, foam and
pump's screen sticker regularly.
6. Connect the fountain
Download the Petoneer App and connect the
fountain to your Wi-Fi to monitor and control.
Power on and ensure the Wi-Fi Indicator LED is blinking fast reflecting the device is ready for
joining the Wi-Fi.
Open the Petoneer App and click the '+' button and get walked through the SET-UP steps.
2.
Scan the QR code on the right and download
the Petoneer App which is available on App Store
and Google Play. Click Sign up to get walked
through to create your Petoneer account.
1.

Notice：
(1) The fountain doesn't support the 5GHz Wi-Fi, please make sure your Wi-Fi is 2.4G.
(2) If the Wi-Fi indicator is not blinking fast after power-on, please long press and hold the manual
feed button until the indicator blinks quickly.
Precautions
1. Please use it in the indoor environment;
2. When cleaning the bucket, do not directly wash the bottom of the bucket or soak it in the water; when
cleaning the whole machine, DO DISCONNECT the power supply;
3. Children must use the unit under the guidance of an adult;
4. Please place the unit on the flat ground to prevent accidental overturning, causing the fountain to sprinkle
or not work correctly.
5. Please shield or organize the power cord well to prevent the pet from biting the cable and causing
dangerous situations such as electric shock;
6. This feeder is suitable for cats or small and medium-size dogs;
7. TDS(Total dissolved solids): The content of dissolved solids in water. The lower the TDS value, the higher
the purity of the water. TDS is used as an indicator to determine the general quality of the water. The water
quality criteria and standards vary a lot depending on different countries and regions. Please refer to the
local standards.
8. As UVC ultraviolet light can't penetrate plastic or clothing, and the visible light source that is exposed by UV
tube does not inflict harm.
9. After long time usage, the yellowing insider the fountain is normal!
Blue
Red
LED Status
Water Level
Filter Change Alert
LED Status Model: FSW020 Size: 8.19*7.80*7.13 Inches
Weight: 43.03 oz(1220 g) (208x198x181mm)
Power Input: DC 5V 2A Capacity: 2L
Communication: Wi-Fi Range: 98.5 feet (30m)
Sterilization Rate: 99.7% UVC Tube Life: 15000 Hours
Specification

FCC NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: The Grantee is not responsible for any changes or modifications not expressly approved
by the party responsible for compliance. Such modifications could void the user's authority to
operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment offand on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.

Read all the instructions
When using electrical appliances, basic safety precautions should always be followed, including
the following:
1. Do not touch hot surfaces. Use handles.
2. To protect against electric shock do not immerse cord, plug into water or other liquid.
3. Close supervision is necessary when any appliance is used by or near children.
4. Unplug from outlet when not in use and before cleaning. Allow cooling before putting on or
taking offparts, and before cleaning the appliance.
5. Do not operate any appliance with a damaged cord or plug, should the appliance malfunction,
or if it has been damaged in any manner. Return appliance to the nearest authorized service
facility for examination, repair or adjustment.
6. The use of the accessory attachments is not recommended by the appliance manufacturer as
it may cause injuries.
Environmental Conditions
Operating Temperature: 14 °F to 131 °F, (-10 ºC to 55 ºC) (indoor only)
SkyRC Technology Co., Ltd. declares that this Fresco(FSL010) / Fresco Pro(FSW010) / Fresco
Ultra(FSW020), is in compliance with the essential requirements and other relevant provisions of the
Radio Equipment Directive (2014/53/EU).
Environment friendly disposal
You can help protect the environment!
Please remember to respect your local regulations: dispose of nonfunctional electrical equipment with
an appropriate waste disposal center.

7. Do not use outdoors.
8. Do not let the cord hang over the edge of table or counter, or touch hot surfaces.
9. Do not place on or near a hot gas or electric burner, or in a heated oven.
10. Always attach the plug to appliance first, then plug the cord in the wall outlet.
11. Do not use the appliance for other than intended use.
12. WARNING: Never leave the appliance unattended whilst in use.
13. Warning: keep the supply cord away from the heating tip and metal enclosure while using.
14. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge unless they have
been given supervision or instructions concerning the use of the appliance by a person
responsible for their safety.
15. Children should be supervised to ensure that they do not play with the appliance.
16. If the SUPPLY CORD is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
17. WARNING: This tool must be placed on its stand when not in use.
SAVE THESE INSTRUCTIONS.
For the purposes of supply by Adapter, only use the detachable supply unit provided with this
appliance:
Manufacturer: SHENZHENKEYUPOWERSUPPLYTECHNOLOGYCOLTD
Model: KA1503-0502000UKU
Input: 100-240V, 50/60Hz,0.35A;
Output: 5VDC, 2A

Manufacturer: SkyRC Technology Co., Ltd.
4, 5, 8 Floor, Building 4, Meitai Science Park, Guanguang Road, Guanlan,
Longhua District, Shenzhen, China.
Within the period of warranty, if the product fails with no fault of user operations, it will be repaired
at Petoneer's expense. The warranty will not cover product failure in examples below:
2). Failure to operate or maintain the product following the (QIG) Quick Installation Guide
Instructions.
3). Failure by natural wear and tear including but not limited to scratching, corrosion, oxidation
and rusting.
4). Failure by non-authorized repair of the product including but not limited to user's own or
third-party repairing attempts or modifications.
* All Pictures shown in the manual are for illustration purpose only. Actual product may vary due
FCC ID: 2AFNL-TYWE3S
201-171044
R
CCAP19LP1970T4
Warranty Terms
