Phiaton BT 150 NC User manual

BT 150 NC
OWNER'S GUIDE

2
1. SAFETY AND GENERAL INFORMATION
2. COMPONENTS & FEATURES
3. RETRACTABLE WIRE EARPHONES
4. CHARGING
5. BLUETOOTH POWER ON/OFF AND EARPHONE CONNECTION WAITING MODE
6. PAIRING WITH A ‘BLUETOOTH DEVICE’
7. MULTIPOINT CONNECTION
8. USING NOISE CANCELLING FEATURE
9. MONITOR FEATURE
10. LISTENING TO MUSIC (PLAY & CONTROL)
11. USING THE CALL FUNCTION
12. CHANGING SOUND MODE
13. OUT OF COMMUNICATION RANGE
14. MISCELLANEOUS FEATURES
15. CONNECTING AND USING THE AUDIO CABLE
16. SPECIFICATIONS
17. PRODUCT SYMPTOMS AND TROUBLESHOOTING
18. FCC COMPLIANCE INFORMATION
19. CE COMPLIANCE INFORMATION
- Please follow the directions, and read the guidelines carefully before use.
Please keep the owner’s guide for future reference.
- Some functions of the BT 150 NC may not be available when it is paired
with certain devices.
- The speci󽗉cations are subject to change without prior notice for quality
improvement.
WIRELESS EARPHONES with ACTIVE NOISE CANCELLING and
TOUCH INTERFACE
Thank you for purchasing PHIATON BT 150 NC.
Contents

3
1. SAFETY AND GENERAL INFORMATION
1) Use a standard USB charging cable (included), with or without a charging adapter.
(5V, over 500mA) * Adapter Not Included
2) Lower the volume prior to listening to audio to prevent potential damage to eardrums
caused by sudden loud sound.
3) Listening to loud music for extended periods of time may cause hearing damage.
4) Do not store the device in places with a temperature higher than 113 ℉/ 45 ℃.
5) This device is IPX4 sweat and water resistant. Please note that it is not water proof. Please
use caution to not oversaturate with moisture or leave excessive moisture on the device
as this can damage the internal components. (For more information, refer to the contact
us page within our website –phiaton.com.)
6) Do not attempt to disassemble, modify or repair the device.
7) Do not cause shock to the device.
8) Keep out of the reach of children and pets.
9) Do not tug on cords or touch power plugs with wet hands.
10) Do not use the device nearby microwave ovens or wireless LAN adapters.
11) When the product is not being used, set the device power switch to ‘OFF’ and the NC power
switch to ‘OFF’.
12) When cleaning the device, use a clean dry cloth to wipe the device clean.
(Do not use solvents.)
13) Remove the ear tips from the earphones, wash them with warm water, dry completely
and check for any debris before reattaching.
14) Replacement ear tips can be purchased from Phiaton Customer Service.
15) Use while driving or walking will prevent outside noise, such as signals or alarms, from
being heard and may be dangerous to yourself and others. Heed caution during use.
16) The radio waves of this device may a󽗈ect electronic medical devices. If you use any
electronic medical device, consult your doctor or the medical device company before
you use it.
※ Use the BT 150 NC only for its intended purposes.
※ This device cannot be used for purposes related to human safety as it may cause radio interference during operation.

4
2. COMPONENTS & FEATURES
1) COMPONENTS
- BT 150 NC
- USB Charging Cable
- Audio Cable (1.0 m, micro USB Plug to 3.5 mm Plug)
- 4 Sizes of Silicon Ear Tips (S, M, L, XL)
- Quick Guide
- Warranty Card
2) FEATURES
Earphones
Bluetooth Power ON/OFF
& Call Button
Noise Cancelling
ON/OFF Switch
Neckband Body
Play/Pause Button
Neckband Housing for earphones
Touch Interface
[Vol+, Vol-]
Touch Interface
[<<, >>]
LED Indicator
USB Cover

5
4. CHARGING
The device may not be charged upon purchase and must 󽗉rst be charged before use.
1) Open the USB cover on BT 150 NC and connect the provided USB charging cable.
2) Connect the provided USB charging cable with a computer (laptop) or you may also use a separately
purchased USB adapter (rating: 5V/over 500mA) to begin charging.
1) The earphones are connected to the neckband with
a retractable wire. To use, gently pull the earphones
from the neckband to a comfortable corded length
to place in your ears.
2) There are stop latches in the reel so when you reach
the desired length for a comfortable 󽗉t, simply allow
the wire to stop at one of the stop latches. You can
either further extend or retract with another slight
pull of the earphone.
3) When you are 󽗉nished listening, remove the
earphones from your ears.
4) Then simply retract the earphones back into the neck-
band housing by gently pulling the earphones slightly
out to engage the retractable wire, until it is wound
completely back into the neckband.
Operation LED Indicator
Charging Red light
Charging complete Blue light
3. RETRACTABLE WIRE EARPHONES
USB Charging Cable
※ Use with care as there is risk of damage to the retractable wire if you pull with too much force or extend too far from the
neckband body.
※ When pulling the retractable wire earphone for storage into the neckband housing, pulling too far will cause the wire to
latch again and not be wound.
- This device has a built-in battery, so it will begin charging
automatically when you connect the charging cable.

6
6. PAIRING WITH A ‘BLUETOOTH DEVICE’
1) Pairing
- Turn on the Bluetooth feature with the ‘Bluetooth
Device’ you want to connect with the BT 150 NC.
- Place the BT 150 NC within 3 feet of the ‘Bluetooth
Device’ you want to connect.
- Press and hold the PLAY Button for over 2.5 seconds
with the BT 150 NC power on to enter Pairing Mode.
3 feet
Status Operation LED Indicator Vibration Noti󽗉cation
ON Press and hold the CALL/
POWER button for 2 seconds
Purple light turns
on for 1 second Vibrates once for 0.3 second
OFF Press and hold the CALL/
POWER button for 2.5 seconds
Red light blinks
5 times Vibrates twice for 0.3 second
※ Pairing mode will start once the power is turned on for the 󽗉rst time after purchase.
※ When the BT 150 NC is not in use, ensure the NC function is switched OFF. If left in the ON position, this will cause the battery
to run out.
Status LED Indicator
Connection Waiting Mode Blue light blinks twice in 6 second intervals
2) Connection Waiting Mode
- When power is turned on, ‘Connection Waiting Mode’ will start if ‘Pairing Mode’ cannot be entered or
the earphones cannot connect with ‘Bluetooth Device’.
- If the ‘Bluetooth Device’ is not connected within 5 minutes in ‘Connection Waiting Mode’, the earphones
will automatically turn o󽗈.
5. BLUETOOTH POWER ON/OFF AND EARPHONE CONNECTION WAITING MODE
1) Bluetooth Power ON/OFF
- Press and hold the [CALL/POWER] Button for 2 seconds to turn the
power on.
- When turning the power o󽗈, press and hold the [CALL/POWER]
Button for 2.5 seconds to turn o󽗈.
(While on an incoming call, you cannot power o󽗈 the device.)
- When turning power on/o󽗈, there is a vibration noti󽗉cation that rings.
Bluetooth Power ON/OFF Button
ON: 2 Seconds
OFF: 2.5 Seconds
Left Side (while wearing BT 150 NC)

7
3) Checkpoints Upon Pairing
- Check to see whether the Bluetooth feature is activated within the ‘Bluetooth Device’ you want to connect.
- When selecting the connection device, connect by selecting stereo headset device. Music cannot be
played when connected through mono headset.
※ In order to properly use the Bluetooth feature of this device, the pro󽗉le (A2DP, HSP, HFP and AVRCP) of the ‘Bluetooth
Device’ you are trying to connect must support the pro󽗉le of this device.
* A2DP–“Advanced Audio Distribution Pro󽗉le”, HSP–“Headset Pro󽗉le”, HFP–“Hands Free Pro󽗉le”. AVRCP–“Audio/Video
Remote Control Pro󽗉le”
※ The device will not operate properly if the pro󽗉les are not supported equally. Even when the pro󽗉les are supported equally,
some features may not properly operate depending on the ‘Bluetooth Device’ speci󽗉cations.
To check the detail speci󽗉cations of this earphone’s pro󽗉le, refer to ‘16. SPECIFICATIONS’.
For more information, please visit phiaton.com or contact Phiaton customer service.
Status LED Indicator Voice Guidance
Pairing
Mode
Blue and Red light
alternately blinks
Pairing Mode
activated
Operation LED Indicator Voice Guidance
Connection success After Purple light blinks twice,
blue light blinks once in 6 second intervals. Device connected
- Within the ‘Bluetooth Device’ you want to connect,
search/select ‘BT 150 NC’.
※ If the ‘Bluetooth Device’ requires a PIN CODE or password,
enter ‘0000’. Bouton de lecture pendant 2,5 secondes.
- Use the earphones to play music or connect a call.
2) Re-connecting a Disconnected Device
① Auto Connection
- Once the device has been paired with a ‘Bluetooth Device’, it will automatically be connected to a
previously connected device once the BT 150 NC power is turned on.
- If Bluetooth becomes disconnected as the discover range between the ‘Bluetooth Device’ and the
BT 150 NC is exceeded, then Bluetooth will not be automatically re-connected.
When you are back within the discover range (33 feet), you must then connect manually.
② Manual Connection
- When having entered ‘Connection Waiting Mode’ during connection.
- Press the CALL/POWER Button or the PLAY Button on the earphone to connect.
- The BT 150 NC will also be connected if you select ‘BT 150 NC’ from the device search list within your
‘Bluetooth Device’.
BT 150 NC
Play/Pause Button
for 2.5 Seconds
Search “BT 150 NC”

8
2
11
2
1
2
※ Sleep Mode will be entered when devices are not connected within two minutes. When trying to connect a device
while in Sleep Mode, pressing any button will re-enter ‘Connection Waiting Mode’ where connection is possible.
※ When the BT 150 NC power is turned o󽗈 and back on, only the second paired device will automatically be connected.
When the 󽗉rst paired device is reconnected, then both of the devices will remain connected.
※ Upon Multipoint Connection, the features operated within BT 150 NC usually operate within the second paired device.
(When using the 󽗉rst paired device, it is possible to operate the device from BT 150 NC.)
※ When using Multipoint Connection, the order of the paired devices may change. To change the order, re-connect the device
you usually use.
1) What is ‘Multipoint Connection’?
- This is a feature where BT 150 NC’s user can simultaneously connect two Bluetooth devices.
2) Multipoint Connecting
- Turn on the Bluetooth feature within the two ‘Bluetooth Devices’ you want to connect with BT 150 NC.
- Refer to ‘6. PAIRING WITH A ‘BLUETOOTH DEVICE’ to pair the 󽗉rst device with the BT 150 NC.
- Press and hold the PLAY Button again for 2.5 seconds to enter ‘Pairing Mode’.
(Here, the 󽗉rst device becomes disconnected.)
- Once ‘Pairing Mode’ has been entered, pair the second device.
- Within the 󽗉rst ‘Bluetooth Device’ you want to connect, select ‘BT 150 NC’ again.
- Now, both of the ‘Bluetooth Devices’ will be connected simultaneously, and now the ‘BT 150
NC’ will control the secondly paired device.
7. MULTIPOINT CONNECTION

9
9. MONITOR FEATURE
1) The monitor feature allows you to mute your music and noise cancelling
temporarily, so you can hear the surrounding sounds without removing
the ear buds.
2) Press the PLAY/PAUSE Button for about 1 second when you want to
hear the sounds around you. (When the Noise Cancelling feature is
ON and or you are listening to music.)
3) Monitor is continued for 30 seconds unless you press any key to
stop the monitor feature quicker.
1) What is ‘Noise Cancelling’?
Noise Cancelling refers to a technology that reduces noise from mid/
low pitched sounds under 1 kHz.
2) Turning Noise Cancelling Feature ON/OFF
- Sliding the NC Button towards ON direction will turn Noise Cancelling
ON and sliding the Button towards OFF will discontinue Noise Cancelling.
(NC function will stop when either L or R earphone is stored.)
3) Noise Cancelling Function Auto ON/OFF (When Using Noise Cancelling Feature)
- If the earphone is retracted back in the neckband, while the NC switch is
still ‘ON”, the Noise Cancelling feature will automatically disable to save
the battery life.
- If you pull the earphones back out from the neckband housing, and the
NC switch is still ‘ON,’ the Noise Cancelling function will resume.
4) Cautions upon using Noise Cancelling Feature
- Noise Cancelling cannot be used when the battery is completely drained.
- Use while driving or walking will prevent outside noise, such as signals
or alarms, from being heard and may be dangerous to yourself and
others. Heed caution during use.
- Noise Cancelling is optimized for mechanical noises from airplanes,
buses, and subway trains and is not required for use within quiet interior
environments.
- Always switch the NC button to “OFF” when the Noise Cancelling feature
is not needed to save the battery life.
8. USING NOISE CANCELLING FEATURE
Noise Cancelling ‘ON’
Monitor ‘ON’:
1 second
Right Side (while wearing BT 150 NC)

10
1) Playing Music
- Shortly press the PLAY/PAUSE Button once to play music from the
‘Bluetooth Device’.
- While music is playing, shortly press the PLAY/PAUSE Button to pause
the playing music. The music will be played from the paused point
when playing music again.
10. LISTENING TO MUSIC (PLAY & CONTROL)
* SBC (Sub Band Codec) is default audio codec installed for any ‘Bluetooth Device’.
* ‘Qualcomm® aptX™ audio’ is high quality audio codec supported by Qualcomm® CSR.
Status LED Indicator
While music is playing
(Connection with ‘Qualcomm® aptX™ audio’) Purple Light slowly blinks every 6 seconds
While music is playing
(Connection with SBC) Blue Light slowly blinks every 6 seconds
2) Controlling Volume and Using Seek
- Both sides of the neckband feature a touch panel to control the volume and music tracks.
- Sweep the touch panel to control the volume of the Left side (while wearing BT 150 NC) to top (+) /
bottom (-) to control the volume.
- Sweep the touch panel of the Right side (while wearing BT 150 NC) to go to the previous / next song.
(You will hear the ‘beep’ signal when operating the touch panel.)
* When listening to music on the BT 150 NC via Bluetooth, you can also control your music and calls directly
from your ‘Bluetooth Device’.
* When the battery is completely drained, you can connect the provided audio cable to hard wire to your device
and continue listening. (The buttons and touch panel will not function when using the optional audio cable so
you will have to use your ‘Bluetooth Device’ for music and call control.)
2) Controlling Volume and Using Seek
- Sweep the touch panel of the left side (while wearing BT 150 NC) to top (+) / bottom (-) to control the
volume.
- Sweep the touch panel of the Right side (while wearing BT 150 NC) to top ( ) / bottom ( ) to go to the
previous / next song. (You can hear the ‘beep’ signal during operating the touch panel)
* Music can be listened to through BT 150 NC by directly operating your ‘Bluetooth Device’.
* When the battery is completely drained, you can connect the provided microphone cable to continue listening.
Right Side (while wearing BT 150 NC) Left Side (while wearing BT 150 NC)
Right Side (while wearing BT 150 NC)
(1 Second)
: Play / Pause
: Monitor
: Press : Brief Hold : Press & Hold
: Pairing
(2.5 Seconds)
