Philips BDP7700 User manual

BDP7700
Register your product and get support at
www.philips.com/welcome
Manual pengguna 49
คู่มือผู้ใช้ 73
User manual 9
Ԛʹ˫ 31
BDP7700_98_UM_V1.0.indb 1 2012-2-28 14:52:07

2
1 Hookup and play
EN Before you connect this Blu-ray disc/ DVD player, read and understand all accompanying
instructions.
ZH-HK Εઅმϊ%OXUD\GLVF'9'ᅌיዀɾکwᇼቇᚾʥעֺτޚᗐܞʵy
060< Sebelum anda menyambungkan cakera Blu-ray/ pemain DVD ini, baca dan fahamkan arahan
yang disertakan.
TH กอนจะเชื่อมตอแผนดิสก Blu-ray /เครื่องเลน DVD อานและทําความเขาใจคําแนะนําทั้งหมดที่แนบมา
BDP7700_98_UM_V1.0.indb 2 2012-2-28 14:52:08

3
Register your product and get support at
www.philips.com/welcome
EN User manual
BDP7700
( )
HDMI VIDEO
VIDE
O
COAXIAL OPTICAL
5.1CH
7.1CH
2CH
1
BDP7700_98_UM_V1.0.indb 3 2012-2-28 14:52:09

4
2
1 HDMI
2 VIDEO+2CH
BDP7700_98_UM_V1.0.indb 4 2012-2-28 14:52:14

5
5.1 CH
5.1CH
7.1 CH
HUR UN
5.1CH
OPTICAL
HDMI
COAXIAL
BDP7700_98_UM_V1.0.indb 5 2012-2-28 14:52:19

6
4
3
5
SOURCE
1
2
TV
BDP7700_98_UM_V1.0.indb 6 2012-2-28 14:52:20

7
6
USB
DVD/VCD/CD
BD/BD 3D
DivX Plus HD/MKV
MP3 / JPEG
2
3
4
1
1
2
3
BDP7700_98_UM_V1.0.indb 7 2012-2-28 14:52:23

9
English
EN
Contents
1 Hookup and play 2-7
2 Use your Blu-ray disc/ DVD player 10
Basic play control 10
Video, audio and picture options 11
DivX videos 12
 
Synchronize audio with video 12
Play a musical slideshow 13
BonusView on Blu-ray 13
BD-Live on Blu-ray 13
Play a Blu-ray 3D video 13
View 2D video/picure in 3D effect 14
Set up a network 14
Smartphone control 15
Browse PC through DLNA 15
Browse Net TV 16
Rent online videos 16
Use a USB keyboard or mouse 17
Use Philips EasyLink 17
Stream media from an Android device 17
3 Change settings 18
Picture 18
Sound 18
Network (installation, Net TV...) 19
Preference (languages, parental
control...) 19
Advanced options (clear memory...) 20
4 Update software 21
Update software via the Internet 21
Update software via USB 21
  22
6 Troubleshooting 23
7 Safety and important notice 25
BDP7700_98_UM_V1.0.indb 9 2012-2-28 14:52:23

10 EN
2 Use your Blu-
ray disc/ DVD
player
Congratulations on your purchase, and

the support that Philips offers (e.g. product
software upgrade), register your product at
www.philips.com/welcome.
Basic play control
During play, press the following buttons to
control.
Button Action
Turn on the player, or switch to
standby.
Access the home menu.
/ Stop play.
Press and hold (more than 4
seconds) to open or close the
disc compartment.
Pause play.
Press repeatedly to slow forward
frame by frame.
Start or resume play.
/ Skip to the previous or next track,

/ Fast backward or forward.
Press repeatedly to change the
search speed.
Press once, and then press
to slow forward.
AUDIO Select an audio language or
channel.
SUBTITLE Select a subtitle language.
DISC
MENU /
POP-UP
MENU
Access or exit the disc menu.
TOP
MENU
Access the main menu of a video
disc.
Color
buttons
Select tasks or options for Blu-ray
discs.
Navigate the menus.
Press to rotate a picture
clockwise or counter-clockwise
during slideshow.
OK 
Return to a previous display menu.
Access more options during play.
BDP7700_98_UM_V1.0.indb 10 2012-2-28 14:52:27

11
English
EN
Video, audio and picture
options
More options are available for video or picture
play from a disc or USB storage device.
Video options
Access more options during video play.
 [Audio language]: Select an audio language.
 [Subtitle Language]: Select a subtitle
language.
 [Subtitle shift]: Change the subtitle
position on the screen. Press to
change the subtitle position.
 [Info]: Display play information.
 [Character set]: Select a character set that
supports the DivX video subtitle (only for
DivX videos).
 [Time search]
via the numeric buttons on the remote
control.
 [2nd audio language]: Select the second
audio language (only for Blu-ray discs that
support BonusView).
 [2nd Subtitle Language]: Select the second
subtitle language (only for Blu-ray discs that
support BonusView).
 [Titles]: Select a title.
 [Chapters]: Select a chapter.
 [Angle list]: Select a camera angle.
 [Menus]: Display a disc menu.
 [PIP selection]: Display a picture-in-picture
window (only for Blu-ray discs that support
BonusView).
1
2
3
 [Zoom]: Zoom into a video picture. Press
to select a zoom factor.
 [Repeat]: Repeat a chapter or title.
 [Repeat A-B]: Mark two points within a
chapter for repeat play, or turn off repeat
mode.
 [2D to 3D]: Convert instantly a 2D video
to be viewed in 3D effect.
 [Picture settings]: Select the most
optimum picture setting (powered by
CinemaPerfect HD).
 [Audio sync]: Synchronize audio with
video (HDMI connection between this
player and your TV is needed).
Note
 Available video options depend on the video source.
Picture options
Access more options during slideshow.
 [Rotate +90]: Rotate a picture 90 degrees
clockwise.
 [Rotate -90]: Rotate a picture 90 degrees
counter-clockwise.
 [Zoom]: Zoom into a picture. Press to
select a zoom factor.
 [Info]: Display picture information.
 [Duration per slide]: Set a display interval
for a slideshow.
 [Slide animation]: Select a transition effect
for a slideshow.
1
2
3
BDP7700_98_UM_V1.0.indb 11 2012-2-28 14:52:28

12 EN
 [Picture settings]: Select the most
optimum picture setting (powered by
CinemaPerfect HD).
 [Repeat]: Repeat a selected folder.
 [2D to 3D]: Convert instantly a 2D picture
to be viewed in 3D effect.
Audio options
Press repeatedly to cycle through the
following options.
 Repeat the current track.
 Repeat all the tracks on the disc or folder.
 Play audio tracks in a random loop.
 Turn off a repeat mode.
DivX videos
You can play DivX videos from a disc, a USB
storage device, or an online video store (see
"Rent online videos).
VOD code for DivX
 Before you purchase DivX videos and play
them on this player, register this player on
www.divx.com using the DivX VOD code.
 Display the DivXVOD code: press
, and select [Setup] > [Advanced] >
[DivX®VOD Code].
DivX subtitles
 Press SUBTITLE to select a language.
 If the subtitle is not displayed correctly,
change the character set that supports the
DivX subtitle. Select a character set: press
, and select [Character set].
Character set Languages
[Standard] English, Albanian,
Danish, Dutch,
Finnish, French, Gaelic,
German, Italian, Kurdish
(Latin), Norwegian,
Portuguese, Spanish,
Swedish and Turkish
[Chinese] 
[Chinese-Traditional] Traditional Chinese
[Korean] English and Korean
Note
 
device, or an online video store, connect this player to a
TV through HDMI.
 



 
formats: .srt, .sub, .txt, .ssa, and .smi.


USB storage device.
An Real Media Variable Bitrate (RMVB) and


your computer onto a recordable disc or USB
storage device. And play them from this player.
Note
 
".RM".
Synchronize audio with video
You can adjust the audio delay time when video
is out of sync with audio.
BDP7700_98_UM_V1.0.indb 12 2012-2-28 14:52:29

13
English
EN
1 Make sure that this player is connected to
yourTV through HDMI.
2 During play, press .
» The options menu is displayed.
3 Select [Audio sync].
4 Press to select a value until audio is in
sync with video.
Play a musical slideshow
Play music and pictures simultaneously to create
a musical slideshow.
1 From a disc or connected USB storage

2 Press , and go to the picture folder.
3 Select a picture from the same disc or
USB, and press OK to start slideshow.
4 Press to stop slideshow.
5 Press again to stop music play.
BonusView on Blu-ray
View special content (such as commentaries) in
a small screen window.
This feature is only applicable to Blu-ray discs
compatible with BonusView (also known as
picture in picture).
1 During play, press .
» The options menu is displayed.
2 Select [PIP selection] > [PIP], and press
OK.
» PIP options [1]/[2] depend on the
video contents.
» The secondary video window is
displayed.
3 Select [2nd audio language] or [2nd
Subtitle Language], and press OK.
BD-Live on Blu-ray
Access exclusive online services, such as movie
trailers, games, ringtones, and other bonus
contents.
This feature is only applicable to Blu-ray discs
that are BD-Live enabled.
1 Prepare the Internet connection and set
up a network (see "Set up a network").
2 Connect a USB storage device or SD card
to this player.
 A USB storage device or SD card is
used to store the downloaded BD-Live
content.
3 Select a USB storage device or SD card
to store: press , and select [Setup] >
[Advanced] > [Local storage].
 To delete the BD-Live previously
downloaded on the USB storage
device or SD card for memory
release, press , and select [Setup] >
[Advanced] > [Clear memory].
4 Play a disc that is BD-Live enabled.
5 On the disc menu, select the BD-Live icon,
and press OK.
» BD-Live starts to load.The loading
time depends on the disc and the
Internet connection.
6 On the BD-Live interface, select an item
to access.
Note
 BD-Live services vary from discs and countries.
 When you use BD-Live, data on the disc and this player
are accessed by the content provider
 Use a USB storage device or SD card with at least 1GB
of free space to store the download.
Play a Blu-ray 3D video
What you need
 A 3D compliant TV
BDP7700_98_UM_V1.0.indb 13 2012-2-28 14:52:29

14 EN
 This player is connected to the TV through
HDMI
 3D glasses compatible with theTV
1 Make sure that 3D output is turned on:
press , and select [Setup] > [Video]
>[Watch 3D video] > [Auto].
2 Play a Blu-ray 3D video.
3 Put on the 3D glasses for 3D effects.
 To play 3D video in 2D, turn off Blu-ray
3D output (press , and select [Setup]
> [Video] > [Watch 3D video] >
[Off]).
View 2D video/picure in 3D
effect
You can convert 2D videos or pictures to be
viewed in 3D effect.
What you need
 A 3D compliant TV
 This player is connected to the TV through
HDMI
 3D glasses compatible with theTV
1 Play 2D video or pictures on this player.
2 Press .
» The options menu is displayed.
3 Select [2D to 3D] > [On].
» 2D video or pictures are converted to
3D effect.
4 Put on the 3D glasses for 3D effects.
Set up a network
Connect this player to a computer network and
the Internet to access the services:
 Browse PC (DLNA): play photos, music,

computer.
 Browse Net TV: access online services,
such as pictures, music and video stores.
 Update software: update the software of
this player via the Internet.
 BD-Live: access online bonus features
(applicable to Blu-ray discs that are BD-
Live enabled).
1 Connect this player to a computer
network and the Internet, through wired
(Ethernet) or wireless connection.
 For wired connection, connect a
network cable (not supplied) to the
LAN port on the back panel of this
player.
 This player has a built-in Wi-Fi for a
wireless connection.
2 Perform the network installation.
PC (DLNA)
PC (DLNA)
BDP7700_98_UM_V1.0.indb 14 2012-2-28 14:52:35

15
English
EN
1) Press .
2) Select [Setup], and press OK.
3) Select [Network] > [Network
installation], and press OK.
4) Follow the instructions on the TV screen to
complete the installation.
Caution
 Before you connect to a network, familiarize yourself
with the network router, media server software for
DLNA, and networking principles. If necessary, read
documentation accompanying network components.
Philips is not responsible for lost, damaged, or corrupt
data.
Smartphone control
Use a smartphone to browse, control and play

What you need
 An iPhone (iOS 3.1.3 and above) or
Android based device (Android 2.1 and
above)
 On your smartphone, download Philips
MyRemote application
 For iPhone, search for the application
in App Store
 For Android based device, search for
the application in Android Market
Before you start
 Connect this player to a home network
(see "Set up a network").
 Connect your smartphone to the same
home network (see the user manual of the
smartphone for details).
 Turn on this player
Control your player
Use a smartphone to browse, control and play

1 Insert a data disc or USB storage device
into this player.
2 On your smartphone, tap the MyRemote
icon from the home screen.
» The name of this player is displayed on
the smartphone.
3 Select this player from the smartphone
screen.
» The smartphone used as a virtual
remote control is enabled.
4 On the smartphone, tap the Media
(Media) tab, and then select the disc or
USB source.
» The folders in the data disc or USB
storage device are displayed.
5 
 To access the remote control, return
to the previous smartphone screen,
and then tap the Remote (Remote)
tab. Only the relevant control buttons
are enabled.
6 Tap the control buttons on the
smartphone to control play.
 To access more control buttons, swipe
the screen to the left or right.
 To exit the application, press the home
button on the smartphone.
Browse PC through DLNA
Through this player, you can stream and play
video, music and photo from a computer on
your TV.
Before you start
 On your PC, install a DLNA-compliant
media server application (such as Windows
Media Player 11 or higher)
 
sharing (see the "Help" document in the
media server application)
1 Connect this player and your PC in the
same home network (see "Set up a
network").
BDP7700_98_UM_V1.0.indb 15 2012-2-28 14:52:36

16 EN
 For better video quality, use wired
network connection whenever
possible.
2 Press .
» The home menu is displayed on the
TV screen.
3 Select [browse PC], and press OK.
» A content browser is displayed.
4 OK to play.
 Use the remote control to control play.
Browse Net TV
You can access variety of Internet applications
and specially adapted Internet websites.
Note
 Koninklijke Philips Electronics N.V. bears no
responsibility for content provided by Net TV service
providers.
1 Connect this player to the Internet (see
"Set up a network").
2 Press .
» The home menu is displayed on the
TV screen.
3 Select [browse Net TV], and press OK.
4 Follow the onscreen instructions to

5 Use the remote control to navigate and
select an Internet application.
Button Action
Navigate and select an a
service or item.
OK 
Return to a previous page, or
delete input text.
Access options related to a
current activity.
Alphanumeric
buttons
Input text (such as an email
address, web URL and
password).
TOP MENU Return to the NetTV home
screen.
To remove the passwords and cookies from
this player, see the section: Change settings >
Network (installation, Net TV...).
Rent online videos
Rent videos from online stores through this
player.
What you need
 A high-speed Internet connection to this
player.
 An HDMI connection between this player
and the TV.
 An SD memory card of type SDHC Class
6, with at least 8 GB memory.
Note
 Use a blank SD card. Formatting a SD card erases any
content on the SD card.
 This service is country dependent.
1 Connect this player to the Internet (see
"Set up a network").
2 Insert a blank SD card into the SD CARD
connector located on the rear panel of this
player.
3 Press .
4 Select [browse Net TV]> Video stores.
5 Select a video store, and follow the
onscreen instructions to rent and watch a
video.
» The video is downloaded to the SD
card.You can watch it now or at any
time within the rental period.
» For the downloaded video on the SD
card, you can watch it only on this
player.
BDP7700_98_UM_V1.0.indb 16 2012-2-28 14:52:36

17
English
EN
6 Use the remote control to play and
control the video.
Use a USB keyboard or
mouse
For convenience of Internet usage, you can
connect a USB keyboard and/or mouse to type
text and navigate pages on the Internet.
1 Connect a USB keyboard or mouse to the
USB connector at the rear panel of this
player.
 If you connect more peripheral USB
devices, connect a USB hub to this
player to make multiple USB ports
available.
 You also can connect a wireless USB
keyboard or mouse (see the user
manual of the wireless device for
details).
2 Use the keyboard to type text, or the
mouse to navigate web pages.
 To change a language for the keyboard,
press , and select [Setup] >
[Preference] > [Keyboard layout].
Note
 If a USB hub is used with this player, do not overload
the USB hub with many USB devices to avoid

Use Philips EasyLink
This player supports Philips EasyLink which
uses the HDMI CEC (Consumer Electronics
Control) protocol.You can use a single remote
control to control EasyLink compliant devices
that are connected through HDMI. Philips does
not guarantee 100% interoperability with all
HDMI CEC devices.
1 Connect the HDMI CEC compliant devices
through HDMI, and turn on the HDMI
CEC operations on theTV and other
connected devices (see the user manual of
the TV or other devices for details).
2 Press .
3 Select [Setup]> [EasyLink].
4 Select [On] under the options: [EasyLink],
[One Touch Play] and [One Touch
Standby].
» EasyLink function is turned on.
One Touch Play
When you play a disc on this player, the TV
automatically switches to the correct video
input source.
One Touch Standby
When a connected device (for example TV)
is put to standby with its own remote control,
this player is put to standby automatically.
Stream media from an
Android device
With Philips SimplyShare, through this player

based device on your TV. For details, visit www.
philips.com/support
BDP7700_98_UM_V1.0.indb 17 2012-2-28 14:52:36

18 EN
3 Change settings
This section helps you change the settings of
this player.
Note
 You cannot change a menu option that is grayed out.
 To return to the previous menu, press .To exit the
menu, press .
1 Press .
2 Select [Setup] > [Video] to access the
video setup options.
 [TV display]: Select a picture display

 [HDMI video]: Select an HDMI video
resolution.
 [HDMI Deep Color]: Display colors
with more shades and hues when the
video content is recorded in Deep
Color and the TV supports this feature.
 [Picture settings]: Select the most
optimum picture setting (powered by
CinemaPerfect HD).
1
2
3
 [User]: Select a personalized picture
setting.This option is activated only
when [User] under [Picture settings]
is selected.
 [Watch 3D video]: Set to 3D or 2D
output when playing a Blu-ray 3D disc.
The player must be connected to a 3D
TV through HDMI.
Note
 If you change a setting, make sure that the TV supports
the new setting.
 For settings related to HDMI, theTV must be
connected through HDMI.
 For the composite connection (via the VIDEO
connector), select a video resolution of 480i/576i
or 480p/576p under [HDMI video] to enable video
output.
Sound
1 Press .
2 Select [Setup] > [Audio] to access the
audio setup options.
 [Night mode]: Select quiet or full
dynamic sound. Night mode decreases
the volume of loud sound and
increases the volume of soft sound
(such as speech).
 [Neo 6]: Enable or disable a surround
sound effect which is converted from
2.0 channel audio.
 [HDMI Audio]: Set an HDMI audio
format when this player is connected
through HDMI.
 [Digital Audio]: Select an audio format
for the sound output when this
player is connected through a digital
connector (COAXIAL or OPTICAL).
 [PCM Downsampling]: Set the
sampling rate for PCM audio output
when this player is connected through
a digital connector (COAXIAL or
OPTICAL).
BDP7700_98_UM_V1.0.indb 18 2012-2-28 14:52:37

19
English
EN
 [Channels]: Select 7.1 channel sound,
or 2 channel / 5.1 channel sound
according to multichannel connection.
 [Speaker setup]: Set the volume level
and distance of each speaker to obtain
the best possible surround sound.
Note
 For settings related to HDMI, theTV must be
connected through HDMI.
 Night mode is only available for Dolby encoded DVD
and Blu-ray discs.
Network (installation, Net
TV...)
1 Press .
2 Select [Setup] > [Network] to access the
network setup options.
 [Network installation]: Start a wired
or wireless installation to make the
network work.
 [View network settings]: Display the
current network status.
 [View wireless settings]: Display the
current Wi-Fi status.
 [Clear Net TV Memory]: Clear the
history of Net TV browser (such as
cookies).
 [Name your Product:]: Re-name this

network.
Preference (languages,
parental control...)
1 Press .
2 Select [Setup] > [Preference] to access
the preference setup options.
 [Menu language]: Select an onscreen
display menu language.
 [Keyboard layout]: Select a language
for a connected keyboard.
 [Audio]: Select an audio language for
video.
 [Subtitle]: Select a subtitle language for
video.
 [Disc menu]: Select a menu language
for a video disc.
 [Parental control]: Restrict access to
discs that are encoded with ratings.
Input "0000" to access the restriction
options.To play all discs irrespective of
the rating, select level "8".
 [Screen saver]: Enable or disable
screen saver mode. If enabled, the
screen enters idle mode after 10
minutes of inactivity (for example, in
pause or stop mode).
 [Auto subtitle shift]: Enable or disable
subtitle shift. If enabled, the subtitle

the TV screen (this feature works with
some Philips TVs only).
 [Change password]: Set or change
a password to play a restricted disc.
Input "0000" if you do not have a
password or if you have forgotten your
password.
 [Display panel]: Change the brightness
of the display panel of the player.
 [Auto standby]: Enable or disable
auto standby. If enabled, the player
switches to standby after 30 minutes
of inactivity (for example, in pause or
stop mode).
 [Fast wake up]: Enable or disable the
player to wake up faster from standby.
If fast wakeup is turned off, less power
is consumed during standby.
 [VCD PBC]: Display or skip the
content menu forVCD and SVCD.
BDP7700_98_UM_V1.0.indb 19 2012-2-28 14:52:38

20 EN
Note
 If your preferred language is not available for disc
language, audio or subtitle, you can select [Others]
from the menu options and input 4-digit language code
which can be found at the back of this user manual.
 If you select a language which is not available on a disc,
this player uses the default language of the disc.
Advanced options (clear
memory...)
1 Press .
2 Select [Setup] > [Advanced] to access the
advanced setup options.
 [BD-Live security]: Restrict or allow
access to BD-Live (only for non-
commercial, user-created BD-Live
discs).
 [Downmix mode]: Control 2-channel
stereo audio output.
 [Software update]: Select to update
software from a network or from USB
storage device.
 [Clear memory]: Delete the previous
BD-Live download on the USB storage
device or SD card. A "BUDA" folder is
automatically created to store the BD-
Live download.
 [Local storage]: Select a USB storage
device or SD card to store the

 [DivX®VOD Code]: Display the
DivX®registration code or the
deregistration code for this player.
 [Version information]: Display the
software version of this player.
 [Restore default settings]: Reset this
player to the default settings made at
the factory, except for password and
parental control level.
Note
 You cannot restrict Internet access on commercial
Blu-ray discs.
 Before you purchase DivX videos and play them on this
player, register this player on www.divx.com with the
DivX VOD code.
BDP7700_98_UM_V1.0.indb 20 2012-2-28 14:52:38

21
English
EN
4 Update software
Before you update the software of this player,
check the current software version:
 Press , and then select [Setup] >
[Advanced] > [Version information], and
press OK.
Update software via the
Internet
1 Connect the player to the Internet (see
"Set up a network").
2 Press , and select [Setup].
3 Select [Advanced] > [Software update]>
[Network].
» If an upgrade media is detected, you
are prompted to start the update.
4 Follow the instructions on the TV screen
to update the software.
» When the update is complete, this
player automatically turns off and on
again.
Update software via USB
1 Check the latest software version on www.
philips.com/support.
 Search for your model and click on
"Software and drivers".
2 Download the software into a USB storage
device.
a Unzip the download, and make sure
that the unzipped folder is named
"UPG_ALL".
b Put the "UPG_ALL" folder in the root
directory.
3 Connect the USB storage device to the
(USB) connector on this player.
4 Press , and select [Setup].
5 Select [Advanced] > [Software update]>
[USB].
» If an upgrade media is detected, you
are prompted to start the update.
6 Follow the instructions on the TV screen
to update the software.
» When the update is complete, this
player automatically turns off and on
again.
Caution
 Do not turn off the power or remove the USB storage
device when the software update is in progress because
you might damage this player.
BDP7700_98_UM_V1.0.indb 21 2012-2-28 14:52:38
