Philips CD304 MK II User manual

Compact disc player CD304 MK Il/coryesr
Service
Service
Service
35493 A12,
For servicing hints for the CD mechanism see
Service Manual C.D.M.-1.
ervice Manual
DIGITAL AUDIO
CONTENTS
1. Elucidation on the lay-out and table of contents per
page.
. Control buttons and technical specification.
. Servicing hints.
. Measurements and adjustments.
. Exploded views and parts lists of mechanical parts.
. Block diagram, circuit diagrams, data on PCBs, parts
lists of electrical parts and wiring diagram.
. Faultfinding method.
Remote control.
Onh WP
On
CLASS 1
Safety regulations require that the set be restored to its original 3127 10 aa
condition and that parts which are identical with those specified be
used.
Documentation Technique Service Dokumentation Documentazione di Servizio Huolte-Ohje Manual de Servicio Manual de Servicio
Subject to modification PH | LI PS Published bysesrvice
4822 725 21058 Consumer Elictronics ,
Printed in The Netherlands
© Copyright reserved CS 5 188 GB

UGE
1. ELUCIDATION ON THE LAYOUT OF THE DOCU-
MENTATION
The documentation consists of chapters.
The number ofthe chapter is indicated by the first digit of
the page number.
The second digit of the page number is the sequence
numbering.
If modifications or supplements require new supple-
mentary or replacement pages, the page number is
extended with a third part:
A digit behind the page number indicates that it concerns
a supplementary page.
A replacement page is indicated by a letter behind the
page number.
CS 5 189 6B
1-1
Example
3-6 is page 6 of chapter 3
3-6-1 is a supplementary page behind page 3-6
3-6-a is the replacement page of page 3-6 (so page 3-6
can be removed from the documentation).
All pages are provided with a date of issue.

TABLE OF CONTENTS PER PAGE
Chapter Page Contents Chapter
1 1-1 Elucidation on the lay-out of the 6
documentation
1-2 Table of contents per page
2-1 Control buttons
2-2 Technical specification
3-1 Servicing hints
3-2 List of service aids
Initiating the service loops
Demounting the top cover
Demounting the bottom plate
Replacing glass fuse 1451
Replacing the transformer fuse
Servicing the front
Demounting the control
and display PCB
Demounting the headphone
amplifier PCB
3-3 Servicing the supply PCB
Servicing the servo and decoder
PCB
Servicing the IR receiver
3-4 Servicing the tray mechanism
4-1 Mechanical measurements
and adjustments to be
performed on the CDM
Mechanical adjustments of the
tray mechanism
4-2 Specification measurement
Changing the transformer
connections
Laser power supply 7
(POS. VOLT. SH.)
Checking and adjusting
Adjusting the focus bandwidth
Check of the AGC and offset
circuits
5 5-1 Parts list
Exploded view tray
5-2 Exploded view cabinet
Parts list
6 6-1 Block diagram
6-2 Circuit diagram of the
power supply 8
6-3 Power supply PCBs
Parts list
Mains filter circuit
6-4 Circuit diagram of the
control and
display circuit
6-5 Control and display
PCBs
Parts list
6-6 Circuit diagram servo
Circuit (part 1)
Page
6-7
6-9
6-10
6-14
6-12
6-13
6-16
6-17
6-18
WP PPT NO ODM
ONNNNN ~o14 i wood
p-o
se i)
Contents ~
Servo PCB
Parts list
Servo PCB
Parts list
Circuit diagram servo
Circuit (part 2)
Circuit diagram
Decoding circuit (part 1)
Decoding PCB
Parts list
Decoding PCB
Parts list
Circuit diagram
Decoding circuit
(part 2)
Circuit diagram
Tray control PCB
Parts list
Circuit diagram of
headphone amplifier
Headphone amplifier PCB
Parts list
Circuit diagram of the
IR receiver
PCB drawing of the IR
receiver
Wiring diagram for
CD304/60R/65R
List of standard symbols
List of chip components
Faultfinding method
Faultfinding method
Faultfinding method
Faultfinding method
Faultfinding method
Faultfinding method
* Faultfinding method
Faultfinding method
Faultfinding method
Faultfinding method
Faultfinding method
Faultfinding method
Exploded view of the
remote control
Parts list
Circuit diagram of the
remote control
PCB drawings of the
remote control
CS 5 199.GB

DIGITAL AUDIO
2. CONTROLS
22
OMAN Oak WN =
— «a —_— ©
ON/OFF
OPEN/CLOSE
TIME
TRACK
SCAN
SELECT down
SELECT up
STORE
CANCEL
Headphone socket
Headphone level potentiometer
SK1
SK15
SK12
SK5
SK13
SK6
SK14
SK7
SK11
BU1
3751
2 3456789 11 10 12 13 1415
12
13
14
15
16
17
18
19
20
21
22
21 20
PREVIOUS
NEXT
REPEAT
PAUSE
SEARCH REVERSE
SEARCH FORWARD
START/REPLAY
STOP/Clear Memory
DIGITAL OUTPUT
FTD DISPLAY
INPUT IR REMOTE CONTROL
SK4
SK10
SK18
SK9
SK19
SK8
SK17
SK16
BU3
1051
6851
2-1
18
19
16
17
CS 5 191GB

-2
ECHNICAL SPECIFICATION
System
Mains voltages
Mains
frequencies
Power
consumption
Frequency range
‘Output voltage
‘Output
impedance
‘S/N ratio
: Compact Disc Digital
Audio System
:110 V, 127 V, 220 V, 240 V
+ 10% (to be changed
by changing the
transformer connections)
: 50 Hz, 60 Hz (no conver-
sion required)
:< 25W
:2 Hz + 20 kHz + 0.05 dB
: O-max. 2 Vrms
: 200 Q
: = 96 dB
® Headphone
~ output voltage
— output
impedance
e Channel
separation
® Channel
difference
© Overall harmonic
distortion
@ Intermodulation-
distortion
© De-emphasis
e Dimensions
(wxhxd)
© Weight
The above specifications apply within a frequency range of 20 Hz + 20 kHz
CS § 192 GB
: 0-max. 5.6 Vrms
>= 15002
: = 93 dB
:< 0.6 dB
> <= 0.003%
: <= 0.003%
: 50 ps or 15 ps (switched
by the subcode on the disc)
: 420x92x300 mm
(tray closed)
: 420x92x450 mm
(tray opened)
> approx. 7 kg

DIGITAL AUDIO
3. SERVICING HINTS
In order to prevent loose metal objects from getting in
the CD mechanism it will be necessary to see to a
clear repair station.
Before the player is being used or serviced, the
transportation screws should be removed.
These screws have to be reapplied after servicing.
The objective can be cleaned with a blow brush.
For servicing hints for the CD mechanism refer to
Service Manual CDM-0 and CDN-1.
Do not loosen any screws other than those mentioned
in the hints.
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are connected
with the same potential as the mass of the set via a
wrist wrap with resistance.
Keep components and tools also at this potential.
GENERAL
CHIP
COMPONENT
SOLDER SOLDER
COPPER TRACK
Sic PCB
GLUE
SOLDERING
fe}
SOLDERING
IRON
SERVICE PACKAGE
DISMOUNTING
VACUUM PISTON
SOLDERING 4822 395 10082
IRON ™~ Xi
e.g WELLER
SOLDER TIP PT-H7
SOLDERING
IRON
SOLDER WICK
4822 321 40042
e.g. A PAIR OF TWEEZERS
HEATING
x
SOLDERING IRON
SOLDER WICK =
CHIP
COMPONENT
Fig. 2
PRECAUTIONS
3-1
The disc should always bed down well on the
turntable.
For this purpose a disc hold-down has been mounted
in a bracket of the drawer mechanism.
When the drawer mechanism has to be demounted for
repair, a loose hold-down should be employed.
The set can then function normally.
Code number of the disc hold-down is 4822 532 60906.
SERVICE AIDS
Service supports
Audio performance test disc
Disc without local defects,
Disc with DO failures, black spots
and finger-prints
4822 395 30202
4822 397 30085
4822 397 30096
Screwdriver set TORX
Set straight 4822 395 50145
Set square 4822 395 50132
Disc hold down 4822 532 60906
7 th order filter 4822 395 30204
IR receiver 4822 212 21449
MOUNTING
e.g. A PAIR OF TWEEZERS
Wy
SOLDER
@0.5 - 0.8 mm
SOLDERING
IRON ;
OR
PRESSURE
+
SOLDER
@0.5 - 0.8mm
SOLDERING TIME
<3 sec/side
B
PRESSURE
/
SOLDERING
t +
IRON
/_ HEATING
“
CLEANING EXAMPLES
27 012C12
CS § 193 GB

3-2
The servo uP can beset to the servicing mode to check the
switch and display PCB and to separately test the servo
systems.
INITIATING SERVICE LOOP A
-—— Put a disc on the turntable.
— Simultaneously depress the CANCEL, PREVIOUS
and STOP keys.
Keep these three keys depressed while switching on
the mains voltage. In this situation the laser and focus
contro! are operative and the turntable motor is
running.
The light pen remains situated under the lead-in
tracks. The radial servo system is switched off.
In this service loop the display can be checked as
follows:
— The display will indicate 01.02, then 02.04, 03.06 and
continue in this way up to 20.40. 20.40 is followed
again by 00.00, 01.02, etc.
The indicators SCAN, PAUSE, REPEAT and DISC
ERROR will light up and will remain switched on.
At indication 01.02, bar 1 of the track bar is also driven
and at 02.04 bar 2, etc.
— If now the CANCEL key is depressed, the TRACK
indication will light up after 2 clock strokes of the
display and the DISC ERROR indication will go off.
The player stays in service loop A.
INITIATING SERVICE LOOP B
The player can be brought from service loop A into service
loop B by depressing the STORE key. Now the radial
servo system has been switched on independently of the
P-bit and the sub-code.
The display makes clear that the set is in service loop B by
means of ABS, REL and TOT.
The player can be brought from service loop B in the
PLAY mode by depressing the START/REPLAY key.
For adjustments that have to be performed on the lower
side for which the unit should be in the position of normal
end use, servicing supports are supplied.
Code number is 4822 395 30202.
These supports can be mounted in the four holes of the
frame.
DEMOUNTING THE TOP COVER
— Remove the 4 screws in the sides.
— Remove the cover from the set by pulling it backwards.
Attention
When mounting the top cover; care should be taken that
the top cover is placed correctly in the guidings of the
front before mounting the four screws.
CS 5 194¢6R
DEMOUNTING THE BOTTOM PLATE
— Remove the 4 screws in the bottom plate.
— Pick up the bottom plate at the rear of the set and pull it
from the 3 fixing bosses at the front of the set.
REPLACING GLASS FUSE 1451
— Remove the top cover.
— The fuse on the mains filter PCB can now be reached
at the left-hand side of the set via a hole in the mains
filter housing.
REPLACING THE TRANSFORMER FUSE
— Remove the bottom plate.
— Remove the plastic cap covering the underside of the
transformer.
— The transformer fuse is now accessible.
— Replace the screening cap once the fuse has been
replaced.
SERVICING THE FRONT
Demounting the front.
— Remove the top cover.
— Remove the 3 fixing screws at the upper side and the3
screws at the lower side of the front.
— The front can now be removed from the set by pulling
it forwards.
— After loosening various connections and connectors,
the front of the set can be removed.
Demounting the control and display PCB
— Remove the 9 screws on the control and display PCB.
— The PCB can now be taken away with the headphone
PCB still in place.
Demounting the headphone PCB
Once the control and display PCB has been taken away,
the headphone PCB can be removed.

SERVICING THE SUPPLY PCB
— Remove the 2 screws B (see Fig. 3a).
— When the connectors have been loosened, the supply
PCB can be taken out of the set from the rear.
Attention
The Audio cable is soldered to the decoder PCB.
When mounting the supply PCB care should be taken that
the PCB falls in the guiding on the frame.
SERVICING THE SERVO PCB AND THE DECODER PCB
(see Fig. 3a)
— Remove the top cover.
— Remove the 2 screws A on the PCB holder.
— When the PCB holder is placed in the service position
(see Fig. 4) measurement can be performed on both
the servo PCB and the decoder PCB.
SERVICING THE IR RECEIVER
For practical reasons, it is best to service the IR receiver
by means of the trial and error method, with which
defects, if any, are traced.
Code number of IR receiver: 4822 212 21449.
After removing the bottom plate, this receiver can be con-
nected via plug 91.
Demounting the IR receiver:
— Remove the top cover.
— Remove the loading mechanism
— When clamping spring 555 has been removed, the
receiver can be demounted.
Before mounting the new receiver, be sure to first adapt it
according to the originally mounted version.
as
SERVO PC.B
==
Qe HEAOPHONE PC.B.
CONTROL AND.
DISPLAY PC.By
CONTROL +DISPLAY PCB.
Fig. 3b 36 SOTAT
36 600 87
Fig. 3a:
3G 59987
Fig. 4
CS 5195GB

3-4
SERVICING THE TRAY MECHANISM
Demounting the tray mechanism
— Remove the top cover.
— Remove the front.
~— Remove the 4 screws C (see Fig. 3a).
— Loosenconnectors 61 and 64 on the tray control PCB.
— The tray mechanism can now be taken out of the set.
— For repairs the tray mechanism can be made operative
outside the set by fixing again connectors 61 and 64
on the drawer control PCB.
— Involtageless condition the drawer can be opened by
moving the drawer forward by means of a non-
scratching sharp device (for example finger nails) that
is placed between front and drawer.
Attention
If, during arepair, the tray mechanism or the tray control
PCB has been demounted, the set will not function.
To avoid this the contacts of the tray in-end switch SK2 on
the tray control PCB should be interconnected.
Replacing the disc hold-down
— See: Exploded View Tray.
— Place the disc hold-down (item 107) in its highest
position (drawer opened as far as possible).
— The disc hold-down can be loosened by bending the 2
lugs on bracket item 508 apart and taking out the disc
hold-down.
CS 5 196 GB
Replacing the tray motor
— See: Exploded View Tray.
— Demount the tray mechanism.
— Remove the belt (item 129) from the motor pulley.
— Remove the 2 screws with item no. 119.
— The motor can now be loosened.
Demounting the drawer (item 127) and lifting piate (item
513) assy
See: Exploded View Tray.
— Demount the tray mechanism.
— Remove motor bracket item 509 by undoing the 3
screws on bracket item 509.
— Remove roller item 108 by loosening the spring ring.
— Slide the tray forward and remove it.

DIGITAL AUDIO
4. MECHANICAL MEASUREMENTS AND ADJUST-
MENTS
MECHANICAL MEASUREMENTS AND ADJUSTMENTS
TO BE PERFORMED ON THE CDM
— Height setting of the turntable
In case of adjustment of the height of the turntable by
means of the set screw on the motor shaft, the voltage
across resistor 3240 on the servo PCB should be set to
0 Volt.
- Checking and adjusting the angle setting
For checking and adjusting the angle setting see the
Service Manual! of C.D.M.
Note
For checking and adjusting the angle setting the drawer
mechanism has to be demounted.
See sub servicing hints.
MECHANICAL ADJUSTMENTS OF THE TRAY
MECHANISM
Adjusting the clearance of the disc (see Fig. 5)
FT-HAND F THE LOADING MECHANISM
Fig. 5 36013A22
The disc may not rub against the black lifting plate (item
513 of the Exploded View Tray).
In case this should happen, the clearance can be adjusted
with adjusting plate G and screw H.
With those the height of axis J of the lifting plate can be
adjusted.
The adjustment should be performed with the drawer in
position ‘CLOSE’.
When screw H is loosened, adjusting plate G can be dis-
placed in so far as this is allowed by the slotted hole of
adjusting plate G.
If you can hear the disc rubbing, the adjusting plate
should be adjusted.
In practice the disc will be adjusted parallel to edge | of the
tray chassis.
4-1
Adjusting the play of the tray (see Fig. 6)
LEFT-HAND SIDE OF THE LOADING MECHANISM
36016 A22
Fig. 6
Spiral spring K ensures that bracket L, with wheel Mon it,
presses against the drawer so that the play of the drawer
becomes minimum.
Optimum adjustment is obtained when the distance
between screw N and the drawer chassis is adjusted for
0.35 mm.
Adjusting the ornamental front of the drawer (see Fig. 7)
TRAY FRONT (top view)
Fig. 7
36012422
The position of the ornamental front of the drawer relative
to the front of the set can be adjusted.
By means of screws O both the height and the position
left-right can be adjusted.
CS 5 197 GB

4-2
ELECTRICAL MEASUREMENTS AND ADJUSTMENTS
Specification measurement
CD PLAYER
S/N AND
DISTORTION
METER
FILTER
eg. SOUND TECHNOLOGY
ST 1700B
Fig. 8
30 459 AI2
To measure the specification use can be made of audio
test disc 4822 397 30085.
Use a 7th order filter, e.g. 4822 395 30204 (see Fig. 8), to
measure:
— Total harmonic distortion (THD).
— Intermodulation distortion.
— Signal-to-noise ratio (S/N).
Changing the transformer connections
TOP VIEW BOTTOM VIEW
FI=S025A/125 °C
Fig. 9
36 114 A7
If the unit has to be connected to a mains voltage devia-
ting from that mentioned on the type plate, the trans-
former connections should be changed as indicated in the
figure.
Attention
In case of adaptation to 110 V or 127 V the glass fuse on
the mains filter PCB must be changed from 200 mA-T to
400 mA-T.
CS 5 198 GB
Laser power supply (POS. VOLT. SH.)
For check and preliminary adjustment of the laser supply
see Service Manual C.D.M.
Adjusting the laser supply
Play track 1 of test disc 4822 397 30096 (disc without
defects).
Connect a DC voltmeter across resistor 3308 on the servo
PCB (= on emitter of transistor 6239 and ground).
Adjust the laser power supply with resistor 3180 until the
voltage across resistor 3308 is 575 + 75 mV.
Adjusting the focus bandwidth
6208(1/2}{B)
MC1458
cor
100n -1
3242 }3243 13245 |2228
Et}
36028 B12
Make a measuring arrangement according to the figure.
Play track 1 of test disc 4822 397 30096 (disc without
defects).
Adjust trimming resistor 3158 on PRE. AMPL. + LASER
PCB for a 180° phase difference between signals A and B.
This corresponds with a minimum distance D in the Lissa-
jous pattern.
R=47kN-1% 5322 116 54671
C=10nF-1% 5322 121 54154
Check of the AGC and offset circuits
(See SERVO PCB)
Play track 1 of test disc 4822 397 30096 (Disc without
defects).
The voltage between pin 1 of 1C6212 and 1 should be
-4Vt2V.
The voltage between pin 14 of 1C6215 and | should be
OVH2V.

gSE
DIGITAL AUDIO
TRAY
101
102
103
104
105
106
107
108
109
110
112
114
115
116
117
Note
4822 492 51628
4822 528 80977
4822 276 11277
4822 492 63071
4822 466 81483
4822 492 32396
4822 528 10511 for
C.D.M.-1
4822 532 11114
4822 535 91709
4822 492 32404
4822 466 60965
4822 492 32395
4822 530 80075
4822 532 51519
4822 522 31777
118
119
120
121
- 122
123
124
126
127
128
129
131
- 4822 402 60909
4822 502 11699
4822 535 91712
4822 532 51521
4822 535 91719
4822 532 51518
4822 535 91711
4822 492 51627
4822 444 40113
4822 528 50177
4822 358 30335 —
4822 361 20483
For mechanical parts of the C.D. mechanism see Service
Manual C.D.M.-1.
101
EXPLODED VIEW TRAY
19mm
5-1
34803D22/B
CS 5 199

5-2
EXPLODED VIEW CABINET
201
202
203
204
206
207
208
209
211
212
213
214
216
217
218
219
221
222
223
224
225
226
227
228
229.
4822 492 63038
4822 444 60457
4822 450 60852
4822 450 25439
4822 410 25439
4822 444 40152
4822 450 60452
4822 492 51643
4822 410 25434
4822 410 25427
4822 410 25429
4822 410 25428
4822 410 25426
4822 410 25438
4822 410 25437
4822 444 60458
4822 276 11309
4822 492 60063
4822 212 21449
4822 256 90635
4822 255 30115
4822 462 71153
4822 410 23674
4822 492 41128
4822 459 80212
=
CS 5 200
231
232
233
234
236
237
238
239
241
242
243
244
246
247
248
249
251
252
253
4822 505 10571
4822 267 30793
5322 492 64624
4822 413 31424
4822 410 25436
4822 410 25432
4822 410 25435
4822 410 25433
4822 410 25431
4822 410 23683
4822 432 92083
4822 146 20904
4822 325 80226
4822 502 11613
4822 255 40181
4822 492 63076
4822 413 41237
4822 462 40409
4822 267 30631
see exploded view tray
#* ONLY FOR CD 304/01
D304
35591E22/B

COMPACT
DIGITAL AUDIO
BLOCK DIAGRAM CD304/60R/65R
PRE-AMP
SERVO 1
LASER
SUPPLY
FNI
Fe SERVO
AMP. 1
SERVO 2
MAINS:
FILTER SUPPLY
“
RE1,RE2
SPLITTER
_
|
FOCUS-
CONTROLLER
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Sal
el
oa
ce
ge
ee
eet
en
L
|
|
|
|
DA1-DA4
EMPHASIS
60B e
AF-L rc
\ZZZZZZAZZIN , 7
6508A 6
SAA7210 SAA7220 TDA 1541
DECODER DIGITAL FILTER
A 8B DUAL DAC oR 6dB :
aw AF-R ca
V2ZZLLIVELI LY ~, 7
DO-HFL
DETECTOR
LOOPFILTER
CURRENT
SOURCE
CHARGE
PUMP
SWAB/SSM
4
RSSQ8S{S0449
TURNTABLE HM
MOTOR
CONTROLLER
TRACK
DETECTOR
1
TURNTABLE
MOTOR
1
SERVO MICRO PROCESSOR +I/O PORT
FCO FM
FC1 FM+
FC2
mDAC
RADIAL
POLARITY
DETECTOR
FOCUS
MOTOR
RE1+RE2
OFFSET
CONTROL
RE1+RE2
NETWORK

6-1 6-1
| DECODER CIRCUIT
pPD41416
SAA7210 SAA7220
DECODER DIGITAL FILTER
A B
LOOPFILTER
CURRENT
SOURCE
CHARGE
PUMP
MUTE
BO MC
He. TRACK Tae TURNTABLE
= CONTROLLER MOTOR
SERVO MICRO PROCESSOR +I/O PORT
RADIAL
POLARITY
DETECTOR
RE RE
RCO
FS. OFFSET
CONTROL
k.d.(RE1+RE2)=<0
RE1+RE2
Xk NETWORK
k RE2=[2
RE2
ee ee ee ee ee ee ee 6 6 1.
1986-08-20
aang
DIGITAL
OUT.
DE-
EMPHASIS
6515
6dB =120B L
LLLLLL ALLL ZL
60B
V2ZZZZZVZIID) >
6507
DE- ——4
KILL
EMPHASIS. [ Tio35
AF S
R
AF S
TDA 1541
DUAL DAC
TRAY
sL2 MOTOR
SK
TRAY-IN
END SWITCH
TRAY-OUT
END SWITCH
|
nn rE saa a ca
mDAC
ae Pa ae eee Oe ee eee en
'
CONTROL+DISPLAY ca |
1 b
| '
: |
e 9
'
LED LED mp |
; DISPLAY DRIVER DISPLAY
= RADIAL
> MOTOR ‘ |
|
sToP { |
'
| '
PRS.01643
107/638
CS 5 201

SUPPLY CIRCUIT :
2451
B8
2454
B3
2457
C8
2462
E6
2465
E 5
2470
D6
2473
C3
2476
D6
6461
B4
6464
E 5
6467
F
5
6472
C5
6475
E
6
2452
B6
2455
B5
2458
C6
2463
F 4
2468
D8
2471
C5
2474
C3
3451
G4
6462
B5
6465
E
4
6469
B7
6473
C4
2453
B5
2456
B3
2461
€E
8
2464
E€
4
2469
D6
2472
C5
2475
D8
6460
B5
6463
B4
6466
F
3
6471
C5
6474
C4
6451
MC78M12CT
3. Tley SERVO PCB 21-4
bs ter DECODER PCB 31-6
SERVO PCB 21-5
DECODER PCB 31-7
CONTROL PCB 51-1
1N4002G
.
SERVO
PCB
21-1
DECODER PCB 31-2
DECODER PCB 31-3
TO SERVO PCB 21-2
TO SERVO PCB 21-3
TO DECODER PCB 31-4
TO DECODER PCB 31-5
SERVO PCB 21-6
oe 12476 oe 3a, 44-1 .-2 TO DECODER PCB 31-8
i 1500p I
6454 6453 J
MC79M12CT MC79M15CT
6465 14002 2 | a | 3 ~36V 6475 2 | 3 ~15V 44-8 1-5 TO DECODER PCB 31-1
oh | 2465 oh| 2462 BAX18 og |2461
80vV7VY
4K
i
py!
ict
i
1
ia
i
n
6456
4N4002
BZX79C24
2463
22n
45-2 | m, TO CONTROL PCB 51-3
S467
-36V
45-3[-6
TO
CONTROL
PCB
51-2
3451 BZD23C7V5
~™ TO CONTROL PCB 51-4
PRS.01605
132-635
CD304
CS 5 202

3M12CT
6467
6469
6471
FS 6472 C5
B7 6473 C4
c 5 6474 C4
SERVO PCB 21-4
DECODER PCB 31-6
SERVO PCB 21-5
DECODER PCB 31-7
CONTROL PCB 51-1
SERVO PCB 21-1
DECODER PCB 31-2
DECODER PCB 31-3
TO SERVO PCB 21-2
TO SERVO PCB 21-3
TO DECODER PCB 31-4
TO DECODER PCB 31-5
SERVO PCB 21-6
DECODER PCB 31-8
DECODER PCB 31-1
™ TO CONTROL PCB 51-3
=6 TO CONTROL PCB 51-2
TO CONTROL PCB 51-4
PRS.01605
T32-635
CD304
6-2

SUPPLY P.C.B. MARKED B
8
:
2
6
5
4
3
2
A
1
ra
ee
ie
ea
a
:
yal
oe
ee
1
|
i ot ieee }4 rt
1
Pe
H
Af
I
‘
1
H
!
B L
TO MAINS TRANSFORMER
point 7
point 7
point 16
point 17
point 18
poift 15
point 12
TO MAINS TRANSFORMER:
points 10,13
points 9,14
points 6,11
points 6,11
point 8
point 8
BPG4 O69
SUPPLY
MC78M12CT
5322
209
86176
245342456
MC79MO6CT
4822
209
82056
247142474
47nF-
50V
=
4822
122
10288
MC79M12CT
4822
209
82065
2463,2464
22
nF-100V
«4822.
122
10289
MC79M15CT
5322
209
86361
2452
1500
uF-
25V
4822.
124
21471
TY40408
MC7805CT
selected4822
209
70425
2469,2470
3300
uF-
16V
-
4822
124
21469
2458
1000
uF-
25V
4822
124
40214
2465,2476
470
uF-
683V
«4822
124
40751
1N4002G
5322
130
30684
:
4N5060
4822
130
31164
Mica
washer
4822
255
40181
HZ24-2
(24Vo)
4822
130
60378
Spring
clip
4822
492
63039
BZD23-C7V5
5322
130
33685
Mains
transformer
4822
146
20904
Transformer fuse 125°C/0.15 A 4822 252 20007
SUPPLY P.C.B.
1
SUPPLY VOLTAGES
Hee + 12V
+124 SV
be IV
-2=- 6
= -18V
c ~6= -36V
TOMAINS TRANSFORMER:
point
points 1013
points 9,14
points 6,11
points 6,11
E point 8
point 8
36213417
36212A17
MARKED B
5 . 6 7 8
41 60 OR
MAINS FILTER
2x25 mH 4822 157 51576
100 nF-250 V
1 nF-400 V
5322 121 44302
4822 122 40368
5322 116 64114
220/240 V version: ;
200 mAT 4822 253 30012
110/127 V version:
400 mAT 4822 253 30016
Fuse holder springs 4822 492 60063
Mains switch SK1 4822 276 11309
CS 5 203

6-4
CONTROL + DISPLAY CIRCUIT
A B c D
TO SUPPLY .
1] PCB 45-2 | 51-3 ‘
~ 2051 = 1 3 § 7 9g
| 22n waf
| ot EVEL GY comes VU
8 1
TO SUPPLY | 2052 = waft ae
PCB 45-1 + oa 22n
~ peace = Crime] ABS REL TOT | TRACK |
5
| 28 [21/12
TO SUPPLY |
PCB 45-3 je.)
)
-26v wT |, lal lolstale tals ae
j 6u8
“1 = oh | 12053 6051
3051 4n? MSL915R
3 fa4e7 |}
SK17 6054 Geese
PLAY BAW 62 al
Sk18
Ski9
3
SK4
a
(=)
S
SK6
SK7
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| SKS}
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
I2D
CS 5 204
TO SERVO PCB 27-2
0
[scan_]
17
RAM
ADRESS
REGISTER
I2c
CONTROL &
TIMING
TO SERVO PCB 27-1
+
=
3054
BZX79
B6V2
6065
52-1
‘TO SUPPLY PCB 45-4
“1 aly +2 2
|
gag [TO SERVO PCB 27-3
C7 ke
|
|
220E
3
Soak Ito SERVO PCB 27-5
6063 +1 aa =
BAW62 2061 |
68u | STOP
oc skis |
aaf |
2062 | t
|
|
on 4 3059 ;: 3056
52-4], TO SERVO PCB 27-4
RESET
|
|
|
sae IR-RECEIVER
(1009) 91-1
+] ve INT/TO
{To IR-RECEIVER
(1009) 91 -
+2a
pons
| TO IR-RECEIVER
009) 31-2
-.
53-2!
i
|
|
|
|
|
|
egeyRan pie ae
40001C 12
