Philips HQ7130 User manual

HQ7130,HQ7120
ENGLISH 4
DANSK 14
DEUTSCH 24
Ελληνικά 35
SUOMI 46
NORSK 56
SVENSKA 66
85
95

4
Important
Read these instructions for use carefully before using
the appliance and save them for future reference.
Only use the powerplug supplied.
The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The powerplug contains a transformer. Do not
cut off the powerplug to replace it with another
plug, as this will cause a hazardous situation.
Do not use a damaged powerplug.
If the powerplug is damaged, always have it
replaced by one of the original type in order to
avoid a hazard.
Make sure the powerplug does not get wet.
Charge and store the appliance at a temperature
between 5 cC and 35 cC.
Always unplug the shaver before cleaning it
under the tap.
The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.
This washable shaver is not suitable for shaving
in the shower.
Do not immerse the shaver in water.
Water may leak from the socket at the bottom
of the appliance when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the shaver.
,
,
,
,
,
,
,
,
,
,
,
,
ENGLISH

Charging
Make sure the appliance is switched off before you
start charging it.
Charging takes approx. 8 hours.
A longer charging time will not result in any
damage to the shaver and will even enhance the
performance of the battery over a longer period.
Charge indications
Charging
When you start charging the empty shaver, the
charging light goes on.
Battery running low
When the battery is running low, the battery-low
light goes on.
When you switch the shaver off, this light blinks a
few times.
Cordless shaving time
After charging, the shaver has a cordless shaving time
of up to 30 minutes.
Charging the appliance
Charge the shaver when the battery-low light goes
on.
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver
,
,
ENGLISH 5

when the battery has been fully charged (after
approx. 8 hours).
Using the appliance
The shaver cannot be used directly from the mains.
Shaving
1 Switch the shaver on by pressing the on/off
button once.
The power-on lights go on to indicate that the
motor is running.
2 Move the shaving heads quickly over your skin,
making both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3 Switch the shaver off by pressing the on/off
button once.
The power-on lights go out.
4 Clean the shaver (see chapter ‘Cleaning and
maintenance’).
5 Put the protection cap on the shaver every
time you have used it, to prevent damage to
the shaving heads.
Trimming
For grooming sideburns and moustache.
1 Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
-
-
ENGLISH6

2 Close the trimmer (‘click’).
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Note:Water may leak from the socket at the bottom of
the appliance when you rinse it.This is normal and not
dangerous.
Every day: shaving unit and hair chamber
1 Switch the shaver off.
2 Press the release button to open the shaving
unit.
3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
ENGLISH 7

Make sure you clean the inside as well as the
outside of the shaving unit.
4 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
5 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.
Every six months: shaving heads
1 Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn the lock clockwise.
4 Close the shaving unit.
,
ENGLISH8

Trimmer
Clean the trimmer every time you have used it.
1 Switch the shaver off.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
Storage
Put the protection cap on the shaver to prevent
damage to the shaving heads.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ8
Philips shaving heads only.
Note: Do not mix up the cutters and the guards to
guarantee optimal shaving performance.
1 Switch the shaver off.
2 Press the release button to open the shaving
unit.
,
,
ENGLISH 9

3 Turn the lock anticlockwise (1) and remove the
retaining frame (2).
4 Remove the shaving heads and place new ones
in the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise.
Make sure that the projections of the shaving
heads t exactly into the recesses.
5 Close the shaving unit.
Accessories
The following accessories are available:
HQ8000 powerplug.
HQ8 Philips Shaving Heads.
HQ110 Philips Shaving Head Ceaning Spray.
HQ8010 car cord.
Environment
Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an ofcial collection point for
recycling. By doing this you will help to preserve
the environment.
Disposal of the battery
The built-in rechargeable battery contains substances
that may pollute the environment.Always remove
-
-
-
-
,
ENGLISH10

the battery before discarding the appliance and
handing it in at an ofcial collection point. Dispose
of the battery at an ofcial collection point for
batteries. If you have trouble removing the battery,
you can also take the appliance to a Philips service
centre, which will remove the battery for you and
will dispose of it in an environmentally safe way.
Only remove the battery if it is completely empty.
1 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver.
2 Let the shaver run until it stops, undo the two
screws in the hair chamber and remove it.
3 Undo the two screws at the back of the shaver
and remove the back panel of the housing.
4 Remove the side panels by pulling them off the
sealed power unit.
5 Undo the three screws in the sealed power
unit.
ENGLISH 11

6 Remove the back panel of the sealed power
unit by means of a screwdriver.
7 Remove the battery.
Be careful, the battery strips are very sharp.
Do not connect the shaver to the mains again after
the battery has been removed.
Guarantee & service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in
your country (you will nd its phone number in
the worldwide guarantee leaet). If there is no
Customer Care Centre in your country, turn to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Troubleshooting
1 Reduced shaving performance.
Cause 1: the shaving heads are dirty.The shaver has
not been rinsed long enough or the water used was
not hot enough.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
Cause 2: long hairs are obstructing the shaving heads.
Clean the cutters and guards with the brush
supplied. See chapter ‘Cleaning and maintenance’,
section ‘Every six months: shaving heads’.
Cause 3: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
,
,
,
