Philips S91 series User manual

9000 series
S91XX / S90XX
4222.002.5861.1 S91XX,S90XX COVER A6 FC_cHR.indd 1 10-03-16 10:18

15
14
1
2
3
4
5
6
16
18 19
17
7
8
9
10
11
12
13
20
21
22
23
24
25

empty page before TOC

English 6
Deutsch 38
Français 73
Italiano 108

English
Contents
Introduction 7
Important safety information 7
Danger 8
Warning 8
Caution 10
Electromagnetic fields (EMF) 12
General 12
General description (Fig.1) 12
The display 13
Charging 14
Battery fully charged 14
Battery low 14
Remaining battery charge 14
Cleaning reminder 15
Travel lock 15
Replacement reminder 16
Exclamation mark 16
Charging 16
Charging with the supply unit 17
Charging in the SmartClean system (S9111/31, S9161/31
only)
17
Using the appliance 18
Switching the appliance on and off 18
Shaving 18
Using the click-on attachments 20
Cleaning and maintenance 22
Cleaning the shaver in the SmartClean system
(S9161/31, S9111/31 only)
23
Preparing the SmartClean system for use 23
Using the SmartClean system 24
Replacing the cartridge of the SmartClean system 26
Cleaning the shaver under the tap 27
6English

Cleaning the click-on attachments 28
Storage 29
Replacement 29
Replacing the shaving heads 29
Ordering accessories 31
Recycling 32
Removing the rechargeable shaver battery 32
Guarantee and support 33
Guarantee restrictions 33
Troubleshooting 33
Shaver 34
SmartClean system 36
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.
Important safety information
Read this important information carefully before
you use the appliance and its accessories and
save it for future reference. The accessories
supplied may vary for different products.
7
English

Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use
the detachable supply unit
(type HQ8505) provided with
the appliance.
- The supply unit contains a
transformer. Do not cut off the
supply unit to replace it with
another plug, as this causes a
hazardous situation.
8English

- This appliance can be used by
children aged from 8 years and
above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not play
with the appliance. Cleaning
and user maintenance shall not
be made by children without
supervision.
- Always unplug the shaver
before you clean it under the
tap.
- Always check the appliance
before you use it. Do not use
the appliance if it is damaged,
as this may cause injury. Always
replace a damaged part with
one of the original type.
9
English

- Do not open the appliance to
replace the rechargeable
battery.
Caution
- Never immerse the cleaning
system or the charging stand in
water and do not rinse it under
the tap.
- Never use water hotter than
80°C to rinse the shaver.
- Only use this appliance for its
intended purpose as shown in
the user manual.
- For hygienic reasons, the
appliance should only be used
by one person.
- Never use compressed air,
scouring pads, abrasive
cleaning agents or aggressive
liquids such as petrol or
acetone to clean the appliance.
10 English

- If your shaver comes with a
cleaning system, always use
the original Philips cleaning
fluid (cartridge or bottle,
depending on the type of
cleaning system).
- Always place the cleaning
system on a stable, level and
horizontal surface to prevent
leakage.
- If your cleaning system uses a
cleaning cartridge, always make
sure the cartridge compartment
is closed before you use the
cleaning system to clean or
charge the shaver.
- When the cleaning system is
ready for use, do not move it to
prevent leakage of cleaning
fluid.
11
English

- Water may drip from the socket
at the bottom of the shaver
when you rinse it. This is normal
and not dangerous because all
electronics are enclosed in a
sealed power unit inside the
shaver.
- Do not use the supply unit in or
near wall sockets that contain
an electric air freshener to
prevent irreparable damage to
the supply unit.
Electromagnetic fields (EMF)
- This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic fields.
General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap. For safety reasons, the shaver can
therefore only be used without cord.
- The appliance is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
General description (Fig.1)
1 Comb for beard styler attachment (S9161/31,
S9111/41, S9111/31 only)
2 Click-on beard styler attachment (S9161/31,
S9111/41, S9111/31 only)
12 English

3 Click-on trimmer attachment (S9041/12,
S9031/12 only)
4 Click-on shaving unit
5 On/off button
6 Socket for small plug
7 Exclamation mark
8 Replacement reminder
9 Battery charge indicator
10 Travel lock symbol
11 Cleaning reminder
12 SmartClean system (S9161/31, S9111/31 only)
13 Cap of SmartClean system
14 On/off button
15 Replacement symbol
16 Cleaning symbol
17 Drying symbol
18 Ready symbol
19 Charge symbol
20 Cleaning cartridge for SmartClean system
21 Supply unit
22 Small plug
23 Retaining ring holder
24 Pouch
The accessories supplied may vary for different
products. The box shows the accessories that have
been supplied with your appliance.
The display
Note: Before you use the shaver for the first time,
remove the protective foil from the display.
13
English

Charging
Quick charge: When you connect the shaver to the
wall socket, the lights of the battery charge
indicator light up one after another repeatedly.
When the shaver contains enough energy for one
shave, the bottom light of the battery charge
indicator starts to flash slowly.
While the shaver continues to charge, first the
bottom light of the battery charge indicator flashes
and then lights up continuously. Then the second
light flashes and lights up continuously, and so on
until the shaver is fully charged (see 'Battery fully
charged').
Battery fully charged
When the battery is fully charged, all lights of the
battery charge indicator light up white
continuously.
Note: This appliance can only be used without
cord. When you press the on/off button during or
after charging, you hear a sound to indicate that
the shaver is still connected to the wall socket.
Note: When the battery is full, the display switches
off automatically after 30 minutes.
Battery low
When the battery is almost empty, the bottom light
of the battery charge indicator flashes orange and
you hear a sound.
Remaining battery charge
The remaining battery charge is shown by the
lights of the battery charge indicator that light up
continuously.
14 English

Cleaning reminder
Clean the shaver after every shave for optimal
performance. When you switch off the appliance,
the cleaning reminder flashes to remind you to
clean the appliance.
Travel lock
You can lock the appliance when you are going to
travel. The travel lock prevents the appliance from
being switched on by accident.
Activating the travel lock
1Press the on/off button for 3 seconds to enter
the travel lock mode.
While you activate the travel lock, the travel
lock symbol lights up white continuously. When
the travel lock is activated, the appliance
produces a sound and the travel lock symbol
flashes.
Deactivating the travel lock
1Press the on/off button for 3 seconds.
The travel lock symbol flashes and then lights
up continuously. The appliance is now ready for
use again.
Note: You can also deactivate the travel lock by
connecting the appliance to the wall socket.
15
English

Replacement reminder
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
The appliance is equipped with a replacement
reminder which reminds you to replace the
shaving heads. The shaving unit symbol lights up
white continuously, the arrows flash white and the
appliance beeps to indicate that you have to
replace the shaving heads.
Note: After replacing the shaving heads, you need
to reset the replacement reminder by pressing the
on/off button for 7 seconds.
Exclamation mark
Overheating
If the appliance overheats during charging, the
exclamation mark flashes orange. When this
happens, the shaver switches off automatically.
Charging continues once the temperature of the
appliance has decreased to the normal level.
Blocked shaving heads
If the shaving heads are blocked, the exclamation
mark lights up orange continuously. The
replacement reminder and the cleaning reminder
flash white alternately and you hear a sound. In
this case, the motor cannot run because the
shaving heads are soiled or damaged.
If the shaving heads are soiled, you have to clean
them. If the shaving heads are damaged, you have
to replace them.
Charging
Charge the shaver before you use it for the first
time and when the display indicates that the
16 English

battery is almost empty. The battery charge is
indicated by the lights of the battery charge
indicator on the display.
When you connect the shaver to the wall socket,
you hear a sound.
Charging takes approx. 1 hour. A fully charged
shaver has a shaving time of up to 50 minutes.
Note: You cannot use the appliance while it is
charging.
Charging with the supply unit
1Make sure the appliance is switched off.
1
2
2Put the supply unit in the wall socket and put
the small plug in the appliance.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Charging in the SmartClean system (S9111/31, S9161/31
only)
1Put the small plug in the back of the
SmartClean system.
2Put the supply unit in the wall socket.
3Press the top cap to be able to place the shaver
in the holder ('click').
4Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system.
17
English

1
2
3
5Place the shaver in the holder (1), tilt the shaver
backwards (2) and press down the top cap to
connect the shaver (‘click’) (3).
Note: The battery symbol starts to flash to indicate
that the appliance is charging. When the battery is
fully charged, the battery symbol lights up
continuously.
Using the appliance
Note: This appliance can only be used without
cord.
Switching the appliance on and off
- To switch on the appliance, press the on/off
button once.
The display lights up for a few seconds.
- To switch off the appliance, press the on/off
button once.
The display lights up for a few seconds and
shows the remaining battery charge.
Shaving
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week)
and exclusively with this appliance for a period of
3 weeks.
Shaving tips
- To ensure the best result, we advise you to pre-
trim your beard if you have not shaved for 3
days or longer.
18 English

- Move the shaving heads over your skin in
circular movements.
Dry shaving
1Switch on the appliance.
The display lights up for a few seconds.
2Move the shaving heads over your skin in
circular movements.
Note: Circular movements provide better
shaving results than straight movements.
3Clean the appliance after use (see 'Cleaning
and maintenance').
Wet shaving
You can also use this appliance on a wet face with
shaving foam or shaving gel.
To shave with shaving foam or shaving gel, follow
the steps below:
1Apply some water to your skin.
2Apply shaving foam or shaving gel to your skin.
3Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4Switch on the appliance.
19
English

5Move the shaving heads over your skin in
circular movements.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6Dry your face.
7Clean the appliance after use (see 'Cleaning
and maintenance').
Note: Make sure you rinse all foam or shaving
gel off the appliance.
Using the click-on attachments
Removing or attaching the click-on
attachments
1Make sure the appliance is switched off.
2Pull the attachment straight off the appliance.
Note: Do not twist the attachment while you
pull it off the appliance.
3Insert the lug of the attachment into the slot in
the top of the appliance. Then press down the
attachment to attach it to the appliance (‘click’).
Using the trimmer attachment (S9041/12,
S9031/12 only)
You can use the trimmer attachment to groom
your sideburns and moustache.
1Attach the attachment to the appliance (‘click’).
2Switch on the appliance.
The display lights up for a few seconds.
20 English
