Philips Luno HQ5426 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ5426
Luno
04/05
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100-240 V 50/60 Hz
- Power consumption : Motor depending
- Motor voltage : 54 V
- Power system : Mains
- Shaving heads : HQ4 - 4222 036 05450
- SAP coding : HQ5426
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Remove shaving unit, to prevent damages during repairs.
- Remove the screws A1 (2 x).
- Remove cover. (see Fig. 1)
- To remove the trimmer, first
disassemble the trimmer slide
by pushing down the locking
pegs (2 x “X” in exploded
view) and move the slide
slightly outwards.
- Make room between trimmer
and cover with a small screw-
driver (“Y” in exploded view).
- Remove screws B1 (2 x).
- The PC-board with motor
and hairchamber can now be
removed from the housing.
- Detach the motor clamping springs (item 16) on the
bearing block with a small screwdriver.
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Pouch - 4222 036 05570
Fig. 1

HQ5426
EXPLODED VIEW & PARTS LIST
B1
A1
12
15
16
14
6
5
10
9
4
3
2
1
7
8
11
13
21
Y
20
X
22
17
18
19
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
4222 036 05430
4222 036 05440
4222 036 05450
4222 036 05460
4222 036 05420
4822 466 10937
4222 036 05470
4222 036 05480
4222 036 05500
4222 036 05510
4822 479 30183
4222 036 05540
4222 036 05550
4822 522 33605
protecting cap
bracket
HQ4 shaving head
holder assy
hair chamber complete
dust seal
on/off knob
panel EUR
housing
on/off slide assy
cleaning brush
printed circuit board
inlet
pinion
Pos Service code Description
15
16
17
18
19
20
21
22
4822 361 30455
4822 492 71735
4222 036 05520
4822 362 40181
4822 492 62703
4222 036 05530
4222 036 05560
4822 321 10095
4822 321 10096
4822 321 10148
4222 036 01590
4822 502 30526
4222 036 05570
motor assy
motor spring
capacitor Y5P 470 pF
carbon brush
spring
trimmer assy
cover
flex assy EUR
flex assy GB
flex assy AUS/NZ
flex assy ARG
screw (torx-slot)
pouch EUR
