Philips FWM197/12 User manual

Philips
Mini Hi-Fi System
• 120W
FWM197
Obsessed with sound
Experience uninterrupted enjoyment of your CD/WMA/MP3 songs for up to 10 hours
on the Philips Mini hi-fi system. Extend your music pleasure by listening to your tunes at
home from your portable player - with MP3 link.
Enrich your sound experience
• 120W RMS total output power
• Bass Reflex Speaker System delivers a powerful, deeper bass
• Dynamic Bass Boost for deep and dramatic sound
• Digital Sound Control for optimized music style settings
• Digital Sound Control for optimized music style settings
Continuous enjoyment of your favorite music
• Autostop cassette deck
• USB Direct for MP3/WMA music playback
• MP3 Link for portable music playback
• Digital tuning with preset stations for extra convenience
• Play MP3-CD, CD and CD-R/RW

FWM197/12
Highlights
Mini Hi-Fi System
120W
120W RMS
This system has 120W RMS total output
power. RMS refers to Root Mean Square
which is a typical measurement of audio
power, or rather, the electrical power
transferred from an audio amplifier to a
loudspeaker, which is measured in watts. The
amount of electrical power delivered to the
loudspeaker and its sensitivity determines the
sound power that is generated. The higher the
wattage, the better the sound power emitted
by the speaker.
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep
bass experience from a compact loudspeaker
box system. It differs from a conventional
loudspeaker box system in the addition of a
bass pipe that is acoustically aligned to the
woofer to optimize the low frequency roll-off
of the system. The result is deeper controlled
bass and lower distortion. The system works
by resonating the air mass in the bass pipe to
vibrate like a conventional woofer. Combined
with the response of the woofer, the system
extends the overall low frequency sounds to
create a whole new dimension of deep bass.
Autostop cassette deck
Autostop cassette deck
USB Direct
With the USB Direct mode, simply plug in your
USB device to the USB port on your Philips
device and your digital music will be played
directly from the Philips device.
MP3 Link
The MP3 link connectivity allows direct
playback of MP3 content from portable media
players. Besides the benefit of enjoying your
favorite music in the superior sound quality
delivered by the audio system, the MP3 link is
also extremely convenient as all you have to do
is to plug your portable MP3 player to the
audio system.
Digital tuning with presets
Simply tune into the station that you want to
preset, press and hold the preset button to
memorize the frequency. With preset radio
stations that can be stored, you can quickly
access your favorite radio station without
having to manually tune the frequencies each
time.
Play MP3-CD, CD and CD-R/RW
MP3 stands for "MPEG 1 Audio layer-7.6 cm
(3") .MP3 is a revolutionary compression
technology by which large digital music files can
be made up to 10 times smaller without
radically degrading their audio quality. MP3 has
become the standard audio compression
format used on the world wide web, allowing
quick and easy audio file transfer.

Issue date 2013-05-10
Version: 3.0.7
12 NC: 8670 000 49722
EAN: 87 12581 46510 0
© 2013 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
FWM197/12
Specifications
Mini Hi-Fi System
120W
Sound
• Sound enhancement: Dynamic Bass Boost, digital
sound control
• Output power: 120 W RMS
Loudspeakers
• Number of speaker boxes: 2
• Speaker drivers: 2" tweeter, 5.25" woofer
• Loudspeaker enhancement: 2-way
• Speaker types: bass reflex speaker system
Audio playback
• Playback media: CD, CD-R, CD-RW, MP3-CD,
WMA-CD
• Disc playback modes: fast forward/backward, next/
previous track search, repeat/one/all/program,
repeat/shuffle/program
•Numberofdecks:1
• Cassette deck technology: mechanical
• Cassette Playback Modes: semi-auto stop
• USB Direct playback modes: fast backward/fast
forward, play/pause, previous/next, program play,
repeat, shuffle, stop
Audio recording
• Recording media: tape
• Tape recording enhancement: CD synchro start
recording
Tuner/Reception/Transmission
• Station presets: 40
• Tuner bands: FM stereo, MW
• Tuner enhancement: auto digital tuning, auto scan
Convenience
• Alarms: CD alarm, USB alarm
• Number of discs: 1
• Clock: on main display, sleep timer
• Loader type: tray
• Display type: LCD display
Connectivity
• Aux in: 2xRCA (Audio)
• USB: USB host
• MP3 Link: 3.5mm stereo line in
Accessories
•Remotecontrol
• User Manual: multi-languages
• Others: Quick start guide
• Warranty: World Wide Guarantee booklet
Dimensions
• Gross weight: 11.2 kg
• Main unit depth: 285 mm
• Main unit height: 292 mm
• Main unit width: 220 mm
• Speaker height: 292 mm
• Speaker depth: 186 mm
• Packaging width: 730 mm
• Packaging height: 348 mm
• Packaging depth: 275 mm
• Speaker weight: 207 mm
Power
• Power supply: 50 Hz
• Power supply: 220 - 240 V
Green
• Eco Power standby: 1 W
• Standby power consumption: < 2 W
•
