Philips PM 5191 User manual

Programmable synthesizer /
function
generator
0.1mHz—-
2
MHz
PM 5191
9445 051 91001
Operating
manual
-
Gebrauchsanleitung
-
Notice
d’emploi
9499 450 08401
87 08 15
industrial & Electro-acoustic System
pHiuips|
Industrial
&
=
Electro-acoustic
Systems

Programmable
synthesizer
/
function
generator
0.1mHz—-
2
MHz
PM
5191
9445 051 91001
Operating manual
Gebrauchsanleitung
Notice d’emploi
9499 450 08401
87 08 15
ea
|
PHILIPS

Please note
In correspondence concerning this instrument, please quote the type number and serial number as given on the
type plate.
Bitte beachten
Bei Schriftwechsel iiber dieses Gerat wird gebeten, die Typennummer und die Geraétenummer anzugeben. Diese
befinden sich auf dem Typenschild an der Riickseite des Gerates.
Noter s. v. p.
Dans votre correspondance et dans vos réclamations se rapportant & cet appareil, veuillez toujours indiquer le
numéro de type et le numéro de série qui sont marqués sur la plaquette de caractéristiques.
Important
As the instrument is an electrical apparatus, it may be operated only by trained personnel. Maintenance and repairs
may also be carried out only by qualified personnel.
Wichtig
Da das Gerat ein elektrisches Betriebsmittel ist, darf die Bedienung nur durch eingewiesenes Personal erfolgen.
Wartung
und
Reparatur
diirfen
nur
von
geschultem,
fach-
und
sachkundigem
Personal
durchgefiihrt
werden.
important
Comme I‘instrument est un équipement électrique, le service doit re assuré par du personnel qualifié. De méme, —
lentretien et les réparations sont a confier aux personnes suffisamment qualifiées.
(c) Philips GmbH — Hamburg — Germany — 1987
All rights are strictly reserved.
Reproduction or divulgation in any form whatsoever is not permitted without written authority from the copyright owner.
Issued by Philips GmbH -Unternehmensbereich Elektronik fiir Wissenschaft und industrie- Werk fir Me&technik
Printed in Germany

1.1.
1.2.1.
1.2.2.
1.2.3.
1.2.4.
1.2.5.
1.2.6.
1.2.7.
1.2.8.
1.2.9.
1.2.10.
1.2.11.
1.2.12.
1.2.13.
1.2.14.
1.3.
1.3.1.
1.3.2.
1.4.
1.4.1.
1.4.2.
2.1.
2.2.1.
2.2.2.
2.2.3.
2.2.4.
2.3.
2.4.
3.5.2.
3.5.3.
3.5.4.
3.5.5.
3.6.
3.7.
3.8.
CONTENTS
GENERAL
INTRODUCTION
CHARACTERISTICS
Safety characteristics
Performance characteristics, specifications
Frequency
Signal output
Amplitudemodulation AM
Step functions
Connectors
1EEE/IEC bus
Storage of parameter settings
Diagnostic program
Overflow, misoperating
Power supply
Environmental capabilities
Safety and quality data; cabinet
ACCESSORIES
Standard
Optional
OPERATING PRINCIPLE
General operating principle
Description of the block diagram
INSTALLATION INSTRUCTIONS
INITIAL INSPECTION
SAFETY INSTRUCTIONS
Maintenance and repair
Earthing
Connections
Mains voltage setting and fuses
OPERATING POSITION
RADIO INTERFERENCE SUPPRESSION
OPERATING INSTRUCTIONS
GENERAL INFORMATION
SWITCHING ON THE INSTRUMENT
SELFTEST ROUTINE
BRIEF CHECKING PROCEDURE
General
' Operations test
OPERATION AND USE
Configuration of the display and control panel
Display, control elements and connectors
Manual input procedure
Modulation mode AM
Error messages, operating errors
SPECIAL APPLICATIONS
REMOTE CONTROL OF THE INSTRUMENT
TEST~PROGRAM PM 5191
~
