PHOENIX Showcontroller PHOENIX4 User manual

PHOENIX Showcontroller GmbH & Co.KG * www.Phoenix-Showcontroller.de
Reproduction and publication of this document, in whole or in part not allowed without
the express permission of the publisher. Amendments and errors reserved..
© 2012 All rights reserved
Laser harp manual

Phoenix4 laser harp
2
Connect the laser harp as described in the installation manual.
Be sure to place the sensor in a convenient angle (about 45 degrees) to the laser beam output.

Phoenix4 laser harp
3
Open the „Phoenix4 Showcontroller“
desktop icon.
Open Phoenix4 Live.
If you are not in Harp mode, please
change to it, by choosing
„Settings>Mode>Harp“ from the top
menu.
You get the dialog window that
Phoenix4 Live needs to be restarted.
Confirm this by clicking „Yes“.
Then you get the chance to save the
last changes.
Phoenix4 Live starts with the harp
optimized user interface.
Afterwards activate the MIDI-In
function in the software.
Open the Phoenix4 Live MIDI/DMX
settings at „Settings>MIDI/DMX“ at
the top menu.

Phoenix4 laser harp
4
Activate the „Use Midi-Input“
function. Choose the „USB MIDI
Interface“ from the Drop-Down Box as
Midi Device.
Set value 48 for „Effect-Startadress“.
Bank Startadress = 1
Effect-Startadress = 48
Button Startadress = 114
Scanner-Startadress = 104
Slider-Startadress = 88
MasterSliders = 120
GlobalDmx = 130
LaserOnOff = 140
Fog = 145
We advice you to set those values for
DMX for the laser harp use.
Close the window by click on the „OK“
button.
Switch on the laser by activating the
„Laser ON/Off“ button.
You can now trigger the animation in
Phoenix4 Live by interrupting the
laser generated harp strings.
The effect banks at Phoenix4 Live are
switched automatically if you change
the banks at the laser harp controller
and an animation is triggered by
interrupting the laser beams.
We hope you enjoy the usage of the laser harp.

Phoenix4 laser harp
5
Please email suggestions, wishes and questions to
[e-mail].
