Phone Labs Unity User manual

Universal Cell Phone Docking Station and Charger
Unity Telephone

This page is intentionally left blank.
Unity Telephone User Guide

Contents
Installation...........................................................................................................................1
Contents .......................................................................................................................... 1
Set Up...............................................................................................................................1
S
Connecting the Unity Telephone to a Land Line............................................................ 2
Connecting the Unity Telephone to a Cell Phone........................................................... 2
Feature Diagram.................................................................................................................. 3
Dial Pad Dialing.................................................................................................................. 4
Menu................................................................................................................................... 4
1. Language ...................................................................................................................... 4
2. Pair Bluetooth................................................................................................................ 4
3. Date/Time..................................................................................................................... 5
4. Clear Msg Indicator ....................................................................................................... 5
5. Banner .......................................................................................................................... 5
Messages............................................................................................................................. 6
Directory............................................................................................................................. 7
Callers................................................................................................................................. 8
Redial.................................................................................................................................. 9
Call Waiting........................................................................................................................ 9
Hold..................................................................................................................................... 9
Mute.................................................................................................................................... 9
Speaker................................................................................................................................ 9
Volume Bar......................................................................................................................... 9
Message Waiting............................................................................................................... 10
Call Handling.................................................................................................................... 10
Voice Dialing.................................................................................................................... 10
One-Touch Dialing ........................................................................................................... 11
Charging your Cell Phone................................................................................................. 11
Operation during Power Outage ....................................................................................... 11
Accessory Port.................................................................................................................. 11
Unity to Dock-
N-Talk Accessory.................................................................................
12
Glossary ............................................................................................................................ 14
Troubleshooting................................................................................................................ 14
Safety and Regulatory....................................................................................................... 15
Unity Telephone User Guide
Flash-To-Talk Feature for Push-to-Talk Service .............................................................. 13
Warranty ............................................................................................................................16
Last Number Redial.......................................................................................................... 11
6. Area Codes ................................................................................................................... 5
7. Call Forward ...................................... ....................................................................... 5
8. Access Dialing .............................................................................................................. 5
Conference Calling........................................................................................................... 11

Unity Telephone User Guide1
Installation
Contents
Unpack and check the contents of the Unity Telephone box and verify that the following items
are contained in your new Unity Telephone package.
Unity Telephone
Telephone Stand
Telephone Handset
Handset Coil Cord
User Guide
A/C Power Adaptor
Warranty Registration Card
If any of these items are missing, please notify the dealer that it was purchased from for a
replacement.
Set Up
Make the connections to Unity Telephone as shown below (underside view of the telephone).
On the right, there is an upper outlet for the Unity Telephone handset coil cord. The lower round outlet
accepts the A/C power adapter.
Once the power adapter is connected, the display and backlight will come on indicating the Unity is
connected to power.
A/C Power
Adapter Plug
Power
Handset
Accessory
Port Jack
Land Line
Jack
A/C Outlet
Modular Line Cord
Connect the telephone stand to the telephone by snapping the tabs on the stand into the opening at the
very bottom on the back side of the telephone. Once the tabs are placed in the openings, press the stand
against the back of the telephone to lock the upper securing tabs in place.
Handset
Cord Jack

Plug in location for the
cell phone cable or
Bluetooth Module
Cell phone icon
Cell phone cable fully
plugged intoUnity
Cell phone icon turns from gray to black
Cell phone battery level indicator
Cell Phone Connected indicator
Cell phone busy indicator
Connecting the Unity Telephone to a Land Line
After plugging in the powercable and snapping on the Telephone Stand,connect one endof the supplied modular
line cord into your wall jack and the other end into the land line jack on the back side of the Unity.Itislocated on
the lower left side of the back of the Unity above theAccessory Port jack.
Unity Telephone User Guide 2
If for any reason you lose A/C power, the Unity Telephone is designed to allow for continued
use for making outgoing land line calls.
Connecting the Unity Telephone to a Cell Phone
There are two ways to connect your cell phone to the Unity Telephone, a cable or aBluetoothModule. To use a
cable, make sure you have the appropriate cable for your cellphone. Plugone end of the cable into your cell phone
and the other end into the connector on the top right side of the Unity as shownbelow. When youconnect it, the
screen willread “Cable In” and you will hear a beep to confirm that the connectionhas beenmade. Thecell phone
icon on the Unity screen will turn from light todark color. If you are using the Bluetooth Module,simply plug it
into Unity using the same connector so that it may be paired with yourBluetoothcapable cell phone (see pairing
instructions on page 4). When it is connected,the screenwill read “Module In”. If the cell phone battery is not fully
charged and you are connected with a cablethe Unity will begin to charge the cell phone and the charging indication
will be able to be seenon the screen of the cell phone. When the Unity is requesting information from the cell phone,
the busy icon will be displayed (a diagonal arrow in the upper left corner of the screen). This will usually be seen
when scrolling through the cell phone directory or Text Message inbox. When acable or Bluetooth Module are
disconnected, the screen will read “Cable Out” or “Module Out,” respectively.
NOTE:

Unity Telephone User Guide3
Feature Diagram
Menu
Messages
Volume Bar
Ringer Level
Handset Volume
Speakerphone Volume
Indicator Lights
Message Waiting Indicator
New Call Light
Soft Keys
Cell Phone Connection
Status Indicator
Dial Pad
Directory
Redial
Call Waiting
Speaker
Cell Line
Line One
Redial
Callers
Navigation Wheel
Up, Down,
Left, Right
Feature
Keys

Unity Telephone User Guide 4
Dial Pad Dialing
To dial telephone numbers using the Dial Pad, simply select the typeof service you want to useby pressing Line
One for a land line call or Cell Linefor acellularcall, and dialnormally as you would using a land linetelephone.
There is no need to dial special digits. You may dial a “#” following the numberif youwant slightly fasterdialing
on the Cell Line. When an incomingcall isringing, pressingthe Speaker Key orliftingthe handset out of the
cradle willanswerwhichever line is ringing.
Pre-dialing Phone Numbers
While the Unity is on-hook, pressing the Dial Pad keys will displaythe dialed digits on theLCD screen.
These digitsmay then be automaticallydialed by going off-hook by picking Line One or Cell Line,
picking up the handset or pressingthe Speaker key.
Hotkey Dialing
Menu
NOTE:
1. Language
2. Pair Bluetooth
While the Unityison-hook, you can press and hold down a single Dial Pad number in order to automatically
go off-hook and dial a number stored in the one-touch dialing keymemory of the cell phone ifyourcell phone
supports that feature.
Press the MENU key to enter the main menu. Select the number corresponding to the menu feature on theDial
Pad of the Unity or use the Up, Down arrows on the Navigation Wheeltoscroll through thelist and press the Soft
Key button “Choose” to activate the desired action.
You will be able toselect Soft Key buttonsin each Menu and Sub-Menu screen inorder to activate
navigation features such as “Back” togo backa screen,, “Save” to save the menu choice, “Dial” to dial the number
currently on the screen, “Redial” to drop the current call and redial the last number dialed, “Pause”to add a pause
to a dialing string, “Unhold” torelease thehold onthe call, “Options” to review additional options for that screen,
“Send” to send a Text Message, “Exit”toexit the Menu and return to the idlescreen. Simply press the associated
Soft Key button toactivate thedesiredfeature.
Press the number 1 key on your Dial Pad orhighlight this option and select the “Choose” SoftKey button.Then
select the desired language from the listand press the numberof the language on yourDial Pad or usethe Up,
Down arrows to highlight this option and select the “Choose” Soft Key button to setthe desired selection.
Use this option topair to your bluetooth enabled cell phone with the Unity Telephone. First youmust connect your
Bluetooth Module tothe Unity. You will know if it is properly connected to the Unity phone when the display
screen says “Module In” and it has a blue flashing light. From the Menu, press the number 2key on your Dial Pad
or highlight this option using the Up, Down Navigation Wheel arrows and select the“Choose” Soft Key. The LCD
screenwill show “Pairing” during the pairing process with the cell phone. When prompted for a password, enter
on your cell phone dial pad.
3774
NOTE:
The Bluetooth Module should only need to be paired once to your cell phone unless you change
bluetooth cell phones and subsequently pair another cell phone.
Once the cell phone is paired tothe BluetoothModule, the blue LED on the Bluetooth Modulewill turn froma
flashing blue state to a steady blue state and th one will light its blue LED located under the LCD screen and youwill
hear an audible beep. A Soft Key label, BT Off,will appearon the lower left Soft Key. When this SoftKey is pressed,

Unity Telephone User Guide5
3. Date/Time
4. Clear Msg Indicator
5. Banner
NOTE: The Bluetooth Module will automatically connect and disconnect when you move the cell phone in
and out of the bluetooth range of approximately 30 feet. If you manually disconnect, the automatic connect
feature will not work until the connection is manually re-enabled by pressing "BT On."
the Bluetooth Module will manually disconnect from the cell phone and a new Soft Key will appear, BT On. Pressing
this Soft Key will re-establish the bluetooth connection.These SoftKeys mayalso be pressed during a call to switch
the call back and forth betweenthecell phone handset and the Unity. If you remove the Bluetooth Module, the blue
lightonthe Unity will turn off and the LCD screen will read "Module Out" and you will hear an audible beep.
Press the number 3 key on your Dial Pad or highlight this option usingthe Up, Down arrows andselect the “Choose”
SoftKey Button. Use the Dial Pad to enterthe month, day, hour, minute and AMor PM. Once these items have been
entered, you will be prompted to save the entries you have made. If you press the “Save” SoftKey Button, theDate and
Timewill saved in memory. Itmayalso be automatically updated from the cellphone dependingonthe functionality of
the cell phone.
If your message indicator is flashing andyou want to manually turn itoff, press the number 4 key on your Dial Pad or
highlight this option and selectthe “Choose” SoftKey to clear the messagelight.
Use theText editor(see Text Messages for details on text editor) to display a custom message on the screen whenthe
Unity phone is idle.
6. Area Codes
7. Call Forward
8. Access Dialing
The Area Codes featureallows local area codes to be entered into the Unity so that calls maybe dialed back if no area
code or “1” prefix is to bedialed.Select “1. Home” to enter an area codefor a local area with 7 digit dialing.All calls
from than area codewillnow appearas a 7 digit number. Selections 2-7 allow for additionallocal areas to be entered that
use10 digitdialing. Enter each other localarea code into aseparate listing numbered 2 through 7. Phone numbers from
these area codes will appearas a 10 digit number. After the area code is entered, it willappearin Sub-Menu listing.
For example:
The Call Forward feature willallow for calls on your land line to be forwarded to another phone number automatically
depending on whether your cell phoneisdocked or not. When your cell phoneis docked, call forwarding on your
landline is automatically turned offandland line calls will ring through normally to the Unity.Whenyour cell phone
is undocked,the feature will be automatically turned on and allcalls will ring to the forwardednumber.
The Access Dialing feature allows for a number(s) to be dialed first before dialing from the Directory List,Callers
List, Redial List or Last NumberRedial Key. Some Centrex lines and PBX systemsrequire the dialing of a “9” first
forcallsto be placed outside the system. Manually dialed calls will still need to dial theoutside access codebut it
will be strippedout for future calls placed using the Last Number Redial Key or the Redial List.
1. Home (212)
2. Local(718)
3. Local(646)
4. Local(None)
5. Local(None)
6. Local(None)
7. Local(None)
1. Enable: Turns the feature on
2. Disable:Turns the feature off
3. Enter Number:Sets the forwarding number
1. Enable: Turns thefeature on
2. Disable:Turns the feature off
3. Enter Number:Sets the pre-dialed number

Unity Telephone User Guide 6
3. Read Messages
Display Keys:
Prev
Displays the previous message that was received.
Next
Displays the next message in the list.
Options
a.
b.
c.
4. Write Message
HINT: Most cell phones will dial into the voice mail service by pressing the “1” key on the Dial Pad.
By selecting Read Messages from the menu, you can read new text messages or view the text messages stored in
your cell phone memory. Use the Navigation Wheel Left and Right arrows to scroll through the list. If the message
is too long to fit on one screen, a flashing down arrow informs you that you may press the Down arrow to read
more of the message or the Up arrow to scroll back up the message.
Delete You can delete a message you wish to discard. You will be prompted with the question
“Are you sure?” You may then “Choose” Yes or No.
Reply You can reply to a Text Message by pressing the “Reply” Soft Key. You may then enter a message.
Pressing “Next” will bring up a screen with the phone number of the person who sent the message. Pressing
“Send” will “Send” the message through the cell phone. You will be prompted with the message
“Are you sure?” You may then “Choose” Yes or No.
Forward You can forward a Text Message by pressing the “Forward” soft key. The Enter Number screen
will appear. Enter the telephone number of the person to whom you wish to forward the message. You can
then press“Send” to send the message . You will be prompted with the message “Are you sure?”
You may then choose “Yes” or “No”.
You will be able to write text messages by using this option. The Enter Message screen will appear and you may
type your message. Pressing “Next” will bring up a screen with the phone number of the person who sent the
message. Pressing “Send” will send the message through the cell phone. You will be prompted with the message
“Are you sure?” You may then choose “Yes” or “No”.
Messages
Press the Messages key for access to the Messages menu which allows you to create or review various types of messages.
The Messages options are:
1. Dial Landline VM: Dials into your land line Voice Mail
2. Dial Cell VM: Dials into your cell phone Voice Mail
3. Read Messages: Allows you to read your text messages
4. Write Message: Allows you to write, edit and "Send" text messages
2. Dial Cell VM
When selecting this option, you do not need to enter your cell phone Voice Mail number for most cell phones. Once
you dial your Voice Mail, use the Dial Pad as prompted by your voice mail service to manage your mailbox as usual.
If your cell pho ne does not connect properly to your voice mail, you will need to enter the specific number to access
your voice mail service. If you do not know your access number, contact your network operator for your Cell phone
Voice Mail access number. If you do know the number, select item 4 on the menu list, “Options” and select item “1”
to enter your voice mail number. See “4. Options” below for more information.
1. Dial Landline VM
This option allows you to directly dial into your Voice Mail service. The default number is the code used by most
landline telephone companies to retrieve messages or change greetings or passwords. The default number can be
easily changed. Refer to the instructions below entitled “5. Options” for further instructions.
5.Options: Allows you to change the number dialed to your cell phone or land line voice mail service

Unity Telephone User Guide7
Left arrow: delete
Right arrow: add a space.
Use the Dial Pad to entera phone number with the
Digit Editor.
Use"Back" to go back and make changes to your message.
Press "Send" to send yourText Message.
NOTE: Press the Dial Pad keys to enter a number (3-digit area code, followed by the 7-digit number).
Press the "Send" Soft Key to send the message.
Use the "Delete" Soft Key to delete digits.
Use the Left and Right arrows to move the cursor.
Directory
1. View Cell Phonebook: View the contents of the cell phone Directory
2. Add Item: Add an item to your local Directory
3. Delete Item: Delete current item from your local Directory
& ( ) , - .
- .
g h i 4
G H I
p q r s 7
P Q R S
* +
m n o 6
M N O
#
w x y z ÿ 9
W X Y Z
0
t u v 8
T U V
a b c
a á ç 2
A B Cj k l 5
J K L d e f
D E F
Navigation Wheel
ê é è 3
1 ! ‘ ?
Press the Directory key to view thelocal Directorylist resident in the Unity telephone.The local Directory list contains
the items that are saved in the Unity’s memory which canhold up to 500 names and phone numbers. In the local dir-
on the Navigation Wheel to scroll the indvidual listings under the selected letter.The “Options” Soft Key lets you
manage your local directory listings. The Local directory options are:
NOTE: Repeatedly press a Dial Pad key until it cycles to the desired character. Pausing moves the
cursor to the next position. Special characters are located under the '1' key. Accented characters (such as
â, é, etc.) are grouped with the keys that contain the unaccented base character. The following illustration
shows the numbers, letters and symbols found on each Dial Pad key.
5. Options
You will be able to write text messages by using this option. The Enter Message screen will appear and you may
type your message. Pressing "Next" will bring up ascreen with the phone numberof the person who sent the
message. Pressing "Send" will sendthe message throughthe cell phone. You will be prompted with the message
"Areyou sure?"You may thenchoose"Yes" or "No".
1. Edit LandlineVM #: Allows you to change thedefault land line VM phone number if necessary. Use the
center Navigation Wheel to editthe number. Select "Save" after you have entered thenew number.
2. Edit Cell VM #: Allows you to change the default cell phone VM number if necessary. Once a phone
number is entered, pressing the “1” dial pad key will automatically cause the Unity to go off-hook and
dial the entered number for voice mail access.
ectory, you can search for items by pressing the key which corresponds to the first letter of the item you are
looking for. For example: press '6' once to look for "Mar y Doe", press '6' twice to look for "Norman Jones", etc.
You can then use the Up or Down arrows to scroll through the Directory listings. Usethe Up and Downkeys

Unity Telephone User Guide 8
4. Edit Item: Change the name or number of the current item
5. Save Item to Cell: copies the current item to the cell phone
6. Copy ALL from Cell: Copy all items from cell phone to local Directory
7. Copy ALL to Cell: Copy all items from local Directory to cell phone Directory
8. Delete ALL items: deletes all items from local Directory
The cell phone directory options are:
1. View Local Phonebook: Allows the review of individual cell phone Directory listings
2. Copy Item from Cell: Copy an item from cell phone to local Directory
3. Copy ALL from Cell: Copy the entire directory from the cell phone to local Directory
Dialing from the Directory:
The Directory list can be usedfor dialing calls on either the Line One key or the Cell Line key by selecting the preferred
line key while the Directory listing ison the screen.Alternatively,lifting the handset, pressing the Speaker key or
"Dial" Soft Key (whichalsoactivates the Speaker) will alsodial the Directorynumber onthe screen andwill automatically
select LineOne unless that line is already busy. Inthat case, the number will bedialed outon the Cell Line.
Callers
Press the Callers key to view the local Callers list of received calls inthe Unitytelephone. The local Callerslist
contains the calls logged in the Unity memory which can hold up to 50 Caller ID records. Use theUpand Down
Navigation Wheel to scroll the Callers list.The "Cell List" Soft Key displays the cellphonecallerlist if available.
Viewing the cell phone's Callers from the Unity is not available on all cellphones.
The "Options" Soft Key letsyou manage your call list.
The local Callers options are:
1.Save Item: Save current item to your local Directory
2.Delete Item: Delete current item from your local Callers list
3.Save Item to Cell: copies the current item to the cell phone
4.Delete ALL items: deletes all items from local Callers list
New calls in the local Callers list are marked with an "n" icon until the item is viewed.
To view Missed or Received Calls in the cell phone's memory, press the "Cell List" Soft Key. Some cell
phones allow you to display the Missed calls and Received calls in separate lists. Use the "Missed" and
"Received" Soft Keys to switch between the lists.
Dialing from the Callers List:
The Callers list can be used for dialing calls on eitherthe Line One key or theCell Line key by selecting the preferred
line key while the Callerlisting is on the screen.Alternatively, lifting the handset, pressing the Speaker key
or "Dial" SoftKey (which also activatesthe Speaker) will also dial the Caller's number on the screenand will
automatically select Line One unless that lineis already busy. In that case, the number will bedialed outon the Cell Line.
HINT: If a right arrow is flashing at the end of the Caller's Number, you can press the NavigationWheel Right
arrow to add a'1' or an area code back in front of the number before dialing.
Saving a PTT Number in the Directory:
PTTnumbers can be saved in the Directory just like normal phone numbers. However, when the number is
initially savedin the Directory, it needs to be savedasa PTT Private number under the Select NumberType
menu option. Selecting this option will ensure that the numberis dialedout automatically as aPTTcall and
not dialed out asa normal cellularcall. Be sure to select the Cell Line for this type of call.
Each call in the Callers list isidentified by an icon as having rung on eitherLine One (by an old style telephone) or
the Cell Line (by a cell phone) foundonthe top left corner ofthe LCD screen.
The "Cell List" soft key displaysthe cell phone directory if available.Viewing the cellphone directory withthe
Unity is not available on all cellphones.

Unity Telephone User Guide9
Redial
Press the Redial key to view the local Redial list resident in the Unity telephone. The local Redial list contains
the calls you made that are logged in the Unity’s memory, which can hold up to the last 25 dialed calls. Use the
Up and Down Navigaton wheel to scroll the Redial list. The “Cell List” Soft Key displays the cell phone redial
list if available. The cell phone redial list is not available on all cell phones. The “Options” Soft Key lets you
manage your Redial list.
The local Redial options are:
1.Save Item: Save current item to your local Directory
2.Delete Item: Delete current item from your local Redial list
3.Save Item to Cell: copies the current item to the cell phone
4.Delete ALL items: deletes all items from local Redial list
Dialing from the Redial List:
The Redial list can be used for dialing calls on either the Line One key or the Cell Line key by selecting the preferred
line key while the Redial listing is on the screen. Alternatively, lifting the handset, pressing the Speaker key or
“Dial” Soft Key (which also activates the Speaker) will also dial the Redial number on the screen and will automatically
select Line One unless that line is already busy. In that case, the number will be dialed out on the Cell Line.
Call Waiting
Hold
Press the Hold Soft Key while on a call to place the call on “Hold”. The display will indicate that a
call is on “Hold.” Press the Line Key of the line on hold or press the Unhold Soft Key to take a call off “Hold.”
Mute
Press the Mute key to mute the handset or speakerphone’s microphone. The display will indicate the
Microphone is muted. Press the Speaker key or press the Mute key again to take a call off “Mute”.
Speaker
In an idle state, pressing the Speaker key will access dial tone so a call may be placed. It will also automatically
dial any digits displayed on the screen (from either pre-dialing or using the Directory, Callers or Redial lists) and
turn on the speakerphone. The Speaker light will illuminate when the speakerphone is on. Pressing the Speaker
key while on the speakerphone call will end the call if the handset is in the cradle (on-hook). If the handset is not
in the cradle (off-hook), pressing the Speaker key will turn off the speaker and transfer the audio to the handset.
Volume Bar
Receiver Volume
During a call using the handset, pressing the volume bar adjusts the receiver volume louder and softer.
Press the Call Waiting key to switch between active calls or to answer a second call after you hear the call call
waiting tone on either Line One or Cell Line, provided the service plan on these lines are provisioned for call
waiting service. While on a call, you will hear a call waiting beep if another caller is trying to reach you; if your
service plan and cell phone supports Call Waiting Caller ID, you will see the number (and possibly name) of the
second caller on your screen. Pressing the Call Waiting key will answer the incoming call. Pressing the Call Waiting
key subsequent times will toggle between the two callers (if this feature is supported by your cell phone) and the
display will indicate the caller to whom you are speaking.

Unity Telephone User Guide 10
Speaker Volume
During a call using the Speaker, pressing the volume bar adjusts the Speaker volume louder and softer.
Ringer Volume
Message Waiting Indicators
If you receive a text message or a new voice mail message on your cellphonewhile it is connected to theUnity
base unit or a voice mail message from yourservice connected to Line One, a Message Waiting prompt will appear
on the LCD screen and the red LED at the top of the Unity will flash. Listening to themessage from the Unitywill
cause the Message Waiting indicator to turn off ifdialed from the Messages Sub-Menu. Disconnectingyour cell
phone from the Unity will also cause the Message Waiting indicators to be turned off if the message was from your
cellular service. If the message is a text message, “Text Msg” will appearon aSoftKey; press to view the message.
Call Handling
Live Call Transfer
Transferring a call from the Unity to the cell phone:
You may also detach your cell phone from the Unity during a call and continue the call on your cell
phone at any time by pressing the BTOff Soft Key located at the bottom leftside of the LCD screen.
If you are using the BluetoothModule, you can also disconnect it from the Unity to transfer the call to the cellphone.
Voice Dialing
When noton a call, pressing the volume bar adjusts the ringer volume louder,softer, or off.When the ringer
is OFF, an icon is displayed on the idle screen in place of the banner.
When a Dock-N-Talk accessory is plugged into the Unity accessory port,you can use the“Do Not Disturb” to
prevent extension telephones from ringing. Pressing the Volume Downkey while the Ringer is off puts the Unity
in Do Not Disturb mode. When the ringer is turned off or the Unity hasbeen put into DoNot Disturbmode,
the Ringer OFF icon is displayed on the idle screen in place of the Banner.
Placing a call from your cell phone:
If you wish to dial a call first from your cell phone while it is docked to the Unity telephone,you can
then immediately transfer the call onto the Unity telephone by pickingup the handset or pressing CellLine to
connect the call using the Speaker.
Transferring an active call from your cell phone to the Unity:
If you are on a call with your cellphone, you can transfer the call to theUnityif your cell phone supports this feature.
Connectthe cell phone to the Unity base unit during the call (if using acable) and you cancontinue thecall on the
Unity handset or speakerphone. Some cell phones may require that youpress ## to connectthe call. If you are using
a Bluetooth Module, when you come into range the call will be transferredtothe Unityifyour cellphone supports
this feature.
To use the voice dialing feature of your cell phone, press the Cell Line keyandhold it down untilthe dialing tone
goes away.You will then hear a toneor a voice prompt from the cell phone. Say the command orname youdesire
and the call will be connected. This feature works only with cellularhandsets that support voice dialingfrom
remote devices.

Unity Telephone User Guide11
One-Touch Dialing
Charging your Cell Phone
When your cell phone is connected to the Unity base unit using a cable connection and is charging, the blue
“connected” light will be illuminated and the battery level will be displayed on the Unity Screen. The battery
level will continue to be displayed. The cell phone screen should also indicate that the cell phone is charging.
Operation during a Power Outage
Accessory Port
The Unity telephone has an accessory port. This port can be used to connect various accessories to
allow additional functionality through a variety of cables. The Dock-N-TalkAccessory Cable allows a
Dock-N-Talk universalcell phone docking station to be connected to the AccessoryPort and will allow you
to use your existing home or office wiring to make all the analog phones ring when your cell phone rings.
It also allows you to make call phone callsfrom any regular home phone or analogoffice phone.
Other planned accessories include the Recording Cable and Push-to-Talk Dispatcher. Please go to
Last Number Redial
The last number dialed on the Unity is displayed on the lower rightside of theLCD display screen.Pressing the
lower right side SoftKey will dialthat numberagain on the first available line. If the Cell Line key is selected first,
you can pressand hold the “*” key down on the dial padto activate the LastNumber Redial in the cellphone.
The last number called from the cell phonewill be automatically dialed. This feature works only with cellular
handsets that support Last Number Redial.
If you have programmed phone numbersin to the Dial Pad keys of your cell phone (afeaturesupported on
most cell phones), you can select Cell Line and pressand hold the same key on the Unity and it will dial the
same number associated withthat keyon the cell phone. This featureworks only with cellular handsets that
support one-touch dialing from remote devices. You may also dial in this manner whilethe phone is on-hook
to automatically dial the one-touch number using the Hotkeydialing feature.
Conference Calling Between Line One and Cell Line
The Unity can connect calls fromLine One and the Cell Line which allows a land line calland a cell phone call
to be linked together as a conference call. Once a call onone line is on holdand you have the secondline engaged on
another call,the Conference featurewill appear ona LCD display Soft Key.Press the Conference Soft Key and
Line Oneand the Cell Line will be connected.
NOTE: Additional extensions can be connected to the call by use of network based 3-waycalling service, land
line extension phones or the connection ofa Dock-N-Talk to the AccessoryPort of the Unity which allows
extensionsto be connected to the cellular partof thecall.
The Unity willhave very limitedfunctionality during a power outage. However, outgoing land line calls will
be able to be made and you can disconnect your cell phone and continue to use it during a power outage.
All of your directories and programming will be maintained during the outageandwill function again normally
when power returns.
www.phonelabs.com to view the latest Accessory Port offerings.

Connecting the Unity to a Dock-N-Talk Accessory
Plug Accessory Cable (ACC)
into Unity Accessory Port
line
Dock-N - Talk Docking Station
Unity Telephone User Guide 12
Do NOT
connect
to active
land-line
telephone
service
-
The Unity Telephone can be connected to a Dock-N-Talk cellphone docking stationinorderto connect extension
sets throughout the home or office. Simply plugone endof the Accessory Cable into the Dock-N-Talk special
connector and the other end into the Accessory Port on the Unity. Then plugone of the RJ-11 jacks ofthe
Dock-N-Talk to a wall jack that hasan unused pair of phonewires connected to extension sets or connect extension
sets directly to the Dock-N-Talk or you may do both. See figure below.

Unity Telephone User Guide13
Flash-To-Talk
TM
Feature for Nextel Push-To-Talk
TM
Service
Phone Labs' new Flash-To-TalkTM feature allows the Nextel Push-To-TalkTM service to be used on the
Unity Telephone. On an iDEN cell phone, the Push-To-TalkTM (PTT) feature is activated by use of
the Call Waiting button. When using the Unity Telephone, the Call Waiting button, which is also
used to answer call waiting, activates the PTT functionality. The main difference is that, unlike the
PTT button, you do not hold down the Call Waiting button while you are speaking. You need to press
the Call Waiting when you begin speaking, and press it again when you finish.
Placing a call
When using the Unity Telephone, go off-hook by either picking upthe receiver orby activating the
speakerphone and pressing Cell Line. Onceyouhear the dial-tone, dial the iDENnumber of the individual
or group you are calling and then press the Call Waiting button to effect a flash. Once you hear aresponse,
you'll need to press Call Waiting to begin speaking, and again whenyou finish speaking. Throughoutthe
conversation,each time youbegin speaking, press the Call Waiting button. Each time you finishspeaking,
press it again.
Receiving a call
When the Unity Telephone rings with a PTT call, you will hear your telephone ring with
a distinctive ringing pattern. Pick up the handset. If the other party is not speaking, you may
immediately begin speaking. If the PTT caller is speaking, when they finish speaking press the
Call Waiting button, answer and press it again when you are finished speaking. Throughout the
conversation, each time you begin speaking, press Call Waiting. Each time you finish speaking,
press it again.
Sprint Nextel cell phones have powerful radios that can cause noise in your
conversation. To avoid this interference, place your Nextel cell phone as far as away as practicable
from both the Unity Telephone.
NOTE:

Unity Telephone User Guide 14
Glossary
Cell Phone
Used generically to refer to any wireless mobile handset that may be operating on different networks.
Also called wireless or mobile phones.
Extension Set
Any analog telephone set that is plugged into the Unity base unit using the Dock-N-Talk plugged
into the Accessory Port.
SIM card
Subscriber Information Module, a removable card that enables users to store personal information such as
phone numbers and SMS messages. This card may be transferred from one cell phone to another.
Used only with GSM cell phones.
SMS
Short Message Service or text messaging. The ability to send and receive text messages from
a cell phone.
Troubleshooting
Digits won’t dial while on a call
Some cell phones require the dial pad cover “flip” to be open in order for digits to be dialed while
on an active call.
“PSTN detected” message is displayed
Your Dock-N-Talk accessory is plugged into a telephone line that is already in use by a land line
service. Disconnect the land line service before plugging into the Dock-N-Talk.

Unity Telephone User Guide15
Safety and Regulatory
When using the Unity Wireless Desktop Terminal, follow these safety precautions to reduce the risk
of electric shock and personal injury:
1. Read and understand all instructions.
2. Unplug the unit from the wall outlets before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
3. Do not use this unit near water (example: a bathtub).
4. This unit should not be placed near or over a radiator or heat register.
5. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric
shock.
6. Use only the power source supplied with the unit.
7. Do not disassemble this unit; take it to a qualified serviceman when service or repair is required.
Opening or removing covers may expose you to dangerous voltages or other risks.
8. Do not use this unit to report a gas leak in the vicinity of this unit.
9. Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If the product has been exposed to rain, water or liquid has been spilled on the product,
disconnect the unit and allow it to dry out. Once dry,it may be tested too see if it still
operates; however, do not open up the product.
c. If the product housing has been damaged.
d. If the product exhibits a distinct change in performance.
10. Avoid using the product during an electrical storm. There may be a remote risk of electric shock
from lightning.
FCC Notices
This unit has been tested and found to comply with the limits for a Class x digital device as specified in
Part 15 and Part 68 of FCC rules. These limits provide reasonable protection against radio and TV
interference in a residential area. However, your equipment might cause TV or radio interference even
when operating properly. To eliminate interference, try one or more of the following corrective
measures:
Relocate or reorient the TV or radio.
To the extent possible, increase the distance between the equipment and the TV or radio.
Use outlets on different electrical circuits for the equipment and the TV or radio.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

Unity Telephone User Guide 16
Warranty Information
Phone Labs warrants to the original purchaser of the Unity™ that under normal operating conditions this
product will be free from defects in material and workmanship for a period of 12 months from the original
date of purchase. Phone Labs’ sole obligation under this warranty or under any other legal obligation is to
repair or replace, at its option, the product if it is deemed defective by Phone Labs during the warranty
period. This will be done free of charge with new or refurbished product or parts, at Phone Labs option,
when the product is returned to Phone Labs, freight or postage prepaid with the original sales receipt
during the warranty period. This warranty does not apply if the product has been otherwise misused,
abused, accidentally damaged, or damaged or malfunctions or fails to function as a result of an act of God
such as fire, flood or lightning (or other incidence of excessive or insufficient voltage) or failure to follow
instructions.
You are responsible for and must pre-pay shipping, handling and insurance costs relating to returning
products for repair or replacement.
Any replacement Product will be warranted for the remainder of the original warranty period or for thirty
(30) days, whichever is longer. The above remedies are the Consumerís exclusive remedies for breach of
warranty. Phone Labs does not warrant against damages or defects in accessories or components not
manufactured by Phone Labs, or against damages resulting from such non-Phone Labs made products or
components. Phone Labs passes on to Buyer the warranty it received (if any) from the maker thereof for
such non-Phone Labs made products or components.
In no event shall Phone Labs be liable for incidental or consequential damages.
This warranty gives you specific legal rights and you may have other rights which vary from state to state.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation
of incidental or consequential damages, so the above limitations may not apply to you. No Phone Labs
dealer nor any other person or entity other than Phone Labs may extend or modify this warranty and no
such modification or extension shall be effective unless it is in writing.
