Phonetics Skymetry WTU-14 User manual

WTU-14
User’s Manual
version 1.11
Phonetics, Inc.
LIT-0085

Every effort has been made to ensure that the information in this
document is complete, accurate and up-to-date. Phonetics, Inc.
assumes no responsibility for the results of errors beyond its control.
Phonetics, Inc. also cannot guarantee that changes in equipment
made by other manufacturers, and referred to in this manual, will
not affect the applicability of the information in this manual.
Copyright © 2004 by Phonetics, Inc. dba Sensaphone
First Edition, version 1.11, January 2005
Written and produced by Phonetics, Inc.
Please address comments on this publication to:
Phonetics, Inc.
901 Tryens Road
Aston, PA 19014
Sensaphone is a registered trademark of Phonetics, Inc.
ii

Important Safety Instructions
Your Skymetry WTU-14 has been carefully designed to give you years of safe,
reliable performance. As with all electrical equipment, however, there are a few
basic precautions you should take to avoid hurting yourself or damaging the unit:
• Read the installation and operating instructions in this manual carefully. Be
sure to save it for future reference.
• Read and follow all warning and instruction labels on the product itself.
• To protect the Skymetry WTU-14 from overheating, make sure all openings
on the unit are not blocked. Do not place on or near a heat source, such as a
radiator or heat register.
• Do not use your Skymetry WTU-14 near water, or spill liquid of any kind into
it.
• Be certain that your power source matches the rating listed on the AC power
transformer. If you’re not sure of the type of power supply to your facility,
consult your dealer or local power company.
• Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be abused by persons walking on it.
• Do not overload wall outlets and extension cords, as this can result in the risk
of fire or electric shock.
• Never push objects of any kind into this product through ventilation holes as
they may touch dangerous voltage points or short out parts that could result in
a risk of fire or electric shock.
• To reduce the risk of electric shock, do not disassemble this product, but
return it to Sensaphone Customer Service or another approved repair facility
when any service or repair work is required. Opening or removing covers may
expose you to dangerous voltages or other risks. Incorrect reassembly can
cause electric shock when the unit is subsequently used.
• If anything happens that indicates that your Skymetry WTU-14 is not
working properly or has been damaged, unplug it immediately and follow the
procedures in the manual for having it serviced. Return the unit for servicing
under the following conditions:
1. The power cord or plug is frayed or damaged.
2. Liquid has been spilled into the product or it has been exposed to water.
3. The unit has been dropped, or the enclosure is damaged.
4. The unit doesn’t function normally when you’re following the operating
instructions.
iii

CAUTION: To reduce the risk of fire or injury to persons, read and follow these
instructions:
1. Replace the battery only with the same or equivalent type recommended
by the manufacturer.
2. Do not dispose of the battery in a fire. The cell may explode. Check with
local codes for possible special disposal instructions.
3. Do not open or mutilate the battery. Released electrolyte is corrosive and
may cause damage to the eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling battery in order not to short the battery with
conducting materials such as rings, bracelets, and keys. The battery or
conductor may overheat and cause burns.
FCC Requirements
Part 15: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
If you experience trouble with the Skymetry WTU-14, or you need information on
obtaining service or repairs, please contact:
Phonetics, Inc.
901 Tryens Road
Aston, PA 19014
Phone: [phone]
FAX: [phone]
iv

v

3 YEAR LIMITED WARRANTY
PLEASE READ THIS WARRANTY CAREFULLY BEFORE USING THE PRODUCT.
THIS LIMITED WARRANTY CONTAINS SENSAPHONE’S STANDARD TERMS AND
CONDITIONS. WHERE PERMITTED BY THE APPLICABLE LAW, BY KEEPING YOUR
SENSAPHONE PRODUCT BEYOND THIRTY (30) DAYS AFTER THE DATE OF DELIVERY,
YOU FULLY ACCEPT THE TERMS AND CONDITIONS SET FORTH IN THIS LIMITED
WARRANTY.
IN ADDITION, WHERE PERMITTED BY THE APPLICABLE LAW, YOUR INSTALLATION
AND/OR USE OF THE PRODUCT CONSTITUTES FULL ACCEPTANCE OF THE TERMS
AND CONDITIONS OF THIS LIMITED WARRANTY (HEREINAFTER REFERRED TO AS
"LIMITED WARRANTY OR WARRANTY"). IF YOU DO NOT AGREE TO THE TERMS AND
CONDITIONS OF THIS WARRANTY, INCLUDING ANY LIMITATIONS OF WARRANTY,
INDEMNIFICATION TERMS OR LIMITATION OF LIABILITY, THEN YOU SHOULD NOT
USE THE PRODUCT AND SHOULD RETURN IT TO THE SELLER FOR A REFUND OF THE
PURCHASE PRICE. THE LAW MAY VARY BY JURISDICTION AS TO THE APPLICABILITY
OF YOUR INSTALLATION OR USE ACTUALLY CONSTITUTING ACCEPTANCE OF THE
TERMS AND CONDITIONS HEREIN AND AS TO THE APPLICABILITY OF ANY LIMITATION
OF WARRANTY, INDEMNIFICATION TERMS OR LIMITATIONS OF LIABILITY.
1. WARRANTOR: In this Warranty, Warrantor shall mean "Dealer, Distributor, and/or
Manufacturer."
2. ELEMENTS OF WARRANTY: This Product is warranted to be free from defects in
materials and craftsmanship with only the limitations and exclusions set out below.
3. WARRANTY AND REMEDY: Three-Year Warranty — In the event that the Product
does not conform to this warranty at any time during the time of three years from original
purchase, warrantor will repair the defect and return it to you at no charge.
This warranty shall terminate and be of no further effect at the time the product is: (1)
damaged by extraneous cause such as fire, water, lightning, etc. or not maintained as
reasonable and necessary; or (2) modified; or (3) improperly installed; or (4) misused;
or (5) repaired or serviced by someone other than Warrantors’ authorized personnel or
someone expressly authorized by Warrantor’s to make such service or repairs; (6) used
in a manner or purpose for which the product was not intended; or (7) sold by original
purchaser.
LIMITED WARRANTY, LIMITATION OF DAMAGES AND DISCLAIMER OF LIABILITY FOR
DAMAGES: THE WARRANTOR’S OBLIGATION UNDER THIS WARRANTY IS LIMITED
TO REPAIR OR REPLACEMENT OF THE PRODUCT, AT THE WARRANTOR’S OPTION
AS TO REPAIR OR REPLACEMENT. IN NO EVENT SHALL WARRANTORS BE LIABLE
OR RESPONSIBLE FOR PAYMENT OF ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL
AND/OR PUNITIVE DAMAGES OF ANY KIND, INCLUDING BUT NOT LIMITED TO ANY
LABOR COSTS, PRODUCT COSTS, LOST REVENUE, BUSINESS INTERRUPTION LOSSES,
LOST PROFITS, LOSS OF BUSINESS, LOSS OF DATA OR INFORMATION, OR FINANCIAL
LOSS, FOR CLAIMS OF ANY NATURE, INCLUDING BUT NOT LIMITED TO CLAIMS
IN CONTRACT, BREACH OF WARRANTY OR TORT, AND WHETHER OR NOT CAUSED
BY WARRANTORS’ NEGLIGENCE. IN THE EVENT THAT IT IS DETERMINED IN ANY
ADJUDICATION THAT THE LIMITED WARRANTIES OF REPAIR OR REPLACEMENT ARE
INAPPLICABLE, THEN THE PURCHASER’S SOLE REMEDY SHALL BE PAYMENT TO THE
PURCHASER OF THE ORIGINAL COST OF THE PRODUCT, AND IN NO EVENT SHALL
WARRANTORS BE LIABLE OR RESPONSIBLE FOR PAYMENT OF ANY INCIDENTAL,
CONSEQUENTIAL, SPECIAL AND/OR PUNITIVE DAMAGES OF ANY KIND, INCLUDING
Skymetry WTU-14 Manual
vi

BUT NOT LIMITED TO ANY LOST REVENUE, BUSINESS INTERRUPTION LOSSES, LOST
PROFITS, LOSS OF BUSINESS, LOSS OF DATA OR INFORMATION, OR FINANCIAL
LOSS, FOR CLAIMS OF ANY NATURE, INCLUDING BUT NOT LIMITED TO CLAIMS IN
CONTRACT, BREACH OF WARRANTY OR TORT, AND WHETHER OR NOT CAUSED BY
WARRANTORS’ NEGLIGENCE.
WITHOUT WAIVING ANY PROVISION IN THIS LIMITED WARRANTY, IF A
CIRCUMSTANCE ARISES WHERE WARRANTORS ARE FOUND TO BE LIABLE FOR
ANY LOSS OR DAMAGE ARISING OUT OF MISTAKES, NEGLIGENCE, OMISSIONS,
INTERRUPTIONS, DELAYS, ERRORS OR DEFECTS IN WARRANTORS’ PRODUCTS OR
SERVICES, SUCH LIABILITY SHALL NOT EXCEED THE TOTAL AMOUNT PAID BY THE
CUSTOMER FOR WARRANTORS’ PRODUCT AND SERVICES OR $250.00, WHICHEVER IS
GREATER. YOU HEREBY RELEASE WARRANTORS FROM ANY AND ALL OBLIGATIONS,
LIABILITIES AND CLAIMS IN EXCESS OF THIS LIMITATION.
INDEMNIFICATION AND COVENANT NOT TO SUE: YOU WILL INDEMNIFY, DEFEND
AND HOLD HARMLESS WARRANTORS, THEIR OWNERS, DIRECTORS, OFFICERS,
EMPLOYEES, AGENTS, SUPPLIERS OR AFFILIATED COMPANIES, AGAINST ANY AND
ALL CLAIMS, DEMANDS OR ACTIONS BASED UPON ANY LOSSES, LIABILITIES,
DAMAGES OR COSTS, INCLUDING BUT NOT LIMITED TO DAMAGES THAT ARE
DIRECT OR INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL, AND INCLUDING
ATTORNEYS FEES AND LEGAL COSTS, THAT MAY RESULT FROM THE INSTALLATION,
OPERATION, USE OF, OR INABILITY TO USE WARRANTORS’ PRODUCTS AND SERVICES,
OR FROM THE FAILURE OF THE WARRANTORS’ SYSTEM TO REPORT A GIVEN EVENT
OR CONDITION, WHETHER OR NOT CAUSED BY WARRANTORS’ NEGLIGENCE.
YOU AGREE TO RELEASE, WAIVE, DISCHARGE AND COVENANT NOT TO SUE
WARRANTORS, THEIR OWNERS, DIRECTORS, OFFICERS, EMPLOYEES, AGENTS,
SUPPLIERS OR AFFILIATED COMPANIES, FOR ANY AND ALL LIABILITIES POTENTIALLY
ARISING FROM ANY CLAIM, DEMAND OR ACTION BASED UPON ANY LOSSES,
LIABILITIES, DAMAGES OR COSTS, INCLUDING BUT NOT LIMITED TO DAMAGES
THAT ARE DIRECT OR INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL, AND
INCLUDING ATTORNEYS FEES AND LEGAL COSTS, THAT MAY RESULT FROM THE
INSTALLATION, OPERATION, USE OF, OR INABILITY TO USE WARRANTORS’ PRODUCTS
AND SERVICES, OR FROM THE FAILURE OF THE WARRANTORS’ SYSTEM TO REPORT
A GIVEN EVENT OR CONDITION, WHETHER OR NOT CAUSED BY WARRANTORS’
NEGLIGENCE, EXCEPT AS NECESSARY TO ENFORCE THE EXPRESS TERMS OF THIS
LIMITED WARRANTY.
EXCLUSIVE WARRANTY: THE LIMITED WARRANTY OR WARRANTIES DESCRIBED
HEREIN CONSTITUTE THE SOLE WARRANTY OR WARRANTIES TO THE PURCHASER.
ALL IMPLIED WARRANTIES ARE EXPRESSLY DISCLAIMED, INCLUDING: THE
WARRANTY OF MERCHANTABILITY AND THE WARRANTY OF FITNESS FOR A
PARTICULAR USE AND THE WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE
AND THE WARRANTY OF NON-INFRINGEMENT AND/OR ANY WARRANTY ARISING
FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
It must be clear that the Warrantors are not insuring your premises or business or
guaranteeing that there will not be damage to your person or property or business if
you use this Product. You should maintain insurance coverage sufficient to provide
compensation for any loss, damage, or expense that may arise in connection with the
use of products or services, even if caused by Warrantors’ negligence. The warrantors
assume no liability for installation of the Product and/or interruptions of the service due
to strikes, riots, floods, fire, and/or any cause beyond Seller’s control, further subject
to the limitations expressed in any License Agreement or other Agreement provided by
Warrantors to purchaser.
vii

The agreement between the Warrantors and the Purchaser, including but not limited to the
terms and conditions herein shall not be governed by the Convention for the International
Sale of Goods. Where applicable, the Uniform Commercial Code as adopted by the State
of Delaware shall apply.
4. PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: In the event that the
Product does not conform to this warranty, the Product should be shipped or delivered
freight prepaid to a Warrantor with evidence of original purchase.
5. LEGAL REMEDIES AND DISCLAIMER: Some jurisdictions may not allow, or may place
limits upon, the exclusion and/or limitation of implied warranties, incidental damages
and/or consequential damages for some types of goods or products sold to consumers
and/or the use of indemnification terms. Thus, the exclusions, indemnification terms and
limitations set out above may not apply, or may be limited in their application, to you. If
the implied warranties can not be excluded, and the applicable law permits limiting the
duration of implied warranties, then the implied warranties herein are to be limited to the
same duration as the applicable written warranty or warranties herein. The warranty or
warranties herein may give you specific legal rights that will depend upon the applicable
law. You may also have other legal rights depending upon the law in your jurisdiction.
6. CHOICE OF FORUM AND CHOICE OF LAW: In the event that a dispute arises out of or
in connection with this Limited Warranty, then any claims or suits of any kind concerning
such disputes shall only and exclusively be brought in either the Court of Common Pleas
of Delaware County, Pennsylvania or the United States District Court for the Eastern
District of Pennsylvania.
Regardless of the place of contracting or performance, this Limited Warranty and all
questions relating to its validity, interpretation, performance and enforcement shall be
governed by and construed in accordance with the laws of the State of Delaware, without
regard to the principles of conflicts of law.
Effective date May 1, 2004
PHONETICS, INC. d.b.a. SENSAPHONE
901 Tryens Road
Aston, PA 19014
Phone: [phone] Fax: [phone]
www.sensaphone.com
Skymetry WTU-14 Manual
viii

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . iii
FCC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . 15
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Skymetry WTU-14 Diagram . . . . . . . . . . . . . . . . . . . . 17
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Web Page Initialization . . . . . . . . . . . . . . . . . . . . .18
Data Message Usage . . . . . . . . . . . . . . . . . . . . . .18
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 2: Installation . . . . . . . . . . . . . . . . . . . 21
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . 21
Activating your Skymetry WTU-14 . . . . . . . . . . . . . . . 21
Mounting the Skymetry WTU-14 (Aluminum Housing) 21
Mounting the Skymetry WTU-14 (NEMA-4X Housing) . 23
Locking the NEMA 4X Enclosure . . . . . . . . . . . . . . .24
Antenna Information . . . . . . . . . . . . . . . . . . . . . . . . . 25
Connecting the Power Supply . . . . . . . . . . . . . . . . . . 25
Connecting a Battery . . . . . . . . . . . . . . . . . . . . . . . . . 26
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Wiring Sensors to Dry Contact Inputs . . . . . . . . . . . . . 28
Normally Closed Sensors . . . . . . . . . . . . . . . . . . . .29
Normally Open Sensors . . . . . . . . . . . . . . . . . . . . .30
Wiring Sensors to Analog Inputs . . . . . . . . . . . . . . . . 31
Wiring Recommendations . . . . . . . . . . . . . . . . . . . . . 33
LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Table of Contents
ix
TABLE OF CONTENTS

Chapter 3: Software Installation . . . . . . . . . . . . . 35
Installing and Starting the Software . . . . . . . . . . . . . . 35
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Activating your Skymetry WTU-14 . . . . . . . . . . . . . . . 36
Connecting Locally . . . . . . . . . . . . . . . . . . . . . . . .36
Skymetry WTU-14 Web Page . . . . . . . . . . . . . . . . . . 38
Chapter 4: Input Programming . . . . . . . . . . . . . 39
Alarm States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Dry Contact Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Dry Contact Programming . . . . . . . . . . . . . . . . . . . . . 41
Configuring the Input Name . . . . . . . . . . . . . . . . . .42
Input Enable/Disable . . . . . . . . . . . . . . . . . . . . . . .42
Configuring the Input Type . . . . . . . . . . . . . . . . . . .42
Configuring the Run Timer . . . . . . . . . . . . . . . . . . .42
Configuring the Pulse Counter . . . . . . . . . . . . . . . .42
Alarm Enable/Disable . . . . . . . . . . . . . . . . . . . . . .43
Alarm on Return-to-Normal . . . . . . . . . . . . . . . . . . .43
Alarm Recognition Time . . . . . . . . . . . . . . . . . . . . .43
Alarm Reset Time . . . . . . . . . . . . . . . . . . . . . . . . .43
Analog Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Analog Inputs Programming . . . . . . . . . . . . . . . . . . . 44
Configuring the Input Name . . . . . . . . . . . . . . . . . .44
Configuring the Input Type . . . . . . . . . . . . . . . . . . .45
Input Enable/Disable . . . . . . . . . . . . . . . . . . . . . . .45
Setting Table Limits . . . . . . . . . . . . . . . . . . . . . . . .45
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Alarm Enable/Disable . . . . . . . . . . . . . . . . . . . . . .45
Alarm on Return-to-Normal . . . . . . . . . . . . . . . . . . .46
Setting the Alarm Limits . . . . . . . . . . . . . . . . . . . . .46
Alarm Recognition Time . . . . . . . . . . . . . . . . . . . . .46
Skymetry WTU-14 Manual
x

Alarm Reset Time . . . . . . . . . . . . . . . . . . . . . . . . .46
Power Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Battery Input . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Special Function Inputs . . . . . . . . . . . . . . . . . . . . . . . 47
Chapter 5: Output Programming . . . . . . . . . . . . 49
Setting the Output Name . . . . . . . . . . . . . . . . . . . . . . 50
Configuring the Output Operating Mode . . . . . . . . . . 50
Switching the Output . . . . . . . . . . . . . . . . . . . . . . . . . 51
Output Status & Statistics . . . . . . . . . . . . . . . . . . . . . . 51
Chapter 6: Pump Control . . . . . . . . . . . . . . . . . 53
How it works—Float Switches . . . . . . . . . . . . . . . . . . 53
How it works—Analog Level Sensor . . . . . . . . . . . . . 55
Installation Recommendations . . . . . . . . . . . . . . . . . . 55
Programming for Pump Control . . . . . . . . . . . . . . . . . 55
Output Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Chapter 7: Machine-to-Machine Control . . . . . . . 59
Local Output Control . . . . . . . . . . . . . . . . . . . . . . . . . 60
Important Information and Warnings . . . . . . . . . . . . . 61
Sample Application . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Chapter 8: Alarm Notification . . . . . . . . . . . . . . 65
How does notification work . . . . . . . . . . . . . . . . . . . . 65
Voice Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Internet E-Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Alphanumeric Pager . . . . . . . . . . . . . . . . . . . . . . . . . 69
Text Messaging to Cell Phones . . . . . . . . . . . . . . . . . . 71
Acknowledgment via E-mail or Text Message . . . . . . . 74
Additional Information . . . . . . . . . . . . . . . . . . . . . . . 74
Table of Contents
xi

Chapter 9: Operation . . . . . . . . . . . . . . . . . . . . 75
PART ONE: Alarm Notification and Acknowledgment . 75
Alarm Recognition . . . . . . . . . . . . . . . . . . . . . . . . .75
Alarm Notification . . . . . . . . . . . . . . . . . . . . . . . . .75
Dialout Note: Call Progress . . . . . . . . . . . . . . . . . .75
Alarm Notification—Voice . . . . . . . . . . . . . . . . . . .76
Alarm Notification—E-mail . . . . . . . . . . . . . . . . . . .76
Alarm Notification—Alphanumeric Pager . . . . . . . . .77
Alarm Notification—Text Message to Cell Phone . . .77
Tier Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Alarm Acknowledgment . . . . . . . . . . . . . . . . . . . . . . 78
Alarm Acknowledgment—Voice Notification . . . . . .78
Alarm Acknowledgment—Alphanumeric Pager . . . . .79
Alarm Acknowledgment—Text Message to Cell Phone .79
Alarm Acknowledgment—Automatic . . . . . . . . . . . .80
PART TWO: Status Request . . . . . . . . . . . . . . . . . . . . . 81
Chapter 10: Skymetry Web Page . . . . . . . . . . . . 83
Status Refresh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Programming Refresh . . . . . . . . . . . . . . . . . . . . . . . . 84
Programming via the Web Page . . . . . . . . . . . . . . . . 84
Switching Outputs via the Web page . . . . . . . . . . . . . 84
Account Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Alarm History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Chapter 11: Testing the Skymetry WTU-14 . . . . . 87
Notification Testing . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Input Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Output Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Control Programming . . . . . . . . . . . . . . . . . . . . . . . . 88
Pump Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Skymetry WTU-14 Manual
xii

APPENDIX A: Checking Your Skymetry WTU-14
for Proper Operation . . . . . . . . . . . . . . . . . 91
APPENDIX B: Troubleshooting . . . . . . . . . . . . . . 93
APPENDIX C: Thermistor Table . . . . . . . . . . . . . . 99
APPENDIX D: SKYMETRY WTU-14 Specifications . 101
APPENDIX E: Replacing the Backup Battery . . . 103
APPENDIX F: Optional Accessories . . . . . . . . . . 105
APPENDIX G: Returning Your Skymetry WTU-14
for Repair . . . . . . . . . . . . . . . . . . . . . . . . . 107
Test Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Table of Contents
xiii

Skymetry WTU-14 Manual
xiv

Chapter 1: Introduction
Congratulations on your purchase of the Skymetry WTU-14 by
Phonetics, Inc.
The WTU-14 Wireless Telemetry Unit is a powerful monitoring,
alarm, and control system. Its built-in wireless technology means
you won’t need a telephone line to communicate with the unit. It
can monitor and control your environment and equipment using
eight dry contact inputs, six analog inputs, built-in power failure
detection, and two relay outputs. It can perform simplex or duplex
alternating pump control using a level transducer or float switches.
The unit can also perform machine-to-machine control among mul-
tiple WTU-14 devices. Up to 8 machine-to-machine control algo-
rithms can be configured per device so that input conditions on one
Skymetry WTU-14 can logically control outputs on another using
simple, fill-in-the-blank, comparison programming. The unit fea-
tures several communication options including: voice telephone call,
e-mail, and text messaging. You can also request a status report
from most two-way text devices, like alphanumeric pagers and
cell phones. The Skymetry WTU-14 is fully programmable via the
included Skymetry Software package for Windows or through the
unit’s web page at www.skymetry.com.
The WTU-14 will produce a web page of input and output status
and alarm history that can be viewed at www.skymetry.com. You
can also program the unit or control outputs from the web page.
The Skymetry is the ultimate choice for remote monitoring and
control where telephone lines are non-existent or too expensive.
Applications include pump houses, cable TV huts, remote equip-
ment rooms, and tower light monitoring.
On the front of the unit are LED indicators to show the operat-
ing status (Power, Battery OK, In-Range, Registered, Alarm, and
Outputs). All programming is stored in nonvolatile memory so that
all programming is retained even without power. The unit will per-
form alarm event logging of the 14 inputs, power, and battery to the
Skymetry web page. A complete status report of all monitored con-
Chapter 1: Introduction
15

ditions can be retrieved via e-mail for viewing on a computer or text
messaging device. The Skymetry.com web page can be updated on
demand to allow viewing of the current conditions at the site from
any internet-connected computer. The unit comes in an aluminum
housing with mounting tabs and is optionally available in a plastic
NEMA-4X enclosure with a 36-hour battery backup.
Features
• 8 Dry Contact Inputs: NO, NC, Pulse Count, Equipment Run-
Time
• 6 Analog Inputs: 10K Thermistor (temperature), or 4–20mA
• 2 Relay Outputs: 20 different automatic and manual modes
• Local Logic Control
• Machine-to-Machine Control among Skymetry units
• Duplex and Simplex Pump Control
• Wireless Alarm Message Delivery via Voice, E-mail, or text
message.
• Status & Programming via web page
• NEMA 4X enclosure and Battery Backup (optional)
• Low Power consumption—suitable for solar operation
Solar Kit available (Part No. FGD-0062)
Skymetry WTU-14 Manual
16

Skymetry WTU-14 Diagram
1. Antenna
2. LEDs
3. Terminal blocks
4. RS-232 DCE
5. Jumpers for Temperature or 4–20mA settings
Chapter 1: Introduction
17

Overview
When installing and programming a Skymetry WTU-14 there are
several steps required for all installations. Listed below are those
required for a typical installation and start-up of the Skymetry
WTU-14.
1) Confirm wireless coverage for the installation site.
2) Select a wireless messaging plan and activate the unit.
3) Install the unit, set the input jumpers, and wire the sensors.
4) Go online locally and program the unit.
5) Wait for the web page to initialize and become active.
6) Verify status on the web site.
7) Test all sensors and alarm notification—see Chapter 11: Testing
the Skymetry WTU-14
Web Page Initialization
Your Skymetry WTU-14 is accessible via the internet at www.
skymetry.com. From the web page you can view status, make
programming changes, and even control outputs. Before any of
these features can be utilized, the unit must first initialize the web
server. This happens automatically immediately after your first local
programming session with the unit. As soon as you disconnect from
your first programming session the unit will begin to update the
web server with all of its programming. This may take an hour or
two depending on how many parameters were programmed. During
this initialization period it is recommended that the unit remain
powered on and no additional programming changes take place. For
detailed information on the Skymetry web page see Chapter 10.
Data Message Usage
Your Skymetry WTU-14 communicates over the wireless network
using data messages. These are transmitted whenever an alarm mes-
sage is delivered, machine-to-machine command is sent, or a web
update is requested. The number of data messages used for each
type of transmission is shown below in the table:
Skymetry WTU-14 Manual
18

Alarm Message to Voice or E-mail 1–4
Alarm Message to Web Server 1
Alarm Acknowledgement 1
Programming Parameter Read or Write 2
Machine-to-Machine Command 1
Status Refresh to the Web Page 5–7
Programming Refresh to the Web Page 9 to 115
The last item, Programming Refresh to the web, depends on how
many changes were made since the last update. Only items that have
changed will be sent. Typically, once the unit has been programmed,
additional programming changes are minimal. However, if you were
to completely reprogram the unit and change every parameter, then
the maximum number of data messages would be transmitted.
Technical Support
This instruction manual will help you install and program the
Skymetry WTU-14 properly. Be sure to read it completely before
beginning the installation process. If there are any questions or
problems that arise upon installation or operation, please contact our
Technical Support team:
PHONETICS, INC.
901 Tryens Road
Aston, PA 19014
Phone: [phone]
FAX: [phone]
suppor[email protected]
Chapter 1: Introduction
19

Skymetry WTU-14 Manual
20
