Description
Specifi cations
Manual Radio Call Points
M400DKMR-AS, M400DKMB-AS
• Manual call points for different
applications
• High range of radio transmission
• 2 frequency bands with
24 bidirectional data channels
• Fault message when door is opened
• Case according to EN 54-11/B
• Communication with radio interfaces
M500RFE-AS und M400RFE-AS
The red Manual Call Point M400DKMR-AS (fi g. A) and
the blue Manual Call Point M400DKMB-AS with lettering
„HAUSALARM“ (fi g. B) communicate with the RF Inter-
faces M500RFE-AS or M400RFE-AS via a secured ra-
dio protocol. The detectors are especially suitable for
areas, where cabling is impossible or uneconomical.
The plastic case, which is designed in accordance with
EN 54-11/B, is provided with an integrated antenna and
accommodates the 3.6V lithium battery.
4 data channels in the frequency band 868MHz as well
as 20 channels in the frequency band 434MHz are avai-
lable for the bidirectional data transmission. The avai-
lability of the channel is checked regularly. During the
learning phase of the detector, i.e., when the detector
is registered at the radio interface, a unique key, based
on a choice of several million codes, is created, which
allows the unambiguous identifi cation of the detector.
Regular status messages, monitoring of the battery vol-
tage and the long life of the included batteries ensure
the high reliability of the system.
A built-in LED optically indicates the activated condition
of the detector. The hinged door can be opened up to
an angle of 180° and it is provided with a replaceable
pane of glass. If the detector has been activated, an
integrated locking device prevents the closing of the
door. When the door is opened, the detector sends a
fault message to the radio interface.
Operating voltage 3.6V (lithium battery, battery life approx. 1.5 years)
Range of radio transmission (free air) 300m
Frequency band 868MHz or 434MHz
Ambient temperature 0°C to +40°C
Dimensions W × H × D 125 × 125 × 36 (mm)
Approval VdS G204103

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
M400DKMx-AS_DBL_LST_EN_0804.PDF • PAGE 2
ABuilding Safety. Building Security.
Manual call point red
Colour fl ame red, RAL 3000
Order number 245022
Order name Manual Call Point/Red/RF M400DKMR-AS
Manual call point blue „HAUSALARM“
Colour blue, RAL 5015
Order number 245023
Order name Manual Call Point/Blue/RF M400DKMB-AS
Lithium battery
Order number 310021
Order name Lithium Battery 3.6V/2.2Ah
