Phonic AURRAS 6A User manual
PHONIC
AURRAS
6A
AURRAS
8A
Powered Nearfield Studio Monitor 有源监听喇叭
PHONIC
1.
7 .
1
V1 .0
3
0/05/2022
2
i
=
�iH*
3
Aurras 6A / Aurras BA Aurras 6A / Aurras BA
4
PIN 1
PIN 2
PIN 3:
SV /2 30V).
•�:
□
□
Aurras 6A / Aurras BA Aurras 6A / Aurras BA
PHONIC保有资料内容修改无需事先通知的权利！
型号 Aurras 6A Aurras 8A
类型 两音路有源监听喇叭 两音路有源监听喇叭
高音单体 1’’ 丝绸柔软球顶 1’’ 丝绸柔软球顶
低音单体 6.5’’ 酰胺纤维 8’’ 酰胺纤维
频率响应 (+/-3dB) 55 Hz - 20 kHz 45 Hz - 20 kHz
高音功放 (瓦特数) 28W 36W
低音功放 (瓦特数) 45W 75W
输入敏感度 - 2 dBu - 2 dBu
高音调整 (-2 dB, -1 dB, FLAT, +1 dB) (-2 dB, -1 dB, FLAT, +1 dB)
输入端
RCA, 平衡 1/4" TRS, 平衡
XLR
RCA, 平衡 1/4" TRS, 平衡
XLR
分频点 1.9 kHz 1.8 kHz
最大音压 90dB 100dB
颜色 黑/白黑/白
尺寸 (宽x 高x 深) 270 x 230 x 320 mm 310 x 270 x 380 mm
重量 9.2 Kg 12.6 Kg
6 7
Aurras 6A / Aurras BA Aurras 6A / Aurras BA
http://www.phonic.com
服務與維修
服務與維修
保修
客戶服務和技術支持
如需更換零件,服務和維修,請聯繫您所在國家的Phonic代理商。Phonic不向用戶提供
維修手冊,且建議用戶不要擅自維修机器,否則將无法獲得任何保修服務。您可登錄
https://www.phonic.com/index.php/where-to-buy查找璃您最近的代理商。
Phonic承諾對每件產品提供完善的保修服務。根據所在地區的不同，保修時間或有延
長。自原始購買之日起，Phonic即對在嚴格遵照使用說明書的操作規範下，因產品材
質和做工所產生的問題提供至少1年的保修服務。Phonic可根據保修條例自行選擇維
修或更換缺陷產品。請務必妥善保管購買憑證，以此獲得保修服務。保修服務只適用
于正常使用下所產生的問題。用戶須嚴格遵照使用說明書正確使用產品，任何因肆意
損壞、擅自維修、意外事故、錯誤使用或人為疏忽所造成的問題，都不再保修受理範
圍之內。此外，擔保維修只適用于在授權代理商處的有效購買。如需了解全部保修信
息，請登錄http://www.phonic.com/。
敬請訪問http://www.phonic.com/support/。從該網站上，您可獲得各種常見問題的
解答，技術指導，並可下載產品驅動，獲得有關退貨指導以及其它有用的信息。我們
將竭盡全力在兩個工作日內回復您的問題。
8 9
ENGLISH
GE
10
IMPORNT SAFETY INSTRUCTIONS
11
10. IMPORTANT SAFETY INSTRUCTIONS
11. REAR PANEL
12. REAR PANEL
13. CONNECTIONS
14. CONNECTIONS
15. ADJUSTING THE VOLUME/TREBLE
1
6
. TECHNICAL INFORMATION
1
7
. SERVICE AND REPAIR
V1 .0
3
0/05/2022
12
REAR PANEL
-
REAR PANEL
13
Aurras 6A / Aurras BA Aurras 6A / Aurras BA
14
CONNECTIONS
CONNECTIONS
15
Aurras 6A / Aurras BA Aurras 6A / Aurras BA
Model Phonic Aurras 6A Phonic Aurras 8A
Type
Studio Monitor Studio Monitor
HF Drivers 1’’ Silk soft dome 1’’ Silk soft dome
LF Drivers 6.5’’ Glass Aramid cone 8’’ Glass Aramid cone
Frequency Response (+/-3dB) 55 Hz - 20 kHz 45 Hz - 20 kHz
High Frequency Rated Power
(Watt)
28W 36W
Low Frequency Rated Power
(Watt)
45W 75W
Input Sensitivity - 2 dBu - 2 dBu
HF Contour Control (-2 dB, -1 dB, FLAT, +1 dB) (-2 dB, -1 dB, FLAT, +1 dB)
Audio Input
RCA, Balanced 1/4" TRS,
Balanced XLR
RCA, Balanced 1/4" TRS,
Balanced XLR
Crossover 1.9 kHz 1.8 kHz
Maximum SPL 90dB 100dB
Color Black/White Black/White
Dimension (W x H x D) 270x 230 x 320 mm 313 x 268 x 383 mm
Weight 9.2 Kg 12.6 Kg
Phonic preserves the right to improve or alter any information
within this document without prior notice
Powered Nearfield Powered Nearfield
16 17
Aurras 6A / Aurras BA Aurras 6A / Aurras BA
http://www.phonic.com
SERVICE AND REPAIR
SERVICE AND REPAIR
WARRANTY INFORMATION
CUSTOMER SERVICE AND TECHNICAL SUPPORT
For replacement parts, service and repairs please contact the Phonic distributor in
your country. Phonic does not release service manuals to consumers, and advice
users to not attempt any self repairs, as doing so voids all warranties. You can
locate a dealer near you at https://www.phonic.com/index.php/where-to-buy.
Phonic stands behind every product we make with a no-hassles warranty. Warranty
coverage may be extended, depending on your region. Phonic Corporation warrants
this product for a minimum of one year from the original date of purchase against
defects in material and workmanship under use as instructed by the user’s manual.
Phonic, at its option, shall repairor replace the defective unit covered by this
warranty. Please retain the dated sales receipt as evidence of the date of purchase.
You will need it for any warranty service. No returns or repairs will be accepted
without a proper RMA number (return merchandise authorization). In order to keep
this warranty in effect, the product must have been handled and used as prescribed
in the instructions accompanying this wattanty. Any tampering of the product or
attempts of self repair voids all warranty. This warranty does not cover any
damage due to accident, misuse, abuse, or negligence. This wattanty is valid only
if the produet was purchased new from an authorized Phonic dealerldisributor. For
complete warranty policy information please visit http://www.phonic.com/.
We encourage you to visit our online help at https://www.phonic.com/index.php/sup-
port/digital-mixers. There you can findanswers to frequently asked questions, tech tips,
driver downloads, returns instruction and otherhelpful information. We make every
effort to answer your questions within one business day.
