PiModules UPS PIco HV3.0 HAT User manual

UPS PIco HV3.0 HAT
Versions Stack/TopEnd/Plus/PPoE
Uninterruptible Power Supply with Peripherals
and I2C control Interface
User Guide
Designed for the Raspberry Pi® 3
Compatible with
Raspberry Pi® 2, Pi Zero, A+, B+,
HAT Compliant
“Raspberry Pi” is a trademark of the Raspberry Pi® Foundation

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
Document Revisions
Version
Date
Modified Sections
Comments
na
06/11/2016
na
First Preliminary Public Document Release
1.0
07/06/2017
all
Public Document Release
Table 1 Document Revisions

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
Table of Contents
DOCUMENT REVISIONS......................................................................................................................1
UNLOCKED FIRMWARE FEATURES .....................................................................................................5
FIRMWARE AND MANUAL FIXES/ADD ON .........................................................................................6
SYSTEM OVERVIEW.......................................................................................................................... 10
INTRODUCTION.......................................................................................................................................10
UPS PICO HV3.0 ADD-ON EQUIPMENT .....................................................................................................13
UPS PICO HV3.0 MODELS ......................................................................................................................14
UPS PICO 3.0 HAT CORE FEATURES..........................................................................................................15
UPS PICO 3.0 HAT TECHNICAL SPECIFICATIONS...........................................................................................18
SETTING UP PROCEDURE.................................................................................................................. 22
WHAT IS IN THE BOX?.............................................................................................................................22
HARDWARE SETUP FOR THE UPS PICO HV3.0 HAT STACK/TOPEND/PLUS .......................................................23
Hardware Interfacing/Interaction with Raspberry Pi® ..................................................................26
Assembly of the THT 40 Pins (2x20) connector ..............................................................................28
Assembly of the FAN Kit.................................................................................................................32
Assembly of the Buzzer (Sounder)..................................................................................................39
Assembly of the Gold-Plated Hardware Reset Pin (POGO Pin) ......................................................41
Assembly of the Bi-Stable Relay.....................................................................................................47
Power Supply Unit Recommendations ...........................................................................................52
SOFTWARE SETUP FOR UPS PICO HV30 STACK/TOPEND/PLUS ......................................................................53
Installation of the Operating System (Raspbian) ...........................................................................53
Installation Procedure of Daemons and email broadcasting System ............................................53
Installation Procedure of the UPS PIco HV3.0 Hardware RTC ........................................................56
Automatic Installation Scripts........................................................................................................57
BOOTLOADER FEATURE –KEEP THE SYSTEM UP TO DATE .................................................................................58
Firmware updates Procedure of the UPS PIco HV3.0 (on RPi3) .....................................................59
Serial Port disable Procedure .........................................................................................................59
Automatic Bootloader Initiation ....................................................................................................60
Manual Bootloader Initiation ........................................................................................................61
Post-Firmware Update procedure..................................................................................................62
USING THE UPS PICO HV3.0 HAT ...................................................................................................... 63
RUNNING THE SYSTEM FOR THE FIRST TIME ..................................................................................................63
SYSTEM FUNCTIONALITY AND FEATURES ......................................................................................................64
SYSTEM COLD START,WARM START,DEFAULT START,AND UPS LEDS BEHAVIORS.............................................65
Cold Start .......................................................................................................................................65
Warm Start ....................................................................................................................................65
Default Start ..................................................................................................................................65
BATTERY POWERING PROTECTION..............................................................................................................66
POWERING MODES .................................................................................................................................66
Example of use...............................................................................................................................67
UPS PICO HV3.0 HAT LOW POWERING FUNCTIONALITY –POWER CYCLING .....................................................67
Raspberry Pi® Shutdown Scenarios................................................................................................67

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
“PICO IS RUNNING”FEATURE....................................................................................................................67
Example of use...............................................................................................................................68
USER SELECTABLE PICO HV3.0 I2C ADDRESSES ............................................................................................68
Example of use –System is in DEFAULT addresses ........................................................................69
Example of use –System is in ALTERNATE addresses ....................................................................69
SUDO I2CSET -Y 10X5B 0X00 0XA0 SET THE SYSTEM TO DEFAULT MODE .......................................................69
UPS PICO HV3.0 HAT STILL ALIVE (STA) FUNCTIONALITY ............................................................................69
Example of use...............................................................................................................................70
UPS PICO HV3.0 HAT USER APPLICATIONS HARDWARE INTERFACES ............................................... 70
UPS PICO HV3.0 HAT LEDS...................................................................................................................72
Example of use...............................................................................................................................73
UPS PICO HV3.0 ABUTTONS ..................................................................................................................74
USER BUTTONS (KEYS).............................................................................................................................76
Example of use...............................................................................................................................77
UPS PICO HV3.0 HAT SOUND GENERATION SYSTEM ...................................................................................78
Example of use...............................................................................................................................78
UPS PICO HV3.0 BI STABLE RELAY............................................................................................................80
Bi Stable Relay Basic Technical Specifications ...............................................................................80
Example of use...............................................................................................................................82
UPS PICO HV3.0 HAT IR RECEIVER INTERFACE ...........................................................................................83
UPS PICO HV3.0 HAT PROGRAMMABLE AUXILIARY 5V@750 MAAND 3.3V@150 MAINTERFACE....................83
Example of use...............................................................................................................................83
UPS PICO HV3.0 SERIAL PORT(S) .............................................................................................................85
Example of use...............................................................................................................................85
UPS PICO HV3.0 FAN CONTROL (ACTIVE COOLING SYSTEM) ........................................................................86
Example of use –Manual FAN ON/OFF .........................................................................................87
Example of use –Automatic FAN ON/OFF .....................................................................................87
UPS PICO HV3.0 BATTERY TYPE SELECTION................................................................................................87
0x6B -> UPS PIco Module Commands ............................................................................................88
Example of use...............................................................................................................................89
UPS PICO HV3.0 HAT MEASURING AND MONITORING SYSTEM ....................................................... 89
POWERING MODE..................................................................................................................................90
BATTERY LEVEL.......................................................................................................................................91
RASPBERRY PI®GPIO 5V LEVEL ...............................................................................................................92
EXTERNAL POWERING LEVEL .....................................................................................................................92
UPS PICO HV3.0 12-BIT A/D CONVERTERS ................................................................................................92
Example of use...............................................................................................................................95
Registers Located at 0x69 I2C address related to A/D readings ....................................................95
Registers Located at 0x6B I2C address related to A/D settings .....................................................95
EMBEDDED NTC TEMPERATURE.................................................................................................................96
TO-92 SENSOR TEMPERATURE..................................................................................................................96
INTEGRATED CHARGER STATUS ..................................................................................................................96
UPS PICO HV3.0 SYSTEM TIME SCHEDULERS ....................................................................................97
BASIC SCHEDULER ...................................................................................................................................98
BS Definitions .................................................................................................................................98
Basic Scheduler Involved PICo Registers/Sets ................................................................................99

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
BS Example 1st - Simple Raspberry Pi® ON/OFF executed infinitive times for 1 minutes (ON/OFF
every minute) ...............................................................................................................................101
BS Example 2nd- Simple Raspberry Pi® ON/OFF executed 100 times for 1 minutes (ON/OFF every
minute).........................................................................................................................................102
EVENTS TRIGGERED RTC BASED SYSTEM ACTIONS SCHEDULER ......................................................................103
ETR SAS Definitions ......................................................................................................................103
ETR SAS Definitions Dependencies ...............................................................................................104
Raspberry Pi® ETR SAS Self Programming....................................................................................104
Template for ETR SAS preparation...............................................................................................105
ETR SAS Involved PICo Registers/Sets ..............................................................................................0
ETR SAS Working Examples..............................................................................................................1
Definition of the 1st Example - Simple Raspberry Pi® ON/OFF Schedule executed 1 time for 1
minutes and repeated every day .....................................................................................................2
Definition of the 2nd Example - Simple Bi-Stable Relay ON/OFF Schedule executed 1 time for 3
minutes and repeated every day. ....................................................................................................4
Definition of the 3rd Example - Simple Raspberry Pi® ON/OFF Schedule executed 60 times for 1
minute every 2 minutes and repeated every day.............................................................................6
SETTING-UP THE ETR SAS ..........................................................................................................................8
Setting Up of the 1st Example - Simple Raspberry Pi® ON/OFF Schedule executed 1 time for 1
minute and repeated every day .....................................................................................................10
Setting Up of the 2nd Example - Simple Bi-Stable Relay ON/OFF Schedule executed 1 time for 15
minutes and repeated every day. ..................................................................................................15
FACTORY DEFAULTS SETTING........................................................................................................... 18
Command Line Factory (automatic) recall.....................................................................................18
Manually Factory Defaults recall ...................................................................................................18
UPS PIco HV3.0 HAT settings on Factory Defaults recall ...............................................................18
A COMPLETE DESCRIPTION OF THE UPS PICO HV3.0 HAT PROGRAMMERS REGISTERS ....................20
THE PICO (I2C) INTERFACE -PERIPHERALS I2C CONTROL INTERFACE ................................................................20
0X69 ->UPS PICO HV3.0 MODULE STATUS REGISTERS SPECIFICATION............................................................21
0X6A -> UPS PICO HARDWARE RTC REGISTERS DIRECT ACCESS SPECIFICATION.................................................23
0X6B -> UPS PICO MODULE COMMANDS ..................................................................................................24
EVENTS TRIGGERED RTC BASED SYSTEM ACTIONS SCHEDULER COMMANDS................................... 30
0x6c -> Start Time Stamp...............................................................................................................30
0x6d -> Actions Running Time Stamp ............................................................................................30
0x6e -> Events Stamp.....................................................................................................................30
0x6f -> Actions Stamp ....................................................................................................................30
UPS PICO TERMINAL BLOCK PCB ......................................................................................................32
INTRODUCTION.......................................................................................................................................32
WHAT IS A VOLTAGE FOLLOWER? ..............................................................................................................35

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
Unlocked Firmware Features
Version
Date
Active Features
Initial
Initial
Interrupts driven interaction with Raspberry Pi® based on Daemons
Initial
Initial
Simple status email broadcasting system based on Daemons
Initial
Initial
Intelligent Uninterruptible Power Supply (UPS)
Initial
Initial
3 User defined keys handler
Initial
Initial
3 User defined LEDs handler
Initial
Initial
LiPO and LiFePO4 chemistry battery support
Initial
Initial
Automatic Battery Charger for LiPO and LiFePO4 batteries
Initial
Initial
Battery Charger Power Tracking (Only Version Plus on External Powering Input)
Initial
Initial
Integrated Hardware RTC with Battery Back-up
Initial
Initial
Automatic Files Safe Shutdown and Wake-up (when Cable Power is back)
Initial
Initial
Single button System Shutdown/Startup and ON/OFF for Battery and Cable (Only
Version Plus) Powered Applications
Initial - 0x30
Initial/15.03.2017
PWM FAN Control with automatic ON/OFF (added on 15.03.2017)
Initial
Initial
Zero Power Bi Stable Relay Control
Initial
Initial
Programmable Integrated Sounder
Initial
Initial
System Monitoring: Temperatures, Voltages
Initial
Initial
Programmers I2C PICo Interface
Initial
Initial
Programmers RS232 Interface (Basic Version)
Initial
Initial
Boot loader for onsite firmware update
Initial
Initial
3 x A/D converters (Basic Version, without high voltage interface)
0x30
15.03.2017
3 x A/D converters Raw Data (without conversion to Voltages)
0x30
15.04.2017
Programmable Auxiliary Battery Backed up 5V@750mA and 3.3V@150mA supply
0x34
15.04.2017
User Selectable PIco HV3.0 I2C addresses (NORMAL, NO_RTC, ALTERNATE)
0x35
20.05.2017
Activated Still Active Timer (watch-dog for the Raspberry Pi)
0x39
15.07.2017
Activated Events Triggered RTC Based System Actions Scheduler
Table 2 Unlocked Firmware features

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
Firmware and Manual Fixes/Add on
Version
Code
Date
Firmware and Manual Fixes and Add-ons
0x24
24.001
15.01.2017
Enable/Disable and set data rate of the PIco RS232 is now working. Fixed default to
disabled RS232. Fixed data rate programmable by user written to PIco EEPROM. Usage
is described in the manual in a proper section.
0x24
24.002
15.01.2017
Activated Register charger at 0x69 and address 0x20 informing user if battery charger
is ON or OFF. Usage is described in the manual in a proper section.
0x24
24.003
15.01.2017
Corrected bug with low battery threshold shutdown for LiPO and LiFePO4 batteries, to
2.95V and 3.5 V
0x24
24.004
15.01.2017
Added full LiFePO4 battery charger cutoff @3.75V
0x24
24.005
15.01.2017
Added for LiPO and LiFePO4 battery charger trickle charging starts up threshold to 4.1V
and 3.6V respectively. This threshold is in additional controlled by the charger IC itself.
0x24
24.006
15.01.2017
User Manual re-structure
0x24
24.007
15.01.2017
Activated Register key at 0x69 and address 0x1A informing user about the pressed
User Key (A, B or C). Usage is described in the manual in a proper section.
0x24
24.008
15.01.2017
Changed Battery Powering Backup activation threshold from 4.75V on 5V GPIOs to
4.65V
Remark: Now the UPS PIco HV3.0 is checking the following conditions for Battery
Power Backup activation on the following conditions:
1. Continuously Fast Falling Powering Edge Monitoring (proprietary algorithm)
2. GPIO 5V powering is unconditionally lower than 4.65V
This will help when used lower quality PSUs that are giving higher voltage drop than
should be when system is loaded.
In any case we strongly recommend using PSU with micro USB cable on the same body
with the PSU, and minimum, recommend 3A.
0x24
24.009
15.01.2017
Corrected (and activated) option with Battery Voltage measure batlevel at 0x69 and
address 0x08 informing user about It. This option was temporary (in former version of
firmware - 0x18) disabled to rewrite firmware part procedures from floating point
arithmetic to fixed one, in order to decrease memory footprint and system speed-up.
Usage is described in the manual in a proper section.
0x24
24.010
15.01.2017
Corrected (and activated) option with Raspberry Pi Voltage measure rpilevel at 0x69
and address 0x0a informing user about It. This option was temporary disabled to
change firmware from floating point arithmetic to fixed one, in order to decrease
memory footprint and system speed-up. Usage is described in the manual in a proper
section.
0x24
24.011
15.01.2017
Corrected (and activated) option with Raspberry Pi Voltage measure eprlevel at 0x69
and address 0x0c informing user about It. This option was temporary disabled in order
to change firmware from floating point arithmetic to fixed one, in order to decrease
memory footprint and system speed-up. Usage is described in the manual in a proper
section.
0x24
24.012
15.01.2017
Corrected (and activated) option for the first A/D converter pre-scaled to 5.2V at 0x69
and address 0x14. This option was temporary disabled to change firmware from

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
floating point arithmetic to fixed one, to decrease memory footprint and system speed
up. Higher Voltage could not be supplied to this A/D converter. Readings are in 10th of
mV in BCD format. Usage is described in the manual in a proper section.
0x24
24.013
15.01.2017
Corrected (and activated) option for the first A/D converter pre-scaled to 5.2V at 0x69
and address 0x16. This option was temporary disabled to change firmware from
floating point arithmetic to fixed one, to decrease memory footprint and system speed
up. Higher Voltage could be supplied to this A/D converter when added an extra
resistor and set a proper variable in the PICo interface. Readings are in 10th of mV in
BCD format. Usage is described in the manual in a proper section. The High Voltage
Conversion interface is not activated yet.
0x24
24.014
15.01.2017
Corrected (but not activated) option for the first A/D converter pre scaled to 5.2V at
0x69 and address 0x18. This option was temporary disabled to change firmware from
floating point arithmetic to fixed one, to decrease memory footprint and system speed
up. Higher Voltage could be supplied to this A/D converter when added an extra
resistor and set a proper variable in the PICo interface. Readings are in 10th of mV in
BCD format. Usage is described in the manual in a proper section. The High Voltage
Conversion interface is not activated yet.
0x24
24.015
15.01.2017
Corrected the option with PIco Serial Port Data Rate selection and
activation/deactivation (RS232) rs232_rate at 0x6B and address 0x02. Default option
is PIco RS232 is disabling (available for user applications). Usage is described in the
manual in a proper section.
0x24
24.016
15.01.2017
Corrected (activated) Battery Selection independent of the boot loader pre-settings.
0x24
24.017
15.01.2017
Improved the cable reentry recognition time, checking is every 5 seconds
0x30
30.018
24.01.2017
Changed low battery thresholds shutdown for LiFePO4 batteries from to 2.95V to 2.9V.
Now for battery LiFePO4 BAT LED is now lighting at 2.95 V, and FSSD is at 2.9V. For
battery LiPO BAT LED is now lighting at 3.6 V, and FSSD is at 3.4V.
0x30
30.019
24.01.2017
PIco HV3.0 Plus: Corrected bug when executed command in Raspberry Pi “sudo halt”
system not goes to the Low Powering Mode when powered from External Powering
Input. Now System is going to Low Powering Mode, and cut the cable power when
“sudo halt” is executed. If “sudo reboot” is executed system restarts the Raspberry Pi.
When system is in Low Powering Mode, can be wake up if:
- any cable power applied or change their conditions (EXT, micro USB or GPIO 5V)
- Fbutton pressed
0x30
30.020
24.01.2017
Changed waiting time for reboot or shutdown, if console command has been executed
“sudo halt” or “sudo reboot” from 300 secs (as it was) to 90 sec now.
0x30
30.021
28.01.2017
Improved the Powering Falling Edge Recognition algorithm
0x30
30.022
28.01.2017
Improved the A/D converter filtering software by using (adding) the “Olympic Scoring”
implementation on each A/D sampling interrupt instead of the former used
“windowed mean value” method
0x30
30.023
10.02.2017
Added software low pass filter to each of the PIco HV3.0 A/D converters (users and
system)
Added decimal rounding on second position after comma to each A/D Voltage
Translator readings (0x69 Registers Set). Each A/D reading converted to
voltage/temperature/current are valid on the first position after comma. Therefore the
4.16V is shown as 4.20V, 4.12V is shown as 4.10V.

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
0x30
30.024
15.02.2017
Improved Keys recognition routine
0x30
30.025
25.02.2017
Improved the de-bouncing filter on the ISR of the pulse train input recognition
0x30
30.026
28.02.2017.
Improved the TO-92 temperature sensor readings and conversion
0x30
30.027
05.03.2017
Improved the NTC temperature sensor readings and conversion
0x30
30.028
10.03.2017
Corrected (and activated) option for the first A/D converter pre-scaled to 5.2V at 0x69
and address 0x16. This option was temporary disabled to change firmware from
floating point arithmetic to fixed one, to decrease memory footprint and system speed
up. Higher Voltage could be supplied to this A/D converter when added an extra
resistor and set a proper variable in the PICo interface. Readings are in 10th of mV in
BCD format. Usage is described in the manual in a proper section. The High Voltage
Conversion interface is not activated yet.
0x30
30.029
11.03.2017
Improved LF batteries charging algorithm
0x30
30.030
12.03.2017
Improved wake up procedure from sleep mode when Raspberry Pi is starting up
0x30
30.031
12.03.2017
I2C ISR Improved and tested to be workable with new preliminary kernel 4.9.11
0x30
30.032
12.03.2017
Added option for the all 3 A/D converters a Raw Data Readings, with internal Reference
to 2.048V (always with Internal Resistors divider presented on a dedicated manual
part). Each reading is passed from the “Olympic Score filtering” as also software Low
Pass Filter. There are not rounded as also not converted to voltage. Just raw data. In
order to ready the user, need to write the 0xFF to the setA_D register.
0x30
30.033
13.03.2017
Improved the Dynamic Power Tracking and separated currents for micro USB and
External Powering with different current thresholds. The EPR has higher current 800
mAh
0x30
30.034
14.03.2017
Activated enable 5V. The usage of it is described in detailed in a proper manual section
0x30
30.035
15.03.2017
Improved storage/recall of system variables in the internal UPS PIco HV3.0 HAT
EEPROM
0x30
30.036
15.03.2017
Activated automatic FAN controls, set as default option, temperature thresholds are:
35 Celsius for ON and 34 Celsius for OFF (1 Celsius hysteresis). User can change the
threshold; however, the hysteresis will be always 1 Celsius. Default the FAN speed is
set to 50%, user can change it. FAN is NOT working when system is in Low Powering
Mode
0x30
30.037
17.03.2017
Updated the default Start-up/EEPROM Stored Values
0x30
30.038
18.03.2017
Added LED OFF, which switches OFF all software, controlled LEDs. CHG, FAN, EXT
cannot be switched off as are connected to the hardware and controlled by it. By
writing the 0x00 to LEDOFF disable the LEDs. Default is 0x01 (means LED ON)
0x31
31.039
20.03.2017
Significantly improved the switching ON of the integrated battery charger IC.
0x32
32.040
10.04.2017
Corrected bug (generated in the 0x30) with RS232 deactivation. Now the if the RS232
is deactivated for PIco (and free for Raspberry Pi Applications) the TXD and RXD pins
are HiZ and not High Level like before.
0x32
32.041
15.04.2017
Internal Improvements making system more robust and smaller

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
0x32
32.042
15.04.2017
Corrected bug with remain voltages on auxiliary 5V@750 mA and 3.3V@150 mA. Now
when auxiliary voltages are off, are exact 0V, and when battery backed up are
respectively 5V and 3.3V
0x35
35.043
01.05.2017
Added Extra Option moving/changing the UPS PIco HV3.0 I2C addresses base to the
following: DEFAULT, NO_RTC, and ALTERNATE.
0x35
35.044
01.05.2017
Improved the low pass filter in the EPR measure system to have more stable and
accurate reading
0x35
35.045
01.05.2017
Final I2C ISR Improvements and tested to be workable with new kernel 4.9.11 including
sometimes I2C handler after Low Powering Mode (sometimes not working properly)
0x35
35.046
20.05.2017
Activated Still Active Timer (watch-dog for the Raspberry Pi)
0x36
36.047
25.05.2017
Improved the Factory Defaults Procedure
0x36
36.048
25.05.2017
Improved de-bouncing procedure for user keys
0x36
36.049
25.05.2017
Improved Interrupts Nesting Handler
0x37
37.050
10.06.2017
Improved Low Powering Mode entering
0x39
39.051
15.07.2017
Activated Events Triggered RTC Based System Actions Scheduler
0x40
40.052
20.07.2017
Activated Disable/Enable of Sounder System Audio information
0x40
40.053
20.07.2017
System Messaging Texts Simplified (shorted)
Table 3 Firmware and Manual Fixes/Add on

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
System Overview
Introduction
The UPS PIco HV3.0A is an advanced uninterruptible power supply designed for the for the
Raspberry Pi® 3 (but compatible also with the Raspberry Pi 2, and Raspberry Pi Zero) that
adds a wealth of innovative power back-up functionality and development features to the
innovative micro-computer!
Offers now total 3A current from the External Power Supply or battery backup, 3User Keys, 3
User LEDs, 3 different types of high capacity batteries, 2 x 3pins bi-stable relay (Zero Power),
as also 3 x A/D 12 bit converters with pre adjustable readings to 5V, 10V, 20V and 30V
conversion (when used with Terminal Blocks PCB or separate external resistor). Now, with
additional External Supply Powering Input; that has implemented Dynamic Power Tracking;
automatically adjust battery charging current according to power availability from 100mA –
1000 mAh, to use all available energy from the Solar Panel in case of use. This feature has
been especially designed to support Solar Panel Powering Raspberry Pi® Systems, as it is
adjusting the charging battery current to available Sunning conditions. The External Supply
Powering Input is able to accept power from 7 V DC up to 28 V DC!! Thus, make it ideal for
Cars, Trucks, Buses and any industrial applications where voltage is usually higher than 24V
DC. The External Supply Powering Input is equipped with Over Current protection, Over
Voltage as also with Zero Voltage Drop Inverse Polarity Protection protecting Raspberry Pi
System form improper usage, but due to zero voltage drop to use all available energy from
the Solar Panel in case of use. The New UPS PIco HV3.0A is an all-in-one tool that allows
implementing easy and fast simple applications as also complicated projects providing a set
of pre-installed peripherals.
The UPS PIco HV3.0A is standard equipped with a 450 mAh 15C LiPO battery specially
designed to enable safe shutdown during cabled power cut and automatic system restart
when cabled power comes back. The included battery provides enough energy to keep
running system for 10-15 minutes in case of absence of the cable power. Additionally, this can
be easily upgraded to the extended 4000mAh version, 8000 mAh as also 12000 mAh batteries
(optional on special request), which enables prolonged use of a Raspberry Pi for more than
32 hours without a power supply connected (with biggest battery installed)!
The UPS PIco HV3.0A design support now batteries with different chemistry: LiPO as also
LiFePO4.Especially the LiFePO4 batteries are addressed to applications where temperatures
environment is more restricted as can be used for supplying from -10 degrees up to +60
degrees. In addition, the LiFePO4 have a unique extremely long life of charging/discharging
that can achieve up to 2000 cycles!!
The implemented trimmed Hardware Real Time Clock and Calendar, guarantees time stamp
when system is running without access to the Network. The Hardware RTCC is backed up and
powered from the integrated system battery.
The integrated Hardware RTCC enables a new extremely usefully feature –the Events
Triggered RTCC Based System Actions Scheduler. The Events Triggered RTCC Based System
Actions Scheduler allows to timely start up, or shutdown the Raspberry Pi® on various internal

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
or external events that include, data available on RS232, IR, A/D, RTCC, and temperature, Opto
Coupled Input or just on requested Time Stamp.
Professional developers often need to protect their application. To support them UPS PIco
HV3.0A offers the XTEA dual path encryption (on read and write path) embedded engine that
protect the developed software with the secure code.
The UPS PIco HV3.0A 450 mAh Stack Plus offers 2.6A battery power backup for the Raspberry
Pi® via GPIOs as also 3A extended power supply, but not only. In addition is offered an
independent from the Raspberry Pi® powering, battery backed output of 5V@750 mA and
3.3V available for the user devices connected to the Raspberry Pi® that must be running even
if the mother Raspberry Pi® is shut down and not powered (i.e. USB powered HUBs, WiFi
Routers, Motion Detectors, HDDs etc). The total current cannot exceed 3A. The current supply
delivered via GPIOs to the Raspberry Pi® is 2.6A
Many applications need to have secondary RS232 in addition to the primary one offered by
the Raspberry Pi®. Until today, it has been solved by users with add-on hardware put on the
top. Not anymore!! With the UPS PIco HV3.0A user have access to integrated secondary serial
port 3.3V level but save also to be used with 5V level. This makes the developed application
cost effective and more robust
Now with additional Terminals Blocks Add-on PCB UPS PIco HV3.0A offers a professional I/O
connectivity for any industrial application including 12V level converter for both Serial Ports
(one of them must be selected).
The Zero Power Bi Stable Relay offers two independent sets of terminals, each one offers up
to 1A contacts able to switch ON/OFF various peripherals of the developed system. Due to
unique design, no power is required when Bi Stable Relay is in Set/Reset state, making it ideal
for battery powered applications. Two independents 3 pins sets offered (NC, NO, CO) are
switched at the same time and are able to relay 2 independent applications.
Now, the high voltage signal can be monitored safely with the Opto Coupled interface, which
can be read as digital as also analogue input.
The IoT developers will find useful the 3 ESD protected 12 bits buffered A/D converters as
also number of internal sensors and sensor interfaces that can be used for system monitoring
such as Battery Voltage, External Powering Voltage, Raspberry Pi Voltage, Current
Consumption,System Temperature and 1-wire interface.
Especially with the added Terminals Blocks Add-on PCB user can preset A/D converters to
scaled measure of 5V, 10V, 20V, as also 30 V with a simple jumper selection or external
resistor. In addition, the Terminals Blocks Add-on PCB offers one A/D converter followed
voltage follower with input impedance of 1M Ohm, allowing very high impedance sensors
connectivity.
The UPS PIco HV3.0A can also be equipped with an optional Infra-Red Receiver which is
routed directly to GPIO18 via the PCB. This opens the door for remote operation of the
Raspberry Pi® and UPS PIco HV3.0A including remotely ON/OFF.

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
The embedded Electromagnetic Programmable Sounder can be used as a simple buzzer but
also as music player due to implemented sound generator and dedicated programmer
interface.
Finally, the UPS PIco HV3.0A features an implemented Automatic Temperature Control PWM
FAN controller, and can be equipped with a micro fan kit, which enables the use of the
Raspberry Pi® in extreme conditions including very high temperature environments. The FAN
speed can be manually/automatically adjusted according to system temperature conditions
linear from 0 % (FAN is OFF) up to 100% by increasing and decreasing rotation speed. Thus,
guarantees the possible lowest level of noise and always cool Raspberry Pi® 3.

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
UPS PIco HV3.0 Add-On equipment
The UPS PIco HV3.0 can be combined with additional already available parts. There are:
1. UPS PIco HV3.0 Fan Kit
2. UPS PIco HV3.0 Relay Kit
3. LiPO Battery 4000 mAh
4. LiPO Battery 8000 mAh
5. LiFePO4 Battery 4000 mAh
6. LiFePO4 Battery 8000 mAh
7. LiFePO4 or LiPO 12000 mAh (only on special order)
8. Terminal Blocks PCB
9. Dedicated UPS PIco HV3.0 Plexiglas case for battery 4000 mAh LF or LP

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
UPS PIco HV3.0 Models
The UPS PIco HV3.0 is available in 5 different models all based on the same PCB:
1. UPS PIco HV3.0 Stack
2. UPS PIco HV3.0 Stack Plus
3. UPS PIco HV3.0 Top End
4. UPS PIco HV3.0 PPoE (future option –not released yet)
5. UPS PIco HV3.0 Top End Plus (future option –not released yet)
The differences between each model are listed here below in the table with Technical
Specifications however the core features for all models are presented here below.

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
UPS PIco 3.0 HAT Core Features
The list of core features of the UPS PIco HV3.0 is as follows (for all models):
•Raspberry Pi B+ HAT Compliant
•Plug and Play –Ultra Simple Semi-Automatic Installation via GitHub
•Interrupts driven interaction with Raspberry Pi® based on Daemons
•Simple status email broadcasting system based on Daemons
•Intelligent Uninterruptible Power Supply (UPS)
•Integrated LiPO Battery (10-15 Minutes of System Power Back-Up)
•Intelligent Automatic Charger with Power Tracking (adjusting the battery
charging current according to power availability from 100 mA –1200 mA) -
implemented only in the UPS PIco HV3.0 Plus and PPoE
•No Additional External Power Input Required (if Stack/TopEnd is used)
•Optional 4000 or 8000 mAh Battery for 8 –16 Hours Run-Time (Not Included)
•Optional 12000 mAh Battery for extremely long Run-Time (Not Included –on
special request)
•Each High Capacity Battery comes with dedicated plastic screwed mounting base
•Support for LiPO and LiFePO4 batteries on the same PCB with simple command
switching
•5V 2.6A Power Backup (Short Peak Output 5V 3A)
•Integrated Hardware Real Time Clock (RTC) with Battery Back-Up
•Automatic File Safe Shutdown and Wake-up Functionality
•Single button System ON/OFF for battery powered applications
•Events Triggered RTC Based System Actions Scheduler (Triggered ON/OFF based
on RTC or External Events –voltage, RS232 data, A/D, IR etc)
•PWM fan control (Fan Not Included), FAN PWM interface is integrated on each
PIco HV3.0 PCB
•3 User Defined LEDs for their own user application
•3 User Defined Buttons for their own user application

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
•Separate TH Soldering Pads for each user button and FSSD for external button
connection
•Bi Stable Relay (Zero Power) with dual separated independent contacts
(Standard UPS PIco HV3.0 Plus or PPoE Only, optional for the UPS PIco HV3.0 )
•Additional 5V (independent from Raspberry Pi® powering) power source with
battery backup, available for user applications also when Raspberry Pi is OFF
(5V@750mA) protected with PPTC FUSE and reverse current flow diode
•Optical Isolated input (opto coupler) –readable also as A/D values (UPS PIco
HV3.0 Plus Only)
•Programmable Integrated Sounder for UPS and User Applications (able to play
music)
•Status Monitoring - Powering Voltage, UPS Battery Voltage, Current and
Temperature
•I2C PICo Interface for Control and Monitoring
•RS232 Raspberry Pi® Interface for Control and Monitoring
•Double path XTEA Based Cryptography for User Software Protection
•2 Level Watch-dog Functionality with FSSD and unconditional Hardware Reset
(if system Hangs-up)
•Extended Voltage Input 7-28V DC protected with zero voltage drop inverse
polarity protection (UPS PIco HV3.0 Plus Only)
•Direct Raspberry Pi® Hardware Reset Button via Spring Test Pin (Pogo pin)
•16 pins Stack-able Header for PIco Add-On Boards
•Boot Loader for Live Firmware Update
•Intelligent IR Remote Power ON/OFF (if IR received installed) (UPS PIco HV3.0
Plus Only, or system shutdown –all models)
•Infra-Red Receiver Sensor Interface (IR Not Included) directly connected to the
GPIO18
•Integrated EDS-Protected 3 Channel A/D 12 Bit Converters 0-5.2V (optional per-
scaled to 10V, 20V and 30V via Terminals Blocks PCB add-on or external resistor)
•Optional A/D converter with voltage follower (ideal for IoT applications) - via
Terminals Blocks PCB add-on boards to 16 pins header

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
•Integrated ESD-Protected 1-Wire Interface
•Programmable second RS232 interface (5V tolerant)
•12V RS232 interface via Terminals Blocks PCB
•Labeled J8 Raspberry Pi® GPIO Pins for Easy Plug & Play of experimental cables
•Fits inside to the Official Raspberry Pi® Case with closed lid (version Top End)
•Fits Inside Most Existing Cases

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
UPS PIco 3.0 HAT Technical Specifications
Features
UPS PIco HV3.0 A Models
UPS PIco HV3.0 A
Stack 450
UPS PIco HV3.0 A
Stack 450 Plus
UPS PIco HV3.0 A
TopEnd 450
Raspberry Pi®
Raspberry Pi® System Compatibility
Compatible Raspberry Pi Models
Designed for Raspberry Pi® 3
Compatible with
Pi2, Pi3, Pi Zero, A+, B+
Designed for Raspberry Pi® 3
Compatible with
Pi2, Pi3, Pi Zero, A+, B+
Designed for Raspberry Pi® 3
Compatible with
Pi2, Pi3, Pi Zero, A+, B+
Cases Compatibility
Cases
Most of the cases
ModMyPi cases
PiModules PIco case
Most of the cases
ModMyPi cases
PiModules PIco case
Most of the cases
Recommended Raspberry Pi
Original Case adopted to
Media Player Applications
Raspberry Pi® GPIO Usage (occupation)
Permanent use of I2C (User selectable
addresses)
GND, 5V, SDA0, SCL0
I2C Addresses 1: 68 69 6a 6b 6c
6d 6e 6f
I2C Addresses 2: 58 59 5a 5b 5c
5d 5e 5f
I2C Addresses 3: 69 6b
GND, 5V, SDA0, SCL0
I2C Addresses 1: 68 69 6a 6b 6c
6d 6e 6f
I2C Addresses 2: 58 59 5a 5b 5c
5d 5e 5f
I2C Addresses 3: 69 6b
GND, 5V, SDA0, SCL0
I2C Addresses 1: 68 69 6a 6b
6c 6d 6e 6f
I2C Addresses 2: 58 59 5a 5b
5c 5d 5e 5f
I2C Addresses 3: 69 6b
Selectable use of Raspberry Pi®
RS232
TXD0, RXD0
OFF(HiZ)
TXD0, RXD0
OFF(HiZ)
TXD0, RXD0
OFF (HiZ)
Selectable use of Raspberry Pi® GPIO
GPIO_GEN22 (pulse train
generator)
GPIO_GEN27 (System Shutdown
initiator)
GPIO_GEN18 (if IR receiver is
used)
GPIO_GEN4 (if 1-wire is used)
GPIO_GEN22 (pulse train
generator)
GPIO_GEN27 (System Shutdown
initiator)
GPIO_GEN18 (if IR receiver is
used)
GPIO_GEN4 (if 1-wire is used)
GPIO_GEN22 (pulse train
generator)
GPIO_GEN27 (System
Shutdown initiator)
GPIO_GEN18 (if IR receiver is
used)
GPIO_GEN4 (if 1-wire is used)
Interactions with Raspberry Pi®
Battery and Charger
Supported Batteries Types
LiPO 3.7V with silicone high
current cables
Standard - LiPO 450 mAh
Standard - LiPO 450 mAh
Standard - LiPO 450 mAh
(dedicated to be used with
Raspberry Pi Original Case)
Optional - LiPO 4000 mAh
Optional - LiPO 4000 mAh
Optional - LiPO 8000 mAh
LiFePO4 3.2V with silicone high
current cables
Optional –LiFePO4 4000
Optional - LiFePO4 4000 mAh
Optional - LiFePO4 8000 mAh
Optional - LiFePO4 12000 mAh
(due to big size of batter only on
special order)
Battery Life Charge/Discharge Cycles
LiPO
450 cycles
450 cycles
450 cycles
LiFePO4
2000 cycles
2000 cycles
2000 cycles
Battery Charger
Standard - Continues fixed
current 303 mAh
Automatic Dynamic Power
Tracing Charger with charging
Standard - Continues fixed
current 303 mAh

UPS PIco HV3.0A Firmware Code 040 Print Date 18.08.2017
Designed and Manufactured by PiModules and ModMyPi
www.pimodules.com www.modmypi.com
current 100 mA –1000 mA,
triggered by voltage changes on
the 5V GPIO or External Power
Source
Charging Modes
LiPO
Automatic Selected :
Full Charging Cycle
Trickle Charging
Automatic Selected :
Full Charging Cycle
Trickle Charging
Automatic Selected :
Full Charging Cycle
Trickle Charging
LiFePO4
Automatic Selected :
Full Charging Cycle
Trickle Charging
Automatic Selected :
Full Charging Cycle
Trickle Charging
Automatic Selected :
Full Charging Cycle
Trickle Charging
Battery Protection
450 mAh
On board cut-off
protection system
when thermal, overcharge or
over discharge
On board cut-off protection
system
when thermal, overcharge or
over discharge
On board cut-off
protection system
when thermal, overcharge or
over discharge
High Capacity LiPO and LiFePO4
On board cut-off
protection system
when thermal, overcharge or
over discharge
On battery, additional PCM
protection
On board cut-off protection
system
when thermal, overcharge or
over discharge
On battery PCM additional
protection
On board cut-off
protection system
when thermal, overcharge or
over discharge
On battery PCM
additional protection
Battery Electrical Isolation System
Battery is Electrically
Isolated (however cable
connected) until system
start up for the first time
and receive 5V from GPIO
Battery is Electrically
Isolated (however cable
connected) until system
start up for the first time
and receive 5V from GPIO
or 7-28V from EXT
Battery is Electrically
Isolated (however cable
connected) until system
start up for the first time
and receive 5V from
GPIO
Battery Back-Up
System Battery Backup
Standard –5V 2.6A current
continuous supply to Raspberry
Pi via GPIO Pins
Standard –5V 2.6A current
continuous supply to Raspberry
Pi via GPIO Pins
Standard –5V 2.6A current
continuous supply to
