Huawei UPS2000-H User manual

UPS2000-H-(6 kVA–10 kVA)
Quick Guide
Issue 01
Date 2022-06-30
HUAWEI DIGITAL POWER TECHNOLOGIES CO., LTD.

Copyright © Huawei Digital Power Technologies Co., Ltd. 2022. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Digital Power Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are the property of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei
Digital Power Technologies Co., Ltd. and the customer. All or part of the products, services and features
described in this document may not be within the purchase scope or the usage scope. Unless otherwise
specied in the contract, all statements, information, and recommendations in this document are
provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every eort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Digital Power Technologies Co., Ltd.
Address:
Website:
Huawei Digital Power Antuoshan Headquarters
Futian,Shenzhen 518043
People's Republic of China
https://e.huawei.com
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. i

About This Document
Purpose
This document describes the installation, cable connection, and power-on
commissioning for the UPS2000-H-(6 kVA–10 kVA) series.
Figures provided in this document are for reference only.
Intended Audience
This document is intended for:
● Technical support engineers
● Hardware installation engineers
● Commissioning engineers
Symbol Conventions
The symbols that may be found in this document are dened as follows.
Symbol Description
Indicates a hazard with a high level of risk
which, if not avoided, will result in death or
serious injury.
Indicates a hazard with a medium level of
risk which, if not avoided, could result in
death or serious injury.
Indicates a hazard with a low level of risk
which, if not avoided, could result in minor
or moderate injury.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide About This Document
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. ii

Symbol Description
Indicates a potentially hazardous situation
which, if not avoided, could result in
equipment damage, data loss, performance
deterioration, or unanticipated results.
NOTICE is used to address practices not
related to personal injury.
Supplements the important information in
the main text.
NOTE is used to address information not
related to personal injury, equipment
damage, and environment deterioration.
Change History
Issue Date Description
01 2022-06-30 This is the rst ocial release.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide About This Document
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. iii

Contents
About This Document................................................................................................................ ii
1 Installation and Cable Connection......................................................................................1
1.1 Installation Preparations....................................................................................................................................................... 1
1.1.1 Site Planning..........................................................................................................................................................................1
1.1.2 Tools......................................................................................................................................................................................... 3
1.1.3 Materials................................................................................................................................................................................. 5
1.1.4 Power Cables......................................................................................................................................................................... 5
1.1.5 Unpacking and Checking................................................................................................................................................ 10
1.2 Installing a Single UPS........................................................................................................................................................ 11
1.2.1 Rack-Mounted Installation............................................................................................................................................. 11
1.2.1.1 Installing the UPS and Lithium Batteries...............................................................................................................11
1.2.1.2 Installing the UPS and Lead-Acid Batteries.......................................................................................................... 12
1.2.2 Tower-Mounted Installation.......................................................................................................................................... 13
1.2.2.1 Installing the UPS and Lithium Batteries...............................................................................................................13
1.2.2.2 Installing the UPS and Lead-Acid Batteries.......................................................................................................... 15
1.2.3 Installing Cables................................................................................................................................................................. 17
1.2.3.1 Cable Routes.................................................................................................................................................................... 17
1.2.3.2 Installing AC Power Cables......................................................................................................................................... 20
1.2.3.3 Installing Lithium Battery Cables............................................................................................................................. 22
1.2.3.3.1 Installing Power Cables for Lithium Batteries.................................................................................................. 22
1.2.3.3.2 Installing Communications Cables for Lithium Batteries..............................................................................23
1.2.3.4 Installing Lead-Acid Battery Cables......................................................................................................................... 24
1.3 Installing a Parallel System............................................................................................................................................... 26
1.4 Connecting a Backfeed Protection Device....................................................................................................................26
1.4.1 Backfeed Protection Device Specications............................................................................................................... 26
1.4.2 Feedback Protection Connections (With Dry Contract Control)....................................................................... 28
1.5 Installing a 4G Module....................................................................................................................................................... 28
1.6 Checking the Installation................................................................................................................................................... 30
2 Power-On Commissioning................................................................................................... 32
2.1 Checking Before Power-On................................................................................................................................................32
2.2 Lithium Battery...................................................................................................................................................................... 32
2.2.1 Single UPS Operations..................................................................................................................................................... 33
UPS2000-H-(6 kVA–10 kVA)
Quick Guide Contents
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. iv

2.2.1.1 Power-On.......................................................................................................................................................................... 33
2.2.1.2 Initial Startup...................................................................................................................................................................33
2.2.1.2.1 Installing the App....................................................................................................................................................... 34
2.2.1.2.2 Logging In to the App............................................................................................................................................... 35
2.2.1.2.3 Quick Settings.............................................................................................................................................................. 38
2.2.1.3 Starting the Inverter......................................................................................................................................................39
2.2.1.4 Powering On Loads....................................................................................................................................................... 40
2.2.1.5 Shutting Down the UPS............................................................................................................................................... 40
2.2.1.6 Cold-Starting the UPS Using Batteries................................................................................................................... 42
2.2.1.7 Performing EPO.............................................................................................................................................................. 42
2.2.2 Parallel System Operations............................................................................................................................................ 43
2.3 Lead-Acid Battery................................................................................................................................................................. 43
2.3.1 Single UPS Operations..................................................................................................................................................... 43
2.3.1.1 Power-On.......................................................................................................................................................................... 43
2.3.1.2 Initial Startup...................................................................................................................................................................43
2.3.1.2.1 Installing the App....................................................................................................................................................... 44
2.3.1.2.2 Logging In to the App............................................................................................................................................... 45
2.3.1.2.3 Quick Settings.............................................................................................................................................................. 48
2.3.1.3 Starting the Inverter......................................................................................................................................................49
2.3.1.4 Powering On Loads....................................................................................................................................................... 52
2.3.1.5 Shutting Down the UPS............................................................................................................................................... 52
2.3.1.6 Cold-Starting the UPS Using Batteries................................................................................................................... 53
2.3.1.7 Performing EPO.............................................................................................................................................................. 54
2.3.2 Parallel System Operations............................................................................................................................................ 54
UPS2000-H-(6 kVA–10 kVA)
Quick Guide Contents
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. v

1 Installation and Cable Connection
1.1 Installation Preparations
NO TICE
● A circuit breaker needs to be installed in the upstream of the UPS to facilitate
maintenance.
● The leakage current of the 6 kVA UPS and 10 kVA UPS is less than or equal to
50 mA, respectively. When selecting an RCD, consider the leakage current of
the UPS and its downstream loads.
● When UPSs are connected in parallel, the output parallel power cables of each
UPS must be at least 1 m long and the length deviation must be less than
±10%. The four cables must be connected at the remote end.
● Check the lead-acid battery voltage range: Use a multimeter to measure the
voltage between the positive and negative battery terminals. Voltage range: 9.6
V x Number of batteries to 14.4 V x Number of batteries. For example, if 20
batteries are installed, the voltage between the positive and negative battery
terminals should range from 192 V (20 x 9.6 V) to 288 V (20 x 14.4 V).
● Check the lithium battery voltage range: Hold down the button on the front
panel of the lithium battery for 5 to 10 seconds to power on the lithium battery
for the rst time. After the startup wizard is complete on the app (the output
voltage is set to 240 V), use a multimeter to check that the positive and
negative voltages of the lithium battery range from 235 V to 245 V.
1.1.1 Site Planning
Floor Loading Capacity
Ensure that the oor can bear the weight of the UPS and its optional components.
Installation Environment
● Do not install the UPS in a hot, cold, or damp place that is beyond the
technical specications.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 1

● Keep the UPS far away from water, heat sources, and ammable and
explosive substances. Install the UPS in an environment free of dust, volatile
gas, salt, and corrosive materials. Avoid direct sunlight.
● Do not install the UPS in environments with conductive metal scraps in the
air.
Clearances
NO TICE
Ensure that the distance between UPS air vents and a wall or obstacle is greater
than or equal to 500 mm.
Clearances should be reserved around the chassis to facilitate ventilation and
operations. Clearances of at least 500 mm should be reserved in front of and
behind the chassis.
Figure 1-1 Clearances for the 6 kVA model (unit: mm)
Figure 1-2 Clearances for the 10 kVA model (unit: mm)
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 2

1.1.2 Tools
The onsite operation personnel can select tools based on the site requirements.
Personal protective equipment
Safety helmet Goggles Protective shoes Reective vest
ESD gloves Insulated gloves Protective gloves
-
Hardware installation tools
Flat-head
insulated torque
screwdriver
(2 mm)
Phillips insulated
torque
screwdriver
(M4/M6)
Utility knife Marker
Cable installation tools
Wire stripper RJ45 crimping
tool
Electro-hydraulic
pliers
Heat gun
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 3

Diagonal pliers Crimping tool Hydraulic pliers Cord end terminal
crimping tool
Cable cutter
Measurement instruments
Clamp meter Multimeter Network tester
-
Engineering auxiliary materials
Label Cable tie Cotton cloth Heat-shrink
tubing
Insulation tape
- - -
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 4

Other tools
Electrician's knife Tweezer Brush Vacuum cleaner
1.1.3 Materials
Item Description Type
Standard
material
This type of materials is
delivered with the equipment
and can be obtained from the
ttings bag.
Materials in the packing list
Auxiliary
material
Customers can purchase this
type of materials from the
supplier or other vendors.
Power cable
Optional
material
Customers can purchase this
type of materials from the
supplier based on application
scenarios.
Battery
1.1.4 Power Cables
NO TICE
● A circuit breaker needs to be installed in the upstream of the UPS to facilitate
maintenance.
● The UPS can generate large leakage currents. An RCD is not recommended. If
leakage protection is required, select a recommended circuit breaker.
● The leakage current of the 6 kVA UPS and 10 kVA UPS is less than or equal to
50 mA, respectively. When selecting an RCD, consider the leakage current of
the UPS and its downstream loads.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 5

Table 1-1 Recommended power cable specications (6 kVA UPS)
Model Wiring Terminal Numb
er of
Phase
s
Rated
Voltage
External
Circuit
Breaker
Cable
Cross-
Sectional
Area
Terminal
Type
6 kVA Input Input (IN) L/
Input (IN)
N/PE
1 220 V
AC/230 V
AC/240 V
AC
50 A
(feature D)
6 mm2OT-6
mm2-
M4-90°
bending
Output Output
(OUT) SL/
Output
(OUT) PL/
Output
(OUT) N/PE
1 220 V
AC/230 V
AC/240 V
AC
40 A
(feature C)
6 mm2OT-6
mm2-
M4-90°
bending
Battery
(lead-
acid
battery)
Battery
(BAT) +/
Battery
(BAT) –/PE
- 144 V DC
to 240 V
DC (12–20
PCS of 12
V
batteries)
50 A
(feature D)
2 x 4 mm2OT-10
mm2-
M4-90°
bending
Battery
(lithium
battery)
Battery
(BAT) +/
Battery
(BAT) –/PE
- 240 V DC 40 A
(feature D)
2 x 4 mm2OT-10
mm2-
M4-90°
bending
Torque for tightening M4 screws: 1.2 N·m
Table 1-2 Recommended power cable specications (10 kVA UPS, single-phase input single-phase
output)
Model Wiring Terminal Numb
er of
Phase
s
Rated
Voltage
External
Circuit
Breaker
Cable
Cross-
Sectiona
l Area
Terminal
Type
10 kVA
(single-
phase
input
single-
phase
output)
Input AC
INPUT/AC
input L2
1 220 V
AC/230 V
AC/240 V
AC
80 A
(feature D)
16 mm2OT-16 mm2-
M6-90°
bending
AC
INPUT/AC
input N
16 mm2OT-16 mm2-
M6-90°
bending
AC
INPUT/AC
input PE
16 mm2OT-16 mm2-
M6-90°
bending
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 6

Model Wiring Terminal Numb
er of
Phase
s
Rated
Voltage
External
Circuit
Breaker
Cable
Cross-
Sectiona
l Area
Terminal
Type
Output AC
OUTPUT/AC
output SL
1 220 V
AC/230 V
AC/240 V
AC
63 A
(feature C)
16 mm2OT-16 mm2-
M6-90°
bending
AC
OUTPUT/AC
output PL
16 mm2OT-16 mm2-
M6-90°
bending
AC
OUTPUT/AC
output N
16 mm2OT-16 mm2-
M6-90°
bending
AC
OUTPUT/AC
output PE
16 mm2OT-16 mm2-
M6-90°
bending
Battery
(lead-
acid
battery)
BATTERY/
Battery +
- 144 V DC
to 240 V
DC (12–20
PCS of 12
V
batteries)
100 A
(feature D)
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery –
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery PE
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
Battery
(lithium
battery)
BATTERY/
Battery +
- 240 V DC 63 A
(feature D)
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery –
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery PE
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
Torque for tightening M6 screws: 4.8 N·m
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 7

Table 1-3 Recommended power cable specications (10 kVA UPS, three-phase input single-phase
output)
Model Wiring Terminal Numb
er of
Phase
s
Rated
Voltage
External
Circuit
Breaker
Cable
Cross-
Sectional
Area
Terminal
Type
10 kVA
(three-
phase
input
single-
phase
output)
Input AC
INPUT/AC
input L1
3 380 V
AC/400 V
AC/415 V
AC
80 Aa
(feature D)
16 mm2OT-16 mm2-
M6-90°
bending
AC
INPUT/AC
input L2
16 mm2OT-16 mm2-
M6-90°
bending
AC
INPUT/AC
input L3
16 mm2OT-16 mm2-
M6-90°
bending
AC
INPUT/AC
input N
16 mm2OT-16 mm2-
M6-90°
bending
AC
INPUT/AC
input PE
16 mm2OT-16 mm2-
M6-90°
bending
Output AC
OUTPUT/AC
output SL
1 220 V
AC/230 V
AC/240 V
AC
63 A
(feature C)
16 mm2OT-16 mm2-
M6-90°
bending
AC
OUTPUT/AC
output PL
16 mm2OT-16 mm2-
M6-90°
bending
AC
OUTPUT/AC
output N
16 mm2OT-16 mm2-
M6-90°
bending
AC
OUTPUT/AC
output PE
16 mm2OT-16 mm2-
M6-90°
bending
Battery
(lead-
acid
battery)
BATTERY/
Battery +
- 144 V DC
to 240 V
DC (12–20
PCS of 12
V
batteries)
100 A
(feature D)
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery –
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery PE
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 8

Model Wiring Terminal Numb
er of
Phase
s
Rated
Voltage
External
Circuit
Breaker
Cable
Cross-
Sectional
Area
Terminal
Type
Battery
(lithium
battery)
BATTERY/
Battery +
- 240 V DC 63 A
(feature D)
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery –
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
BATTERY/
Battery PE
2 x 6
mm2
OT-16 mm2-
M6-90°
bending
● a: In bypass mode, the UPS obtains power from phase A, and the input current is the total
three-phase current.
● Torque for tightening M6 screws: 4.8 N·m
NO TE
● Purchase input and output power cables based on site requirements. You are advised to
use cables that comply with standards such as UL 758 or IEC 60228.
● Use power cables made of soft conductors that work at 90°C or even softer conductors.
If you use power cables made of solid conductors or twisted conductors, the cables may
fail to be connected.
Table 1-4 BBB box scenario
Item Wiring Terminal Cable Cross-
Sectional Area
Terminal Type Torque for
Tightening
Screws
Connection
between the 6
kVA UPS and the
BBB box
Battery (BAT) + 6 mm2OT-6 mm2-
M4-90° bending
M4: 1.2 N·m
Battery (BAT) – 6 mm2OT-6 mm2-
M4-90° bending
M4: 1.2 N·m
PE 16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
OUTPUT DC (+) 6 mm2OT-6 mm2-
M6-90° bending
M6: 4.8 N·m
OUTPUT DC (–) 6 mm2OT-6 mm2-
M6-90° bending
M6: 4.8 N·m
PE 16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 9

Item Wiring Terminal Cable Cross-
Sectional Area
Terminal Type Torque for
Tightening
Screws
Connection
between the 10
kVA UPS and the
BBB box
BATTERY/Battery
+
16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
BATTERY/Battery
–
16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
BATTERY/Battery
PE
16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
OUTPUT DC (+) 16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
OUTPUT DC (–) 16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
PE 16 mm2OT-16 mm2-
M6-90° bending
M6: 4.8 N·m
BBB boxes can be cascaded. Use two cables with a cross-sectional area of 16 mm2 respectively to
connect the positive and negative poles of two BBB boxes. The terminal type is OT-16 mm2-
M6-90° bending.
1.1.5 Unpacking and Checking
Context
Figure 1-3 Transportation rules
NO TICE
● Only trained personnel are allowed to move the equipment.
● Do not move the equipment by holding its mounting ears, front panel, wiring
terminal cover, or control panel.
● Move the chassis with caution. Any bumping or falling may damage the
equipment. After placing the equipment, unpack it carefully to prevent
scratches.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 10

Procedure
Step 1 Verify that the UPS packaging is intact. If any damage is found, notify the carrier
immediately.
Step 2 Move the equipment to the specied position.
Step 3 Remove the packing materials. Check whether the UPS exterior is in good
condition and free of collision marks or scratches. If any damage is found, notify
the carrier immediately.
Step 4 Check the type and quantity of ttings against the packing list. If some ttings are
missing or do not match the models in the packing list, record the information
and contact the supplier immediately.
----End
1.2 Installing a Single UPS
1.2.1 Rack-Mounted Installation
1.2.1.1 Installing the UPS and Lithium Batteries
Procedure
Step 1 Install mounting ears on both sides of the UPS.
Figure 1-4 Installing UPS mounting ears
Step 2 Install the UPS with mounting ears and batteries on the rack.
NO TE
● Three people are required to install lithium batteries. For details, see the label on the
lithium batteries.
● Lithium batteries are 3.6 U high and cannot be rounded up to 4 U. Install ller panels
between lithium batteries and between the lithium battery and the UPS to ll the 0.4 U
gap to meet the IEC 60297 standard.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 11

Figure 1-5 Installing the UPS and batteries
----End
1.2.1.2 Installing the UPS and Lead-Acid Batteries
Procedure
Step 1 Install mounting ears on both sides of the UPS.
Figure 1-6 Installing UPS mounting ears
Step 2 Install mounting ears on both sides of the battery.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 12

Figure 1-7 Installing battery mounting ears
Step 3 Install the UPS and batteries with mounting ears on the rack, and then install the
battery front panels.
Figure 1-8 Installing the UPS and batteries
----End
1.2.2 Tower-Mounted Installation
1.2.2.1 Installing the UPS and Lithium Batteries
Procedure
Step 1 Assemble the support bases.
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 13

Figure 1-9 Assembling a support base
Step 2 Remove the mounting ears from both sides of the battery.
Figure 1-10 Removing mounting ears
Step 3 Place the UPS and batteries on the support bases.
Figure 1-11 Placing the UPS and batteries
UPS2000-H-(6 kVA–10 kVA)
Quick Guide 1 Installation and Cable Connection
Issue 01 (2022-06-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 14
