Pioneer PRV-LX10 User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
RRV3355
T – ZZR FEB. 2006 Printed in Japan
DVD RECORDER
PRV-LX10
¶This service manual should be used together with the following manual(s).
Model No. Order No. Remarks
PRV-LX10 /WYV/RB RRV3069
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Power Requirement
Type
Model
PRV-LX10 WK/RB AC220-240V &&&&2#####&&
Please comfirm the figures

2
1234
1234
C
D
F
A
B
E
PRV-LX10
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
7CONTRAST TABLE
PRV-LX10/WYV/RB and /WK/RB are constructed the same except for the following:
<PACKING>
P15- 1 Power Cord ADG1214 DDG1093
P15- 3 Operating Instructions DRE1028 Not used
(English/French)
P15- 3 Operating Instructions Not used DRE1033
(English/Korea)
P15- 4 Air Filter Replacement Instructions DRH1078 Not used
and Precautions (English / French)
P15- 4 Air Filter Replacement Instructions Not used DRH1089
and Precautions (English / Korea)
P15-11 Under Pad DHA1571 Not used
P15-11 Under Pad Assy Not used DXA2080
NSP Korea Recycle Label M Not used DRW2292 No. 1
P15-16 Upper Pad 2 DHA1655 Not used
P15-16 Upper Pad 2 Assy Not used DXA2079
P15-17 F Pad 2 DHA1656 Not used
P15-17 F Pad 2 Assy Not used DXA2081
P15-18 R Pad 2 DHA1657 Not used
P15-18 R Pad 2 Assy Not used DXA2082
P15-20 Packing Case DHG2456 DHG2609
P15-21 Mirror Mat Bag DHL1124 Not used
P15-21 Mirror Mat Bag Assy Not used DXA2083
NSP Korea Recycle Label HDPE Not used DRW2291 No. 2
P15-22 Packing Sheet DHC1052 Not used
P15-22 Packing Sheet Assy Not used DXA2084
NSP Korea Recycle Label HDPE Not used DRW2291 No. 3
P15-24 NSP GE SUB Manual DRH1084 Not used
Power Cord K Label Not used DRW2301 No. 4
NSP Label (WEEL) DRW2279 Not used
<EXTERIR SECTION>
P21-14 HDD 120G 4R120L0 VXF1016 Not used
P21-14 HDD 160G WD160BGUC Not used VXF1068
KETI Label Not used DRW2280 No. 5
<REAR PANEL>
P23- 4 NSP Rear Panel DNC1703 DNC1774
P23-18 Rear Panel Assy DXA2022 DXA2074
Notes : The numbers in the remarks column correspond to the numbers on the “EXPLODED VIEWS”.
Ref.
No. Remarks
PRV-LX10 PRV-LX10
Part No.
Mark Symbol and Description
/WYV/RB /WK/RB

3
1234
1234
C
D
F
A
B
E
PRV-LX10
EXPLODED VIEWS
• PACKING SECTION
Battery Cover
Accessory Base
No.1
No.1
Power Cord
Polythylene Bag
No.4
Under Pad
ASSY
F Pad 2 ASSY Packing Case
Packing Sheet
Packing Sheet
Mirror Mat Bag
Mirror Mat Bag ASSY
Remote Control Unit
Accessory Plate
WEEL Label
No.2
No.1
No.3
No.1
No.3
Upper Pad 2
ASSY
Packing Sheet ASSY
Packing Sheet ASSY
R Pad 2 ASSY

4
1234
1234
C
D
F
A
B
E
PRV-LX10
EXTERIOR SECTION
Gasket
Gasket
Bonnet
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Screw
Bonnet Assy
No. 5
To DECB
(CN1471)
To PCIB
(CN2102)
To PWRB
(CN9)
BC
JKDB Assy
422IB Assy
Earth Terminal
Screw
Screw
Screw
Rear Panel
Gasket RP
Fan Spacer
DC Fan Motor
Note:
When removing the JKDB Assy or 4221B Assy,
be sure to remove the rear panel first.
Note:
When replacing the JKDB Assy, be sure to remove the 3P BNC
earth plate (CU) from the old Assy and attach it to the new Assy.
Note: Gasket locations
Blind Plate
Rear Panel Assy
Terminal Cover
REAR PANEL SECTION
