JVC DR-M10 User manual

JVC
DVD VIDEO RECORDER
DR-M10
i_ilil
VIDEO
RAM/RW I SUPER VIDEO I
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and
Serial No. which are located on the
rear of cabinet. Retain this
information for future reference.
Model No.
Serial No.
LPTO899-OO1B

2EN
Dear Customer,
Thank you for purchasing the JVC DVD vide() recorder.
Before use, please read the safety information an(]
precautions to ensure safe use of your new unit.
CAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance iservicing) instructions in the
literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
CAUTION:
This unit should be used with AC 120V'_, 60Hz only.
To prevent electric shocks and fire hazards, DO NOT use any
other power source.
CAUTION:
TO PREVENT E[ECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLO[. FULtY INSERT.
ATTENTION:
POUR EVITER LES CHO(:S _l ECTRIQUES, INTRODUIRE LA
LAME LA PlUS LARGE DE ]A FICHE DANS [A BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU
FOND.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's
attention to Article 820-40 of the NFC that provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
CAUTION:
Changes or modifications not approved by IVC could void
user's authority to operate the equipment.
CAUTION
A UNI[ IS A CI.ASS 1 lASER PROIDUCY. HOWEVER ]HIS UNII USES A VISIBLE lASER BEAM WHICH COULD
CAUSE HAZARDOUS RADIAlION EXPOSURE IF DIRECI ED. BE SURE IO OPERA] E [HE UNIT CORRECIIY AS
INSTRUC I ED.
WHEN IHIS UN[] IS PLUGGED [NIO ]HE WALl OU FEEl, DO NO] PLACE YOUR EYES CI.OSE IO [HE
OPENING OF IHE [DISC FRAY AND O[HER OPENINGS IO EOOK INTO ]HE INSIDE OF [HIS UNII.
USE OF CONTROLS OR ADJUS1 MENTS OR PERFORMANCE OF PROCEDURES OIHER FHAN IHOSE SPECIFIED
HEREIN MAY RESUI T IN HAZARDOUS RADIAIION EXPOSURE.
DO NOT OPEN COVERS AND DO NO1 REPAIR YOURSE[ F. REFER SERVICING TO QUA[ IF[ED PERSONNEl.
CLASS 1 lASER PRODUCT
REPRODUC [ION OF I.ABELS
WARNING [ABE[ INSIDE OF/HE UNI[
CAUTIONVISIBLE AND INVISIBLE LASER RADiATiON WHEN OPEN. AVOID EXPOSURETO BEAM.
DO NOT STAREiNTO BEAM ORViEW DIRECTLYWiTH OPTICAL iNSTRUMENTS.
ADVARSELSYNL,_ oG USVNL,GL ,SERS'rR, L,NGVED._BN[NG.UNDGAUDSAETTELSEFORSTRAL[NG
SEIKKEIND I STRALEN=HELLERIKKE MEDOPTISKEINSTRUMENTER.
ADVARSELSYNLIGOGUSYNLIGLASERSTRALINGNARDEKSELAPNE&UNDGAEKSPONERINGFORSTRALEN
STIRR[KKEINN[ STRALENELLERSEDIREKTEMEDOPTISKEINSTRUMENTER.
VARO! AVATTAESSAOLET ALTTIINANAKYV_,AJANAKYMATON LASERSATEILYLLE
ALA TUIJOTAS_,TEESEENAL_,KAKATSOSlT_,OPTISENLAITTEENLAPL
VARNING SYNLIGOCHOSYNLIGLASERSTRALNINGN_,BDENNADELAROPPNAD.STRALENAR FARLIG
STIRRAEJIN I STRALENOCHBETRAKTAEJSTRALENMEDOPTIBKAINSTRUMENT.
OR
ohdistunstasuoma'_rseesi(_

E-3
IMPORTANTPRODUCT
SAFETYINSTRUCTIONS
Electrical energy can perform many useful functions. But
improper use can result in potential electrical shock or fire
hazards. This product has been engineered and manufactured to
assure your personal safety. [n order not to defeat the built-in
safeguards, observe the following basic rules for its installation,
use and servicing.
ATTENTION
Follow and obey all warnings and instructions marked on your
product and its operating instructions. For your safety, please
read all the safety and operating instructions before you operate
this product and keep this booklet for future reference.
INSTALLATION
1. Grounding or Polarization
(A) Your product may be equipped with a polarized alternating-
current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way.
This is a safety feature.
If you are unable to insert the plug fully into the outlet, try
reversing the plug. if the plug should still fail to fit, contact
your electrician to replace your obsolete oudet. Do not
defeat the safety purpose of the polarized plug.
(g) Your product may be equipped with a 3-wire grounding-type
plug, a plug having a third (grounding) pin. This plug will
only fit into a grounding-type power oudet. This is a safety
feature.
[f you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
2. Power Sources
Operate your product only from the type of power source
indicated on the marking label. If you are not sure of the type of
power supply to your home, consult your product dealer or local
power company. If your product is intended to operate from
battery power, or other sources, refer to the operating
instructions.
3. Overloading
Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or
electric shock.
4. Power Cord Protection
Power supply cords should be routed so that they are not likely
to be walked on or pinched by items place(] upon or against
them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
5. Ventilation
Slots an(] openings in the cabinet are provided for ventilation. [o
ensure reliable operation of the product and to protect it from
overheating, these openings must not be blocked or covered.
• Do not block the openings by placing the product on a be(],
sofa, rug or other similar surface.
• Do not [)lace the product in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the
manufacturer's instructions have been adhered to.
6. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
ANTENNA INSTALLATION INSTRUCTIONS
1. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded so as
to provide some protection against voltage surges an(] built-up
static charges. Article 810 of the National Electrical Code, ANSI/
NFPA 70, provides information with regard to proper grounding
of the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding connectors,
location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
2. Lightning
For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time,
unplug it from the wall outlet an(] disconnect the antenna or
cable system. This will prevent damage to the product due to
lightning and power-line surges.
3. Power Lines
An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be
taken to kee I) from touching such power lines or circuits as
contact with them might be fatal.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
LEADIN WIRE
GROUNOCLAMP
ELECTRICSERVICE
_ANTENNA
DISCHARGE UNIT
(NECSECTION
810-20)
3ROUNDING
CONDUCTORS
(NEC SECTION810-21)
GROUNDCLAMPS
POWER SERVICEGROUNDING ELECTRODESYSTEM
(NEC ART250. PARTH)
NEC - NATIONAL ELECTRICAL CODE

EN
USE
1. Accessories
"]b avoid personal injury:
• Do not place this product on an unstable cart, stand, tripod,
bracket, or table. It may fall, causing serious injury to a child
or adult, and serious damage to the product.
• Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the product.
• Use a mounting accessory recommended by the manufacturer
and follow the manufacturer's instructions for any mounting of
the product.
• Do not try to roll a cart with small casters across thresholds or
deep-pile carpets.
2. Product and Cart Combination PORTABLECARTWARNING
A product and cart combination should (Symbolprovidedby RETAC)
be moved with care. Quick stops,
excessive force, an(] uneven surfaces
may cause the product and cart
combination to overturn.
3. Water and Moisture
Do not use this product near wate_for example, near a bath
tub, wash bowl, kitchen sink or laundry tub, in a wet basement,
or near a swimming pool and the like.
4. Object and Eiquid Entry
Never push objects of any kin(] into this product through
openings as they may touch dangerous voltage points or short-
out [)arts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
5. Attachments
Do not use attachments not recommended by the manufacturer
of this product as they may cause hazards.
6. Cleaning
Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
7. Heat
The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat,
SERVICING
1. Servicing
if your product is not operating correctly or exhibits a marked
change in performance and you are unable to restore normal
operation by following the detailed procedure in its operating
instructions, do not attempt to service it yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
2. Damage Requiring Service
Unplug this product from the wall outlet an(] refer servicing to
qualified service personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
product.
c. If the product has been expose(] to rain or water.
d. If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage an(] will
often require extensive work by a qualified technician to
restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in
performance--this indicates a need for service.
3. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or which have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock or other hazards.
4. Safety Check
Upon completion of any service or repairs to this product, ask
the service technician to perform safety checks to determine that
the product is in safe operating condition.
HOW TO USE THIS INSTRUCTION MANUAL
• All major sections and subsections are listed in the l\d_le Of
Contents on page 6. Use this when searching for information
on a specific procedure or feature.
• The index on pages 12 17 lists frequently-used terms, and
the number of the page on which they are used or explained in
the manual. This section also illustrates the controls and
connections on the front and rear panel, the front display
panel and the remote controh
• The _€_ mark signals a reference to another page for
instructions or related information.
• Operation buttons necessary for the various procedures are
clearly indicated through the use of illustrations at the
beginning of each major section.
BEFORE YOU INSTALL YOUR NEW UNIT...
•.. please read the sections/literature listed below•
• "CAUTIONS" on [)age 2
• "IMPORTANT PRODUCT SAFETY INSTRUCTIONS" on
pages 3 - 4

EN5
This equipment has been tested and found to comply with
the limits for a Class g digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
2. DO NOT block the unit's ventilation openings or
holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to
get outd
3. DO NOT place heavy objects on the unit or Remote.
4. DO NOT place anything which might spill on top of
the unit or Remote.
(If water or liquid is allowed to enter this equipment,
fire or electric shock may be caused.)
5. DO NOT expose the apparatus to dripping or
splashing.
6. DO NOT use this equipment in a bathroom or places
with water. Also DO NOT place any containers filled
with water or liquids (such as cosmetics or medicines,
flower vases, potted plants, cups, etc.) on top of this
unit.
7. DO NOT place any naked flame sources, such as
lighted candles, on the apparatus.
8. AVOID violent shocks to the unit during transport.
VCR Plus+, C _ and PlusCode are registered trademarks of
Gemstar Development Corporation.
The VCR Plus+ system is manufactured under license from
Gemstar Development Corporation.
DSS TM is an official trademark of DIRECTV, Inc., a unit of GM
Hughes Electronics. DISH Network r_ is a trademark of Echostar
Communications Corporation.
DE]
DIGITAL
• Manufactured under licence from Dolby Laboratories.
"Dolby" and double-D symbol are trademarks of Dolby
Laboratories.
• "DTS" and "DTS Digital Out" are trademarks of Digital
Theater Systems, Inc.
• This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and
other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited
viewing users only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassembl
is prohibited.
MOISTURE CONDENSATION
Moisture in the air will condense on the unit when you
move it from a cold place to a warm place, or under
extremely humid conditions--just as water droplets form
on the surface of a glass filled with cold liquid. In
conditions where condensation may occur, disconnect
the unit's power plug from the wall and keep it
disconnected for a few hours to let the moisture dry, then
turn on the unit.
ATTENTION
To mobile phone users:
Using a mobile phone in the vicinity of the unit may
cause picture vibration on the TV screen or change
the screen to a blue back display.
On placing the unit:
Some TVs or other appliances generate strong
magnetic fields. Do not place such appliances on top
of the unit as it may cause picture disturbance.
When the equipment is installed in a cabinet or a shelf,
make sure that it has sufficient space on all sides to allow
for ventilation (10 cm or more on both sides, on top and
at the rear/.
When discarding batteries, environmental problems must
be considered and the local rules or laws governing the
disposal of these batteries must be followed strictly.
Failure to heed the following precautions may result in
damage to the unit, Remote or disc.
1. DO NOT place the unit --
in an environment prone to extreme temperatures
or humidity.
-- in direct sunlight.
in a dusty environment.
-- in an environment where strong magnetic fields are
generated.
on a surface that is unstable or subject to vibration,

EN CONTENTS
DISCINFORMATION 7
About Discs ......................................................... 7
INDEX 12
INSTALLINGYOURNEWUNIT 18
Basic Connections ............................................. 18
S-VIDEO Connection ........................................ 19
Component Video Connection .......................... 20
INITIALSETTINGS 21
Plug & Play Set .................................................. 21
I.anguage ........................................................... 22
Clock Set ........................................................... 24
Tuner Set ........................................................... 26
Monitor Set ....................................................... 28
Cable Box Control Setting ................................. 29
DBS Receiver Control Setting ............................ 32
PLAYBACKOPERATIONS 35
Basic Playback .................................................. 35
Playback Features .............................................. 36
live Memory Playback ...................................... 41
Using Play Set Up Menu ................................... 46
Parental lock .................................................... 53
EDITING 86
I)V l)ubbing ...................................................... 86
Edit From A Camcorder ..................................... 88
Edit To Or From Another Recorder .................... 89
Digital Audio Dubbing ...................................... 90
REMOTE 91
Remote Control Functions ................................. 91
SYSTEMCONNECTIONS 95
Connecting ro A Dolby l)igital Decoder or
An Amplifier With Built-in Drs ...................... 93
SUBSIDIARYSETTINGS 96
Mode Set ........................................................... 96
Format a disc ................................................... 1O1
Finalize a disc ................................................. 102
Scan Mode Set ................................................. 103
]ray I.ock ........................................................ 103
TROUBLESHOOTING 104
GLOSSARY 108
SPECIFICATIONS 109
RECORDING 57 LISTOFTERMS
Basic Recording ................................................ 57
Recording Features ............................................ 58 FORSERVICING(Onlyin U.S.A.)
110
111
TIMERRECORDING 60
VCR Plus+ _) limer Programing .......................... 60
Changing VCR Plus+ <_)Setting ........................... 62
Manual Timer Programing ................................. 64
On-Disc Timer Programing ............................... 66
Satellite Auto Recording .................................... 71
WARRANTY(OnlyinU.S.A.) 112
NAVIGATION 72
library Database DVD Navi .............................. 72
Modify Original InR)rmation .............................. 75
Modify Play list Information .............................. 78
Modify I ibrary Information ................................ 82
Playback with MP3/JPEG Navigation ................. 84

DISC INFORMATION EN 7
AboutDiscs
Recordable/playablediscs
You can use discs with the following Iogos for recording and
playback.
DVD-RAM 12 cm: 4.7 GB/9.4 GB
8 cm: 1.4 GB/2.8 GB (VR mode)
DVD-R/RW Discs
[t is only possible to use DVD-R discs which _onform with
DVD-R standard Version 2.0.
When a DVD-R/RW disc (Video mode) is finalized (_ pg. 102),
it can be played back on a standard DVD player as a
DVD VIDEO disc.
When a DVD-RW disc (VR mode)is finalized (_-_" pg. 102), it
can be played back on a standard DVD player compatible with
the VR mode of DVD-RW discs.
• Use discs labeled "lx SPEED".
• This unit is not in compliance with DVD-RW Version 1.2.
• This unit is not in compliance with DVD+RW discs.
RAM
RAM4.7
DVD-R
R
R4.7
DVD-RW
RW
Version 2.0
Version 2.1
Version 2.1/3x
12 cm: 4.7 GB
8 cm: 1.4 GB
(Video mode)
General Version 2.0
General Version 2.0/4x
General Version 2.0/8x
12 cm: 4.7 GB
(Video modeNR mode)
Version 1.1
Version 1.1/2x
Before finalizing (_ pg. 102) --
-- it is possible to record on unrecorded areas of the disc, edit
the disc title an(] program titles, an(] delete programs.
• Before finalizing it is possible to play or record DVD-R/RW
(Video mode) discs only on this unit.
• [t is impossible to overwrite recorded areas of DVD-R discs.
• Available recording capacity does not increase even if a
recorded program is deleted from a DVD-R disc.
After finalizing (_J pg. 102) --
After a DVD-R/RW disc (Video mode) has been finalize(), it is
possible to play back the recorded programs (video and/or
audio) on a standard DVD video player as a DVD VIDEO disc.
• Edited titles are displayed as the "DVD menu" in video mode.
• The above table is based on the information as of February
2004.
• Recording and playback may not be performed with some
DVD-RAM, DVD-R/-RW, and CD-R/-RW discs depending on
the characteristics and condition of the disc used, leading to
unsatisfactory results. Using discs manufactured by JVC is
recommended since they have been tested to be compatible
with this uniL
DVD-RAM Discs
It is only possible to use discs whkh conform with DVD-RAM
standard Version 2.0 or 2.1.
• It is impossible to record on DVD-RAM discs which do not
confornl to this standard. If you use a disc formatted under a
different standard version, format it on this unit before use.
• [t may not be possible to record, play back, edit or dub a
DVD-RAM disc even if it conforms to the standard if it was
recorded or edited on the devices from other manufacturers or
on a PC, or if it has far too many titles, or if there is very little
available capacity remaining on the disc.
• DVD-RAM discs recorded on this unit cannot be played back
on an incompatible DVD player.
• [t is possible to record copy-once programs of digital
broadcasts only onto 4.7/9.4 GB DVD-RAM discs (2.8 GB
DVD-RAM discs are not compatible).
• It is impossible to record, edit or delete the data either in video
mode or in VR mode.
• Either in video mode or in VR mode, although the disc can be
played back on DVD players from other manufacturers,
sometimes it may not be possible to play depending on the
disc and recording conditions.
• It is impossible to record on CD-R/RW or DVD-R discs used
for authoring.
• [t is impossible to record onto DVD-R/RW iVideo mode) discs
broadcasts that allow you to copy once. The copy once
programs can only be recorded onto DVD-RW discs formatted
in VR mode.
NOTES:
The following may result if you play back a DVD-R disc
recorded on another unit.
• The disc does not play.
• A mosaic pattern (block noise) appears on the screen.
• Video or audio may be dropped out.
• The unit stops during playback.

8EN DISC INFORMATION (cont.)
Discsfor PlaybackOnly
You (an use dis(s with the following Iogos for playba(k only.
DVD VIDEO
Q
VIDEO
(example of region code
indications)
@N
@@
Audio CD
CD-DA
DIGITAL AUDIO
CD-RW
CD-DA/
files
{ReWritable]
Video CD/Super Video CD
[DIGITAL VIDEOI(SUPERVIDEO]
CD-R
CD-DA/
files
[Recordable]
CD-ROM
files
UnplayableDiscs
The following types of discs cannot be played using this unit.
Do not attempt to play back any kind of disc that is damaged
(cracked, warped, or repaired with adhesive tape) or discs in
unusual shapes (heart-shaped, octagonal, or other forms). If such
discs are accidentally played back, it may cause noise that can
lead to speaker damage.
• CD-ROM discs (including PHOTO-CD and CD-G)
• Discs recorded in Packet Write (UDF) format.
• 1.3-GB double density CDs (DDCD)
• High density CDs (HDCD)
The following discs also cannot be played back.
• Discs of a region number other than "1"
• DVD-RAM (2.6 GB/5.2 GB)
RegionNumber
The world is divided into 6 regions for DVD VIDE(J) discs.
DVD VIDEO discs are assigned a region number to indicate
which region they may be played back in. A disc cannot be
played back on this unit unless the region number of the disc
matches that of the unit. [he region number for this unit is "1 ".
Only discs whose region number includes "1" or "ALl" can be
played back such as shown below.
Examples of DVD VIDEO labels which can be played back using
this unit.
• Playback may not be performed depending on the
characteristics and condition of the disc used.
• DTS Audio CDs can also be played back (An optional DTS
decoder is required).
• MP3 and IPEG discs can be played back on this unit only
when they have been recorded in the [SO9660 or Joliet format
and finalized.
•JPEG files that can be played back on this unit must conform to
JFIF/Baseline process, and the maximum resolution of a JPEG
file is 3,840 x 2,160 pixels.
• CD-R/RW discs recorded in music CD format need to be
finalized to play on this unit.
• Operation and audio quality of this unit are not guaranteed for
discs that do not conform to the Compact Disc specification
(CD-DA).
Before you play back a CD, check for the CD logo and read
the notes on the package to confirm that it conforms to the
Compact Disc specification.
• Depending on the intentions of the author of the software,
recording conditions of DVD discs and Video CD/SVCD discs
may be restricted. Since this unit plays back discs according to
the intentions of the author of the software as indicated on the
disc, some functions may not operate as commanded.
• When switching from the first layer to the second layer of
double-layered DVD VIDEO discs, the image and sound may
be momentarily distorted. This is not a malfunction.
• DVD-AUDIO discs compatible with DVD video players can
be played.
• Super Audio CDs (SACD) compatible with conventional CD
players can be played.
Marks of discs in this instruction manual
Allows operation
with a DVD-RAM
disc.
Allows operation
with a DVD-R disc.
Allows operation
with a Video CD/
Super Video CD
(SVCD) disc.
Allows operation
with an Audio CD
disc.
Allows operation
with a DVD-RW
disc.
Allows operation
with a DVD VIDEO
disc.
Allows operation
with a disc
including MP3 files.
Allows operation
with a disc
including JPEG files.

RecordingMediumandFormat FileStructureofDiscs E.9
DVD-RAM
• Recording and erasing can be performed as many times as
possible on a disc.
• Editing can be performed after recording, such as deleting
unwanted parts.
• While recording, it is possible not only to start playback of a
program currently being recorded, but also to watch another
program previously recorded.
DVD-RW (VR mode)
• Recording and erasing can be performed as many times as
possible on a disc.
• Editing can be performed after recording, such as deleting
unwanted parts.
DVD-RW (Video mode)
• Can be played back on other DVD players.
• New recording can be performed by erasing all the data on a
disc once played back.
DVD-R
• Can be played back on other DVD players.
• Suitable when keeping a recorded disc for a long time.
DVD VIDEO
Typkally, DVD VIDE(:) discs are made up of larger units called
"titles". Each title has a number (title number) that can be used
to select desired titles. Titles are further divided into units called
"chapters". Each chapter has a number (chapter number) that
can also be used to select desired chapters. Note that some discs
are not divided into titles and chapters.
When you record a program on a DVD-RAM/RW (VR mode)
disc
A single recording session results in a single title (a single
chapter). However, chapter marks are automatically inserted
when recording is pause(], or audio changes from monaural or
bilingual to stere() due to commercial breaks, etc. It is also
possible to insert chapter marks at desire(] locations during
playback. (_-_"pg. 38)
When you record a program on a DVD-R/RW (Video mode)
disc
A single recording session results in a single title (a single
chapter). However, chapter marks are automatically inserted
when recording is paused, or audio changes due to commercial
breaks, etc. It is also possible to insert chapter marks at desired
locations during either recording or playback. Once the disc has
been finalize(], these chapter marks are deleted and new chapter
marks are assigned automatically approximately every 5
minutes.
_._ DVD-RAM, DVD-RW, DVD-R or DVE) VIDEO dis(
T,t,el qp nt,e2 H
• In Video mode, even before finalizing, it is impossible to
perform editing operations other than changing the disc name
and/or title names and deleting programs and/or titles.
• After finalizing, it is impossible to perform editing operations.
Audio CD/Video CD/SVCD
Typically, Audio CD discs are divided into separate tracks each
containing one song. Each track is assigned a number. For
example, the third track is Track 3. The same is true for Video
CD/SVCD discs.
However, some discs are not divided into tracks.
Audio CD or Video CD/SVCD
Track 1 -1 Track 2 _ Track 3 i_ Track 4

Z0EN DISC INFORMATION (cont.)
JPEG/MP3 Disc (CD-R/RW/ROM)
MP3/JPEG files put in directories nested in several levels on a
disc will be organized as if they were put in single level
directories (groups) by the MP3/JPEG Navigation of this unit,
?-_ pg. 84)
File structure of a disc before starting the MP3/IPEG Navigation
Root
DVDVIDEOMarks
Sometimes marks are printed on a DVD disc and/or on its
packaging to indicate information regarding the contents and
functions of the disc. Check the marks indicating the contents
and functions of the disc. Note, however, that in some cases a
disc may not include a mark even for a function it supports.
Marks related to video
Directory
CZZZZ) MP3 file
O JPEG file
File structure of the disc after starting the MP3/JPEG
Navigation
Files are automatically grouped as follows and displayed on the
MP3/]PEG Navigation screen. Data is displayed in the
alphabetical order of file name. Files are grouped base(] on
roots.
Root ] file 1.mp3 }
file 2.rap3
Europe ] file 3.rap3 }
POPS file 4.mp3 )
file 5.rap3 }
ROCK]
• This unit can recognize up to 9 hierarchies including
directories an(] files.
Also, it can recognize up to 250 files in each group, an(] up to
99 groups on a disc.
NOTES:
•Video CD/SVCD discs that support Playback Control (PBC)
The contents of a disc are re(orded into several hierarchies,
and played back according to the instructions on the screen
while navigating through the hierarchies. It is also possible to
playback recorded tracks consecutively without activating the
PBC function even when playing a PgC-compatible disc.
C_" pg. 40)
•Regarding the contents recorded on discs
Some files may not be played back depending on the file types
and other factors.
Mark
@
@
Description
Number of subtitles
Number of angles
Recorded under the standard 4:3 aspect
ratio
Screen includes black bands at the top
and the bottom of image which has a
standard 4:3 aspect ratio (letter box)
Video playback is in Wide video mode
(16:9) on wide televisions, but in letter
box on televisions with standard 4:3
aspect ratio.
Video playback is in Wide video mode
(16:9) on wide televisions, but pan and
scan is used on televisions with standard
4:3 aspect ratio (either the left or right side
of the image is cut-outh
Marks related to audio
Mark Description
®))
Dolby Digital mark
BB_ It has been developed by Dolby
D I G I T A L kaboratories as a digital surround system.
DTS (Digital Theater Systems)
DIGITAL You can enjoy DTS audio if you connect
an amplifier with a built-in DTS decoder
SURROUND to the DIGFFAL OUT connector of the
unit.

EN11
Placinga Disc
Opening the disctray
Press A on the unit or Remote to open the disc tray.
CareandHandlingof Discs
How to handle discs
When handling a disc, do
not touch the surface of the
disc. Since discs are made
of plastic, they are easily
damaged. If a disc gets dirty,
dusty, scratched or warped,
the images and sound will
not be picked up correctly,
and such a disc may cause the unit to malfunction.
Unit Remote
•Pressing the button on the unit or on the Remote again closes
the disc tray.
• Use the buttons on the unit or on the Remote to open and
close the disc tray.
• Do not block the disc tray with your hand while it is opening
or closing as this may result in hardware failure.
• Do not place unplayable discs or any object other than a disc
on the disc tray.
• Do not press down strongly on the disc tray or place any heavy
objects on it.
Discs without cartridges
Place the disc on the disc tray with the label side facing up.
Since disc size changes depending on the disc to be played
back, be sure to correctly align the disc with the grooves for its
size. If the disc is not in its groove, it may be scratched or
otherwise damaged. To insert an 8 cm disc, [)lace it according to
the inner groove.
DVD-RAM discs contained in cartridges
Double-sided discs:
Remove the disc from the cartridge. Align the disc with the
grooves on the disc tray as shown in the illustration and insert
with the side you wish to play back or record facing down. If you
insert the disc with "Side A" facing down, programmes are
recorded on the side A.
Single-sided discs:
Remove the disc from the cartridge. Align the disc with the
grooves on the disc tray as shown in the illustration and insert
with the label side facing up.
NOTE:
qb prevent accidental erasure of important recordings, slide the
protect tab to the protect position using a ballpoint pen, etc.
Release the protect tab to record, edit, or perform other
operations.
Label side
Do not damage the label side, stick paper to or use any
adhesives on its surface.
Recording side
Make sure that discs are not scratched and dirty on the recording
side before use. Scratches and dirt on the recording side of a disc
may hinder proper playback and recording. Also be careful that
a DVD-RAM disc may get scratched or dirt when removed from
cartridge then put back in after use.
Storage
Make sure that discs are kept in their cases. If discs are piled on
top of one another without their protective cases, they can be
damaged. Do not put discs in a location where they may be
exposed to direct sunlight, or in a place where the humidity or
temperature is high. Avoid leaving discs in your cart
Maintenance of discs
If there are fingerprints or other dirt
adhering to a disc, wipe with a soft dry
cloth, moving from the centre outwards.
If a disc is difficult to clean, wipe with a
cloth moistened with water. Never use
record cleaners, petrol, alcohol or any
anti-static agents.
CAUTION
Sometimes during playback, noise may appear or irrlages
may be garbled. This is sometimes due to the disc. (It may not
be up to industry standards.)
These symptoms are caused by the discs, not by the
malfunction of the unit.

J2 EN
FRONTVIEW
INDEX
O Infrared Beam Receiving Window
0 Front Display Panel _ pg, 14
O Disc Tray
O Open/Close Button (___)_ pg. 11
O Stop Button (11)u pg. 35, 57
O Play Button (1_)_ pg. 35
O PauseButton (11)_ pg. 35
O Recording Mode Button (REC MODE) _ pg. 57
O Record Button (O) _ pg. 57
Standby/On Button (_b/I (STANDBY/ON))
q[DS-video/Video/Audio Input Connectors
(S-VIDEO/VIDEO/AUDIO (L/R)) _ pg. 88
DV Input connector (DV IN (|,*))_ pg. 86
*F, (i.LinkJ letels to the IEEE1394_1995 industl 7speciti_tion and
extensions theleoL The _, Io_o is used k_l ploducts complL_nt with
the LLink standald.
[b access covered connectors, pull and opeil the
C011 nector cover.

REARVIEW
EN13
@
ENN_ CO_(_E_nr- OUTPUT I{
I]t Antenna Input Connector (ANTENNA IN)
_ pg. 18
O Component Video Output Connectors
(COMPONENT OUTPUT) z__pg. 20
O Video/Audio Output Con nectors (VIDEO/
AUDIO OUTPUT) z__pg. 18, 19, 20, 89
O S-video Input Connector (S-VIDEO INPUT)
_ pg. 19
O Video/Aud io Input Con nectors (VI DEO/AU DIO
INPUT (L-I/L-2)) _ pg. 89
O Cable Box Control Connector (CABI E BOX)
_ pg. 29, 32
O AV COMPU I.INK Connector _¢ pg. 100
ORegion Number Label _:_ pg. 8
0Mains Power Cord _:_ pg. 18
_) Antenna Output Connector (ANTENNA OUT)
_ pg. 18
• S-video Output Connector (S-VIDEO OUTPUT)
z__pg. 19
11_Digital Audio Output Connectors
(DIGIIAL OUT (COAXIAl!OPTICAl.))
_ pg. 90, 95
Cooling Fan
• This pievents time tempelature from Hsing inside time unit.
Do not H'movl' it.
• Install the unit so as not to Nod< the area alound the fan.
• Time cooling fan on time rear of the unit may be activatt,d even if the
unit is tulned off in the fl)llowing cases;
-- in the REC LINK standby mode (_ _ pg. 71)
when "AUTO CLOCK" is set to "ON" (Z#_ pg. 24)

14EN
FRONTDISPLAYPANEL
INDEX (cont.)
0Disc Type/Status Indicator
When a disc is loaded, the type of the disc is indicated.
When a disc is running, the disc marks rotate.
During High-Speed Search: Rotate faster than normal
playback,
During Slow Motion: Rotate slower than normal
playback,
While recording: Inner red ring lights in the same
way as normal playback. During
Instant Timer Recording (ITR),
inner red ring slowly blinks.
While paused: Disc marks blink when either
recording or playing back.
While stopped: Disc marks all light.
While resume stopped: Disc marks all blink.
While the disc tray opened: Disc marks all light out.
No disc on the disc tray: Disc marks all light out.
O VR Mode Indicator __:"pg. 101
Eights when a DVD-RW disc is formatted in VR mode.
O Timer Recording Indicator z__pg. 60, 64, 66, 69
_: Lights when a disc set up for On-Disc Timer
Programing is loaded,
Q: Eights when timer recording other than On-Disc
Timer Programing is on stand-by or being
executed.
Lights when On-Disc Timer Programing is on
,,stand-by or being execute((,
-'k¢_-: Blinks quickly if you press (D (TIMER) in the
following cases;
• Disc is not loaded.
• Clod< has not been set.
• There is no program setting.
ORecording Mode Indicator (XP/SP/IP/EP/FR)
_ pg. 58
Blinks when recording mode is being set.
While "FR" is blinking, the left 3 digits of the Multi Display
(([_ _) indicate setting values ranging from "60" to "480".
After the value has been set, only "ER" lights.
Groupfritle Indicator (GRPfrlTLE) _" pg. 9, 49
"GRP" or "TITLE" lights depending on a disc loaded while
the left 2 digits of the Multi Display (_) indicate the numbers
explained below,
"GRP': Total number of groups or group number being
played back are displayed on the Multi Display,
"TITLE": Total number of titles or title number being played
back are displayed on the Multi Display.
O Track/Chapter Indicator (TRK/CHAP) _ pg. 9, 49
"TRK" or "CHAP" lights depending on a disc loaded while
the 3rd and 4th digits from the left of the Multi Display (_))
indicate the numbers explained below.
"TRK': [btal number of tracks or track number being
played back are displayed on the Multi Display.
"CHAP": Chapter number being played back are displayed
on the Multi Display.

VCD
DVD
XPSPLPEPFR
-RW
-RAN_
GRP _ TRK CHAP
O Simulated Surround Effect Indicator (3D)
_ pg. 50
Eights when a simulated surround effect is set to "3D-ON" in
Play Set Up menu.
Linear PCM Indicator (LPCM)
Lights when "XP MODE REC AUDIO" is set to "LINEAR
PCM" (_ pg. 98) for recording with DVD-RAM, DVD-R and
DVD-RW discs, and when Iinear PCM audio is played.
O Random/Program Playback Mode Indicator
(RND/PRGM)
"RND': Eights when Random Playback mode is set.
(_ pg. 52)
"PRGM": Eights when Program Playback mode is set.
(z_" pg. 52)
_) Repeat Mode Indicator (C3/1/A-B) _ pg. 48, 49
Select Repeat Playback mode in Play Set Up menu.
"_Z3": Whole disc is played back repeatedly.
"_,Z_I ": A single title/chapter/track is played back
repeatedly.
"OA B": The selected part (AB) is played back
repeatedly.
No display: Repeat Playback mode is off.
([])Video Output Indicator (@) _ pg. 103
No display: Indicates that interlace mode is engaged.
[j_: Indicates that progressive mode is engage(].
(Example) _ lights when video output mode is in
progressive mode.
Group/I-itle Number Display _ pg. 9, 49
@)Track/Chapter Number Display _ pg. 9, 49
([])Remaining Time/Elapsed Time Indicator
_ pg. 38, 58
Lights when remaining time of DVD-RAM, DVD-R and
DVD-RW discs is displayed, and lights out when elapsed
time is displayed.
The right 6 digits of the Multi Display (_)) indicate elapsed or
remaining time of each track.
No display: Indicates elapsed time of the disc.
Displayed: Indicates remaining time of the disc.
_])Remaining Time/Elapsed Time Display
_ pg. 38, 58
Multi Display
Displays clock, received channel, elapsed time, and
remaining time.
Also displays status of the unit (NO DISC/OPEN/CLOSE/
READING).

] 6EN INDEX (cont.)
ON-SCREENDISPLAY
When "SUPERIMPOSE" is set to "AUTO" and ON SCREEN on the Remote is pressed in Record mode, various
operational indicators appear on the TV screen. Tb clear the operational indicators, press ON SCREEN again.
DVD,RAM
ODisc Display
Displays the type of the disc loaded on the disc tray.
O Title Number*
Displays number of the title currently being played back.
O Playback Operation Status Indicator*
Indicates playback operation status by pictographs.
O Playback Time*
Displays playback time of the title currently being played
back.
O Recording Mode
Displays recording mode as XP, SP, LP, EP, FR, FR60 FR360,
FR420 and FR480. Current recording mode is displayed
during recording, and recording mode in which the program
was recorded is displayed during playback. The recording
mode is not displayed during play list playback.
O Title Number
Displays playback title number during playback, and
recording title number during recording.
* During Live Memory playback, playback ope_ation status is
displayed. During nom_al playback, the multi_ hannel
encoding method is displayed.
O Chapter Number
Displays playback chapter number during playback, and
recording chapter number during recording.
0Clock Display
O Bar Meter Display _ pg. 43
Displays playback point and other information in bar meten
_) Title Name Display
Displays title name newly registered to the title recorded on
DVD-RAM/RW/R discs, or file name of IPEG and MP3 files.
• Operation Status Indicator
Indicates operation status by pictographs. (Also indicates its
speed for forward high-speed search, reverse high-speed
search and slow motion.)
Time Display
Displays single title playback elapsed time, single track playback
elapsed time, single track remaining time, total elapsed time,
total remaining time, and other information in turn.
@ Audio Display
Displays audio that is being input.
Input Display
Displays currently selected input.

EN17
REMOTE t]) Recording Mode Button (RECMODE) _ pg. 57
Live Check Button dIVE CHECK) _ pg. 44
1_ISet Up Button (SETUP) u pg. 28
Display Button (DISPLAY) _ pg. 16, 38, 43, 58
Audio Button (AUDIO) _ pg. 39
@)Subtitle Button (SUBTIILE) _ pg. 39
TV/CABI.E/DBS/DVD switch _ pg. 28
I_ DVD Standby/On Button (DVD _/I (STANDBY/
ON))
I_tTV/CA BI.E/DBSStandby/O n Butto n (TV/CBI./D BS
¢/1(SrANDBY/ON)) _ pg. 92
I_ TV Volume Button (TV VOLUME +/-/_ pg. 92
I_ Channel Button (CH +/-) _ pg. 94
I_ Memo Button (MEMO) _ pg. 74, 81, 85
Mark Button (MARK) _ pg. 38
_I Satellite Auto Recording Button (REC I.INK)
_ pg. 71
_ Timer Button (® (TIMER))_ pg. 61, 65
Navigation Button (NAVIGATION) _ pg. 72
_ D Button _ pg. 22, 44
Enter Button (ENTER)_ pg. 22
!_ Return Button (RETURN) _ pg. 40, 60
_) Forward Skip Button (_1_1)_ pg. 36, 44
Next Button (NEXT) _ pg. 40
_) Forward Search Button (1_I_) _ pg. 37, 44
Forward Slow Button (SLOW +) _ pg. 37
_1 Play Button (I_ (PLAY))z__pg. 35
Select Button (SEI.ECT)
@1PauseButton (11(PAUSE))z__pg. 35, 44
@IStop Button (11)_ pg. 35, 44, 57, 86
Clear Button (CLEAR) _ pg. 37, 60
!_ Skip Search Button (_,_) _ pg. 37, 44
Open/Close Button (A (OPEN/CLOSE)) _ pg. 11
_) One Touch Replay Button (_) _ pg. 44, 45
(D Play Set Up Button (ON SCREEN)_ pg. 46
(D Progressive Scan Button (PROGRESSIVESCAN)
_ pg. 103
I_ Angle Button (ANGLE) _ pg. 39
OTV Muting Button (TV MUTING) _ pg. 92
TV/VIDEO Button _ pg. 58
t81Number Keys _ pg. 36, 53, 57, 60, 91
Character Keys _ pg. 76
ODBS Button _ pg. 65
O Auxiliary Button (AUX) _ pg. 65
0 Cancel Button (X (CANCEl.))
_ pg. 53, 60, 69, 85
O Program Check Button (PROG/CHECK) _ pg. 69
OVCR Plus+ Button _ pg. 60
OR)p Menu Button (TOP MENU) _ pg. 36
_ Button _ pg. 28
lIDMenu Button (MENU) _ pg. 36
Reverse Skip Button (1_1_1)_ pg. 36, 44
Previous Button (PREVIOUS) _ pg. 40
!_)Reverse Search Button (_1_1) _ pg. 37, 44
Reverse Slow Button (SLOW -) _ pg. 37
Record Button (0 (REC))_ pg. 57
How To Use
Before use, insert two AA size batteries into the Remote with
the polarity ((Z) and O) matched correctly as indicated on
the battery compartment or on the lid.
The Remote can operate most of your unit's functions, as well
as basic functions of TV sets of JVC and other brands.
(_-_ pg. 92)
•Point the Remote toward the remote sensor.
• The maximum operating distance of the remote control is
about 8 m. (26.25fl)
NOTES:
• When inserting the batteries, be sure to insert in the correct
directions as indicated under the battery cover.
• If the Remote doesn't work properly, remove its batteries,
wait for approximately 5 minutes, replace the batteries and
then try operating the unit again.

18 EN INSTALLING YOUR NEW UNIT
BasicConnections
It's essential that your unit be properly connected.
THESE STEPS MUST BE COMPLETED BEFORE ANY
VIDEO OPERATION CAN BE PERFORMED.
Check lhe c0nlenls.
Make sure the package contains all of the accessories
listed in "SPECIFICAYIONS" on page 109.
F_ Installtheunit.
Place the unit on a stable, horizontal surface.
ANTENNA
OUT
I
I
I
I
Audio/video cable
(supplied)
_,Fcable
(supplied)
Antenna or Cable
Coaxial cable ]
._ :Flat feeder
Matching transformer
(not supplied)
AUDIO/VIDEO AC Outlet
OUTPUT T
AC Power Cord
To 75 ohm
Terminal
]b Audio/video
input connectors
TV
I_1 Connecttheunittoa TV.
[] Disconnect the TV antenna from the IV.
[] Connect the TV antenna cable to the ANTENNA IN
connector on the rear panel of the unit.
[] Connect the supplied RF cable between the
ANTENNA OUT connector on the rear panel of the
unit and the TV's antenna connector.
[] Connect the supplied audio/video cable between the
AUDIO/VIDEO OUTPUT connectors on the rear
panel of the unit and the TV's audio/video input
connectors.
•Set your TV to AV mode.
• For switching the TV's mode, refer to the instruction manual of
your TV.
Connecttheunittopowersource.
Plug the end of the AC power cord into an AC outlet. This
unit performs Plug & Play Set automatically. (_-_" pg. 21 )
• The clock and tuner channels will automatically be set when
the antenna is connected and when the AC power cord is first
connected to an AC outlet. (If "AUTO" and the channel
indicator are displayed on the front display panel before the
unit is powered on, the clock an(] tuner channels are being set
automatkally, Wait for the time to be displayed on the front
display panel before turning on the unit,)
NOTES:
• It requires the RF (-onne(tion to enjoy TV programs.
• The playback image is not displayed without one of the
following: A/V, S-Video, or Component Video connection.

EN19
S-VIDEO
Connection
ANTENNA [
ANTENNA
OUT
I
I
I
I
S-Video cable
(not supplied)
]b S-VIDEO
nput connector
Antenna or Cable
Flat feeder
Matching transformer
(not supplied)
S-VIDEO OUTPUT
A_DIO OUTPUT
AC Outlet
AC Power Cord T
Yellow:
Not con nected
Audio/video cable
(supplied)
To Audio input
_onnectors
IITo connect to TV's S-VIDEO input and AUDIO input
connectors
Connecttheunittoa TV.
[] Connect the antenna, unit and TV as per "Basic
Connections" (_-_ pg. 18).
[] Connect the unit's S-VIDEO OUTPU1- connector to
the TV's S-VIDEO input connector.
[] Connect the unit's AUDIO OUIPUT connectors to the
TV's AUDIO input connectors.
_Connecttheunittopowersource.
Plug the end of the AC power cord into an AC outlet. This
unit performs Plug & Play Set automatically. (_:_ pg. 21 )
• The clock and tuner channels will automatically be set when
the antenna is connected and when the AC power cord is first
connected to an AC outlet. (If "AUTO" and the channel
indicator are displayed on the front display panel before the
unit is powered on, the dock an(] tuner channels are being set
automatically. Wait for the time to be displayed on the front
display panel before turning on the unit.)
NOTES:
• You _an obtain high-quality S-VHS pictures,
• If your IV is not stereo-capable, use the unit's AUDIO
OUTPUT connectors to connect to an audio amplifier for
Hi-Fi stereo sound reproduction.
• For switching the TV's video input mode, refer to the
instruction manual of your television.
]b 75 ohm
]_rminal
TV

20 EN INSTALLING YOUR NEW UNIT (cont.)
ComponentVideo
Connection
Antenna or Cable
Coaxial cable ]
._ Flat feeder
Matching transformer
(not supplied)
ANTENNA
IN
COMPONENT OUTPUT
Component Video
cable
(not supplied)
To Component
Video Input
connectors
AC Outlet
Component video connection enables you to obtain high-quality
component video pictures,
IITo connect to TV's component video input connectors
ConnecttheunittoTV.
[] Perform [] -[] in step [] in "Basic Connections"
g-_ pg. 18).
[] Connect the unit's COMPONENT OUTPUI
connectors to the TV's component video input
connectors.
[] Connect the unit's AUDIO OUIPUT connectors to the
TV's AUDIO input connectors.
F_ Connecttheunittopowersource.
Plug the end of the AC power cord into all AC outlet, lhis
unit performs Plug & Play Set automatically. (_7_pg. 21 )
• The clock an(] tuner channels will automatically be set when
,,_N ot_-:_':):nne(ted
Audio/video cable
(supplied)
the antenna is connected and when the AC power cord is first
connected to an AC outlet. (if "AUTO" an(] the channel
indicator are displayed on the front display panel before the
unit is powered on, the clock an(] tuner channels are being set
automatically. Wait for the time to be displayed on the front
display panel before turning on the unit.)
NOTES:
• If your 1-V is not stereo-capable, use the unit's AUDIO
OUTPUT connectors to connect to an audio amplifier for
Hi-Fi stere() sound reproduction.
• For switching the TV's vide() input mode, refer to the
instruction manual of your television.
To audio input
con nectors
R) 75 ohm
Terminal TV
