Pips Technology P372 User manual

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 1 of 76
P372 Licence Plate Recognition Camera
User Manual
PIPS Technology Ltd PIPS Technology Inc
York House 10511 Hardin Valley Road,
School Lane Building C,
Chandler’s Ford Knoxville
Eastleigh SO53 4DG TN 37932-1565
United Kingdom USA
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
E-mail [e-mail]
Web site http://www.pipstechnology.com
- 18653 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 2 of 76
This page is intentionally blank
- 18654 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 3 of 76
Document Revision History
Revision Date Comments
1st Draft 1 March 2004 Initial release
2nd Draft 27 March 2004 2nd Draft
2.0 10 January 2005 Formal Issue of version
2.1 26 January 2005 Rear connector information re-written
More information about trigger and relay connections
Tables of commands reformatted
Camera mounting details added
2.2 16 August 2005 Application RS-232 port connections on rear panel
detailed
- 18655 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 4 of 76
This page is intentionally blank
- 18656 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 5 of 76
Contents
1. Introduction..............................................................................................................................................................9
1.1. Layout of the manual ...................................................................................................................................................9
2. Equipment Overview.......................................................................................................................................10
2.1. Siting the P372...........................................................................................................................................................11
2.2. Rear connection panel................................................................................................................................................11
2.3. Installation..................................................................................................................................................................11
2.4. Computer configuration of the P372 .........................................................................................................................12
2.4.1. Communications Link........................................................................................................................................12
2.4.2. IP Addressing.....................................................................................................................................................12
2.4.3. PC Support Software .........................................................................................................................................13
2.4.4. FTP Server .........................................................................................................................................................13
2.4.5. Keaterm..............................................................................................................................................................13
2.5. Set up tools.................................................................................................................................................................14
2.6. Aligning number plates..............................................................................................................................................14
3. Maintenance...........................................................................................................................................................15
4. Fault Finding.........................................................................................................................................................15
Appendix 1 Mechanical and Electrical Specification for the P372..................................................................................16
1.1 Mechanical.................................................................................................................................................................16
1.2 Electronic ...................................................................................................................................................................16
1.3 Environmental Specification......................................................................................................................................16
1.4 Statutory and Regulatory Considerations..................................................................................................................16
Appendix 2 Connector pin outs.........................................................................................................................................17
Appendix 3 P372 General Configuration..........................................................................................................................20
3.1 Overview....................................................................................................................................................................20
3.2 Connection & Control................................................................................................................................................20
3.3 EPROM configuration ...............................................................................................................................................20
3.3.1 Boot device.............................................................................................................................................................21
3.3.2 Examples................................................................................................................................................................21
3.4 Application configuration..........................................................................................................................................22
3.4.1 Mode and Sync.......................................................................................................................................................30
3.4.2 Camera exposure configuration.............................................................................................................................31
3.4.3 Example exposure settings.....................................................................................................................................32
3.4.4 direction selection..................................................................................................................................................32
3.4.5 closeloop.................................................................................................................................................................33
3.4.6 ALPR configuration...............................................................................................................................................34
3.5 Plate database.............................................................................................................................................................36
3.5.1 Performance ...........................................................................................................................................................37
3.6 Communication & file transfer facilities...................................................................................................................38
3.6.1 WEB management and reporting...........................................................................................................................39
3.7 Trigger system............................................................................................................................................................41
3.8 BMP support ..............................................................................................................................................................41
3.8.1 Test system.............................................................................................................................................................42
3.9 Batch processing ........................................................................................................................................................43
3.10 Network support.........................................................................................................................................................43
3.10.1 Ping.........................................................................................................................................................................44
3.10.2 Telnet......................................................................................................................................................................45
3.10.3 Debug .....................................................................................................................................................................45
3.10.4 Mail ........................................................................................................................................................................45
3.10.5 FTP.........................................................................................................................................................................46
3.10.6 HTTP......................................................................................................................................................................46
3.10.7 PPP .........................................................................................................................................................................46
3.10.8 Time services .........................................................................................................................................................46
3.11 Gzip & Gunzip...........................................................................................................................................................46
3.12 Storage subsystem support.........................................................................................................................................46
3.12.1 Flash file system.....................................................................................................................................................46
3.12.2 DOS file system.....................................................................................................................................................47
3.13 Time synchronisation.................................................................................................................................................48
Appendix 4 Vehicle logging software notes.....................................................................................................................49
4.1 Overview....................................................................................................................................................................49
4.2 General configuration ................................................................................................................................................49
- 18657 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 6 of 76
4.3 Example functional specification ..............................................................................................................................49
4.4 OEM specific configuration.......................................................................................................................................49
4.5 Data format.................................................................................................................................................................51
4.5.1 Log files..................................................................................................................................................................51
4.5.2 Patch files...............................................................................................................................................................52
4.5.3 File locations..........................................................................................................................................................52
4.6 Time Synchronisation................................................................................................................................................53
4.7 PC configuration ........................................................................................................................................................53
4.8 System connection .....................................................................................................................................................53
4.8.1 Initial connection....................................................................................................................................................53
4.8.2 Network configuration...........................................................................................................................................53
Appendix 5 OEM Journey time system.............................................................................................................................57
5.1 Journey time system specific configuration..............................................................................................................57
5.2 Vehicle tag message...................................................................................................................................................58
5.2.1 Format of tag message...........................................................................................................................................58
5.3 Heart beat message.....................................................................................................................................................59
5.3.1 format of heart beat message.................................................................................................................................59
5.3.2 Heartbeat status report ...........................................................................................................................................59
5.4 Time synchronisation.................................................................................................................................................60
Appendix 6 P372 Application Notes.................................................................................................................................61
6.1 Tolling system............................................................................................................................................................61
6.1.1 File formats ............................................................................................................................................................61
6.1.2 Time stamps...........................................................................................................................................................62
6.1.3 Command channel..................................................................................................................................................62
6.1.4 Message channel....................................................................................................................................................64
6.1.5 Keep alive...............................................................................................................................................................64
6.1.6 Error codes .............................................................................................................................................................65
6.1.7 Status report ...........................................................................................................................................................65
6.1.8 Tolling specific configuration options...................................................................................................................66
6.2 Security monitoring system.......................................................................................................................................67
6.3 Car parking.................................................................................................................................................................68
Appendix 7 High level commands at the CLI Interface ...................................................................................................69
Appendix 8 Customer comment proforma........................................................................................................................76
- 18658 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 7 of 76
Copyright Notice
The information within this handbook is authorised for distribution to customers, authorised service centre
personnel, and distributors of PIPS Technology. Every effort has been made to supply information within
this handbook that is correct. However, PIPS Technology assumes neither responsibility for its use, nor
any infringements of patents or other rights of third parties which would result. No licence is granted by
the manufacturer under any patent or patent rights. The manufacturer reserves the right to modify and
update the equipment at any time without prior notice.
No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or
by any means to a third party without the prior consent of the copyright holder.
The manufacturer's warranty will be invalidated if untrained personnel operate the equipment or if any
attempt is made to service the equipment by untrained personnel.
Warranty
PIPS Technology warrants products and spare parts of its own manufacture against faulty materials and
workmanship for a period of 12 months, or as modified by the contract, from the date of purchase or on
site acceptance, if installed by PIPS Technology authorised personnel.
The warranty excludes consumable materials and parts with an inherently limited life and excludes faults
arising from misuse, neglect or vandalism.
PIPS Technology will replace or repair at its option and at no cost to the purchaser any faulty items
reported to it within the warranty period.
Service
Service of this equipment by replacement of parts, on site repair or routine maintenance inspections is
available. Please contact PIPS Technology for a quotation.
Technical Support
Should you require technical support, please contact PIPS Technology in the United Kingdom.
Users finding errors or omissions in this document are requested to advise PIPS Technology.
Write or telephone:
PIPS Technology Ltd
York House
School Lane
Chandlers Ford
Eastleigh
Hampshire
SO53 4DG
Tel: [phone]
Fax: [phone]
e-mail [email protected]o.uk
PIPS Technology Inc.,
10511 Hardin Valley Road,
Building C,
Knoxville
TN 37932-1565
TN 37932-1565
USA
Tel: [phone]
Tel: [phone]
If you telephone please have the following information available:
product name and version number
operating system and version number
Design Changes
PIPS Technology reserves the right to change the design of any product from time to time without notice
and with no obligation to make corresponding changes in products previously manufactured.
Trademarks
Windows and NT are registered trademarks of Microsoft Corporation.
- 18659 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 8 of 76
Notification de Copyright
L'information dans ce manuel est autorisée pour la distribution aux clients, au personnel des services de
maintenance autorisés, et aux distributeurs de PIPS Technology Ltd (ci-après dénommée "La
compagnie") Tout effort a été fait pour que l’information dans ce manuel soit correcte. Cependant, "La
compagnie" n'assume ni la responsabilité pour son usage, ni aucune infraction à des brevets ou à
d'autres droites des tiers qui résulteraient de son utilisation. "La compagnie" n'accorde aucune licence
sous aucun brevet ou propriété industrielle. "La compagnie" se réserve le droit de modifier et mettre à
jour le matériel à tout moment sans préavis.
Aucune partie de cette publication ne peut être reprise, reproduite ou enregistrée sous quelque forme que
ce soit sans l'accord écrit préalable de "La compagnie".
La garantie de "La compagnie" sera infirmée si le matériel est utilisé ou si n'importe quelle tentative est
faite de le réparer par un personnel non formé par "La compagnie".
Garantie
Cette garantie s’étend aux produits et pièces de rechange fabriquées par "La compagnie" contre les
matériaux défectueux et l'exécution défectueuses pendant une période de 12 mois ou comme modifiée
par le contrat, de la date de l'achat ou sur l'acceptation de site, si le matériel est installé par "La
compagnie" ou un personnel autorisé.
La garantie exclut les matériaux consommables et les parties avec une durée de vie limitée et exclut des
défauts redevant de l'abus, de la négligence ou du vandalisme.
"La compagnie" substituera ou réparera, à son option, et à aucun coût à l'acheteur tous les éléments
défectueux reportés au cours de la période de garantie.
Service
Le service de ce matériel par le remplacement des parties, par des inspections de maintenance ou de
réparation sur de site est disponible. Prière de contacter "La compagnie" pour la liste des coûts.
Support Technique
Pour tout support technique, prière de contacter "La compagnie" au Royaume-Uni.
Si vous trouvez des erreurs ou des omissions dans ce document prière d'informer "La compagnie"
Écrivez ou téléphonez :
PIPS Technology Ltd.
York House
School Lane
Chandlers Ford
Eastleigh
Hampshire
SO53 4DG
UK.
Téléphone : [phone]
Fax : [phone]
E-mail : [email protected]
Si vous téléphonez, prière d’avoir l'information suivante disponible :
nom de produit et nombre de version
système d'exploitation et nombre de version
Changements de Conception
"La compagnie" se réserve le droit de changer la conception de n'importe quel produit de temps ăautre
sans communication préalable et sans l'obligation de faire les changements correspondants des produits
construits antérieurement.
Marques déposées
Windows NT sont des marques déposées de Microsoft Corporation.
- 18660 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 9 of 76
1. Introduction
This user manual will provide the reader with sufficient information to set up and operate the P372
Licence Plate Recognition Camera safely and to carry out any routine maintenance tasks that may be
necessary.
NOTE. This manual is to be read and clearly understood before operating the equipment.
1.1. Layout of the manual
The manual is organised into chapters as follows:
Section 1
This section is an introduction to the P372 Licence Plate Recognition Camera and gives an
outline description of the contents of the manual.
Section 2
This section deals with the preparation of the system for use, describes the controls and
interfaces to the P372. Example notes on software installation are provided.
Section 3
This section describes the maintenance tasks required to ensure continued successful operation
of the P372.
Section 4
This section is a troubleshooting guide that helps in the diagnosis of the most common problems
and, in most cases, suggests the appropriate course of action.
The appendices provide information on the configuration of the P372 with examples of customer
applications.
- 18661 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 10 of 76
2. Equipment Overview
The P372 is a single or dual camera complete with video processing/ control/ Automatic Licence Plate
Reader (ALPR). The P372 is enclosed in a rugged extruded aluminium housing sealed to IP67.
The P372 can be supplied with CCIR (50Hz) or EIA (60Hz) camera(s).
The P372 offers the following functions:
Integral monochrome camera module, with lens and optical band-pass filter.
Integral colour camera module (optional).
Integral infrared (IR) pulsed light emitting diode (LED) illuminator that compensates for
sunlight and vehicle headlights.
Camera control. The P372 controls its camera(s). The settings for the camera(s) can be
changed on a field-by-field basis to implement the PIPS Technology patented triple flash
exposure control.
Plate Detection. The P372 detects the retro reflective return from a licence plate in hardware
using digital signal processing (DSP) algorithms and captures the field containing the best
image of the licence plate.
Plate Recognition. The P372 streams the captured image to the software ALPR engine that
performs OCR on the image and reports the VRN with an associated confidence of the result.
Trigger. The P372 generates an internal trigger, from the DSP algorithm, to capture the
image or an external trigger may be supplied to capture the image.
Colour Overview. The P372 can be fitted with a colour overview camera to provide an
overview image associated with the captured VRN image.
Control. The P372 can be controlled from a PC or network using RS232 or Ethernet links.
Modem. The P372 can be controlled from a modem allowing the P372 to work at remote sites
and report the data over a GPRS modem link.
Hot list. The P372 can check, in real time, the detected VRN against a white or black list of
VRNs. Alarms can be raised when a match is found. New hot lists can be downloaded to the
P372.
Image handling. The P372 can store the images as BMP or compressed JPEG files to local
memory or they can be transmitted over the Ethernet link to a server. Groups of images, VRN
and overview can be grouped together and associated as one record. This group can be
watermarked and hashed to ensure the integrity of the data.
Upgrades. The P372 can receive software upgrades over the Ethernet link and store the file
in flash memory.
File system. The P372 has a battery backed SRAM file system used to store the event and
analysis logs. All files are date and time stamped from the internal clock. The internal clock
can be synchronised to an external time server.
- 18662 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 11 of 76
2.1. Siting the P372
The P372 can be sited on poles, gantries or any elevated position giving a clear view of the road
or carriageway to be monitored.
2.2. Rear connection panel
Figure 1 P372 Rear Connections
Figure 2 P372 Rear Connections - Detail
Details of the Connector ‘Pin-Outs’ are included in Appendix 2.
2.3. Installation
The P372 can be supplied with a break-out box for easy evaluation. This box provides Ethernet,
video and serial connectors and the trigger and relay connections are also available at the serial
connector. It also provides easy connection of the PSU unit.
For permanent installations information is provided in Appendix 2 for the cable configuration.
- 18663 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 12 of 76
If required, connect the video monitor output(s) from the P372 to a suitable video monitor(s) using
standard 75 Ohm video coaxial cable. Ensure that the video cable is terminated in 75 Ohms
once (only) including all units through which the video signal may be looped.
Connection to the host system may be made via serial, Ethernet or modem connection as
required by the OEM application.
If computer control of the settings is to be used then the unit may be connected to the computer
by means of a standard serial port cable (NB not a NULL MODEM type).
The camera has an upper voltage limit of 18V. The terminal voltage at the camera must not drop
below 12V otherwise the camera will reset. This restriction provides a limit to the maximum
length of standard cable.
The standard cable is Belden type 9903. This has a "power pair" (red and black) which is
equivalent to 24AWG. If an 18V power supply is used, then the maximum length of cable is
limited 60 feet (18 metres).
At the bottom of the camera is fitted a mounting plate which slides in a slot in the extrusion.
There are three tapped holes. The outer two are tapped M6 whilst the middle hole is tapped 1/4 -
20 UNC, which is the standard 1/4 inch tripod thread.
This plate can be slid along the housing slot by loosening the locking grub screw.
2.4. Computer configuration of the P372
This section describes the process required to prepare the software for a complete P372
demonstration system. Not all operations or procedures described here may be required in every
demonstration or evaluation situation. The assumption is that the P372 will be connected to a
single host PC.
2.4.1. Communications Link
In its current development and demonstration incarnation the P372 requires two
communications links. These are the debug serial port and a TCP/IP connection to an ftp
server for software loading and optional application software.
In this document, it is assumed that the TCP/IP connection is to a host PC running MS
WINDOWS™ 2000™ service pack 4.
The PC must have TCP/IP protocol and FTP server installed. The detailed mechanism
for doing this is beyond the scope of this document.
2.4.2. IP Addressing
The P372 must be issued with an IP (Internet protocol) address in order to communicate
with management and application software. Also, the P372 needs to know the address of
71.8mm
35.9mm
M6 M6
1/4 - 20 UNC Lockin
g
M3
g
rub scre
w
Fig 3. Mounting Plate
- 18664 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 13 of 76
its host PC server for software loading. An IP address is usually seen as a group of four
numbers separated by dots. e.g. 100.100.100.100.
The IP addresses used need to match the rest of the network system in which the P372 is
installed. The local network administrator will usually be responsible for issue of IP
addresses.
For the purposes of this document assume that the PC is allocated 10.10.10.254 and the
P372 is allocated 10.10.10.100.
2.4.3. PC Support Software
This section covers the PC software required to load and manage a demonstration or
evaluation P372 system.
Confirm the IP address of the PC:
START | CONTROL PANEL | SETTINGS | NETWORK | PROTOCOLS | TCPIP |
PROPERTIES
2.4.4. FTP Server
If it is not already in place:
Add the FTP server:
START | CONTROL PANEL | SETTINGS | NETWORK | SERVICES | ADD |
MICROSOFT PEER WEB SERVICES
Configure the web server:
START | PROGRAMS | MICROSOFT PEER WEB SERVICES | INTERNET SERVICE
MANAGER
Select FTP. Uncheck “Allow only anonymous connections”
Select directories. Add the desired directory. Typically d:\inetpub\ftproot
Add the FTP account.
Username: ftp_boot
Password: ftp_boot
Allow guest permissions with access only to the FTP directory set above
2.4.5. Keaterm
A telnet compatible terminal emulation program is required to interact with the P372
Command Line Interpreter (CLI). Hyperterm or telnet as supplied by Microsoft may be
used. However these are of limited functionality. PIPS Technology recommend and use
Attachemate KEA420 – KeaTerm. There are other flexible packages available which
would also be very suitable.
Install Keaterm, following the installation guidelines. Novell support is not required.
Create a short cut to Keavt.exe and drag this onto the desktop. Copy the KEA debug
configuration file into place:
copy cd:\372debug.ktc ..\kea\user
Edit the short cut:
..keavt.exe ..\kea\user\372debug.ktc
Connect the 372 to the PC via the supplied debug serial lead. By default connect to
COM1.
- 18665 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 14 of 76
2.5. Set up tools
2.6. Aligning number plates
To aid the alignment of the P372 can export the image captured to a viewfinder application.
Double click on the PIPS Viewfinder application on the desk top and the following screen
appears.
Figure 2 PIPS Viewfinder application
Confirm that the P372 is detecting a plate. Enter the IP address of the P372 and select the Run
button.
The camera can be adjusted to align the plate in the image box in the viewfinder window.
This tool makes the alignment of the P372 camera possible when the P372 is looking at moving
traffic. Using a monitor would result in only a few fields of images moving down the screen. The
viewfinder application captures and holds the image until it is overwritten by the next image. This
allows fine alignment adjustments of the of the P372 camera to be made.
- 18666 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 15 of 76
3. Maintenance
The P372 operates with a power supply unit outputting a voltage between 12 and 18 volts. There are no
user serviceable parts within the P372.
Routine maintenance of the P372 is limited to cleaning the unit and ensuring that the unit is properly
secured and aligned.
4. Fault Finding
If the fault persists after following the procedures described in the table below, contact PIPS Technology
for advice.
No Fault Possible Cause Check/Solution
1 No Video Cable damage or failure Check all cables and power supply.
Replace/repair damaged cable.
Restore power supply.
2 Poor Retro-Reflection
from Number Plate
Poor camera module alignment
Camera focus incorrectly set
IR illuminator failure
Dirt on camera
Camera window covered with
protective film
Adjust/align using static number
plate.
Test using static number plate.
If focus is poor, contact PIPS
Technology for advice.
View with a Camcorder. If
illumination is not present, contact
PIPS Technology for advice.
Clean the front window
Remove protective film.
3 Complete System
Failure
Power supply failure Check integrity of supply and
rectify as required.
Table 1 P372 Fault Finding Guide
- 18667 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 16 of 76
Appendix 1 Mechanical and Electrical Specification for the P372
1.1 Mechanical
Overall Dimensions 210 mm long, 107mm diameter excluding
hood
Overall Weight 1.5kg
Casing Material Aluminium, black anodised
1.2 Electronic
Operating Voltage 11.5 to 18 volts (at the camera connector)
Power Requirements Maximum
Doze, LEDs off
Doze, LEDs off,
Cameraoff
20 watts
14 watts
6 watts
1.3 Environmental Specification
Temperature (Storage) -50, +50C
Temperature (Working) -20, +50C
Sealing To IP67
Vibration (General Transport Specification )
Mil Std-810D Method 514
Shock BS-EN 60068 2-27
1.4 Statutory and Regulatory Considerations
EMC FCC Part 15, Subpart B, Class B (Digital
Devices)
EN50081-1, EN50082-2
CE Low Voltage Directive
Transport environmental specification TR1034
- 18668 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 17 of 76
Appendix 2 Connector pin outs
A2.1. Rear Panel Socket
Mating Cable Connector - Straight cable entry PIPS part number J34423C08ST19P
Right Angle cable entry PIPS part number J34423C0819P
Mating Cable with connector A350/34 (unterminated at other end)
Contact No Connection A350/34 Cable Cable wire colour
A Ethernet XR- Orange
B Ethernet XR+ Yellow
C Ethernet Screen Drain wire of individual screens
D Ethernet XT- Green
E Ethernet XT+ Blue
F Camera 1
G Camera Screen Grey
H Camera 2 White
I Battery Negative Black
K Battery Positive Red
L Screen Overall screen drain wire
M 0 Volts
N Reserved
O Reserved
P Reserved
R Application Port RS-
232 In (To P372)
S Application Port RS-
232 Out (From P372)
T Reserved
U External LED Drive
Table A.2.2(A). P372 Connector - Rear Connector with Socket Contacts
- 18669 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 18 of 76
A2.2. Rear Panel Plug
Mating Cable Connector - Straight cable entry PIPS part number U34423C08ST19P
Right Angle cable entry PIPS part number U34423C0819P
Mating Cable with connector A350/33 (unterminated at other end)
Contact No Connection A350/33 Cable Cable wire colour
A Ethernet XR-
B Ethernet XR+
C Ethernet/RS232 Screen Drain wire of individual screens
D Ethernet XT-
E Ethernet XT+
F Camera 1 Red
G Camera Screen
H Camera 2
I Battery Negative
K Battery Positive
L Screen Overall screen drain wire
M Trigger 1 (Current out) White
N RS232 RXD Orange
O RS232 TXD Yellow
P External video
R Relay 1 (NO) Green
S Relay 2 (Common) Black
T Relay 3 (NC) Blue
U Trigger 2 (Current in) Grey
Table A.2.2(B). P372 Connector - Rear Connector with Pin Contacts
A.2.3. RS232 Signals
Signals are RXD – Receive Data by P372
TXD – Transmit Data from P372
The RS232 "common" conductor is shared with the Ethernet "common" conductor.
- 18670 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 19 of 76
A.2.4. Trigger Input
The 372 camera has an optically isolated trigger input. External current must be provided to enable
correct operation. An example circuit, operating from 12V, is shown below. Other voltages can be used
by changing the value of the series resistor so as to maintain a current of at last 10mA. The forward
voltage drop of the LED in the opto-coupler is typically 1.5V. The poly-fuse in series with the diode of the
opto-coupler is self-resetting.
A.2.5. Relay Contacts
A changeover relay is provided to connect to other equipment. Using a relay ensures isolation as well as
felixibility so far as voltages and polarities are concerned.
Relay 1
Relay 3
Relay 2
Fig A.2.2. Relay Configuration
P372
12V
100mA Polyfuse
120 ohms
Opto-
coupler
Trigger 2
Trigger 1
820 ohms
Trigger Relay
Contact Closure
Fig A.2.1. Typical Trigger Circuit
P372
- 18671 -

P372 Licence Plate Recognition Camera User Manual
© PIPS Technology Ltd Page 20 of 76
Appendix 3 P372 General Configuration
3.1 Overview
P372 system configuration information is stored one of two places. Low level and system
configuration information is stored within EEPROM. High level application information is stored
within a file. This file may be located within any of the available file systems.
A small number of configuration options are accessible from the EPROM boot loader as these
configuration options must be set in order to start or to load software into the P372.
3.2 Connection & Control
Initial control and configuration of the P372 must be done via the engineering access serial
(RS232) port (the debug port). This serial port is a 3-wire connection and is by default configured
for 19200bps, 8 databits, 1 stop bit, XON/XOFF protocol. Once basic network configuration is
complete, then it is possible to perform configuration and control via a single TELNET connection
over TCP/IP protocol.
The P372 will generate unsolicited monitor and debug messages on the engineering access port.
The volume and detail of this information stream may be managed via various configuration
options described below. In addition this data stream may also be monitored via a TELNET
connection. This is described in further detail below.
Communication with the P372 control software is performed via a Command Line Interpreter
(CLI). The CLI indicates that it is ready to accept further commands by means of a double
chevron prompt:
>>
3.3 EPROM configuration
(These options are duplicated within the application CLI)
Command Comment
show boot Shows boot mode and file
set boot dev {filespec} Set program boot file and device. Device may be: ATE,
prom, ftp or file (see section 3.3.1. below)
show date Shows date and time
set date dd-mmm-yyyy hh:mm:ss
show conf Show name of confiuration file
set conf full_filespec Set source for application configuration file
show server
set serial nnnn Set the unit serial number. This entry requires a security
code.
set ethernet aaaa bbbb cccc Set the unit hardware Ethernet address. This entry
requires a security code.
set server aaa.bbb.ccc.ddd Set default ftp server IP address
set internet aaa.bbb.ccc.ddd set the IP address of the 372
set password
- 18672 -
