Pit Boss PBPZ1 Parts list manual

WARNING: Please read the entire manual before installation and use of this charcoal burning appliance. Failure
to follow these instructions could result in property damage, bodily injury or even death. Contact your local
building or fire officials about restrictions and installation inspection requirements in your area.
ASSEMBLY AND OPERATION INSTRUCTIONS
PBPZ1

 
SAVE THESE INSTRUCTIONS! MANUAL
MUST BE READ BEFORE OPERATING!
MODEL : PBPZ1
PART : 75300
FOR OUTDOOR USE ONLY. NOT FOR COMMERCIAL USE.

2
 
Charcoal Pizza Oven
Assembly instructions
www.tesco.com
Produced in China for TESCO Stores Ltd.
Tesco 2016 2
Before you start
Warnings
REMEMBER-DO NOT USE INDOORS! FOR OUTDOORS ONLY.
Great care has been taken during production to remove sharp
edges but you should handle all components with care to
avoid possible injury.
• Keep a fire extinguisher handy.
• Hot fat may drip at the bottom of the fire bowl so keep your
feet clear.
• If fire flares up due to dripping fat, douse flames with fine
water spray.
•DO NOT touch metal parts of the BBQ until it has
completely cooled to avoid burns. BBQ handles will be hot
and unsafe to touch during use, unless you are wearing
protective gear (pot holders, gloves, BBQ mittens,
hot pad etc).
• Never handle charcoal after lighting.
• Ensure coals have completely burnt before removing
the ash.
• Not to be installed in or on recreational vehicles and/or
boats.
• Store away ONLY when barbecue is completely
extinguished and cool.
• In construction of this BBQ use all and only the
components provided.
•Caution! Do not use spirit or petrol for lighting or
relighting.Use only firelighters complying with EN1860-3.
•Caution! Keep well away from heat sensitive materials
and objects.
• After use, extinguish and allow cooling.
• Only store away when thoroughly cool and extinguished.
•Caution! To avoid damage to property, ALWAYS place this
appliance on a surface which is suitably heat resistant as
this appliance will get extremely hot during operation.
•Caution! To avoid injury, be aware that the resting
surface directly beneath this appliance will get very hot
during operation and will remain very hot sometime after
afterwards-keep feet, other limbs and all property/item
well away from this area.
•Attention! This barbecue will become very hot. Do not
move it during operation.
•Warning: Keep children and pets away.
• Important! Please retain this manual for future reference.
• Unwrap all packaging materials and place components on
top of carton box or on a clean floor to prevent it from
scratching.
•Keep small parts out of reach of children.
Do's
Stand your barbecue on a safe, level surface, well away from
flammable items such as wooden fences or over-hanging
tree branches.
Keep children and pets away.
An adult should always be in charge of the BBQ. Never leave a
hot barbecue unattended.
Be careful of sharp edges during assembly.
When you are ready to start, make sure you have the
right tools, plenty of space and a clean, dry area for
assembly.
Check the pack and make sure you have all the parts listed.
During assembly, children should be kept away from the
product due to possible risk of injury.
Ensure this product is fully assembled as illustrated before use.
To clean, wipe with a sponge and soapy water. Do not use
solvent based cleaners or detergents as they can bleach or
damage this product.
Tools not included.
Don'ts
CAUTION! Do not use spirit or petrol for lighting or re-lighting!
Use only firelighters complying to EN1860-3!
ATTENTION! Once lit, DO NOT move your BBQ or leave
it unattended!
Always make sure the barbecue is fully extinguished and
completely cool before applying any covers OR
storing away-remember coals can remain hot for sometime and
could re-ignite under certain conditions UNLESS fully damped
down and/ or extinguished.
CAUTION! NEVER STORE a barbecue indoors unless ALL coals
and ash have been thoroughly removed and thrown away
outdoors and all barbecue surfaces have been cleaned and are
cool, as otherwise this could lead to fire and/or emissions of
poisonous gases which could cause death.
DO NOT use power tools to construct this product.
DO NOT over tighten screws or bolts.
DO NOT tighten screws until fully assembled.
DO NOT sit or stand on the product.
DO NOT use the product if parts are missing, damaged or worn.
2

3
COPYRIGHT NOTICE
Copyright 2017. All right reserved. No part of this manual may be
copied, transmitted, transcribed, stored in a retrieval system, in any
form or by any means without expressed written permission of,
Dansons Inc.
3411 North 5th Avenue, Suite 500, Phoenix, ,  85013
[e-mail] | [e-mail]
www.pitboss-grills.com
Toll-Free: 1-877-303-3134, Fax: [phone]
Safety Information .......................................................... 2
Parts ....................................................................................4
Assembly Preparation...................................................... 7
Assembly Instructions ..................................................... 7
Operating Instructions
Lighting Methods....................................................................... 10
Lighting The Oven.......................................................................11
Cooking Levels ............................................................................ 12
Cooking Pizzas ............................................................................ 13
Troubleshooting ........................................................................ 13
Care & Maintenance ........................................................14
Warranty
Conditions.................................................................................... 15
Exceptions.................................................................................... 15
Contact Customer Service........................................................ 15
Warranty Service ....................................................................... 15
  

4

www.tesco.com
Fixtures and fittings supplied (not actual size)
Ref Dimension(mm) Visual Qty
A M6X12 39
B Axle nut 2
CM6 nut 5
DM6X15 shoulder
bolt 4
E R pin 2
FAxle spacer 2
10
Produced in China for TESCO Stores Ltd.
Tesco 2016
Charcoal Pizza Oven
Assembly instructions
www.tesco.com
Components supplied (not actual size)
Ref Description Visual Qty
1Bottom shelf 1
2 Left front leg 1
3 Left rear leg 1
4Right front leg 1
5Right rear leg 1
6Firebowl assembly 1
7Axle 1
8Cart left/right
support 2
9Cart front/rear
support 2
10 Wheel 2
11 Wheel cap 2
12 Door handle 2
13 Handle loop 2
Ref Description Visual Qty
14 Handle stopper 2
15 Damper Handle 1
16 Chimney 1
17 Cooking grill 1
18 Pizza stone 1
19 Charcoal tray 1
20 Charcoal grill 1
21 Side shelf front
bracket 1
22 Side shelf back
bracket 1
23 Side shelf 1
24 Cooking grill handle 2
25 Side handle 1
Components supplied (not actual size)
11
Produced in China for TESCO Stores Ltd.
Tesco 2016
Charcoal Pizza Oven
Assembly instructions

5
www.tesco.com
Components supplied (not actual size)
Ref Description Visual Qty
1Bottom shelf 1
2 Left front leg 1
3 Left rear leg 1
4Right front leg 1
5Right rear leg 1
6Firebowl assembly 1
7Axle 1
8Cart left/right
support 2
9Cart front/rear
support 2
10 Wheel 2
11 Wheel cap 2
12 Door handle 2
13 Handle loop 2
Ref Description Visual Qty
14 Handle stopper 2
15 Damper Handle 1
16 Chimney 1
17 Cooking grill 1
18 Pizza stone 1
19 Charcoal tray 1
20 Charcoal grill 1
21 Side shelf front
bracket 1
22 Side shelf back
bracket 1
23 Side shelf 1
24 Cooking grill handle 2
25 Side handle 1
Components supplied (not actual size)
11
Produced in China for TESCO Stores Ltd.
Tesco 2016
Charcoal Pizza Oven
Assembly instructions
