Pixel Range pixelsmart User manual

1
General set up
1Mount the fixture in the required position. The integral yoke can
act as a floor stand or hanger.
Important
• Whensuspendedoffground,alwaysuseasafetywireratedto
aminimumof45Kg(100lbs)throughacornerholeoftheyoke.
2 Whereexternalcontrolistobeused,connectaDMXlead(XLR
5-pinfemale)totheinputsocketontheundersideofthexture.
Whensuspended
offground,always
useasafetywire
rated to a minimum
of45Kg(100lbs)
throughoneofthe
corner holes in the
yoke.
3 Whereotherxturesaretobeusedinacontroldaisy-chain,
connectaDMXlead(XLR5-pinmale)totheoutputsocketonthe
undersideofthexture.
4 ConnectpowertothextureusingaNeutrik®PowerCon®
connector.Inserttheconnectorandtwistitclockwiseuntil
it clicks into place.
Important
• Ifpowerdaisy-chainingxtures,donotexceedatotalloadof
3kWinasingledaisychain(subjecttosupplyandcabling
restrictions).Maximumpowerrequirementperxture:185Watts.
Seealsothe‘Startup(peak)’noteonpage7.
5Use the control panel to access the internal menu and choose the
appropriateoperationmodeandrelatedsettings(seeover).
DMX in (XLR 5pin
male) connector
Fuse holder
DMX out
(XLR 5pin
female)
connector
PixelSmart
Version 1.64 R11 firmware
Operation modes
ThePixelSmartprovidesarangeofoperationmodes.Theseare
selected using the MODEsectionofthecontrolmenu:
DMX AllowsRGBWWcontrolviaDMXinput.Internalchase
effectsarenotavailablewithinthismode.
MANU ProvidesRGBWWcolourmixingindependentlyofany
external control. Use the internal control menu
(MANsection)toselecttherequiredcolourvalues.
EF M Allowsthedisplayofthedualinternalchaseeffects,
independentlyofanyexternalcontrol.Usetheinternal
controlmenu(PROGsection)toselecttherequired
chaseeffects,speedsandcrossfades.
4+E ProvidescontrolofRGBWmixingandselectionofthe
dualinternalchaseeffectsviaDMXinput.Requires12
DMXchannels.
5+E ProvidescontrolofRGBWWmixingandselectionof
thedualinternalchaseeffectsviaDMXinput.Requires
13DMXchannels.
61+E ProvidescontrolofindividualRGBWWemittermixing
andselectionofthedualinternalchaseeffectsviaDMX
input.Requires69DMXchannels.
16bt AllowsRGBWWcontrolviaDMXinput,usingtwo8bit
channelspercolour.Internalchaseeffectsarenotavail-
ablewithinthismode.
Factory reset (perform this prior to new use)
Toclearprevioussettings:Attherearpanel,pressthemiddle
twobuttons( and )whilethecurrentaddressandmode
arebeingdisplayed.ThefourdigitdisplaywillshowFACT then
SETtoindicatethatthexturehasbeenreturnedtoitsdefault
condition.Thisisusefultoremoveanysettingsthatmightcause
confusioninanewconguration(e.g.masterintensitysettings).
Power in socket
Connector required:
Neutrik®PowerCon®
(NAC3FCA)
Power out socket
Connector required:
Neutrik®PowerCon®
(NAC3FCB)

2
Chase effects
Thissectiondescribeseachoftheinternalchaseeffects
thatareselectableeitherviathecontrolmenu(PROG
> C1/C2 > EFEC)orusingDMXvaluessentfrom
anexternalsource.Tousetheinternaleffects,setthe
MODE option either to EF M(forinternalmenucontrol)
or 4+E,5+E or 61+E(forexternalDMXcontrol).
DMX EFEC Chase effect description
value value
0-3 00 Off
4-7 01 Rainbowchaseupward
8-11 02 Rainbowchasedownward
12-15 03 Coolwhitechaseupward
16-19 04 Coolwhitechasedownward
20-23 05 Coolwhiteouter/innerstrobe
24-27 06 50/50dutycyclecoolwhitestrobe
28-31 07 50/50dutycycleredstrobe
32-35 08 50/50dutycyclepurplestrobe
36-39 09 50/50dutycycleyellowstrobe
40-43 10 50/50dutycyclegreenstrobe
44-47 11 Pulsecoolwhitestrobe
48-51 12 Pulsebluestrobe
52-55 13 Pulserainbowstrobe
56-59 14 Pulsered/green/bluestrobe
60-63 15 Allemitterrainbowchase
64-67 16 Allemitterrainbowchasereverse
68-71 17 Allemitteryellow/bluechase
72-75 18 Horizontalsplitrainbowchase
76-79 19 Alternatelinesyellow/bluechase
80-83 20 Alternatelinesred/bluechase
84-87 21 Horizontalsplitred/yellowchase
88-91 22 Alternatelinesrainbowchase
92-95 23 Horizontalsplitrainbowchase
96-99 24 Horizontalsplitrainbowpulse
100-103 25 Staticwarmwhite
104-107 26 Staticyellow
108-111 27 Staticlightblue
112-115 28 Static purple
116-119 29 Static red
120-123 30 Static green
124-127 31 Staticcoolwhite
128-131 32 Randomcolourdots
132-135 33 Rainbowandwhitespreadchaseoutw.
136-139 34 Redandwhitespreadchaseoutward
140-143 35 Greenandwhitespreadchaseoutward
144-147 36 Blueandwhitespreadchaseoutward
148-151 37 Warm&coolwhitespreadchaseoutw.
152-155 38 Warmwhitespiraldotchase
156-159 39 Warm&coolwhitetwinkle
160-255 40 Rainbowclockwisedotll(testsequence)
Using the menu
• Whennotinthemenu,thefourdigitdisplayscrollsthe
currentDMXaddressandmode.Thedisplay’srighthand
decimalpoint(datadot)isusedtoindicatestatus(seebelow).
•Press toenterthemenu.ThefourdigitdisplaywillshowADDR.
•Use and tomovebetweenmenuoptions(ortochangea
valuewithinanoption).
•Press toenteranoption(ortoxachangedvaluewithinan
optionandreturntothepreviousoptionlevel).Note: If you do
not press to fix a value, operation will revert to the
previously set mode at the next power on.
•Press toexitfromamenuoption(andeventually
exitthemenucompletely).
General notes
• EnsurethatonlyoneDMX
deviceinthechainisset
asmaster(e.g.thelighting
desk).Thisxtureisusually
settoslavemode.
•Thisxtureisshippedwith
theDMXaddresssetto
001.
•Thefourdigitdisplaycan
besettoswitchoffwhen
notinuse.Torestore,press
.Toalterthismodeuse:
PERS >DISP.
MENU ENTER
www.pixelrange.com
*Refer to product manual for proper operating instructions
DOWN UP


Master/slave/data indication
Therighthanddecimalpoint(datadot)ofthedisplayisusedtoindicatethemas-
ter/slavesettingsandalsothepresenceofaDMXinputsignal,asshownbelow:
Data dot ON Master mode
Data dot FLASHING Slavemode(DMXdatainputpresent)
Data dot OFF Slavemode(noDMXdatapresent)
Notes:
• EnsurethatonlyoneDMXdeviceinthechainissetasmaster(e.g.thedesk).
• UsePERS > datatochangebetweenmasterandslavemodes.
• Whensettomastermode,thexturewillscrollMASTERinplaceofaDMX
address(whennotwithinthemenu).
• Ifthedisplayhasbeensettoautooff(disp > aoff),thedatadotwill
remainactivebutatalowerbrightness.
DMX links and termination
ThissectionprovidesusefuladviceforgainingreliableoperationfromyourDMX
installation:
• Usegoodqualityexibletwistedpaircablethathasanominalcharacteristic
impedanceof120ohms.Microphonecableshavealowerimpedanceanda
highercapacitance,whichcanleadtodataerrors.
• Useadaisychainarrangementtolinkxturestogether,sothattheoutputof
onextureisconnectedtotheinputofthenext.
• Connectnomorethan32devicestoasingleDMXrun.Iffurtherxtures
areneeded,thenuseaDMXboostertoallowupto32morexturestobe
attached.
• NeversplitaDMXcabletoformtwobranches(aY-split).Ifseparatebranches
arerequired,useapoweredDMXsplitter.
• Ensurethatthedevicesateachendofthedaisychainarebothterminated
usinga120ohmresistor(usuallycontainedwithinaseparateXLRconnector
thathasnocable-theresistorformsalinkbetweenpins2and3).Control
desks are usually internally terminated.
Itispossibletogetawaywithbreakingsomeoftheaboverules,particularlyon
smallerinstallationsthathaveshortcablerunsandfewxtures.However,results
canbeunpredictableandproblemswillinevitablyhityouattheveryworsttime:
Duringyourshow.
Pleaseseethe‘Troubleshooting’sectionforusefulfaultndingtips.

3



































 
















 






 
Control menu contents
SetsthebaseDMXaddressfromwhichthecontrolchannelswillbegin.
Showsthemainprocessorsoftwarerevision.Nochangesarepossiblewithin
this option. Press whileviewingthisoptiontoseethesoftwaresub-revision.
Showsthedisplaycontrollersoftwarerevision.Nochangesarepossiblewithin
this option.
Selectstheprimaryinternalchaseeffect.SeeChaseeffectsfordescriptions.
Select MODE > EF Mtoshowtheselectedchase.
Selectsthecrossfadespeedbetweenthestepsoftheselected
C1chaseeffect.
SelectsthespeedoftheselectedC1chaseeffect.
SelectsthemasterintensitylevelofchaseeffectsC1 and C2.
Selectsthesecondaryinternalchaseeffect.SeeChaseeffectsfordescriptions.
Select MODE > EF Mtoshowtheselectedchase.
SelectsthecrossfadespeedbetweenthestepsoftheselectedC2chaseeffect.
SelectsthespeedoftheselectedC2chaseeffect.
Sets the red intensity. Select MODE > MANU(manual)toshowtheresult.
Sets the green intensity. Select MODE > MANU(manual)toshowtheresult.
NotavailablewhenPERS > RES is set to1CH.
Setstheblueintensity.SelectMODE > MANU(manual)toshowtheresult.
NotavailablewhenPERS > RES is set to1CH.
Setsthecoolwhiteintensity.SelectMODE > MANU(manual)toshowtheresult.
NotavailablewhenPERS > RES is set to1CH.
Setsthewarmwhiteintensity-onlyavailablewhenPERS > RES is set to 5CH.
Select MODE > MANU(manual)toshowtheresult.
Selectsnumberofchannelsrequiredtocontrolallemitters.Optionsrangefrom1
through4,5and61.Emittersaregroupedtogetheraccordingly(seechannellayouts).
Determineswhetherthisxturewillactasamastercontrollingothers.
WhencontrolledviaDMXthisxturemustbesettoSLAV.
DMX and16btmodesonly.WhensetONthisenables16-bitmasterintensitycontrol
(2x8-bitchannels).For8-bitcontrolusethehighchannelalone(seechannellayouts).
DMXmodeonly.WhensetoN,allowsyoutodeterminethedimmertypeviaDMX.
ThischannelisalwaysthenalDMXchannel.See‘ChangingdimmercurveviaDMX’.
DMXmodeonly.RotatesDMXchanneltoemittermappingby90degreeincrements
toallowforunitsmountedonthesideorinverted.See‘Rotatingtheemitterlayout’.
WhensetoN,thisoptionscrollsthroughtheprimarycoloursatpoweronto
demonstratecorrectoperationoftheemitters.
Determinestheintensityofthefourdigitcontrolpaneldisplay.Valuesrangefrom
0(dimmest)to15(brightest).
WhensettoAOFF,thecontrolpaneldisplaywillblankout25seconds
afterthemenuisexited.Thedatadotindicatorwillremainactive.
Providesachoiceoftwodimmerresponses(FINE or TUNG)tosuitrequirments.
See‘Dimmercurveoptions’fordescriptionsofeachoption.
RGBWWcontrolusinganexternalDMXcontrolinput.PERS > MINT set to ON
provides16-bitmasterintensitycontrol.Nochaseeffectsareselectable.
DisplaystheresultingRGBWWlevelsthataresetviatheMANsectionoftheinternal
menu.ExternalDMXcontrolisnotpossibleinthismode.
Displaysthechaseeffect(s)determinedwithinthePROGsection.ExternalDMX
controlisnotpossibleinthismode.
DMXCh1to4:RGBWcolourmixing,Ch5to7:C1Effect,Speed&Xfade,
Ch8to10:C2Effect,Speed&Xfade,Ch11&Ch12:16-bitmasterintensity.
DMXCh1to5:RGBWWcolourmixing,Ch6to8:C1Effect,Speed&Xfade,
Ch9to11:C2Effect,Speed&Xfade,Ch12&Ch13:16-bitmasterintensity.
DMXCh1to61:RGBWWcolourmixing,Ch62to64:C1Effect,Speed&Xfade,
Ch65to67:C2Effect,Speed&Xfade,Ch68&Ch69:16-bitmasterintensity.
16bitRGBWWcontrolusingtwoDMXchannelspercolour.PERS>MINT set to On
provides16-bitmasterintensitycontrol.Nochaseeffectsareselectable.

4
N
B
A
C
DE
F
G
H
IL
JK
O
P
Q
R
S
T
M
U
Y
W
XV
N
B
A
C
DE
F
G
H
IL
JK
O
P
Q
R
S
T
M
U
Y
W
XV
N
B
A
C
DE
F
G
H
IL
JK
O
P
Q
R
S
T
M
U
Y
W
XV
N
B
A
C
DE
F
G
H
IL
JK
O
P
Q
R
S
T
M
U
Y
W
XV
Emitter layouts
Toprovideamorecompletegamutofprimary,pastelandopenwhite
shades,PixelSmartusestwelvequad-colouremitters(red,green,blue
andcoolwhite)togetherwiththirteenwarmwhiteemitters.Thevari-
ousoperatingmodes(andthePERS > RESsetting)providechoices
astohowtheemittersareassignedtoDMXcontrolchannels.When
61+E or DMXmodes(thelatterwithPERS > RES=61)areused,you
cancontrolindividualemittersdirectly.
Theemittersareaddressedasshowninthediagrambelow.[A]to
[L]arequadcolouremittersand[M]to[Y]arewarmwhiteemitters:
Channel layouts for DMX mode
WhenusingDMXmode,themannerinwhichLEDemittersareas-
signedtoDMXchannelsisdirectlydeterminedbythePERS > RES
option. The dmxmodedoesnotusechaseeffects.Therstchannel
ofthextureoccursattheDMXaddressselectedusingaddr and
successivechannelsforthexturefollowfromthere.
Channel dmX dmx) dmx dmx
(RES=1) (RES=4) (RES=5) (RES=61)
1 Allemitters Red Red [A]Red
 2 Mast.int.(c)* Green Green [A]Green
 3 Mast.Int.(f)* Blue Blue [A]Blue
 4  Allwhites Coolwhite [A]Coolw
 5  Mast.int.(c)* Warmwhite [B]Red
 6  Mast.int.(f)* Mast.int.(c)* [B]Green
 7   Mast.int.(f)* [B]Blue
 8    [B]Coolw
. .
 47    [L]Blue
 48    [L]Coolw
 49    [M]Warmw
 50    [N]Warmw
. .
 61    [Y]Warmw
 62    Masterint.(c)*
 63    Masterint.(f)*
Rotating the emitter layout (PERS > MAP)
Whenaddressingtheindividualemitters(usingeitherthe61+E or
DMXmodes),PixelSmartallowsyoutorotatetheemitteraddressing
througheither90,180or270degreessothatunitscanbemounted
ontheirsidesorbefullyinvertedandstillshowthesamepatterns.
Use the PERS >MAP option to select the appropriate rotation
option:12CK,03CK,06CKor09CK.Eachoptionrepresentsthe
position(ontheuprightfrontface,usingaclockanalogy)wherethe
initial[A]emitterwillbelocated.Thestandardsettingof12CK(no
rotation)isshownabove.Theothersettingsareshownbelow:
PERS>MAP=03CK Ü
Forunitswherethe3
o’clockpositionisnow
upright.
PERS>MAP=09CK Ü
Forunitswherethe9
o’clockpositionisnow
upright.
ÛPERS>MAP=06CK
Forinvertedunitswhere
the6o’clockpositionis
nowupright.
Dimmer curve options (PERS > DIMR)
PixelSmartprovidestwodimmercurveoptionstodetermineexactly
howthedigitalvaluesreceivedviatheDMXlinkareconvertedinto
emitterintensities.Thedimmercurvesettingaffectsallmodes.
Toalterthedimmercurve,gotothePERSmenu,choosetheDIMR
option,selecttherequiredsettingandthenpressthe buttontosave.
Thedimmercurveoptionsareasfollows:
• FINEProvidesasquarelawdimmercurvewithfastreactionto
changingDMXvalues.
• TUNG Alters the dimming response to closely emulate the smooth
thermallagactionofstandardtungstenbulbs.TheTUNG setting
canbeusedwithalloperationmodes.Note:Thismodecanaf-
fectthewaythatfastchasesequencesappear.
Changing the dimmer curve via DMX
(PERS > DTYP)
PixelSmartallowsyoutochangethedimmingresponsecurvere-
motelyviaDMXcontrol.Whenenabled,the‘dimmertype’channel
willbeaddedasthelastchannelforthexture,aftertheMaster
Intensitychannels,ifenabled.ThedimmercurveviaDMXsetting
affectsthefollowingmodes:DMX,16BT,4+E,5+E and 61+E.
Toenableremote‘dimmertype’control:GotothePERSmenu,
choose the DTYP option and change its setting to ON.
Onceenabled,thevaluesenttothe‘dimmertype’channelwill
dynamicallyaffectwhichdimmercurvesareused:
• Values0to85selecttheFINEdimmerresponse,
• Values86to255selecttheTUNGSTENdimmerresponse.
Dimmer select**
is chan. 2if
Mast. int. is OFF
or chan. 4if
Mast. int. is ON Dimmer select**
is chan. 5if
Mast. int. is OFF
or chan. 7if
Mast. int. is ON
Dimmer select**
is chan. 6if
Mast. int. is OFF
or chan. 8if
Mast. int. is ON
Dimmer select**
is chan. 62 if
Mast. int. is OFF
or chan. 64 if
Mast. int. is ON
*The16-bitmasterintensitychannelsareenabledonly
whenthepers > mint option is set to on.For8-bit
masterintensitycontrol,usethehigh(coarse)intensity
channel.
**Thedimmerselectchannelisenabledonlywhen
the PERS > DTYP option is set to On.Values0to
85selectFINEdimmerresponse;values86to255
selectTUNGSTENdimmerresponse.See ‘Chang-
ingthedimmercurveviaDMX’.
(c) =Coarseorhighchannel,(f)=Fineorlow
channel

5
Channel layouts for remote effects modes
Thetablebelowshowshowcolourmixing,chaseeffects,master
intensityanddimmerselectcontrolsaremappedtoDMXchannels
forthe4+E,5+E and 61+Emodes.Inallmodes,therstchannel
ofthextureoccursattheDMXaddressselectedusingaddr and
successivechannelsforthexturefollowfromthere.
Channel 4+E 5+E 61+E
1 Red Red [A]Red
 2 Green Green [A]Green
 3 Blue Blue [A]Blue
 4 Allwhites Coolw [A]Coolw
 5 c1Effect Warmw [B]Red
 6 c1 Speed c1Effect [B]Green
 7 c1Xfade c1Speed [B]Blue
 8 c2Effect c1Xfade [B]Coolw
 9 c2 Speed c2Effect [C]Red
 10 c2Xfade c2Speed [C]Green
 11 Masterint.(c) c2Xfade [C]Blue
 12 Masterint.(f) Masterint.(c) [C]Coolw
 13 Dimmerselect** Masterint.(f) [D]Red
 14  Dimmerselect** [D]Green
 15   [D]Blue
 16   [D]Coolw
 17   [E]Red
 18   [E]Green
 19   [E]Blue
 20   [E]Coolw
. .
 48   [L]Coolw
 49   [M]Warmw
 50   [N]Warmw
. .
 61   [Y]Warmw
 62   c1Effect
 63   c1 Speed
 64   c1Xfade
 65   c2Effect
 66   c2 Speed
 67   c2Xfade
 68   Masterint.(c)
 69   Masterint.(f)
 70   Dimmerselect**
**ThedimmerselectchannelisenabledonlywhenthePERS
> DTYP option is set to On.Values0to85selectFINEdimmer
response;values86to255selectTUNGSTENdimmerresponse.
See‘ChangingthedimmercurveviaDMX’.
(c) =Coarseorhighchannel,(f)=Fineorlowchannel
Channel layouts for 16-bit mode
Whenusing16btmode,themannerinwhichLEDemittersareas-
signedtoDMXchannelsisdirectlydeterminedbythePERS > RES
option. The16btmodedoesnotusechaseeffects.Therstchannel
ofthextureoccursattheDMXaddressselectedusingaddr and suc-
cessivechannelsforthexturefollowfromthere.
Channel 16BT 16Bt) 16BT 16BT
(RES=1) (RES=4) (RES=5) (RES=61)
1 Allemitters(c) Red(c) Red(c) [A]Red(c)
 2 Allemitters(f) Red(f) Red(f) [A]Red(f)
 3 Mast.int.(c)* Green(c) Green(c) [A]Green(c)
 4 Mast.int.(f)* Green(f) Green(f) [A]Green(f)
 5  Blue(c) Blue(c) [A]Blue(c)
 6  Blue(f) Blue(f) [A]Blue(f)
 7  Allwhites(c) Coolw(c) [A]Coolw(c)
 8  Allwhites(f) Coolw(f) [A]Coolw(f)
 9  Mast.int.(c)* Warmw(c) [B]Red(c)
 10  Mastint.(f)* Warmw(f) [B]Red(f)
 11   Mast.int.(c)* [B]Green(c)
 12   Mast.int.(f)* [B]Green(f)
 13    [B]Blue(c)
 14    [B]Blue(f)
 15    [B]Coolw(c)
 16    [B]Coolw(f)
 17    [C]Red(c)
 18    [C]Red(f)
 19    [C]Green(c)
 20    [C]Green(f)
. .
 95    [L]Coolw(c)
 96    [L]Coolw(f)
 97    [M]Warmw(c)
 98    [M]Warmw(f)
 99    [N]Warmw(c)
 100    [N]Warmw(f)
. .
 119    [X]Warmw(c)
 120    [X]Warmw(f)
 121    [Y]Warmw(c)
 122    [Y]warmw(f)
 123    Mast.Int.(c)*
 124    Mast.Int.(f)*
Dimmer select**
is chan. 3if
Mast. int. is OFF
or chan. 5if
Mast. int. is ON
Dimmer select**
is chan. 9if
Mast. int. is OFF
or chan. 11 if
Mast. int. is ON
Dimmer select**
is chan. 11 if
Mast. int. is OFF
or chan. 13 if
Mast. int. is ON
Dimmer select**
is chan. 123 if
Mast. int. is OFF
or chan. 125 if
Mast. int. is ON
*The16-bitmasterintensitychannelsareenabled
onlywhenthepers > mint option is set to on.For
8-bitmasterintensitycontrol,usethehigh(coarse)
intensity channel.
**Thedimmerselectchannelisenabledonly
whenthePERS > DTYP option is set to On.Val-
ues0to85selectFINEdimmerresponse;values
86to255selectTUNGSTENdimmerresponse.
See‘ChangingthedimmercurveviaDMX’.
(c) =Coarseorhighchannel,(f)=Fineorlow
channel

6
Using master mode to drive other units
PixelSmartcancontrolanynumberofotherPixelRangexturesvia
DMXlinks,withouttheneedforacontroldesk.
1 Setthisunitasmaster(PERS > DATA > MAST)andensureall
others are set to slave(PERS > DATA > SLAV).Connectall
xturesviaDMXdaisy-chain.
 Note:Don’t forget to terminate the devices at either end of the
chain - see ‘DMX links and termination’.
2 SeteachslavetoMode > DMX.
3 Setthemastertoeithercreatechasesorstaticcolours:
Chases:SelectMode > EF m and then use PROG > C1 and
C2tocreatetherequiredeffects(seepage2).
Static colours:SelectMode > MANU and then use MAN >
RED,GRN,BLUE and WHiT to mix the colour.
4 SeteachslaveDMXaddress(usingADDR > DMX)accordingto
thefollowing:
 12cellsareoutputingroupsof4DMXchannelstogiveRGBW
valuespercell(48channelsintotal).Settheaddressofeach
slavextureaccordingtowhichofthe12cellsyouwantthemto
appearwithin,ortobeginwith(formulti-cellxtures):
 •Cell1 A001
 •Cell2 A005
•Cell3 A009
•Cell4 A013
•Cell5 A017
•Cell6 A021
Troubleshooting
• Display panel is blank:Pressacontrolpanelbutton,ifthedisplay
stilldoesnotshow,checktheinputpowerandfuse.
• No response during DMX control:Checkwhetheramaster
intensity input is required. 4+E,5+E and 61+E modes al-
waysrequireamasterintensityinput(channels11,12and68
respectively).DMX and 16bThaveanoptionalmasterintensity,
dependingonthesettingofPERS > MINT.IftheMINT setting
is Onthennooutputwilloccuruntilalevelgreaterthanzerois
applied to the master intensity channel.
Note: It is good practice to perform a factory reset before these
fixtures are used on any new installation.
This will ensure that settings like the MINT option are set to off
and do not create the potential for confusion. See page 1 for
details of how to perform a factory reset.
• No response during DMX control:IfliveDMXisconnected,the
righthanddecimalpointonthedisplayshouldash-ifnot,
checktheDMXcable(s)andthedeskoutput.
• Erratic operation during DMX control: Check that the final fixture
withintheDMXdaisychainiscorrectlyterminatedwitha120
ohm terminator plug.
• Erratic operation during DMX control: Check that the selected
MODEmatchesthepersonalitybeingusedonthecontroldesk.
• Erratic operation during DMX control: EnsurethatonlyoneDMX
deviceinthedaisychainissetasmaster.
• Rapid colour/intensity changes not occuring:Checkwhetherthe
tungstendimmermodeisselected(PERS > dIMR > TUNG).This
wouldslowthereactiontimesoftheemittersandcouldmeanthat
rapidchangesareblendedintoeachother.ChoosetheFINE
dimmermodetoachieveafasterreaction.
• Standalone chase effects not working: Check that a chase has
beenprogrammedusingPROG >C1 and/or PROG >C2 and
also that MODE >EF M is selected. Check also that PROG >
LEVL is not set at zero.
• Standalone RGBW mixing not working: Check that one or more
colourvalueshavebeensetwithinMAN section and also that the
MODE >MANU is selected.
Firmware upgrades
Firmwareupgradesarereleasedfromtimetotimeinordertopro-
videnewoperationalfeatures.ThePixelSmarthasbeendesignedto
allowstraightforwardrmwareupgradingviaitsDMXinterface,a
PixelU2DUSBdeviceandacomputer.
PleasecontactPixelRangetechnicalsupportfordetails.
Fuse type: 20mm 6.3A
(T6.3AL250VP)
slow-blow, glass body
Fuse access
Thesinglefuseislocatedontheundersideofthextureneartothe
powerconnectors.Useasmallatbladescrewdrivertotwistthe
fuseholderanticlockwiseuntilthecarriercanbeextractedtoreveal
thefuse.
•Cell7 A025
•Cell8 A029
•Cell9 A033
•Cell10 A037
•Cell11 A041
 •Cell12 A045
Note: For best results, set PERS > RES to 4CH on each slave unit.

7
Weight
 Fixtureandyoke: 8.75kg(19.3lbs)
Power
 Inputvoltage: 90to264VAC,47to63Hzautosensing
 Connectors: Suppliedwithcableonly:live,neutral&earth
 Powerrequirements: @ 230V/50Hz @ 115V/60Hz
Standby  20watts  20watts
Maximum (const.)  185watts  185watts
Start up (peak*)  60amps  30amps
* The peak value occurs only at first power up and
lasts only for a period measured in microseconds.
Approvals
Miscellaneous
 Enclosurerating: IP20(notprotectedagainstmoistureingress)
 Controlinput: USITTDMX512(inputconnectorpinoutbelow)
Specifications
Dimensions
PIN 1
Ground
PIN 2
Data –PIN 3
Data +
PIN 5
Not used
PIN 4
Not used
DocumentationbyCorporate Text & Design(www.ctxd.com)
Release1.64e
www.pixelrange.com
UK [phone]
[email protected]
USA [phone]
[email protected]
235mm (9.25”)
215mm (8.46”)
337mm (13.26”)
298mm (11.73”)
