Playsonic PSF105W User manual

1
Refrigerator
USER’S MANUAL
PSF105W
This product was supplied by Shomar Ltd Dublin. If you have a
questions regarding your appliances please contact us on
01- 4505327 or visit our website.www.shomar.ie
To register and extend your warranty please go to
www.playsonic.ie

2
Dear customer:
Thank you for buying this upright freezer. To ensure that you
get the best results from your new freezer, please take time
to read through the simple instructions in this booklet.
Please ensure that the packing material is disposed of in
accordance with the current environmental requirements.
When disposing of any Freezer equipment please contact
your local waste disposal department for advice on safe
disposal.
This appliance must be only used for its intended purpose.
CAUTION :
The appliance is not intended for use by young children or
infirm persons without supervision.
Young children should be supervised to ensure that they do
not play with the appliance
General
This type of refrigerator is widely used in places such as
hotels ,offices, student dormitories and houses. It is mostly
suitable for refrigerating and preserving foods such as fruits
and beverage. It enjoys the advantages of small size,
Lightweight, Low electric consumption and easy use.

3
Chief Technical Data
Model
Item PSF105W
Type of Preventing From
Electric Shock Ⅰ
ⅠⅠ
Ⅰ
Refrigerant (g) R600a,35g
Total Storage Volume( ) 83
Rated Voltage(V) 220-240~
Rated Frequency(Hz) 50
Energy(kWh/24h) 0.47
Weight (kg) 33.5

4
Main configuration：
1、Thermostat
2、Drawer
3、Leveler leg
1
2
3

5
UNPACKING YOUR FREEZER
WARNING: Use two or more people to move Freezer.
Failure to do so can result in back or other
injury.
· Remove tape and any labels from your Freezer before
using(except the rating label).
· To remove any remaining tape or glue, rub the area briskly
with your thumb.
· Tape or glue residue can also be easily removed by rubbing a
small amount of liquid dish soap over the adhesive with your
fingers. Wipe with warm water and dry.
· Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your Freezer.
· When moving the Freezer, do not tilt the Freezer beyond
45°from upright position.
CLEANING BEFORE USE：
：：
：
After you remove all of the packaging materials, （ especially
the foam between outside condenser and cabinet should be
removed ） clean the inside of your Freezer before using it.
SPACE REQUIREMENTS
WARNING: Keep flammable materials and vapors, such as
gasoline, away form Freezer.
Failure to do so can result in death, explosion, fine or
burns.
· To ensure proper ventilation for your Freezer, allow for
200mm space on each side between walls, 200mm space
between back of your Freezer and the wall, and 300mm

6
space between counter top and the roof or ceiling.
· If you are installing your Freezer next to a fixed wall, leave
sufficient space on the hinge side to allow for the door to
swing open.
· Never install your Freezer near heat source and direct sun
shins.
ELECTRICAL REQUIREMENT
WARNING: DO NOT REMOVE GROUND PRONG.
DO NOT USE AN ADAPTOR.
DO NOT USE EXTENSION CORD.
Failure to follow these instructions can result in
death, fire or electrical shock.
Before you move your Freezer into its final
location, it is important to make sure you have the
proper electrical connection.
Recommended Earthing Method
A 220 ～ 240 Volt /50 Hz AC only 10 ampere fused and properly
earthed electrical supply is required. It is recommended that a
separate circuit serving only this appliance be provided. Use a
receptacle which cannot be turned off with a switch or pull
chain. Do not use an extension cord.
NOTE: Before performing any type of installation, disconnect
the Freezer from the electrical source. When you are finished,
connect the Freezer to the electrical source and reset the
control to the desired setting.

7
LEVELING
If the Freezer is not leveled during installation. The doors may
not close or seal properly, causing cooling, frost, or moisture
problems. It is very important of the Freezer to be level in order
to function properly.
To level your Freezer you may either turn the level leg
clockwise to raise that side to the Freezer or turn counter –
clockwise to lower that side.
NOTE: Having someone push against the top of the Freezer
take some weight off the leveling leg. This makes it easier to
adjust the leveling leg.
USE OF THE APPLIANCE
To obtain the best possible results form your Freezer, it is
important that you operate it properly.
Temperature Control
The temperature in the freezer is controlled by the thermostat
control knob.It is loaded in the top-front of the freezer. Turn the
thermostat control knob up or down to regulate the temperature
inside the freezer. The markings on control knob indicated the
“1~4” for the different temperature grades. The temperature
decreases with position “1” being the warmest and position “4”
being the coldest. the marking “black point”means the freezer
stop working 。
Set the control to position between “1” and “4” for normal use,
the exact position is beyond the temperature in the freezer,
generally , choose the number“2” 。

8
Store Frozen Food
When using the freezer for the first time or after defrosting, turn
the temperature control to set “4” for at least two hours before
introducing the food to be stored.
All frozen food products you purchase should be placed in the
freezer as soon as possible to avoid the frozen food from
defrosting.
Storage recommendation printed on the packaging of frozen
food by the manufacturers should be always be followed.
Be careful that the drawer mustn’t mangle the refrigeration
pipeline
Freezing Fresh Food
Ensure that your freezing operations are carried out under the
most hygienic conditions as freezing alone does not sterilize
the food. It is advisable to freeze the food by packing it into
separate meal portions and not in bulk form. Never put hot or
even warm foodstuffs into the freezer. Prior to storing the
frozen food, pack it in plastic bags, aluminum sheets or
freezing containers and place into the freezer. See the data
sheet at the rear of this booklet for the maximum permissible
amount in kilograms of fresh food that can be frozen in any 24
hour period with a room temperature of 25. Never freeze
more than the maximum permissible.
Note: Never put bottled food or drinks in the freezer
compartment.

9
.For best performance, leave enough space in the Freezer
compartment for air to circulate around the packages.
Notice ： You can use it without drawer under some conditions.
Defrosting
Remove the mains plug from the wall socket, open the door
and remove all the food to a cool place. Defrost using a plastic
scraper, or let the temperature rise naturally until the frost melts.
Then wipe away the remaining ice and water, after this plug the
freezer back into the mains supply.
Note: To avoid damaging the freezing compartment wall, do
not use any sharp objects to remove the frost or
separate the frozen food.
Cleaning your freezer
Before you start to clean your freezer remove the mains plug
from the power supply.
Use a clean sponge or soft and a mild detergent in warm water.
Do not use abrasive or harsh cleaners.
Hand wash, rinse and dry all surfaces thoroughly.
Do not use cleaning waxes, concentrated detergents, bleaches
or cleaners containing petroleum on plastics and rubber parts.
Never use paper towels, window sprays, scouring cleansers or
flammable fluids on plastic parts as these can scratch or
damage material.
Clean with a cloth soaked in this solution and then dry with a
soft cloth.

10
PROLONGED OFF PERIODS
If the freezer is not in use for a long period of time, proceed as
follows:
Disconnect the freezer from the main supply by removing the
plug from the wall socket.
Clean and dry the inside as instructed under the heading of
cleaning the Freezer.
Leave the door open to prevent any unpleasant smells from
building up while the freezer is not in use.
TROUBLESHOOTING
In case of malfunction, you can solve many common problems
easily.
Your Freezer will not operate…Check if
-- The power supply cord is unplugged.
The doors will not close completely…Check if
-- The drawers are out of position.
-- The gaskets are dirty.
-- The Freezer is not level.
The freezer is noisy when running…Check if
-- Check the freezer is level and it is not in contact with
another appliance or kitchen furniture.
The freezer does not cool sufficiently…Check if
-- If the door has been opened too often, or it has been left
open for a while it will take time for the freezer to reach its
set temperature.
-- Check the airflow the rear of the freezer has not been

11
reduced due to insufficient clearance.
The following characteristics should not be looked upon
as a problem.
-- A gentle tricking sound caused by coolant flowing the
pipe.
-- Compressor operating at high temperature.
WARNNING
REQUESTING ASSISTANCE OR SERVICE
If the problem is not due to one of the items listed in
Troubleshooting, Contact the dealer or authorized Service
Company.
RECOMMENDATIONS
1) WARNING – Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.

12
2) WARNING – Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
3) WARNING – Do not damage the refrigerant circuit.
4) WARNING – Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
5) The appliance has to be unplugged after use and before
carrying out user maintenance on the appliance.
6) This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
7) Children should be supervised to ensure that they do not
play with the appliance.
8) If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
9) Please abandon the refrigerator according to local
regulators for it use flammable blowing gas and refrigerant.
10 ） Please according to local regulations regarding disposal of

13
the appliance for its flammable refrigerant and blowing gas.
Before you scrap the appliance, please take off the doors to
prevent children trapped.
Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this
product for environmental safe recycling.
Name Of Company: Shomar Ltd
Address: Shomar Ltd, Unit 9 Western Industrial Estate, Dublin
12, Ireland.
Telephone: [phone]
Fax: [phone]
Email: [e-mail]

14
Refrigerator door install guidelines about swapping
left&right
1 、 Disassemeble the screws behind the fixed roof with cross-slot
screwdriver and remove the cover from the
refrigerator.
The
two
screws fixed
the cover.

15
2 、 Remove the screws fixed the top-hinge with cross-slot
screwdriver.
T
he screws fixed
the top-hinge

16
3 、 Replace the top-hinge and the door limit block and the door
bearing bush to the other side
A 、 replace the top-hinge.

17
B 、 replace the door bearing bush and the limit block.

18
4 、 Disassemble the screws fixed the bottom-hinge with
cross-slot screwdriver and replace the hinge to the other side
then fix it with screws 。
note ： the refrigerator incline angle less 45 ° .
The screws
fixed the
bottom-hinge

19
5 、 replace the leveler to the other side and adjust it to make sure
the cabinet level

20
6 、 Set the door right position,fix the top-hinge and then the roof
cover.
Ensure the Appliance is unplugged and empty 。
Adjust the two leveling feet to their highest position 。
We recommend you have someone to assist you 。
NOTE ：
：：
：
To take the door off it is necessary to tilt the Appliance
backward 。
