Playsonic PSR107LW User manual

1
Refrigerator
USER’S MANUAL
PSR107LW

2
Dear customer:
Thank you for buying this upright refrigerator. To ensure that
you get the best results from your new refrigerator, please
take time to read through the simple instructions in this
booklet.
Please ensure that the packing material is disposed of in
accordance with the current environmental requirements.
When disposing of any Refrigerator equipment please
contact your local waste disposal department for advice on
safe disposal.
This appliance must be only used for its intended purpose.
CAUTION :
The appliance is not intended for use by young children or
infirm persons without supervision.
Young children should be supervised to ensure that they do
not play with the appliance
General
This type of refrigerator is widely used in places such
as hotels ,offices, student dormitories and houses. It is
mostly suitable for preserving foods such as fruits and
beverage. It enjoys the advantages of small size,
lightweight, low electric consumption and easy use 。

3
Chief Technical Data
Model
Item PSR107LW
Type of Preventing From
Electric Shock Ⅰ
ⅠⅠ
Ⅰ
Refrigerant (g) R600a,18g
Total Storage Volume(L) 133
Rated Voltage(V) 220-240~
Rated Frequency(Hz) 50
Energy（kWh/24h）0.32
Weight (kg) 30.5

4
Main configuration：
1、Thermostat
2、Glass shelf
3、Plastic pallet
4、Crisper
5、Leveler leg
UNPACKING YOUR REFRIGERATOR
WARNING: Use two or more people to move refrigerator.
Failure to do so can result in back or other
injury.
1
2
4
3
5

5
· Remove tape and any labels from your refrigerator before
using(except the rating label).
· To remove any remaining tape or glue, rub the area briskly
with your thumb.
· Tape or glue residue can also be easily removed by rubbing a
small amount of liquid dish soap over the adhesive with your
fingers. Wipe with warm water and dry.
· Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator.
· When moving the refrigerator, do not tilt the refrigerator
beyond 45°from upright position.
CLEANING BEFORE USE：
：：
：
After you remove all of the packaging materials, （ especially
the foam between outside condenser and cabinet should be
removed ） clean the inside of your refrigerator before using it.
SPACE REQUIREMENTS
WARNING: Keep flammable materials and vapors, such as
gasoline, away form refrigerator.
Failure to do so can result in death, explosion, fine or
burns.
· To ensure proper ventilation for your refrigerator, allow for
200mm space on each side between walls, 200mm space
between back of your refrigerator and the wall, and 300mm
space between counter top and the roof or ceiling.
· If you are installing your refrigerator next to a fixed wall, leave
sufficient space on the hinge side to allow for the door to
swing open.

6
· Never install your refrigerator near heat source and direct sun
shins.
ELECTRICAL REQUIREMENT
WARNING: DO NOT REMOVE GROUND PRONG.
DO NOT USE AN ADAPTOR.
DO NOT USE EXTENSION CORD.
Failure to follow these instructions can result in
death, fire or electrical shock.
Before you move your refrigerator into its final
location, it is important to make sure you have the
proper electrical connection.
Recommended Earthing Method
A 220 ～ 240 Volt /50 Hz AC only 10 ampere fused and properly
earthed electrical supply is required. It is recommended that a
separate circuit serving only this appliance be provided. Use a
receptacle which cannot be turned off with a switch or pull
chain. Do not use an extension cord.
NOTE: Before performing any type of installation, disconnect
the refrigerator from the electrical source. When you are
finished, connect the refrigerator to the electrical source and
reset the control to the desired setting.
LEVELING
If the refrigerator is not leveled during installation. The doors
may not close or seal properly, causing cooling, frost, or
moisture problems. It is very important of the refrigerator to be
level in order to function properly.

7
To level your refrigerator you may either turn the level leg
clockwise to raise that side to the refrigerator or turn counter –
clockwise to lower that side.
NOTE: Having someone push against the top of the
refrigerator take some weight off the leveling leg. This makes it
easier to adjust the leveling leg.
USE OF THE APPLIANCE
To obtain the best possible results form your refrigerator, it is
important that you operate it properly.
Temperature Control
Controls for the refrigerator is located at the fop shelf of the
refrigerating compartment. When you first install your
refrigerator, set the Thermostat knob at 3. Give your
refrigerator time to cool down completely before adding food. It
is best to wait 24 hours before adding food.
The thermostat knob controls the temperature. The higher
number setting, the longer the compressor will run to keep the
temperature colder.
When the thermostat control knob is set to OFF, the refrigerator
is not running,
Fresh Food Storage
Wrap or store food in the refrigerator in airtight and moisture –
proof material. This prevents food odor and taste transfer
throughout refrigerator.

8
· Fruit – wash, let dry and store in
refrigerator in plastic bags or
crisper.
· Leafy vegetables- Remove wrapping and trim or tear
off bruised and discolored areas,
wash in cold water and drain.
Place in plastic bag or plastic
container and store in crisper.
· Fish – Use fresh fish the same day as
purchased.
· Meat – Store most meat in original
wrapping as long as it is airtight
and moisture – proof. Re – wrap if
necessary.
· Leftovers – Cover leftovers with plastic wrap
or aluminum foil.
Plastic containers with tight lied
can also be used.
Defrosting
Refrigerator compartment – Defrosting process is
automatic by thermostat
knob Melted frost flow into
drip tray and automatic
evaporating.

9
Cleaning your refrigerator
Before you start to clean your refrigerator remove the mains
plug from the power supply.
Use a clean sponge or soft and a mild detergent in warm water.
Do not use abrasive or harsh cleaners.
Hand wash, rinse and dry all surfaces thoroughly.
Do not use cleaning waxes, concentrated detergents, bleaches
or cleaners containing petroleum on plastics and rubber parts.
Never use paper towels, window sprays, scouring cleansers or
flammable fluids on plastic parts as these can scratch or
damage material.
Clean with a cloth soaked in this solution and then dry with a
soft cloth.
PROLONGED OFF PERIODS
If the refrigerator is not in use for a long period of time, proceed
as follows:
Disconnect the refrigerator from the main supply by removing
the plug from the wall socket.
Clean and dry the inside as instructed under the heading of
cleaning the refrigerator r.
Leave the door open to prevent any unpleasant smells from
building up while the refrigerator is not in use.
TROUBLESHOOTING
In case of malfunction, you can solve many common problems
easily.
Your Refrigerator will not operate…Check if

10
-- The power supply cord is unplugged.
-- The thermostat knob is set to OFF position.
The light so not work … Check if
-- The power supply cord is unplugged.
-- A household fuse or circuit breaker has tripped.
-- A light bulb is loose in the socket.
-- A light bulb has burned out.
Food in the refrigerator compartment freezing … Check if
-- The thermostat knob is set too cold.
-- The position of food stored touches the refrigerant power of
refrigerator back wall.
Food in the refrigerator compartment is not cold … Check if
-- The air vents are blocked in the compartment. This
prevents the movement of cold air.
-- The door(s) are opened too often of not close properly.
-- A large amount of food has just been added to the
refrigerator or refrigerator compartment.
-- The position of thermostat knob is adjusted too low.
Melted frost Leak over compartment inside or on floor …
Check if
-- The drain – off mouth entrance is blocked.
-- Evaporator pan is in place.
The refrigerator seems to make unusual noise … Check if
-- The refrigerator is leveled on the floor.

11
-- The body of the refrigerator touches the wall.
-- The drip tray is not placed properly.
There is interior moisture build - up … Check if
-- The air vents are blocked in the refrigerator.
-- The door is opened often.
-- The room is humid.
-- The food is not packaged correctly.
-- The control is not set correctly of the surrounding
conditions.
The doors will not close completely … Check if
-- The shelves are out of position
-- The gaskets are dirty.
-- The fridge is not level.
WARNNING
1) WARNING – Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.

12
2) WARNING – Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
3) WARNING – Do not damage the refrigerant circuit.
4) WARNING – Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
5) The appliance has to be unplugged after use and before
carrying out user maintenance on the appliance.
6) This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
7) Children should be supervised to ensure that they do not
play with the appliance.
8) If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
9) Please abandon the refrigerator according to local
regulators for it use flammable blowing gas and refrigerant.
10 ） Please according to local regulations regarding disposal of

13
the appliance for its flammable refrigerant and blowing gas.
Before you scrap the appliance, please take off the doors to
prevent children trapped.
Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this
product for environmental safe recycling.
Name Of Company: Shomar Ltd
Address: Shomar Ltd, Unit 9 Western Industrial Estate, Dublin
12, Ireland.
Telephone: [phone]
Fax: [phone]
Email: [e-mail]

14
Refrigerator door install guidelines about
swapping left&right
1 、 Disassemeble the screws behind the fixed roof with cross-slot
screwdriver and remove the cover from the
refrigerator.
2 、 Remove the screws fixed the top-hinge with cross-slot
screwdriver.
The
two
screws fixed
the cover.

15
3 、 Replace the top-hinge and the door limit block and the door
bearing bush to the other side
A 、 replace the top-hinge.
T
he screws fixed
the top-hinge

16
B 、 replace the door bearing bush and the limit block.

17
4 、 Disassemble the screws fixed the bottom-hinge with
cross-slot screwdriver and replace the hinge to the other side
then fix it with screws 。
note ： the refrigerator incline angle less 45 ° .

18
5 、 replace the leveler to the other side and adjust it to make sure
the cabinet level
The screws
fixed the
bottom-hinge

19
6 、 Set the door right position,fix the top-hinge and then the roof
cover.
Ensure the Appliance is unplugged and empty 。
Adjust the two leveling feet to their highest position 。
We recommend you have someone to assist you 。
NOTE ：
：：
：
To take the door off it is necessary to tilt the Appliance

20
backward 。
You should rest the Appliance on something solid e.g.a chair just
below the top panel 。
Do not lay the Appliance completely flat as this may damage the
coolant system 。
