Norlake NSPR502WWG User manual

NOR-LAKE SCIENTIFIC
A Division of
NOR-LAKE, INCORPORATED
727 Second Street
P.O. Box 248
Hudson, Wisconsin 54016
800-477-5253
715-386-2323
800-388-5253 PARTS
715-386-4290 FAX
www.norlake.com
NOR-LAKE SCIENTIFIC
SLIDING GLASS DOOR LAB REFRIGERATOR
Nor-Lake, Inc.
Registered to ISO 9001:2000
File No. A3204
Designed to meet the demanding requirements of
scientific and laboratory applications. Cabinet
incorporates industrial quality. Improved air flow and
heavy duty refrigeration system maintain your valuable
products.
Standard Product Features:
■Digital microprocessor temperature controller
■Hi/lo audible/visual alarm with remote alarm
contacts
■LED temperature display
■Operating temperature of 4°C
■Exterior front and sides are painted white
baked enamel with a smooth finish
■Top and bottom are galvanized steel
■4 casters, two locking
■3 epoxy coated cantilevered shelves per door,
which are adjustable to 1” increments
■Extra large sliding glass doors
■Doors have a self closing feature and key
locks, hold open feature
■Glass is tempered thermopane
■Interior fluorescent lighting
■Complete top mount refrigeration system
■Air-cooled condensing unit
■Automatic condensate evaporation
■Automatic defrost
■Coated evaporator
■Complete cabinet is foamed-in-place with CFC Free
high density polyurethane foam insulation
■Warranties: 18 months parts and labor
(US and Canada) 18 months parts (International)
■UL and C-UL listed, CE Mark
Optional Features:
■6" legs
■Duplex outlet
■Extra shelves
■Access port 2”
sleeve with cover
■Stainless steel
exterior
■
■Stainless steel
interior
■Temperature chart
recorder
■Chart paper
■4-20 MA Ouput
NSPR502WWG/
SCIENTIFIC

Revision Date: 8/06
© 2006 NOR-LAKE, INC.
Printed in the U.S.A.
Part Number: 133828
SPECIFICATIONS
Model NSPR502WWG/0 NSPR502WWG/5
Crated Height 84” (208 cm) 84” (208 cm)
Crated Width 59” (150 cm) 59” (150 cm)
Crated Depth 41” (104 cm) 41” (104 cm)
Crated Weight (lbs) (kg) 711 (323 kg) 711 (323 kg)
Interior Height 59” (149.9 cm) 59” (149.9 cm)
Interior Width 51” (129.5 cm) 51” (129.5 cm)
Interior Depth 28” (76.2 cm) 28” (76.2 cm)
Overall Height* 80-3/8” (204.2 cm) 80-3/8” (204.2 cm)
Overall Width 55” (139.7 cm) 55” (139.7 cm)
Overall Depth 34” (86.4 cm) 34” (86.4 cm)
Gross Cubage (ft3.) 47-1/2 (1.35m3) 47-1/2 (1.35m3)
Shelf Area (sq. ft.) 26 (2.4 m2) 26 (2.4 m2)
Glass Area (sq. ft) 17.47 (1.62m2) 17.47 (1.62m2)
Number of Shelves 6 6
Number of Casters 4 4
Number of Legs 4 Optional 4 Optional
Condensing Unit Size 1/3 1/3
Refrigerant R134a R134a
Electrical Characteristics 115/60/1 230/50/1
Cord & Plug Furnished Yes No
Maximum Fuse Size 15 15
Total Amp Draw 10.7 5.1
Specifications subject to change without notice.
TOP
NSPR502WWG/
Voltage Model
Suffix Code Voltage Description NEMA Plug NEMA Receptacle
/0 115/1PH, 60HZ 5-15P 5-15R
/5 230V, 1PH, 50HZ Power Inlet
(IEC 60320) Module
Cord Supplied
Locally
