Starting up the PX-PA15AW
Chapter 1 Starting up the PX-PA15AW
Here is a description of how to configure and log in to the PX-PA15AW.
1. After the Receiver Box has been connected, turn it on and wait for
10 seconds.
We recommend using the Ethernet LAN port to connect
to the Receiver Box. Either by direct connection or
through a hub device. The Ethernet cable for the direct
connection is not required to be of the cross type.
2. You must set the network adapter to the same network segment
before connecting to the Receiver Box.
The adapter cannot use a DHCP client since the
Receiver Box supports DHCP clients but not DHCP
servers.
Here is how to set up the IP address.
a. From the Windows Control Panel, open Network
Connections, click Local Area Connection, and then click
Properties. You will see the following dialog box.
1

Starting up the PX-PA15AW
b. Click Internet Protocol (TCP/IP) and change the IP address
to a number between 192.168.168.2 and 192.168.168.254.
(Don't use 192.168.168.30).
Type 255.255.255.0 for the Subnet mask.
Example of an IP Address
2

Starting up the PX-PA15AW
3. Use your Internet browser to open http://192.168.168.30/ to see
the configuration page for the Receiver Box. Type "admin" as User
name, and "1234" for Password.
You must disable your firewall and proxy settings.
If the configuration page doesn't open, turn the device
off and on to reset it.
3

Setting up the PX-PA15AW
Chapter 2 Setting up the PX-PA15AW
The main menu has all the controls for configuring your PX-PA15AW.
Status
Under Status, you can view the current settings of the Ethernet LAN or
WLAN.
Click General and LAN to see the Device Information and LAN
Settings, including the MAC and IP address.
WLAN settings can be seen by clicking WLAN.
•The Region setting will tell you if 802.11a Ad-hoc mode is
supported or not. For region ETSI, the 802.11a 5 GHz Ad-hoc
mode is not supported.
•The Link Status may be Up, indicating that it is connected to a
PX-PA15AW Sender, or Down, indicating that it is available
for connecting.
4

Setting up the PX-PA15AW
Setup
Under Setup, you can choose LAN or WLAN.
LAN is used to choose DHCP or static for the IP address.
•If you select DHCP, you have to find the IP address by using
another tool or by asking your MIS department if you ever
need to reconfigure. An alternative would be to push and hold
the Reset button on the Receiver Box for more than 5 seconds
to revert to the factory default IP address.
•If you change to another network segment, remember to
configure the computer to the same network segment.
5

Setting up the PX-PA15AW
Use WLAN to change these settings.
•Country is used to identify the WLAN card set.
•Region is used to identify the radio certification. For example,
FCC, ETSI.
•SSID is defaulted to use “WMS100-IMAGE”
•Channel & Transmission rate is used to identify the
transmission speed. Channels higher than 36 are for 802.11a
(5 GHz). Transmission rates faster than 24 Mbps indicates that
you can use 802.11a and 802.11g modes.
Some WLAN cards don’t support the 802.11g Ad-hoc
mode. These will use the IEEE standard 802.11b. The
performance will be lower.
•If the channel is changed, a new Web page will open for the
settings. After finishing the settings, click Apply.
•The default settings will be Channel 11, 802.11b, and 802.11g
Ad-hoc mode.
6

Setting up the PX-PA15AW
Maintenance
Click to upgrade firmware or reset factory default and bridge functions.
Change Username/Password
Click for security control to restrict access to the PX-PA15AW Receiver
Box. You can press the Reset button for more than 5 seconds to get
the default user name and password if you forget it. Only English
alphanumeric characters are accepted for passwords.
