POD Camping 480 User manual

POD Camping 480
(walls 42)
NB! Please read whole installation
manual before start.
All given measurements are
in millimeters.

Details list.
POD Camping 480
(walls 42mm.)
1
2316*94*44
x9
2
4800*94*44
x2
3
2316*44*44
x3
7b
4000*140*42
4000*140*42
7a
x21
2200*43*18
x21
5a
5b
5c
5d
6a
6b
6c
6d
x2
x2
x2
x2
x1
x1
x1
x1
2200
assembled
2172
assembled
10b
10a
10
625*43*18
x2
x2
715*43*18
8
1100*1650
1610*43*18
1150*43*18
8b
8a
x1
x2
x2
9
9b
9a
700*1800
1760*43*18
x1
x2
x2
750*43*18
12b
x2
x21
4
4046*113*28
665*665
x1
11
600*95*28
x23
1804*43*18
12a
x2
N
O
L= 1000
L= 1000
x10pkg
x16
13a
13b
13c
13d
x4
x4
x4
x4
J
L
4,5x90
4,5x60
4,0x50
3x40
x70
x120
x360
x60
~1,5 kg
H
I
M

1.
18x M
18x M
9x DET 2
2x DET 1
2x DET 1
9x DET 2
POD Camping 480
600
70
4800
2404
2316
mm=mm
mm=mm
I
II
3x DET 3
Side view
DET 3
Side view
DET 3
18x H

2.
103x H
20x DET 4
POD Camping 480
I
Fix screws over one board,
diagonally in every board.
First board and ends of boards fix
screws in every board.
42
44
44
X
X-44 mm.
II
III
1x DET 4
8x H
IV

3.
POD Camping 480
3.
I
DET 5a
DET 5b
DET 5c
DET 5d
Cut boards from
pallet L~1800 mm
10x I
6x M
Drill holes Ø4mm
before screws
Cut boards from
pallet L~1800 mm
10x I
6x M
II
Front and back wall
Middle wall
DET 6a
DET 6b
DET 6c
DET 6d

POD Camping 480
4.
1x DET 7a
1x DET 7b
4x H
Use waterlevel!
Fix temporarily to
support walls.
mm=mm
12x H
Drill holes Ø4 mm before screws.

POD Camping 480
5.
1x DET 7a
1x DET 7b
20x H
I
10x DET 7a
10x DET 7b
60x H
II
III
Remove
8x DET 7a
8x DET 7b
48x H

III
6x H
I
1x DET 7b
1x DET 7a
Wall midpoint
~75°
~75°
II
IV
7x H
POD Camping 480
6.

I
POD Camping 480
7.
Remove all
brackets
III
Cut out, follow
the guidelines
1660
1110
~110
675
675
1000
II
Front
Mark door
opening.
Mark window
opening.
Cut out, follow
the guidelines
Remove all
brackets
Back
Middle
710
1810
~70
Mark door
opening.
IV

I
POD Camping 480
8.
Cut out, follow
the guidelines
Place doors and
window from inside.
Use waterlevel.
1x DET 8
1x DET 9
1x DET 10
II
III
32x I
Vertically fix screw in every board.
32x I
Vertically fix screw in every board.
16x I
IV
V
2x M
Drill holes Ø4mm
before screws.

I
POD Camping 480
9.
2x DET 9a
2x DET 9b
16x J
2x DET 10a
2x DET 10b
12x J
II
2x DET 8a
2x DET 8b
18x J
46x H
23x DET 11
III
IV
2x H
Drill holes Ø4mm
before screws.
V
10x J
8x J
2x DET 12b
VI
2x DET 12a

II
POD Camping 480
10.
L
Check also roof shingles
installation manual inside package.
DET N
DET O
Cut and use it
on other end.
DET N
I
III
Cut

POD Camping 480
11.
20x H
2x DET 13a
2x DET 13b
2x DET 13c
2x DET 13d
2x DET 13a
2x DET 13b
2x DET 13c
2x DET 13d
20x H
Cut the ends
if necessary
