Polaris NG60H Quick start guide

3
Reverse Camera
Cam 1
Cam 2
Cam 3
Reverse (Green)
GND (Black)
Acc+ (Red)
Plugs into back of monitor
Wiring Notes:
• The NG60 has 4 camera inputs but is designed for one camera to be triggered when
reverse gear is engaged.
• Whichever camera you want to trigger when reverse gear is engaged, please make
sure you plug it into the reverse camera input.
• You can still access Cam 1, 2 & 3 whilst in reverse, please see page 4 for instructions
on how to do this.
• If you don't wish for a camera to activate whilst in reverse, then simply plug your
camera into either Cam 1, 2 or 3 as you can view these cameras whilst driving.
• Cam 1, 2 & 3 can be accessed at any time whilst driving forward, please see
page 5 for instructions on how to do this.
• The NG60 is 12-32Volt and is built into the monitor.
• If you are only wiring up one camera to engage when in reverse please run the
Acc+ (red) along with the reverse trigger wire (green) directly to your reverse lights.
This way the monitor will power down when drive is activated. If you add an
additional camera(s) at a later stage, please run the ACC+(red) to accessories
power so you can access the additional camera(s) whilst driving.
If you have any questions in regards to the wiring of this unit, please contact
Polaris on 1300 555 514
Wiring Diagram
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 3

NG60—reverse trigger only wiring diagram
Twist together and wire to reverse power
Ideal setup if you only want a single camera to come on when reverse
gear is engaged. The monitor will power off when drive is engaged.
If you add any more cameras at a later stage, you will need to wire the
12V+ to accessories power
If you wish to view the camera at any time, plug the camera into
Camera 1 and do not wire up the reverse trigger
Miniature Camera
7 metre extension cable
Reverse trigger
12V+ (ACC)
GND -
Plug camera into reverse camera input

NG60WR Wiring Diagram
7 metre extension cable
Reverse trigger
12V+ (ACC)
GND -
Plug camera into Cam 1
If you wish to view the camera at any time, please plug the camera
into camera 1
If you wish for the camera to only come on when you engage
reverse, plug the camera into the reverse camera input and wire
both the 12V+ (ACC) and the reverse trigger to reverse power
White Round Camera

Reverse Trigger
Ground
ACC Power
7M EXT.
1. It’s preferred that this camera stays on all the time, to do so plug the
7m extension into camera 1 plug, and have the wiring as normal.
2. If you only want this camera to come on in reverse and you’re not going
to be adding any other cameras, plug the 7m extension into the reverse
plug. Also when wiring, connect the reverse wire and accessories wire
together and power if from reverse power, this is done so that the
monitor only turns on in reverse.
NG-CV05 Wiring Diagram
2M CARSIDE WOZA
CABLE
2.5M COIL CABLE
10M CARAVAN WOZA
CABLE

Reverse Trigger
Ground
ACC Power
7M EXT.
1. The mini camera is designed to be at the back of the vehicle, and is
generally plugged into the reverse input so that it comes on in reverse.
2. Your white IR camera will be plugged into cam 1 input, so you can
access it whenever you like or have it on constantly.
NG-CV10 Wiring Diagram
2M CARSIDE WOZA
CABLE
2.5M COIL CABLE
10M CARAVAN WOZA
CABLE
7M MINI
CAM EXT.

Reverse Trigger
Ground
ACC Power
2x 7m Ext.
1. Make sure the camera you want to come on in reverse, is plugged into
the reverse camera plug. (Either the 120° or 40°, generally the 120°)
2. If you don’t want a triggering camera, just plug both cameras into cam1
and cam 2.
NG-60DC Wiring Diagram

NG-CV05DC Wiring Diagram
Reverse trigger
12V+ (ACC)
GND -
Dual WOZA Kit
7 metre ext cables
Dual Camera
If you want your 120 degree camera to
engage when in reverse, plug into the
reverse camera input.
Plug your 40 degree camera into Cam 1 so
you can view at any time
The 120 degree lens is generally meant for reversing purposes
only. However if you wish to view both the 120 and the 40
degree lens at any time, simply plug the dual camera into Cam 1
and Cam 2 and do not wire up the reverse trigger wire.

NG-CV60DC Wiring Diagram
Reverse trigger
12V+ (ACC)
GND -
Dual WOZA Kit
Dual Camera
Generally the tow vehicle camera plugs into the reverse camera
input however if you want to bypass the reverse trigger, simply
plug all three cameras in Cam1, Cam 2 and Cam 3 and do not
wire up the reverse trigger wire.
Plug your miniature camera (mounts on the back of tow vehicle) into the reverse
camera input
Plug your dual camera into camera 1 and camera 2
Miniature Camera

NG60H Wiring Diagram
10 metre extension cable
Reverse trigger
12V+ (ACC)
GND -
Plug camera into Cam 1
If you wish to view the camera at any time, please plug the camera
into camera 1
If you wish for the camera to only come on when you engage
reverse, plug the camera into the reverse camera input and wire
both the 12V+ (ACC) and the reverse trigger to reverse power
Heavy Duty Camera
