Polaris IDD User manual

Pantone 419C
Interactive
Digital Display
Owner’s Manual

1

2
Copyright 2014 Polaris Industries Inc.
All information contained within this publication is based on the
latest product information available at the time of publication.
Product improvements or other changes may result in
differences between this manual and the product. Depictions
and/or procedures in this publication are intended for reference
use only.
No liability can be accepted for omissions or inaccuracies.
Polaris Industries Inc. reserves the right to make changes at any
time, without notice and without incurring obligation to make the
same or similar changes to products previously built. Any
reprinting or reuse of the depictions and/or procedures
contained within, whether whole or in part, is expressly
prohibited.
The following are trademarks of POLARIS Industries Inc.:
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
Polaris Industries Inc. is under license. Other trademarks and
trade names are those of their respective owners.
Printed in U.S.A.
P/N 9925416
POLARIS® PERC® RANGER®
RIDERX™ RZR® AXYS™
RiderX™

3
Table of Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Interactive Digital Display . . . . . . . . . . . . . . . . . . . . . .7
General Information . . . . . . . . . . . . . . . . . . . . . . . . .9
Display Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Maps/Trails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
GPS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
System Settings. . . . . . . . . . . . . . . . . . . . . . . . . . .23
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
IDD For Snowmobiles. . . . . . . . . . . . . . . . . . . . . . . . .30
General Snowmobile IDD Information . . . . . . . . . .30
Initialization Process . . . . . . . . . . . . . . . . . . . . . . .32
Left Hand Controls. . . . . . . . . . . . . . . . . . . . . . . . .33
Vehicle Settings . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Detonation Elimination Technology . . . . . . . . . . . .42
Engine Overheat Indicators . . . . . . . . . . . . . . . . . .43
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Before Connecting . . . . . . . . . . . . . . . . . . . . . . . . .44
Connection Management. . . . . . . . . . . . . . . . . . . .45
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
RiderX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Connect, Register and Update. . . . . . . . . . . . . . . .60
Update Process Flow Chart. . . . . . . . . . . . . . . . . .70
Frequently Asked Questions . . . . . . . . . . . . . . . . . . .71

4
Welcome
Thank you for purchasing a Polaris Interactive Digital
Display (IDD), and welcome to the Polaris RiderX family.
Your IDD is easy to use and will allow you to customize
the information displayed through the use of alternate
screen selections. The RiderX app gives you the power
to plan, track and share your rides, as well as connect to
radar weather, rider services and more.
For a safe and enjoyable riding experience with your new
IDD, please read your vehicle’s owner’s manual and this
IDD owner’s manual. If you should need additional
assistance with IDD operation or software updates,
please see your Polaris dealer or visit RiderX.com.
WARNING! Do not enter information or adjust this
device while operating your vehicle. Distracted driving
can result in loss of control, collision or accident,
which may result in serious injury or death. Avoid
using any features and devices while driving that may
take your attention away from the road or trail and
safe driving habits, even for a moment.
The operator assumes all risk associated with using
this device. Please read the owner’s manual provided
with your vehicle.
CAUTION! The speedometer may display incorrect
values at the existence of electromagnetic radiation
>= 10 V/m.

5
Quick Start Guide
Before Riding With Your New IDD
1. Read this entire manual.
2. Familiarize yourself with the features and operation of
the IDD while the vehicle is stationary.
3. Register for a RiderX account (page 60).
4. Register your IDD (page 61).
5. Update trails data or maps/trails data to verify that the
trails data on the IDD is current (page 61).
IDD Features
NOTE: Trails data expires 90 days from the file’s
release date.
Key 1
Alternate Screen
Selection Key 2
ODO / Trip 1 / Trip 2
Key 3
Main Menu Key 4
Battery Voltage /
Temperature Reading
Key 5
Bluetooth Menu or
Diagnostics
if present

6
The icon bar at the top of the screen allows quick access
to cell phone-related information, a real time clock and
the GPS heading.
In most situations, the GPS and mapping features will
function best while the vehicle is outdoors in an open
space. The GPS signal may be impeded by overhead
structures or by being too close to a structure.
Please follow the installation instructions provided in the
accessory kit or see your dealer for assistance.
Getting Started
Use the ignition key to turn the IDD on or off or to reboot
(when necessary).
Models With Battery
Models Without Battery
ON Turn the key to the ON/RUN position.
OFF Turn the key to the OFF position.
REBOOT Option 1: Turn the key OFF for 5 seconds,
then turn the key to ON/RUN.
Option 2: With the key ON, press and hold
Display Key 5 for 20 seconds, then release.
ON Start the engine.
OFF Turn the key to the OFF position.
REBOOT Option 1: Turn the key OFF for 5 seconds,
then start the engine.
Option 2: With the engine running, press and
hold Display Key 5 for 20 seconds, then
release.
NOTE: Using the auxiliary engine stop switch on a
snowmobile to turn off the engine will not turn off the
IDD.
Phone
Battery
Phone
Signal
Strength
Missed Text
Messages
GPS
Heading
Missed
Calls
Real Time
Clock
Blue if
Bluetooth
Connected

7
Interactive Digital Display
The Polaris IDD features a 4.3-inch high resolution full
color LCD display that provides access to the following
information and functions.
Performance
View the speedometer, tachometer, dual trip meters,
odometer.
Operating Conditions
View fuel level, coolant temperature, battery voltage,
gear position, all-wheel drive status, diagnostics and
maintenance warnings.
Riding Conditions
View the clock, change display between day and night
mode.
Bluetooth Functionality
Use Bluetooth-enabled communication with cell phone
(with notification of incoming calls or texts and ability to
view battery strength and signal strength).
GPS/Mapping
Use the compass and full-featured GPS when the GPS
receiver is installed (includes the display of latitude,
longitude and elevation). Mark and save waypoints and
tracks.
Security (Snowmobiles)
If security is enabled, lock your vehicle using a security
code.
Screen Options
Customize screens.
NOTE: The compass is controlled by the GPS
system. Calibration is not required.

8
Software Upgrades
Update software for the life of the vehicle.
Update the IDD every 90 days or more often (especially
before long trips) to ensure the most recent trails data is
on your IDD at all times. Log in at RiderX.com to
download the latest software updates. If you need
assistance, please see your Polaris dealer.
Maps/Trails are supplied as an aid and should not be
used for any purpose requiring precise measurement of
direction, distance or location. Polaris makes no warranty
as to the accuracy or completeness of this map data. You
assume all risks associated with using the maps/trails
function.
NOTE: Trails data expires 90 days from the file’s
release date. If an update is not performed within 90
days, a notification screen displays.

9
General Information
Device Operating Requirements
Phone functionality is dependent on the capabilities of
your cell phone. Text messaging functionality may vary
depending on your phone’s operating system.
Care and Maintenance
Use a soft cloth to clean the housing. Mild soap and
water may be used. Do not use harsh or abrasive
cleaners.
For best results, use a microfiber towel to clean the
screen. Window cleaner or alcohol may be used.
Storage
When preparing the vehicle for storage, make sure the
ignition switch is in the OFF position to prevent battery
drain and a shortened battery life.
NOTE: Some cell phones or operating systems will
not work as shown in this manual.
NOTICE: Immediately clean off any gasoline that
splashes on the display.

10
Display Keys
Use the five display keys to access the IDD menus.
Press and release any key to display the IDD menu icons
at the lower edge of the screen. With the menu icons
displayed, press a specific key to view menu options for
that key.
Key 1
Alternate Screen
Selection Key 2
ODO / Trip 1 / Trip 2
Key 3
Main Menu Key 4
Battery Voltage /
Temperature Reading
Key 5
Bluetooth Menu or
Diagnostics
if present
IDD Menu Icons
(varies by current screen displayed)

11
Key 1 - Alternate Home Screen Selection
1. Press any key to display the IDD screen icons.
2. Press Key 1 repeatedly to display each home screen
option.
Key 2 - Odometer / Trip Meter 1 / Trip Meter 2
1. Press any key to display the IDD screen icons.
2. Press Key 2 repeatedly to display each option.
• Odometer (ODO)
•Trip1
•Trip2
Off-Road Vehicle
Home Screen Options
Snowmobile
Home Screen Options
PRIMARYSECONDARYAUXILIARY

12
Key 3 - Main Menu
1. Press any key to display the IDD screen icons.
2. Press Key 3 to display the main menu options.
3. Toggle through the menu.
Key 2: Toggle up
Key 4: Toggle down
4. Use the remaining keys to perform other actions in
the main menu.
Key 1: Toggle between day and night screen
(brightness) (See page 24 to adjust brightness levels
for both screen options.)
Key 3: Select
Key 5: Exit menu
Key 4 - Battery Voltage / Coolant Temperature
1. Press any key to display the IDD screen icons.
2. Press Key 4 repeatedly to display each option.
• Battery Voltage
• Coolant Temperature
Key 5 - Bluetooth Menu (or Diagnostics Menu)
1. Press any key to display the IDD screen icons.
2. Press Key 5 to display Bluetooth features. If a fault
exists, Key 5 enters the Diagnostics menu (see page
29).
3. Use the display keys to access Bluetooth features.
Key 1: Phone
Key 2: Text
Key 3: Toggle Bluetooth on/off
Key 4: Settings
Key 5: Exit menu

13
Maps/Trails
View Map
1. Press any key to display the IDD screen icons.
2. Press Key 3 to display the main menu options.
3. Toggle to MAPS/TRAILS. Press Key 3 to select.
4. Use the display keys to access the map features.
Key 1: Zoom out
Key 2: Zoom in
Key 3: Display menu
Key 4: Pan (disabled above 10 MPH / 16 km/h)
Key 5: Advance to next screen (GPS/Tracks Map)
Key 1 Key 2 Key 3 Key 4 Key 5

14
GPS/Tracks Map
Use the display keys to navigate the GPS/Tracks menu.
Key 1: Center the map on your GPS location. The
centering will occur after vehicle speed exceeds 10 MPH
(16 km/h).
Key 2: Place a marker at your GPS location. If your
vehicle is stopped, the keyboard will display so you can
name and save the waypoint. (See Keyboard Operation
on page 15.) If your vehicle is moving, the waypoint will
be placed and automatically named. Press and hold Key
2 to enter the Waypoint Manager menu.
Key 3: Display the keyboard to name and save the track.
Up to 10 tracks can be saved. Press and hold Key 3 to
enter the Track Manager menu.
Key 4: Display a confirmation message before clearing
the current track.
Key 5: Exit
Key 1 Key 2 Key 3 Key 4 Key 5

15
Keyboard Operation
1. Use the display keys to navigate the keyboard.
Key 1: Move left
Key 2: Move up
Key 3: Select the letter or number
Key 4: Move down
Key 5: Move right
Phone
1. Press any key to display the IDD screen icons.
2. Press Key 3 to display the main menu options.
3. Toggle to PHONE. Press Key 3 to select.
Key 1 Key 2 Key 3 Key 4 Key 5
Key 1 Key 2 Key 3 Key 4 Key 5

16
4. The phone main menu screen displays.
5. Use the display keys to navigate the phone main
menu.
Key 1: Missed Calls
Key 2: Text Messages
Key 3: Turn Bluetooth on/off
Key 4: Bluetooth Settings
Key 5: Exit
6. When one of the IDD main screens is displayed,
press any key to display the IDD screen icons. Press
Key 5 to access the phone menu. (The diagnostic
screen displays if an active fault exists. See page 29.)
7. For more information about the Bluetooth functions,
see page 44.
Key 1 Key 2 Key 3 Key 4 Key 5
Key 1 Key 2 Key 3 Key 4 Key 5

17
GPS Settings
1. Press any key to display the IDD screen icons.
2. Press Key 3 to display the main menu options.
3. Toggle to GPS MANAGER. Press Key 3 to select.
4. Toggle through the menu.
• Track Manager
• Waypoint Manager
• Satellite Status
5. Press Key 3 to select.
Track Manager / Waypoint Manager
The Track Manager allows you to edit a track name, hide
or display a track and import or export a track.
The Waypoint Manager allows you to edit, delete, import
or export a waypoint or view a saved waypoint on the
map.
Key 1 Key 2 Key 3 Key 4 Key 5

18
When Go To is turned ON in the Waypoint Manager, an
arrow displays on the map, pointing in the direction of the
selected waypoint. This feature can be used for only one
waypoint at a time.
1. Press Key 5 to toggle to the selection list.
2. Press Key 4 until Go To is highlighted. Press Key 5 to
toggle the setting ON or OFF.
3. Press Key 5 to exit the map.
NOTE: When Go To is ON, the arrow points to the
waypoint that was selected when Go To was turned
ON.
Key 1 Key 2 Key 3 Key 4 Key 5
Key 1 Key 2 Key 3 Key 4 Key 5

19
Importing and Exporting Tracks and Waypoints
Importing or exporting tracks and waypoints requires a
USB drive in the accessory connector. An exported file
will be a .gpx format file that can be read by various
devices or imported into mapping software. Any files you
import must be available on the USB drive at the root
level (not in a folder) and must be .gpx format files.
1. Enter the desired manager menu (Tracks or
Waypoints).
2. Press Key 5 to toggle to the selection list. Toggle to
Import or Export. Press Key 5 to select.
3. Toggle to the desired track or waypoint file name.
Press Key 5 to select.
Key 1 Key 2 Key 3 Key 4 Key 5
Key 1 Key 2 Key 3 Key 4 Key 5
