CTX PR1400F User manual

English8188
¨¨¨
1
English
TABLE OF CONTENTS
SAFETY INSTRUCTIONS .................................................................. 2
INTRODUCTION ............................................................................. 4
Package Contents ..................................................................... 4
Installing or Removing the Tilt/Swivel Base ............................ 5
Specifications ........................................................................... 6
Recommended Use of the Monitor .......................................... 7
CONTROLS AND ADJUSTMENTS ................................................... 8
Front User Controls. ................................................................ 8
"General" ................................................................................. 9
"Picture" .................................................................................. 9
"Geometry" .............................................................................. 9
"Color" ..................................................................................... 9
"Advance" .............................................................................. 10
Moire ............................................................................. 10
Convergence .................................................................. 10
Purity.............................................................................. 10
Degauss .......................................................................... 10
Sharpness ....................................................................... 10
"Property" .............................................................................. 11
Status .............................................................................. 11
Recall ............................................................................. 11
Language ........................................................................ 11
"Signal" .................................................................................. 12
Contrast ................................................................................. 12
Energy Declaration ................................................................ 12
TECHNICAL INFORMATION ......................................................... 13
Compatibility ......................................................................... 13
Pin Assignment ............................................................... 13
Pin Assignments of the BNC and USB Connectors ......... 13
Preset Timing Chart ........................................................ 14
TROUBLESHOOTING .................................................................... 15
DIMENSION .................................................................................. 16

¨¨¨
2
English
1. Please read carefully all of these instructions below and keep the manual
for later use.
2. Please install the swivel base for this product before using it.
3. The voltage ratings and the rated frequency are on the overlay centered
at the rear side of this product. Do not connect with any other sources
of voltage or frequency, and, please follow all warnings and instructions
marked on the product.
4. Unplug this product from the wall outlet before cleaning and use a
damp cloth to clean it. Do not use liquid cleaners or aerosol cleaners.
5. Do not expose this product to rain or moisture.
6. Do not place this product on an unstable cart, stand, or table. The
product may fall, causing serious damage to the product.
7. Do not block or cover ventilating openings with cloth or other material.
Neither should this product be placed near or over a radiator or a heat
register, nor should the product be placed in a built-in installation
unless proper ventilation is provided.
8. This product is equipped with a 3-wire grounding model plug. This
plug will only fit into a grounding-model power outlet. This is a safety
feature. If you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the grounding-model plug. Choose a Tandem Blade
attachment plug configuration power cord for 230V AC input.
Due to the safety requirements of different areas, please select a suitable
power cord according to the following rules, in addition to the electric
rating:
A. Northern America area: Please select a UL listed and CSA certified
power cord.
B. Germany: Please select a VDE certified power cord.
C. Nordic countries: Please select a power cord certified by SEMKO,
NEMKO, DEMKO or FIMKO.
D. The other areas: Please select a power cord suitable to the local
power system and power outlet.
SAFETY INSTRUCTIONS

English8388
¨¨¨
3
English
Usually when this product is sold a suitable power cord is provided by
the manufacturer. However, this product is sometimes resold or
transported to another area with a different power system and safety
requirements. Please pay attention to the selection of a suitable power
cord.
The plug on the power cord is intended to serve as the disconnect
device, the socket-outlet shall be installed near the equipment and
shall be easily accessible.
9. Do not allow anything to rest on the power cord. Do not locate this
product where persons can walk on the cord.
10. Never push objects of any kind into this product through cabinet slots
as they may touch dangerous voltage points or short out parts that
could result in the risk of fire or electric shock. Never spill liquid of
any kind on the product.
11. Do not attempt to service this product yourself, as opening or removing
covers may expose you to dangerous voltage points, or other risks.
Refer all servicing to service personnel.
12. Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions.
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If when the operating instructions are followed, the product does
not operate normally, adjust only those controls that are covered
by the operating instructions since improper adjustment of other
controls may result in damage and will often require extensive work
by a qualified technician to restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance, indicating
a need for service.
SAFETY INSTRUCTIONS

¨¨¨
4
English
Introduction
The monitor is a multiple frequency high-resolution color monitor for IBM
compatible PC's or Macintosh and workstation systems. The monitor is
equipped with microprocessor based intelligence and multiple frequency
scanning capability, allowing it to provide maximum compatibility for various
system platforms.
The monitor uses the latest screen technology including a 0.24mm SONY FD
Trinitron® CRT to display crisp text and vivid color graphics. The full-function
digital control and On-Screen Display (OSD) system provides easy adjustment
of image geometry and color settings for different display modes with the
precision of a fixed frequency monitor.
The monitor also has full ergonomic features. In addition to the user friendly
controls and user comfort features, the emission level of the electric and
magnetic field is kept low to meet the Swedish MPR II and TCO standards.
The monitor is also equipped with energy saving functions; it is compatible
with the VESA power saving standards.
Furthermore, the monitor has a built-in the USB (Universal Series Bus) hub.
Please refer to the "USB SetUp Guide" for USB hub use information.
INTRODUCTION
Package Contents
The following lists all of the items included in the monitor package box. Please
save the original box and packing materials for future transportation or shipment
of the monitor.
Rear View
Front View
User's Manual
USB Cable
Diskette
Power Cord Signal Cable
PR1400F
User's Manual

English8588
¨¨¨
5
English
Installing or Removing the Tilt/Swivel Base
1.Turn off the system and all attached peripherals.
2.Carefully turn the monitor upside down.
Remove the Tilt/Swivel Base:
1.Squeeze and hold the latches.
2.Pull the tilt/swivel base to the rear of the monitor and lift to remove the
base.
Installing the Tilt/Swivel Base:
1.Align the base with the slots on the bottom of the monitor and insert the tilt/
swivel base into the slots.
2.Push the tilt/swivel base firmly toward the front of the monitor until the
latches click into the locked position.
INTRODUCTION
Install Remove

¨¨¨
6
English
INTRODUCTION
Specifications
Note: Specifications are subject to change without notice.
Color Picture Tube 21" (19.8" viewable screen size) diagonal
measurement, 90 degree deflection, SONY FD
Trinitron® CRT, anti-glare, anti-reflection, anti-static,
medium short persistence phosphor
AG Pitch 0.24 mm(center)
Input Signal Video: 0.7 Vp-p/75 ohm, analog positive
Sync: Separate Sync.: TTL Level
Horizontal Sync.: positive/negative
Vertical Sync.: positive/negative
Composite Sync.: TTL Level, positive/negative
on green video
(0.3Vp-p Negative)
Scan Frequency Horizontal: 30 to 125 KHz automatically
Vertical: 50 to 160 Hz automatically
Max. Resolution 2048 x 1536 @75Hz pixel, non-interlaced
Display Colors Analog input, unlimited colors
Pixel Rate 300 MHz
Plug & Play DDC 1 / DDC 2B
USB Downstream port x 4
Per downstream port support current 500mA(Max.)
Power Supply 100-120 VAC/200-240 VAC, 50/60 Hz (automatically)
Power Consumption 145W max.
Dimensions 514.5(W) x 528.2(H) x 513.5(D) mm
Weight 43kgs (G.W.), 38 kgs(N.W.)
Environment Operating Temperature: 0°C to 35°C
Consideration Humidity 20% to 80%
Storage Temperature: 20°C to 60°C
Humidity 10% to 90%

English8788
¨¨¨
7
English
Recommended Use of the Monitor
When setting up and using the monitor, pay special attention to the following
for optimum performance:
 Do not use your monitor against a bright background or where sunlight or
other light sources will shine directly on the screen.
 The monitor should be placed just below eye level (10°~15°) for optimum
viewing.
 Set the monitor's brightness to match ambient room light.
 For optimum focus, the contrast control should not be set to the maximum
level unless the input signal level is extremely low. Also, the brightness
control should be set to a point where the overall background area just
begins to disappear.
 Allow adequate ventilation around the monitor so that the heat from the
monitor can be properly dissipated.
 Neither the monitor itself, nor any other heavy objects, should rest on the
power cord. Damage to the power cord can cause fire or an electric shock.
 Keep the monitor away from high-capacity transformers, electrical motors,
or other strong magnetic fields.
 Your monitor should not be used in damp, dusty, or dirty areas.
 Handle your monitor with care when transporting it.
CAUTION
 Do not scrape or knock the surface of the CRT with a pen, a
screwdriver and so on.
 Clean the CRT surface with a lint-free, nonabrasive, soft cloth, do
not use a solution or glass cleaner containing corpuscles like
abrasives, alcohols and alkalines.
INTRODUCTION
!
ê

¨¨¨
8
English
CONTROLS AND ADJUSTMENTS
Controls and Adjustments
Once you have installed the monitor with your system, please read the
instructions of this section which give you some guidelines on how to use the
monitor more efficiently. It leads you through the various function of the user
controls and explains how to adjust the monitor to your personal preference.
Front User Controls
1. Power Switch
To turn the monitor on or off.
2. Power LED Indicator
As long as the monitor is powered, this indicator is lit. In normal operation, it
lights green. While in stand-by mode, the indicator lights yellowish-green,
while in off mode it is amber.
3. Adjust Keys
To adjust the parameter of the selected function.
To adjust the contrast level of the screen.
4. Menu Key
To display and select the "General", "Picture", "Geometry", "Color",
"Advance", "Property", "Signal" functions.
Power Saving Note:
This monitor is equipped with a automatic power-saving circuitry design that
will work with any computer which meets the VESA DPMS standard. It also
meets the ENERGY STAR low power state definition.

English8988
¨¨¨
9
English
Geometry
Color
General
Advance
Property
Signal
Sidepin
50
50
63
78
50
Geometry
Color
General
Advance
Property
Signal
9300°K
6500°K
5000°K
User
65
65
65
D. Color
C. Geometry
B. Picture
A.General
CONTROLS AND ADJUSTMENTS
a. Press "4"to select Brightness or Contrast.
b. Press "+" or "" for preferred picture.
a. Press "4"to select Vertical and Horizontal position,
Vertical and Horizontal size.
b. Press "+" or "" for preferred picture.
a. Press "4"to select Side-pin, Balance, Keystone,
Parallel and Rotation.
b. Press "+" or "" for preferred picture.
a. Press "4"to select various white color temperature
standards.
b. In User item press "+" to confirm action color
adjustment.
c. Press "4" to select Red, Green and Blue.
d. Press "+" or "" to increase or decrease density.
(1) Press "3" or "4" to open the On-Screen menu function. Seven adjustment
functions will appear on the On-Screen menu.
Press "3" key to scroll down through the selections.
Geometry
Color
General
Advance
Property
Signal Brightness
100
50
Geometry
Color
General
Advance
Property
Signal
Geometry
Color
General
Advance
Property
Signal
9300°K
6500°K
5000°K
User
:Proceed
User
70
70
70
Geometry
Color
General
Advance
Property
Signal H-Position
38
49
77
53

¨¨¨
10
English
50
Purity
CONTROLS AND ADJUSTMENTS
Geometry
Color
General
Advance
Property
Signal
Moire
Converge
Purity
Degauss
Sharpness
:Proceed
50
R
R
B
B
E. Advance
a. Press "4"to select Moire, Converge, Purity,
Degauss or Sharpness.
b. Press "+" to proceed.
c. Press "+" or "" to gain preferred picture.
a. In Converge, press "+" to proceed.
b.Press "4"to select Horizontal or Vertical adjust.
c. Press "+" or "" to gain preferred picture.
E-1. Moire
E-2. Converge
a. In Moire, press "+" to proceed.
b. Press "+" or "" to gain preferred picture.
E-3. Purity
a. In Purity, press "+" to Proceed.
b.Press "4"to select the function you want to adjust.
Color purity can be adjusted in the top and bottom
rows, and, the four corners of the screen.
c. Press "+" or "" to gain preferred color uniformity.
0
Moire
50
Purity
Sharpness
:Yes
:No
E-4. Sharpness
In Sharpness, press "+" to enhance sharpness, or ""
to disable this function.
