9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
VEHICLE IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
MODEL NUMBER DESIGNATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
ENGINE DESIGNATION NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.2
VEHICLE IDENTIFICATION NUMBER (VIN) DESIGNATION. . . . . . . . . . . . . . . . . . . . .1.2
VEHICLE AND ENGINE SERIAL NUMBER LOCATIONS. . . . . . . . . . . . . . . . . . . . . . . . 1.3
VEHICLE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4
PUBLICATION NUMBERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.4
REPLACEMENT KEYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.4
SPECIAL TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5
GENERAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
GENERAL: 2013 RANGER RZR / EPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.6
DETAILED: 2013 RANGER RZR / EPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.7
GENERAL: 2013 RANGER RZR S / INT’L. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
DETAILED: 2013 RANGER RZR S / INT’L. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.9
GENERAL: 2013 RANGER RZR 4 / EPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10
DETAILED: 2013 RANGER RZR 4 / EPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.11
MISC. SPECIFICATIONS AND CHARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
CONVERSION TABLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.12
STANDARD BOLT TORQUE SPECIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.13
METRIC BOLT TORQUE SPECIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.13
SAE TAP / DRILL SIZES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.14
METRIC TAP / DRILL SIZES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.14
DECIMAL EQUIVALENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.14
PRELIMINARY VERSION

1.2
GENERAL INFORMATION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
VEHICLE IDENTIFICATION
Model Number Designation
Example: R13VH76AD
Engine Designation Number
1204620 RZR800-13...........................................................Twin Cylinder, Liquid Cooled, OHV 4 Stroke, Electric Start
Vehicle Identification Number (VIN) Designation
Example: 4XAVH76A4DB000000
GROUP MODEL
YEAR CHASSIS DRIVELINE ENGINE CATEGORY OPTION REGION
1st digit 2/3rd digit 4th digit* 5th digit* 6th digit* 7th digit* 8th digit 9thdigit** 10th digit
A = ATV
R = RANGER
11
12
13
C = Sportsman 6x6
D = Sportsman Tour
E = Trail Boss
F = Sportsman Youth
G = Sport
H = RANGER 6x6
J = RZR XP
K = Sport Youth
M = Sportsman
N = Trail Blazer
P = Phoenix
R = RANGER Midsize
S = RZR
T = Sportsman X2
U = RANGER Fullsize
V = RZR
W = Multi-pass RGR
X = Multi-pass RZR
Z = Sportsman XP
A = 2x4 Chain
B = 2x4 Shaft
C = 4x4 AC Drive
E = 4x4 Shaft / IRS
G = 4x4 Chain rear / 
shaft front
H = 4x4 Shaft / IRS
J = 2x4 Swing arm Manual
N = 4x4 Shaft ADC
P = 2x4 / IRS Manual
R = 6x6 Shaft / IRS
T = 4x4 Shaft / Trailing Arm
X = 4x4 Shaft EBS
Displacementinccdivided
by 10 and rounded to two
digits
(i.e. 50 = 498cc)
- - - - - - - - - - - -
For electric vehicles
08 = 48 Volt
12 = 72 Volt
A = ORV
D = Diesel
E = EU On-road
F = INT’L
G = EV
L = LSV
M = Military
S=Scandinavian
V = EU On-road
C = Calif.
- - OR - -
5 = 550
6 = 570
7 = 760
8 = 850
9 = 875
E = EPS
D = Diesel
F = D + E
* = digits that would transfer to 17 digit VIN and are used in digits 4-8 respectively
** = 9th digit will be used on color/featured versions of models (not including the base)
First 3 digits and 9th digit are used in model number only. They are not used with the 17 digit VIN.
World Mfg. ID
Vehicle Descriptors Vehicle Identifiers
Chassis Driveline Engine Size Engine Modifier Category Check Digit Model Year * Mfg. Location
Individual Serial No.
12345678910 11 12 13 14 15 16 17
4 X A V H 7 6 A 4 D B 0 0 0 0 0 0
* Model Year: A = 2010; B = 2011; C = 2012; D = 2013
PRELIMINARY VERSION

1.3
GENERAL INFORMATION
1
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
Vehicle and Engine Serial Number Locations
Whenever correspondingabouta Polaris ORV,refer to thevehicleidentificationnumber(VIN)andengineserialnumber.
TheVINcan befoundstampedonthe rearupperframerail,behindtheleftrearfender,neartheair box (seeFigure1-1).
Theenginemodelandserialnumbercanbefoundonadecalappliedtothesideof theengine’scylinder(see Figure1-2).
Figure 1-1
VIN
Engine Serial
Figure 1-2
Number
PRELIMINARY VERSION

1.4
GENERAL INFORMATION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
VEHICLE INFORMATION
Publication Numbers
NOTE: When ordering service parts be sure to use the correct parts manual.
NOTE: Polaris factory publications can be found at www.polarisindustries.com or purchased from
www.purepolaris.com.
Replacement Keys
Replacement keys can be made from the original key. To identify which series the key is, take the first two digits on the
original key and refer to the chart to the right for the proper part number.
Model Model No. Owner’s Manual Parts Manual
2013 RANGER RZR R13VH76AC, AD, AN, AS 9924099 9924104
2013 RANGER RZR EPS R13VH7EAI 9924099 9924104
2013 RANGER RZR S R13VE76AD, AI, AS, AW 9924099 9924100
2013 RANGER RZR S INT’L R13VE76FI, FX 9924099 9924101
2013 RANGER RZR 4 R13XE76AD 9924099 9924106
2013 RANGER RZR 4 EPS R13XE7EAI 9924099 9924106
Series# Part Number
20 4010278
21 4010278
22 4010321
23 4010321
27 4010321
28 4010321
31 4110141
32 4110148
67 4010278
68 4010278
Key Series
Number
KEY COVER
P/N 5533534
PRELIMINARY VERSION

1.5
GENERAL INFORMATION
1
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
SPECIAL TOOLS
Special tools maybe required whileservicing thisvehicle.Some ofthe toolslisted ordepictedaremandatory,whileother
tools may be substituted with a similar tool, if available. Polaris recommends the use of Polaris Special Tools when
servicing any Polaris product. Dealers may order special tools through Polaris’ official tool supplier, SPX Corporation,
by phone at 1-800-328-6657 or on-line at http://polaris.spx.com/.
Select “SPX Website - Tools, diagnostics” from
the “Service and Warranty” drop down menu
PRELIMINARY VERSION

1.6
GENERAL INFORMATION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
GENERAL SPECIFICATIONS
MODEL: 2013 RANGER RZR
MODEL NUMBER: R13VH76AC, AD, AN, AS
ENGINE NUMBER: 1204670
MODEL: 2013 RANGER RZR EPS
MODEL NUMBER: R13VH7EAI
ENGINE NUMBER: 1204670
Category Dimension / Capacity
Length 103 in. / 261.6 cm
Width 50 in. / 127 cm
Height 69 in. / 175.3 cm
Wheel Base 77 in. / 196 cm
Ground Clearance 10 in. / 25.4 cm
Dry Weight 945 lbs. / 429 kg
Gross Vehicle Weight 1727 lbs. / 783 kg
Front Storage
Capacity 25 lbs. / 11.3 kg
Cargo Box Dimension 42 in. x 22 in. / 107 cm x 56 cm
Cargo Box Capacity 300 lbs. / 136 kg
Maximum Weight
Capacity (Payload)
740 lbs. / 335.6 kg
(Includesrider(s),cargo,accessories
and trailer tongue weight)
Hitch Towing Capacity 1500 lbs. / 680 kg
HitchTongueCapacity 150 lbs. / 68 kg
Category Dimension / Capacity
Length 103 in. / 261.6 cm
Width 50 in. / 127 cm
Height 69 in. / 175.3 cm
Wheel Base 77 in. / 196 cm
Ground Clearance 10 in. / 25.4 cm
Dry Weight 961 lbs. / 436 kg
Gross Vehicle Weight 1727 lbs. / 783 kg
Front Storage
Capacity 25 lbs. / 11.3 kg
Cargo Box Dimension 42 in. x 22 in. / 107 cm x 56 cm
Cargo Box Capacity 300 lbs. / 136 kg
Maximum Weight
Capacity (Payload)
740 lbs. / 335.6 kg
(Includesrider(s),cargo,accessories
and trailer tongue weight)
Hitch Towing Capacity 1500 lbs. / 680 kg
HitchTongueCapacity 150 lbs. / 68 kg
PRELIMINARY VERSION

1.7
GENERAL INFORMATION
1
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
MODEL: 2013 RANGER RZR / EPS
MODEL NUMBER: R13VH76AC, AD, AN, AS
MODEL NUMBER: R13VH7EAI
ENGINE NUMBER: 1204670
CLUTCH CHART (All Non-EPS Models)
CLUTCH CHART (EPS Model with EBS)
Engine
Platform H.O. Domestic Twin Cylinder,
Liquid Cooled, 4-Stroke
Engine Number 1204670 RZR800-13
Engine Displacement 760cc H.O.
Number of Cylinders 2
Bore & Stroke (mm) 80 x 76.5 mm
Compression Ratio 11:1
Compression Pressure 165 - 185 psi
Engine Idle Speed 1250 ± 100 RPM
Engine Max Operating RPM 6600 RPM
Lubrication Pressurized Wet Sump
Oil Requirements PS-4 Plus Synthetic
Oil Capacity 2 qts. / 1.9 liters
Coolant Capacity 4.8 qts. / 4.5 liters
Overheat Warning Instrument Cluster Indicator
Exhaust System Dual Headpipe / Single Silencer
Fuel System
Fuel System Type Bosch M17 EFI
Fuel Delivery Electronic Fuel Pump (in tank)
Fuel Pressure 45 +/- 2 psi (310 +/- 14kPa)
Fuel Filters See Chapter 4
Fuel Capacity / Requirement 7.25 gal. (27.4 liters)
87 Octane (minimum)
Electrical
Alternator Max Output 500 Watts @ 3000 RPM
Headlights (Halogen) 2-Halogen:Low55W/High60W
Headlights (LED) 2 - Dual Beam LED:
Low 27 Watts; High 40 Watts
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System Electric Start
Ignition System Bosch M17 (ECU Controlled)
Ignition Timing (Variable) 3° -10°BTDC @ 1200 RPM
Spark plug / Gap RC7YC3 / .035 in. (0.9 mm)
Battery (RZR) Yuasa YTX20HL /
18 Amp Hr. / 310 CCA / 12 Volt
Battery (RZR EPS) Deka ETX30L / 30 AH
365 CCA / 12 Volt
Instrument Type Multifunction Instrument Cluster
DC Outlet Standard 12 Volt
Relays Chassis / EFI / Fan
Fuel Pump / EPS
Circuit Breaker Fan Motor: 20 Amp
Fuses (Fuse/Relay Box) Drive / Fuel Pump: 10 Amp
Lights / EFI / Accessory: 20 Amp
Fuses (Power Fuse Holder) EFI: 20 Amp
Chassis / EPS: 30 Amp
Drivetrain
Transmission Type Polaris Automatic PVT
Drive Ratio - Front 3.82:1
Drive Ratio - Final 3.70:1
Shift Type In Line Shift - H / L / N / R / P
Front Gearcase
Fluid Type / Capacity Polaris Demand Drive Plus 6.75 oz. (200 ml)
Transmission: Main Gearcase
Fluid Type / Capacity Polaris AGL Plus 24 oz. (710 ml)
Transmission: Transfer Case
Fluid Type / Capacity Polaris AGL Plus 14 oz. (414 ml)
Rear Gearcase
Fluid Type / Capacity Polaris Premium ADF 26 oz. (769 ml)
Clutch Type (Standard Model)Standard PVT
Clutch Type (EPS Model)PVT with EBS
Drive Belt 3211113
Steering / Suspension
Front Suspension Independent Dual A-arm
w/Anti-Sway Bar
Front Travel 9 in. / 23 cm
Rear Suspension Rolled IRS w/Anti-Sway Bar
Rear Travel 9.5 in. / 24 cm
Shock Preload Adjustment
Front / Rear Cam Adjustment
Toe Out 1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Type / Size Steel / 12 x 6
Aluminum / 12 x 6
Rear Wheel Type / Size Steel / 12 x 8
Aluminum / 12 x 8
Front Tire Type / Size Ancla / 25 x 8 R12
Maxxis / 25 x 8 R12
Rear Tire Type / Size Ancla / 25 x 10 R12
Maxxis / 25 x 10 R12
Tire Air Pressure - Front / Rear 8 psi (55 kPa)
Brake - Front / Rear Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
Altitude Shift
Weight Drive
Spring Driven Spring
Meters
(Feet)
0-1500
(0-5000) 23-62
(5632337) Green (7043789) Blk / Almond (7043167)
1500-3700
(5000 - 12000) 23-58 (B)
(1322911) Green (7043789) Blk / Almond (7043167)
Altitude Shift
Weight Drive
Spring Driven Spring
Meters
(Feet)
0-1500
(0-5000) 23-66
(5632763) Green (7043789) Red (3234452)
1500-3700
(5000 - 12000) 23-62
(5632337) Green (7043789) Red (3234452)
PRELIMINARY VERSION

1.8
GENERAL INFORMATION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
MODEL: 2013 RANGER RZR S
MODEL NUMBER: R13VE76AD, AI, AS, AW
ENGINE NUMBER: 1204670
MODEL: 2013 RANGER RZR S INT’L
MODEL NUMBER: R13VE76FI, FX
ENGINE NUMBER: 1204670
Category Dimension / Capacity
Length 104 in. / 264.2 cm
Width 60.5 in. / 154 cm
Height 70.5 in. / 179 cm
Wheel Base 77 in. / 196 cm
Ground Clearance 12.5 in. / 32 cm
Dry Weight 1000 lbs. / 454 kg
Gross Vehicle Weight 1782 lbs. / 808 kg
Front Storage
Capacity 25 lbs. / 11.3 kg
Cargo Box Dimension 42 in. x 22 in. / 107 cm x 56 cm
Cargo Box Capacity 300 lbs. / 136 kg
Maximum Weight
Capacity (Payload)
740 lbs. / 335.6 kg
(Includesrider(s),cargo,accessories
and trailer tongue weight)
Hitch Towing Capacity 1500 lbs. / 680 kg
HitchTongueCapacity 150 lbs. / 68 kg
Category Dimension / Capacity
Length 104 in. / 264.2 cm
Width 60.5 in. / 154 cm
Height 70.5 in. / 179 cm
Wheel Base 77 in. / 196 cm
Ground Clearance 12.5 in. / 32 cm
Dry Weight 1016 lbs. / 461 kg
Gross Vehicle Weight 1782 lbs. / 808 kg
Front Storage
Capacity 25 lbs. / 11.3 kg
Cargo Box Dimension 42 in. x 22 in. / 107 cm x 56 cm
Cargo Box Capacity 300 lbs. / 136 kg
Maximum Weight
Capacity (Payload)
740 lbs. / 335.6 kg
(Includesrider(s),cargo,accessories
and trailer tongue weight)
Hitch Towing Capacity 1500 lbs. / 680 kg
HitchTongueCapacity 150 lbs. / 68 kg
PRELIMINARY VERSION

1.9
GENERAL INFORMATION
1
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
MODEL: 2013 RANGER RZR S / INT’L
MODEL NUMBER: R13VE76AD, AI, AS, AW
MODEL NUMBER: R13VE76FI, FX
ENGINE NUMBER: 1204670
CLUTCH CHART
Engine
Platform H.O. Domestic Twin Cylinder,
Liquid Cooled, 4-Stroke
Engine Number 1204670 RZR800-13
Engine Displacement 760cc H.O.
Number of Cylinders 2
Bore & Stroke (mm) 80 x 76.5 mm
Compression Ratio 11:1
Compression Pressure 165 - 185 psi
Engine Idle Speed 1250 ± 100 RPM
Engine Max Operating RPM 6750 RPM
Lubrication Pressurized Wet Sump
Oil Requirements PS-4 Plus Synthetic
Oil Capacity 2 qts. / 1.9 liters
Coolant Capacity 4.8 qts. / 4.5 liters
Overheat Warning Instrument Cluster Indicator
Exhaust System Dual Headpipe / Single Silencer
Fuel System
Fuel System Type Bosch M17 EFI
Fuel Delivery Electronic Fuel Pump (in tank)
Fuel Pressure 45 +/- 2 psi (310 +/- 14kPa)
Fuel Filters See Chapter 4
Fuel Capacity / Requirement 7.25 gal. (27.4 liters)
87 Octane (minimum)
Electrical
Alternator Max Output 500 Watts @ 3000 RPM
Headlights (Halogen) 2-Halogen:Low55W/High60W
Headlights (LED) 2 - Dual Beam LED:
Low 27 Watts; High 40 Watts
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System Electric Start
Ignition System Bosch M17 (ECU Controlled)
Ignition Timing (Variable) 3° -10°BTDC @ 1200 RPM
Spark plug / Gap RC7YC3 / .035 in. (0.9 mm)
Battery Yuasa YTX20HL /
18 Amp Hr. / 310 CCA / 12 Volt
Instrument Type Multifunction Instrument Cluster
DC Outlet Standard 12 Volt
Relays Chassis / EFI / Fan
Fuel Pump
Circuit Breaker Fan Motor: 20 Amp
Fuses (Fuse/Relay Box) Drive / Fuel Pump: 10 Amp
Lights / EFI / Accessory: 20 Amp
Fuses (Power Fuse Holder) EFI: 20 Amp
Chassis: 30 Amp
Drivetrain
Transmission Type Polaris Automatic PVT
Drive Ratio - Front 3.82:1
Drive Ratio - Final 3.70:1
Shift Type In Line Shift - H / L / N / R / P
Front Gearcase
Fluid Type / Capacity Polaris Demand Drive Plus 6.75 oz. (200 ml)
Transmission: Main Gearcase
Fluid Type / Capacity Polaris AGL Plus 24 oz. (710 ml)
Transmission: Transfer Case
Fluid Type / Capacity Polaris AGL Plus 14 oz. (414 ml)
Rear Gearcase
Fluid Type / Capacity Polaris Premium ADF 26 oz. (769 ml)
Rear Gearcase (INT’L)
Fluid Type / Capacity Polaris Premium ADF 22 oz. (650 ml)
Clutch Type Standard PVT
Drive Belt 3211133
Steering / Suspension
Front Suspension / Shock Independent Dual A-arm
Standard: Monotube
FOX™: PODIUM
Front Travel 12 in. / 30.5 cm
Rear Suspension / Shock Rolled IRS w/Anti-Sway Bar
Standard: Monotube
FOX™: PODIUM
Rear Travel 12 in. / 30.5 cm
Shock Preload Adjustment
Front / Rear
Standard: Cam Adjustment
FOX™: Threaded Spanner
Wrench Adjustment
Toe Out 1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Type / Size Aluminum / 12 x 6
Rear Wheel Type / Size Aluminum / 12 x 8
Front Tire Type / Size ITP “900XCT” / 27 x 9 R12
Maxxis Bighorn / 26 x 9 R12
Rear Tire Type / Size ITP “900XCT” / 27 x 11 R12
Maxxis Bighorn / 26 x 12 R12
Tire Air Pressure - Front / Rear 8 psi (55 kPa)
Brake - Front / Rear Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
Altitude Shift
Weight Drive
Spring Driven Spring
Meters
(Feet)
0-1500
(0-5000) 23-62
(5632337) Green (7043789) Blk / Almond (7043167)
1500-3700
(5000 - 12000) 23-58 (B)
(1322911) Green (7043789) Blk / Almond (7043167)
PRELIMINARY VERSION

1.10
GENERAL INFORMATION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
MODEL: 2013 RANGER RZR 4
MODEL NUMBER: R13XE76AD
ENGINE NUMBER: 1204671
MODEL: 2013 RANGER RZR 4 EPS
MODEL NUMBER: R13XE7EAI
ENGINE NUMBER: 1204671
Category Dimension / Capacity
Length 130 in. / 330 cm
Width 60.5 in. / 154 cm
Height 75 in. / 190.5 cm
Wheel Base 103 in. / 262 cm
Ground Clearance 11.5 in. / 29 cm
Dry Weight 1255 lbs. / 569 kg
Gross Vehicle Weight 2206 lbs. / 1000 kg
Front Storage
Capacity 25 lbs. / 11.3 kg
Cargo Box Dimension 42 in. x 22 in. / 107 cm x 56 cm
Cargo Box Capacity 300 lbs. / 136 kg
Maximum Weight
Capacity (Payload)
900 lbs. / 408 kg
(Includesrider(s),cargo,accessories
and trailer tongue weight)
Hitch Towing Capacity 1500 lbs. / 680 kg
HitchTongueCapacity 150 lbs. / 68 kg
Category Dimension / Capacity
Length 130 in. / 330 cm
Width 60.5 in. / 154 cm
Height 75 in. / 190.5 cm
Wheel Base 103 in. / 262 cm
Ground Clearance 11.5 in. / 29 cm
Dry Weight 1271 lbs. / 577 kg
Gross Vehicle Weight 2206 lbs. / 1000 kg
Front Storage
Capacity 25 lbs. / 11.3 kg
Cargo Box Dimension 42 in. x 22 in. / 107 cm x 56 cm
Cargo Box Capacity 300 lbs. / 136 kg
Maximum Weight
Capacity (Payload)
900 lbs. / 408 kg
(Includesrider(s),cargo,accessories
and trailer tongue weight)
Hitch Towing Capacity 1500 lbs. / 680 kg
HitchTongueCapacity 150 lbs. / 68 kg
PRELIMINARY VERSION
