Polaris ACE 570 User manual

Owner'sManual
forMaintenanceandSafety
2017
ACE™570

For videos and more information
about a safe riding experience with
your Polaris vehicle, scan this QR
code with your smartphone.

1
WELCOME
Thank you for purchasing a POLARIS vehicle, and welcome to our
world-wide family of POLARIS enthusiasts. Be sure to visit us online at
www.polaris.com for the latest news, new product introductions,
upcoming events, career opportunities and more.
Here at POLARIS we proudly produce an exciting line of utility and
recreational products.
• Snowmobiles
• All-terrain vehicles (ATVs)
• Low emission vehicles (LEVs)
•RANGER®utility vehicles
•RZR®sport vehicles
• VICTORY® motorcycles
• INDIAN® motorcycles
• GEM® electric vehicles
Always follow the instructions and recommendations in this manual.
The manual contains instructions for minor maintenance, but
information about major repairs is outlined in the POLARIS Service
Manual and should be performed only by a factory-certified Master
Service Dealer® (MSD) technician. Please see your dealer for all of
your service needs during (and after) the warranty period.

2
POLARIS® and ACE™ are trademarks of POLARIS Industries Inc.
Copyright 2016 POLARIS Industries Inc. All information contained within this
publication is based on the latest product information at the time of publication. Due to
constant improvements in the design and quality of production components, some minor
discrepancies may result between the actual vehicle and the information presented in
this publication. Depictions and/or procedures in this publication are intended for
reference use only. No liability can be accepted for omissions or inaccuracies. Any
reprinting or reuse of the depictions and/or procedures contained within, whether whole
or in part, is expressly prohibited.
The original instructions for this vehicle are in English. Other languages are provided as
translations of the original instructions.
2017 POLARIS ACE 570 Owner’s Manual
P/N 9927489

3
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Features and Controls. . . . . . . . . . . . . . . . . . . 24
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Winch Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Emission Control Systems . . . . . . . . . . . . . . . 84
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . 132
POLARIS Products. . . . . . . . . . . . . . . . . . . . . 134
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . 135
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Maintenance Log . . . . . . . . . . . . . . . . . . . . . . 144
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

4
INTRODUCTION
This POLARIS vehicle is an off-road vehicle. Familiarize yourself with
all laws and regulations concerning the operation of this vehicle in your
area.
The following signal words and symbols appear throughout this manual
and on your vehicle. Your safety is involved when these words and
symbols are used. Become familiar with their meanings before reading
the manual.
The safety alert symbol indicates a potential personal injury hazard.
DANGER
A DANGER indicates a hazardous situation that, if not avoided, will result in
death or serious injury.
WARNING
A WARNING indicates a hazardous situation that, if not avoided, could result in
death or serious injury.
CAUTION
A CAUTION indicates a hazardous situation that, if not avoided, could result in
minor or moderate injury.
NOTICE
A NOTICE indicates a situation that could result in property damage.
The Prohibition Safety Sign indicates an action NOT to take in order
to avoid a hazard.
The Mandatory Action Sign indicates an action that NEEDS to be
taken to avoid a hazard.

5
INTRODUCTION
Failure to heed the warnings and safety precautions contained in this manual
can result in severe injury or death. Your POLARIS vehicle is not a toy and can
be hazardous to operate. This vehicle handles differently than cars, trucks or
other off-road vehicles. A collision or rollover can occur quickly, even during
routine maneuvers like turning, or driving on hills or over obstacles, if you fail to
take proper precautions.
• Read this owner’s manual and review the safety DVD that came with your
vehicle. A free extra copy of the DVD can be obtained by contacting your local
POLARIS dealer. Understand all safety warnings, precautions and operating
procedures before operating the vehicle. Keep this manual with the vehicle.
• Never operate this vehicle without proper instruction. Take an authorized
training course.
• This vehicle is an ADULT VEHICLE ONLY. You MUST be at least age 16 and
have a valid driver’s license to operate this vehicle.
• Always use the cab nets (or doors) while riding in this vehicle. Always keep
hands, feet and all other body parts inside the vehicle at all times.
• Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants
and over-the-ankle boots.
• Never use this vehicle with drugs or alcohol, as these conditions impair
judgment and reduce operator reaction time.
• Complete the New Operator Driving Procedures outlined on pages 58-59.
Never allow a guest to operate this vehicle until the guest has completed the
New Operator Driving Procedures.
• Never permit a guest to operate this vehicle unless the guest has reviewed the
owner’s manual and all safety labels and has completed a safety training
course.
WARNING

6
INTRODUCTION
European Vibration and Noise
The driver-perceived noise and hand/arm and whole body vibration levels of this
machinery is measured per EN 15997.
The operating conditions of the machinery during testing:
The vehicles were in like-new condition. The environment was controlled as
indicated by the test procedure(s).
The uncertainty of vibration exposure measurement is dependent on many
factors, including:
• Instrument and calibration uncertainty
• Variations in the machine such as wear of components
• Variation of machine operators such as experience or physique
• Ability of the worker to reproduce typical work during measurements
• Environmental factors such as ambient noise or temperature

7
INTRODUCTION
Declaration of Conformity
Polaris Sales Europe Sàrl
Route de I’Etraz
Business Center A5
1180 Rolle, Switzerland
Telephone [phone]
DECLARATION OF CONFORMITY
January 1, 2016
Polaris Sales Europe Sàrl declares that the vehicle(s)
listed below conform to the essential requirements
applicable to all terrain vehicles.
APPLICABLE EUROPEAN DIRECTIVES: TEST / EVALUATION METHODS
2006/42/EC as amended
(Machinery Directive) EN ISO 12100:2010 Hazard Analysis EN 15997:2011/AC:2012 Driver
Perceived
Noise Level & Vibration
2014/30/EU as amended
(EMC Directive) UNECE R10
MODEL COMMERCIAL NAME SERIAL NUMBER
A_ _DA _ 57_ _
(All combinations) ACE 570 (See Product Identification Label)

8
INTRODUCTION
Vehicle Identification Numbers
Record your vehicle's identification numbers and key number in the
spaces provided. Remove the spare key and store it in a safe place. An
ignition key can be duplicated only by ordering a POLARIS key blank
(using your key number) and mating it with one of your existing keys.
The ignition switch must be replaced if all keys are lost.
Vehicle Model Number: ___________________________________________________
Vehicle Identification Number (VIN): _________________________________________
Engine Serial Number: ___________________________________________________
Key Number____________________________________________________________
Engine Serial
Number
Key
Number
VIN
(Right Front Frame) ####

9
SAFETY
Safety Training
Safety training is a top priority for POLARIS. POLARIS strongly
encourages you and any family members who will be riding this vehicle
to take a training course.
For more information about safety, contact an authorized POLARIS
dealer or visit the POLARIS web site at www.polaris.com.
Your POLARIS vehicle is considered an off-road vehicle. Familiarize
yourself with all laws and regulations concerning the operation of this
vehicle in your area.
We strongly advise you to strictly follow the recommended maintenance
program outlined in your owner's manual. This preventive maintenance
program is designed to ensure that all critical components on your
vehicle are thoroughly inspected at specific intervals.

10
SAFETY
Safe Riding Gear
Always wear helmet, eye protection, gloves, long-sleeve shirt, long
pants, over-the-ankle boots and seat belt at all times. Protective gear
reduces the chance of injury.
Helmet
Wearing a helmet can prevent a severe head injury. Whenever riding this
POLARIS vehicle, always wear a helmet that meets or exceeds
established safety standards.
Approved helmets in the USA and Canada bear a
U.S. Department of Transportation (DOT) label.
Approved helmets in Europe, Asia and Oceania
bear the ECE 22.05 label. The ECE mark consists
of a circle surrounding the letter E, followed by the
distinguishing number of the country which has
granted approval. The approval number and serial number will also be
displayed on the label.
E
4
051039
0006.31
Helmet
Eye Protection
Gloves
Over-the-Ankle
Boots
Long Pants
Long
Sleeves

11
SAFETY
Safe Riding Gear
Eye Protection
Do not depend on eyeglasses or sunglasses for eye protection.
Whenever riding this POLARIS vehicle, always wear shatterproof
goggles or use a shatterproof helmet face shield. POLARIS
recommends wearing approved Personal Protective Equipment (PPE)
bearing markings such as VESC 8, V-8, Z87.1, or CE. Make sure
protective eye wear is kept clean.
Gloves
Wear gloves for comfort and for protection from sun, cold weather and
other elements.
Boots
Wear sturdy over-the-ankle boots for support and protection. Never ride
a POLARIS vehicle with bare feet or sandals.
Clothing
Wear long sleeves and long pants to protect arms and legs.
Rider Comfort
Under certain operating conditions, heat generated by the engine and
exhaust system can elevate temperatures in the rider cab area. The
condition occurs most frequently when a vehicle is being operated in
high ambient temperatures at low speeds and/or high load conditions for
an extended period of time. The use of certain windshield, roof and/or
cab systems may contribute to this condition by restricting airflow. Any
discomfort due to heat buildup in this area can be minimized by wearing
proper riding apparel and by varying speeds to increase airflow.

12
SAFETY
Safety Labels and Locations
Warning labels have been placed on the vehicle for your protection.
Read and follow the instructions of the labels on the vehicle carefully. If
any of the labels depicted in this manual differ from the labels on your
vehicle, always read and follow the instructions of the labels on the
vehicle.
If an informational or graphic label becomes illegible or comes off,
contact your POLARIS dealer to purchase a replacement. Replacement
safety labels are provided by POLARIS at no charge. The part number is
printed on the label.
General Alert (7182088)
Before you operate this vehicle, read the owner’s manual. Never allow anyone
under 16 years of age to operate this vehicle. Never use alcohol or drugs before
or while operating. Never operate the vehicle on any public street, road or
highway. Always wear the seat belt. Always use the cab nets (or doors) while
riding in this vehicle. Wear approved helmet, goggles, and protective clothing.
Never carry a passenger on this vehicle. Vehicle rollover could cause severe
injury or death. Always avoid operating in a manner that could result in vehicle
rollover. Avoid exhibition driving.
Hitch Capacity Label (7182091)
Trailer Maximum Weight: 680 kg (on level ground)
Hitch Maximum Vertical Weight: 68 kg
7182088
General Alert
680 kg
68 kg 7182091
Hitch Capacity Alert

13
SAFETY
Safety Labels and Locations
Passenger/Tire Pressure Alert (7182090)
Read Operation and Maintenance Manual for more detailed loading information.
Do not carry a passenger in the cargo box.
Maximum Cargo Box Load: 110 kg
Tire Pressure: 45 kPa
Maximum Weight Capacity
(including weight of operator, cargo and accessories: 261 kg
Front Compartment Storage Capacity Alert (7182092)
Maximum Weight Capacity: 55 kg
Clutch Cover Alert (7181427)
Keep body parts away from belt.
7182092
< 55 kg
Storage Capacity Alert
(on access cover under rack)
Passenger/Tire Pressure Alert
Clutch Cover Alert
7181427

14
SAFETY
Safety Warnings
Failure to operate this vehicle properly can result in a collision, loss of control,
accident or rollover, which may result in serious injury or death. Heed all safety
warnings outlined in this section of the owner’s manual and in the safety DVD
provided with your vehicle. See the OPERATION section of the owner’s manual
for proper operating procedures.
Operating Without Instruction
Operating this vehicle without proper instruction
increases the risk of an accident. Complete the
New Operator Driving Procedures outlined on
pages 58-59.
All operators must read and understand the owner's
manual and all warning and instruction labels
before operating the vehicle. Never allow a guest to
operate this vehicle until the guest has completed
the New Operator Driving Procedures outlined on
pages 58-59.
Age Restrictions
This vehicle is an ADULT VEHICLE ONLY.
Operation is prohibited for anyone under 16 years
of age or anyone without a valid driver’s license.
The operator must be tall enough to sit with back
against the seat, both feet flat on the floor and both
hands on the steering wheel.
Using Alcohol or Drugs
Operating this vehicle after consuming alcohol or
drugs could adversely affect operator judgment,
reaction time, balance and perception.
Never consume alcohol or drugs before or while
operating this vehicle.
Protective Apparel
Riding in this vehicle without wearing an approved
helmet and protective eyewear increases the risk of
a serious injuries in the event of an accident.
Always wear a helmet, eye protection, gloves, long-
sleeve shirt, long pants and over-the-ankle boots.
WARNING
<16

15
SAFETY
Safety Warnings
Seat Belts
Riding in this vehicle without wearing the seat
belt increases the risk of serious injury in the
event of rollover, loss of control, other accident
or sudden stop. Seat belts may reduce the
severity of injury in these circumstances.
The operator MUST wear the seat belt at all
times.
Cab Nets
Riding in this vehicle without using the cab nets
(or doors, if equipped) increases the risk of
serious injury or death in the event of an
accident or rollover. Always use the cab nets
(or doors) while riding in this vehicle. Always
keep hands and feet inside the vehicle at all
times.
Operating on Public Roads
Operating this vehicle on public streets, roads
or highways could result in a collision with
another vehicle. Always heed all local laws
and regulations governing the operation of
this vehicle.
Rollovers
A rollover can result in serious injury or death.
Avoid operating in a manner that could result
in a rollover.
Jumps and Stunts
Exhibition driving increases the risk of an
accident or rollover. DO NOT do power slides,
“donuts”, jumps or other driving stunts. Avoid
exhibition driving.

16
SAFETY
Safety Warnings
Carrying a Passenger
This POLARIS vehicle is a single-rider
vehicle. Carrying a passenger greatly
reduces the operator's ability to control
the vehicle, which may result in an
accident or rollover. Carrying a
passenger in the cargo box could result
in a fall from the vehicle or contact with
moving components. Never carry a
passenger on this vehicle.
Operating With a Load on the Vehicle
The weight of both cargo and operator impacts vehicle operation and stability.
For your safety and the safety of others, carefully consider how your vehicle is
loaded and how to safely operate the vehicle. Follow the instructions in this
manual for loading, tire pressure, gear selection and speed.
•Do not exceed vehicle weight capacities. The vehicle’s maximum weight
capacity is listed in the specifications section of this manual and on a label on
the vehicle. When determining the weight you are adding to the vehicle,
include the weight of the operator, accessories, loads in the rack or box and
the load on the trailer tongue. The combined weight of these items must not
exceed the maximum weight capacity.
• The recommended tire pressures are listed in the specifications section of this
manual and on a label on the vehicle.
Always follow these guidelines:
Under ANY of these conditions: Do ALL of these steps:
Operator and/or cargo exceeds half the
maximum weight capacity 1. Slow down.
2. Verify tire pressure.
3. Use extra caution when
operating.
Operating in rough terrain
Operating over obstacles
Climbing an incline
Towing

17
SAFETY
Safety Warnings
Improper Tire Maintenance
Operating this vehicle with improper tires or
with improper or uneven tire pressure could
cause loss of control or accident.
Always use the size and type of tires specified
for your vehicle.
Always maintain proper tire pressure as
described in the owner's manual and on safety
labels.
Operating at Excessive Speeds
Operating this vehicle at excessive speeds
increases the operator's risk of losing
control. Always operate at a speed that's
appropriate for the terrain, the visibility and
operating conditions and your skills and
experience.
Failure to Inspect Before
Operating
Failure to inspect and verify that the vehicle
is in safe operating condition before
operating increases the risk of an accident.
Always perform the pre-ride inspection
before each use of your vehicle to make
sure it's in safe operating condition. See
page 54.
Always follow the inspection and maintenance procedures and schedules
described in this owner’s manual. See page 85.

18
SAFETY
Safety Warnings
Turning Improperly
Turning improperly could cause loss of traction, loss of control, accident or
rollover. Always follow proper procedures for turning as described in this
owner’s manual.
Avoid sharp turns. Never turn while applying heavy throttle. Never make abrupt
steering maneuvers. Practice turning at slow speeds before attempting to turn at
faster speeds.
Improper Hill Climbing
Improper hill climbing could cause loss of
control or rollover. Use extreme caution when
operating on hills. Always follow proper
procedures for hill climbing as described in this
owner's manual. See page 62.
Descending Hills Improperly
Improperly descending a hill could cause loss
of control or rollover. Always follow proper
procedures for traveling down hills as described
in this owner’s manual. See page 64.
