Polaris Magnum 2x4 User manual

LRRIS
InDUSTRIES Inc:.
ATV AND LIGHT UTILITY VEHICLE
SERVICE MANUAL
Foreword
This manual is designed primarily for use by ATV service technicians in a properly equipped shop. Since a
certain knowledge of mechanical theory, tool use, and shop procedures
is necessary to perform the service
work safely, all operations should be performed by qualified service personnel only.
In order to perform the
work efficiently
and prevent costly errors, the technician should read the text and be familiar with procedures
before starting the work. Cleanliness of parts and tools as well as the work area
is of primary importance.
All references to left and right side of the vehicle are from the operator's perspective when seated
in a normal
riding position.
This manual includes procedures for maintenance operations, component identification and unit repair, along
with service specifications for 1996-1998 model Polaris ATVs and Light Utility Vehicles. The section index
tabs enable the user to quickly locate the section desired.
In addition, a table of contents is placed at the
beginning of each section for location of specific page numbers and service information. Keep this manual
available for reference
in the shop area.
To keep this manual current it is important that it is updated yearly with new model information and
specifications.
At the time of publication all information contained
in this manual was current. However, all materials and
specifications are subject to change without notice.
Comments or suggestions about this manual may
be directed to: Polaris Industries Inc., Service Publications
Supervisor, 1225 Highway 169 North, Minneapolis, Minnesota 55441-5078.
1996-1998 Service Manual Volume II Part No. 9913680
1998 Service Manual Update Part No. 9914752
Printed in U.S.A.

UNDERSTANDING SAFETY LABELS AND INSTRUCTIONS
Throughout these instructions, important information is brought to your attention by the following symbols:
.&,.The Safety Alert Symbol means ATIENTIONI BECOME ALERTI YOUR SAFETY IS INVOLVED!
A DANGER
Failure to follow DANGER instructions will result in severe injury or death to the operator, passenger, bystand-
er or person inspecting or servicing the ATV.
A WARNING
Failure to follow WARNING instructions could result in severe injury or death to the operator, passenger, by-
stander or person inspecting or servicing the ATV.
A CAUTION indicates special precautions that must be taken to avoid minor personal injury, or ATV or proper-
ty damage.
NOTE:
A NOTE provides key information to clarify instructions.
Trademarks
Polaris acknowledges the following products mentioned in this manual:
FLEXLOC, Registered Trademark of SPS Technologies
Loctite, Registered Trademark of the Loctite Corporation
STA-BIL, Registered Trademark of Gold Eagle
FOX, Registered Trademark of Fox Shox
Nyogel, Trademark of Wm. F. Nye Co.
Fluke, Registered Trademark of John Fluke Mfg. Co.
Mity Vac, Registered Trademark of Neward Enterprises, Inc.
Ammco, Registered Trademark of Ammco Tools, Inc.
Torx, Registered Trademark of Textron
Hilliard, Trademark of the Hilliard Corporation

Table ofContents
9913680
Chapter 01 .............................. General Information
Chapter 02 ....................................... Maintenance
Chapter 03 ............................................... Engine
Chapter 04 ........................ Fuel System/Carburetion
Chapter 05 ....................... Body/Steering/Suspension
Chapter 06 ........................................ PVT System
Chapter 07 .......................................... Final Drive
Chapter 08 ...................................... Transmission
Chapter 09 .............................................. Brakes
Chapter 10 ............................................ Electrical

CHAPTER 1
GENERAL INFORMATION
Model Identification ........................... 1.1 - 1.1 c
Publications Numbers . . . . . . . . . . . . . . . . . . . . . . .
.. 1.2 -1.2a
Service Videos
............................... 1.2a
Service/Information Bulletin
Index. . . . . . . .. . . . . .. 1.3 -1.3b
Paint Codes
................................. 1.4 -1.4b
Model Specifications, 1996 1.5 -1.8
Model Specifications, 1997
.................... 1.8a -1.8d
Model Specifications, 1998
.................... 1.8e -1.8h
Standard Torque Specifications. . . . . . . . . . . . . . .
.. 1.9
Decimal Equivalent Chart . . . . . .. . . . . . . . . . . . . .
.. 1.10
Conversion Table . . . . . . . . . . . . . . . .. . . . . . . . . . . .. 1.11
Tap Drill Charts. . . . . .. . . . . . . . . . . . . . . . . . . . . . . .. 1.12
Warranty
.................................... 1.13
Service Tips
................................. 1.14
Glossary of Terms
............................ 1.15 -1.17
Tool Ordering Information ..................... , 1.18
Routing Diagrams
............................ 1.19 -1.24

GENERAL INFORMATION
Model Identification
Engine Serial Number Location
Whenever corresponding about an engine, be sure to refer to the engine model number and serial number. This
information can be found on the sticker applied to the manual starter recoil housing. An additional number is
stamped
in one of the following locations:
• 4 stroke models -center top of crankcase beneath the cylinder coolant elbow
• 2 stroke liquid cooled models -center top of crankcase beneath the carburetor mounting flange
• 2 stroke air cooled models -top of crankcase near right side of cylinder
Machine Model Number and Serial Number Location
The machine model number and serial number are im-
portant for vehicle identification. The machine model
number
is located on the frame on the left side of the
vehicle near the
oil tank. Depending on model, the Se-
rial number will be stamped into the frame in one of the
following locations:
• On the right side of the vehicle in front
of the shift selector box (A). (1996)
• Under the seat on the upper shock
mount cross member (8) (1996)
• On the right hand frame rail (C) near
the air box. (1997)
• On the left hand lower frame rail (D)
near the rear A-arm mount.
(199B-Current)
Transmission 1.0. Number Location
Transmission model and serial numbers are located
on top of the transmission case below the shifting bell-
cranks.
Carburetor 1.0. Number Location
The carburetor 1.0. number is in one of the following
locations:
4 stroke models -right side center of
the carburetor body
• 2 stroke models -right side of carbu-
retor body near choke plunger boss
Polaris Industries Inc.
1.1
VIN Location -1996
VIN Location - 1996/1997
VIN Location -199B-Current
Example
Mod :ffl 13411571
Ser #t 96-1Q273
Transmission 1.0. Numbers
5/98
