Polhus F5823/34-Ida Quick guide

DE - Anweisungen für Montage, Wartung und sicheren Gebrauch.
EN - Instrucons for assembly, maintenance and safe use.
FR - Instrucons de montage, d’entreen et d’ulisaon en toute sécurité.
NL - Instruces voor montage, onderhoud en veilig gebruik.
CZ - Pokyny pro montáž, údržbu a bezpečné použi.
SK - Návod na montáž, údržbu a bezpečné používanie.
SWE - Monteringsanvisning
Polhus
Polhus Akebolag
Djäknegatan 31
211 35 Malmö
hps://www.polhus.com/
F5823/34-Ida
IDA
Issue - B 09/05/2023

WD15-0100 (145x40) x 100mm x6
WD15-2740 (145x40) x 2740mm x6
WD32-2584 (170x16) x 2584mm x2
WD32-2776 (170x16) x 2776mm x2
WD34-1900 (95x16) x 1900mm x5
WD34-2174 (95x16) x 2174mm x5
WD1471 (135x34) x 2232mm x3
WD1472 (135x34) x 1201mm x3
WD14-3417 (88x18) x 3417mm x31
WD32-3416 (170x16) x 3416mm x2
W17
W18
W19
W20
W21
W22
W23
W24
W25
W26
BOM Table
ITEM NO. PART NUMBER DESCRIPTION QTY.
17 WD14-3417 PROFILE #14 X 3417mm TIMBER 31
18
WD15-0100 PROFILE #15 X 100mm TIMBER 6
19 WD15-2740 PROFILE #15 X 2740mm TIMBER 6
20 WD32-2584 PROFILE #32 X 2584mm TIMBER 2
21 WD32-2776 PROFILE #32 X 2776mm TIMBER 2
22 WD32-3416 PROFILE #32 X 3416mm TIMBER 2
23 WD34-1900 PROFILE #34 X 1900mm TIMBER 5
24 WD34-2174 PROFILE #34 X 2174mm TIMBER 5
25 WD1471 PROFILE #11 X 2232mm TONGUE & GROOVE 3
26 WD1472 PROFILE #11 X 1201mm TONGUE & GROOVE 3
WD11-0608 (135x34) x 608mm x28
WD11-0794 (135x34) x 794mm x14
WD11-1340 (135x34) x 1340mm x14
WD11-2232 (135x34) x 2232mm x42
WD11-5800 (135x34) x 5800mm x14
WD12-2270 (95x40) x 2270mm x2
WD12-5692 (95x40) x 5692mm x7
WD13-0200 (45x45) x 200mm x4
WD13-0476 (45x45) x 476mm x2
WD13-0550 (45x45) x 550mm x2
WD13-1894 (45x45) x 1894mm x4
WD13-2142 (45x45) x 2142mm x4
WD13-2166 (45x45) x 2166mm x4
WD13-2759 (45x45) x 2759mm x2
WD14-2230 (88x18) x 2230mm x64
WD14-2583 (88x18) x 2583mm x31
W1
W2
W3
W4
W5
W6
W7
W8
W9
W10
W11
W12
W13
W14
W15
W16
BOM Table
ITEM NO. PART NUMBER QTY.
1 WD11-0608 28
2 WD11-0794 14
3 WD11-1340 14
4 WD11-2232 42
5 WD11-5800 14
6 WD12-2270 2
7
WD12-5692 7
8
WD13-0200 4
9
WD13-0476 2
10 WD13-0550 2
11 WD13-1894 4
12 WD13-2142 4
13 WD13-2166 4
14 WD13-2759 2
15 WD14-2230 64
16
WD14-6000 31
17
WD15-0100 6
18 WD15-2740 6
19 WD32-2776 2
20 WD32-6000 2
21 WD34-1900 5
22 WD34-2174 5
23 WD1471 3
24 WD1472 3
25
2.5 x 60 Galvanised
Nail
792
26 4.5 x 50 Wood Screw 98
27
4.5 x 70 Wood Screw 481
28 4.5 x 80 Wood Screw 28
29
6 x 180 Wood Screw 141
30 PH009 2
BOM Table
ITEM
NO.
PART
NUMBER
DESCRIPTION QTY.
1 WD11-0608 Profile #11 x 608mm Tongue & Groove 28
2 WD11-0794 Profile #11 x 794mm Tongue & Groove 14
3 WD11-1340 Profile #11 x 1340mm Tongue & Groove 14
4 WD11-2232 Profile #11 x 2232mm Tongue & Groove 42
5 WD11-5800 Profile #11 x 5800mm Tongue & Groove 14
6 WD12-2270 Profile #12 x 2270mm Timber 2
7
WD12-5692 Profile #12 x 5692mm Timber 7
8
WD13-0200 Profile #13 x 200mm Timber 4
9
WD13-0476 Profile #13 x 476mm Timber 2
10 WD13-0550 Profile #13 x 550mm Timber 2
11 WD13-1894 Profile #13 x 1894mm Timber 4
12 WD13-2142 Profile #13 x 2142mm Timber 4
13 WD13-2166 Profile #13 x 2166mm Timber 4
14 WD13-2759 Profile #13 x 2759mm Timber 2
15 WD14-2230 Profile #14 x 2230mm Timber 64
16
WD14-2583 Profile #14 x 2583mm Timber 31
17
WD14-3417 Profile #14 x 3417mm Timber 31
18
WD15-0100 Profile #15 x 100mm Timber 6
19 WD15-2740 Profile #15 x 2740mm Timber 6
20 WD32-2584 Profile #32 x 2584mm Timber 2
21 WD32-2776 Profile #32 x 2776mm Timber 2
22 WD32-3416 Profile #32 x 3416mm Timber 2
23 WD34-1900 Profile #34 x 1900mm Timber 5
24 WD34-2174 Profile #34 x 2174mm Timber 5
25 WD1471 Profile #11 x 2232mm Tongue & Groove 3
26 WD1472 Profile #11 x 1201mm Tongue & Groove 3
50mm x102
70mm x472
180mm x142
Pin x854
80mm x28
x2
(+1 extra log)

5800mm
2300mm
100mm
100mm
100mm
100mm
6000mm
2500mm
A
B
D
E
C
PLINTPLAN / FOUNDATION PLAN / BETONBLOCK / PLAN DE FONDATIONS

497mm
497mm
497mm
497mm
1A
W6
(x2)
W7
(x7)
70mm x 20
80mm x 28
70
80

310mm 560mm 560mm 560mm
560mm
1B
W6
(x2)
W7
(x7)
70mm x 20
80mm x 28
70
80
ENG; Option Floor Insulation
SWE: Förslag Golvisolering;
GER: Vorschlag Bodendämmung;
FRA: Option Isolation du sol

2875mm
20mm
20mm
20mm
20mm
20mm
2
W15
(x32)

3Pin x160
Pin

4
W12
x2
W10
x2
W14
70
70mm x19

5
W4
70
70mm x4

6
70
W9
x2
W11
x2
70mm x4

20mm
20mm
20mm
7
20mm
W15
(x32)

8Pin x160
Pin

9
70mm x19
W14
70
W10
x2
W12
x2

1622mm1622mm
10
70mm x24
W3
W4
x2
70
W5
W1
x2

11 W9
x2
W11
x2
70mm x18
70

12
W5
W1
x2
W4
x3
W3
70
180
70mm x20
180mm x20

13
70
180
W5
W4
x3
W1
x2
W3
70mm x20
180mm x14

A
B
C
D
E
14
W1
x22
W5
x1
W3
x11
W4
x33
W5
x10
180
70
A
B
C
D
E
70mm x266
180mm x69

A
A

B
B
