Polyconcept USA 841-121 User manual

Project#70001 –Retro Cordless Phone
Date: 12 July 2004
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the
following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not place this product on an unstable cart, stand or table. The product may
fall, causing serious damage to the product.
5. Slots and openings in the cabinet and the back or bottom are provided for
ventilation, to protect it from overheating, these openings must not be blocked or
covered. The openings should never be blocked by placing the product on a bed,
sofa, rug or other similar surface. This product should never be placed near or
over a radiator or heater. This product should not be placed in a built-in
installation.
6. Never push objects of any kind into this product through cabinet slots as they
may touch dangerous voltage points or short out parts that could result in a risk
of fire or electric shock. Never spill liquid of any kind on the product.
7. To reduce the risk of electric shock, do not disassemble this product, but take it
to a qualified serviceman when service or repair work is required. Opening or
removing covers may expose you to dangerous voltages or other risks. Incorrect
re-assembly can cause electric shock when the appliance is subsequently used.
8. Unplug this product from the wall outlet and refer servicing to qualified service
personnel in the following cases:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.

9. Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be damaged by persons walking on it.
10. Do not use this product near water, for example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool.
11. Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
12. Do not use the telephone to report a gas leak in the vicinity of the leak.
13. Use only the power cord and batteries indicated in this manual. Do not dispose
of batteries in a fire. They may explode. Check with local codes for possible
special disposal instructions.
14. Caution: Risk of explosion of battery is replaced by an incorrect type. Use only
SANIK, type no. SNAA60HSJ1.
15. Use only with Class 2 power source 9V DC 200mA.
16. Plug the adaptor to the socket-outlet which near the equipment and shall be
easily accessible.
SAVE THESE INSTRUCTIONS
IMPORTANTES MESURES DE SÉCURITÉ
Certaines mesures de sécurité doivent être prises pendant l’utilisation de matérial
téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures.
En voici quelquesunes:
1. Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une baignoire, d’un
lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol humide ou
près d’une piscine.
2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pendant
un orage électrique. Ceci peut présenter un risque de choc électrique causé
par la fuite.
3. Ne pas utiliser l’appareil télephonique pour signaler une fuite de gaz s’il est
situé près de la fuite.
4. Utiliser seulement le cordon d’alimentation et le type de piles indiqués dans
ce manuel. Ne pas jeter les piles dans le feu: elles peuvent exploser. Se
conformer aux règlements pertinents quant à l’élimination des piles.
INSTALLATION INSTRUCTIONS
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifically

designed for wet locations.
3. Never touch uninstalled telephone wires or terminals unless the telephone line
has been disconnected at the network interface.
4. Use caution when installing or modifying telephone lines.
CONSUMER INFORMATION
This equipment complies with Part 68 of the FCC rules and the requirements adopted
by the ACTA. On the bottom of this equipment is a label that contains, among other
information, a product identifier in the format US:AAAEQ##TXXXX. If requested,
this number must be provided to the telephone company.
An applicable certification jacks Universal Service Order Codes (USOC) for the
equipment is provided (i.e., RJ11C) in the packaging with each piece of approved
terminal equipment.
A plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements adopted
by the ACTA. A compliant telephone cord and modular plug is provided with this
product. See installation instructions for details.
The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact the local telephone
company.
If this equipment causes harm to the telephone network, the telephone company will
notify you in advance that temporary discontinuance of service may be required. But
if advance notice isn’t practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a complaint with the
FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the
telephone company will provide advance notice in order for you to make necessary
modifications to maintain uninterrupted service.
Please follow instructions for repairing if any (e.g. battery replacement section);
otherwise do not replace or repair any parts of the device unless specified.
Connection to a party line service is subject to state tariffs. Contact the state public
utility commission, public service commission or corporation commission for
information.
This equipment is hearing aid compatible.

NOTICE:
If your home has specially wired alarm equipment connected to the telephone line,
ensure the installation of this [equipment ID] does not disable your alarm equipment.
If you have questions about what will disable alarm equipment, consult your
telephone company or a qualified installer.
NOTICE:
According to telephone company reports, AC electrical surges, typically resulting
from lightning strikes, are very destructive to telephone equipment connected to AC
power sources. To minimize damage from the these types of surges, a surge arrestor is
recommended.
Should you experience trouble with this equipment, please Contact Polyconcept
USA, Inc., by calling Toll Free: 1 [phone] for repair or warranty information.
If the equipment is causing harm to the telephone network, the telephone company
may request that you disconnect the equipment until the problem is resolved.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is needed.
Consult the dealer or an experienced radio/TV technician for help.
EQUIPMENT LIMITATIONS NOTICE
“NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment
Technical Specifications”

Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company. The equipment
must also be installed using an acceptable method of connection. The customer should
be aware that compliance with the above conditions may not prevent degradation of
service in some situations.
Repairs to certified equipment should be coordinated by a representative designated
by the supplier. Any repairs or alterations made by the user to this equipment, or
equipment malfunctions, may give the telecommunications company cause to request
the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of
the power utility, telephone lines and internal metallic water pipe system, if present,
are connected together. This precaution may be particularly important in rural areas.
CAUTION:
Users should not attempt to make such connections themselves, but should contact the
appropriate electric inspection authority, or electrician, as appropriate.
“NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is
0.0. TheREN assigned to each terminal equipment provides an indication of the
maximum number of terminals allowed to be connected to a telephone interface. The
termination on an interface may consist of any combination of devices subject only to
the requirement that the sum of the Ringer Equivalence Numbers of all the devices
does not exceed five.”
CONTROLS
1. Base
2. Base Antenna
3. Page Button
4. Voice Mail/In-use/Charge Indicator
5. Cradle
6. Charge Contact plate
7. DC Jack
8. Telephone Line in Jack
9. Handset Antenna
10. Ear Piece Cover
11. LCD Display
12. Memory Button
13. Format Button

14. Talk Button
15. Battery Contact Plate
16. Pause Button
17. Flash/Program Button
18. Mouth Piece Cover
19. Ringer On/Off Switch
20. Channel/Delete Button
21. Tone/Exit Button
22. Caller ID/Volume (σand τ) Button
23. Redial Button
900-MHz Cordless Telephone with Caller ID
IMPORTANT
Charge the handset battery for 12 continuous hours prior to first use.
INTRODUCTION
Your 900-MHz Retro Cordless Telephone is a fine-quality home communications
product. It is carefully designed and produced by a world leader of consumer and
industrial electronics equipment. With proper maintenance and care, it will provide
you with years of enjoyment and convenience.
MAIN FEATURES
900-MHz Technology
Extended Range –The use of 900-MHz frequency band for signal transmission
between base and handset means greater communication range compared to
conventional 43-49 MHz cordless telephones.
Ultra-Low Noise –The high frequency communication also features significantly
reduced noise levels.
40-Channel Auto/Manual Scan –Your new telephone uses one of 40 channels in the
900-MHz frequency band. It automatically selects a clear channel every time you
receive or place a call on the handset.
COMPANDERPLUSNoiseReduction
The noise reduction technology now filters out more background noise.

Caller ID* and Caller ID with Call Waiting*
(*Each feature works with your telephone company. A subscription is required.)
40-number Caller ID list
10-name/number directory
Receiver volume control
3-line trilingual display
Ringer On/Off switch
Low battery warning
*Important:
To use all of the features of this phone, you must subscribe to either the standard
Name/Number Caller ID Service or Caller ID with Call Waiting Service. To know
who is calling while you are on the phone, you must subscribe to Caller ID with Call
Waiting Service.
GETTING STARTED
Checking the package contents
Make sure your package includes the items shown here.
(Drawing)
INSTALLATION
Modular Jack
To properly connect your phone to your telephone lines, you will need an RJ11 type
modular phone jack. If you do not have a modular jack, call your local phone
company to find out how to get one installed.
Installation note: Avoid places near electrical equipment such as refrigerators,
computers, TVs or fluorescent lamps. These may cause interference or reduce the
operation range of the cordless telephone.
Connections
(Drawing)
1. Set the Ringer On/Off Switch (19) on the front of the handset to the ON
position and place the handset in the base.
2. Plug the AC/DC adaptor into the DC Jack (7) on the bottom of the base and the

other end into an electrical outlet. The Voice Mail/In-use/Charge Indicator(4)
lights, verifying the battery is charging.
Charge the handset battery for 12 continuous hours prior to first use. The initial
battery charge is important for best performance.
Low Battery Warning:When the battery is low you will hear a short beep every 7
seconds. Please follow the same steps as above to recharge your battery for best
performance.
Important: Do not connect the telephone line to the modular jack until the phone has
been charged for 12 continuous hours.
3. Plug the telephone line cord into the Telephone Linein Jack (8) on the bottom
of the base and into a modular jack.
Caution:Use the original AC/DC adaptor, that came with this phone. Using other
adaptors may damage the phone.
Note:The phone automatically defaults to touch tone dialing. To change to pulse
(rotary) dialing, see Tone/Pulse dialing.If you do not know which type of service
you have, check with your telephone company.
Digital Security System
Your cordless phone uses a digital security system to provide protection against false
ringing, unauthorized access and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After a
power outage or battery replacement, place the handset in the base for about 20
seconds to reset the code.
INITIAL PROGRAMMING
Before using this telephone the following 3 initial program set-ups must be
completed:
Language setting
1. Make sure the phone is off (not in TALK mode).
2. Press the Flash/Program Button (17) until 1ENG 2FRA 3ESP shows on screen.

English is factory set.
3. Use the handset number keys to enter the desired setting. For example, to choose
French, press the number 2key.
4. Press the Flash/Program Button (17) to store selection. You will hear a
confirmation tone.
Tone/pulse setting
1. Make sure the phone is off (not in TALK mode).
2. Press the Flash/Program Button(17) until 1 TONE 2 PULSE shows on screen.
Tone is factory set.
3. Use the number keys to enter the desired setting. For example, to choose Tone
dialing, press the number 1key.
4. Press the Flash/Program Button(17) to store selection. You will hear a
confirmation tone.
Area code setting
This required to use Caller ID service from your telephone company.
1. Make sure the phone is off (not in TALK mode).
2. Press the Flash/Program Button (17) until ---SET AREA CODE shows on
screen.
3. Use the handset key pad to enter your 3-digit area code.
4. Press the Flash/Program Button (17) to store selection. You will hear a
confirmation tone.
BASIC
Receiving a call
1. When the phone rings the screen shows caller information*.
2. Press the Talk Button(14).
*If you do not subscribe to a caller ID service, there will be no information on
display.
Ringer switch
The Ringer On/Off Switch (19) must be ON for the handset to ring during incoming
calls.
Volume
While talking, press the Caller ID/Volume (σandτ)Button(22) to control the
receiver volume. There are four volume levels. Press σto increase the volume level,

and press τto decrease. VOL 1 is the lowest level and VOL 4 is the loudest.
Making a call
Press the Talk Button(14) before you dial and press it again to hang up.
Redialing a call
Press the Talk Button(14) and then the Redial Button (23) to redial the last number
you dialed (up to 32 digits). If you get a busy signal, and want to keep dialing the
number, just press the Redial Button(23) again (you do not have to turn the phone
off and back on).
Flash button
Use the Flash/Program Button(17) to use special calling services such as Call
Waiting or Call Transfer. You must subscribe to these services available through your
local phone company.
Tip:Do not use Talk Button(14) to activate custom calling services or you’ll hang
up the phone.
Voice mail/In-use/Charge indicator
Flashes when you have a new voice mail.
Lights when the handset is being charges in the base.
Lights when the handset is in use.
(Drawing)
VOICE MAIL/IN-USE/CHARGE indicator
PAGE button
Voice mail
When you subscribe to a voice mail service offered by your phone company, the
phone alerts you when voice mail has been received. MESSAGE WAITING appears
on screen for 60 seconds when a voice mail is received. The Voice Mail/In-
use/Charge Indicator (4) on the base flashes to indicate there is voice mail waiting.
After the voice mail has been reviewed MSG WAITING OFF appears on screen and
the Voice Mail/In-use/Charge Indicator(4) stops flashing.
This indicator does not work with your answering machine.
Note: The phone will only work with an FSK type of VMWI system. It will not work

with the Stutter Dial Tone type of VMWI system.
Channel button
Press and release the Channel/Delete Button (20) to advance to the next channel to
get rid of static while talking.
Temporary tone
This feature enables pulse (rotary) service phone users to access touch-tone services
offered by banks, credit card companies, etc.
1. Call the bank’s information line.
2. Press the Tone/Exit Button (21) after your call is connected.
3. Follow the voice instructions to complete your transaction.
4. Hang up when finished. The phone returns to pulse (rotary) service.
Exit button
Press the Tone/Exit Button (21) to cancel any command you initiated.
Handset locator
This feature helps to locate a misplaced handset. Press the Page Button(3) on the
base. The handset beeps continuously for about two minutes or until you press any
key on the handset. Press the Page Button (3) to cancel.
Note:The Ringer On/Off Switch (19) does not have to be ON position for this
feature to work.
CALLER ID FEATURES
(Drawing)
Time
Date
Number of calls
This phone receives and displays caller’s information when you subscribe to a Caller
ID service from your telephone company. This information can include the phone
number, date, and time: or the name, phone number, date, and time. The phone can
store up to 40 callers for later review.
Caller ID with call waiting
When you subscribe to Caller ID with Call Waiting service (Visual Call Waiting™)

from your phone company, you are able to see who is calling when you hear the call
waiting beep. The caller information appears on screen after you hear the tone.
Press the Flash/Program Button (17) to put the first caller on hold and answer
the incoming call.
Press the Flash/Program Button (17) again to return to the first caller.
Important: In order to use the Caller ID functions with this phone, you must
subscribe to either the standard Name/Number Caller ID Service or Caller ID with
Call Waiting Service. Services may vary by region. Contact your phone company.
Caller ID list
When you receive a call, the information is transmitted by the phone company to your
Caller ID telephone between the first and second ring and then stored in the Caller ID
memory.
When the memory is full, a new call automatically replaces the oldest call in memory.
NEW appears on screen for calls received that have not been reviewed. REPT
indicates that a new call from the same number was received more than once.
Reviewing Caller ID list
As calls are received and stored, the Caller ID list is updated to let you know how
many calls have been received.
Press the Caller ID/Volume (σandτ) Button (22) to scroll through the list from
the most recent to the oldest or from the oldest to the most recent.
Dialing a Caller ID number
1. Make sure the phone is off (not in TALK mode).
2. Use the Caller ID/Volume (σand τ) Button (22) to display the desired Caller
ID entry.
3. Press the Talk Button(14). The number is dialed automatically.
Transferring Caller ID entries to the directory
You can transfer up to 10 Caller ID entries to your phone’s directory.
1. Use the Caller ID/Volume (σand τ) Button (22) to scroll to the call entry you
want to transfer to the directory
Note: Before transferring a caller ID number, make sure the number appears in proper
digits for your dialing area. If not, change it using the Format Button (13). For
example, if the caller ID number appears 1-416-222-5555 but it is not a long distance
number, press the Format Button (13) until it shows 416-222-5555 (without 1).

Caller ID number display
Use the CID/VOL keys to scroll to the phone number you want to store or call.
Press the Format Button(13) to change to the required number of digits.
The Format Button (13) lets you select how many digits of the number to be
displayed.
77-digit telephone number.
10 3-digit area code + 7-digit telephone number.
11 Long distance code 1 + 3-digit area code + 7-digit telephone number.
2. Press the Memory Button(12).
3. Press the desired memory location number. Example: press number 1key to
store the caller in location 1.
4. Press the Memory Button(12) again. You will hear a confirmation tone.
To replace a name/number stored in the directory with a new call entry:
1. Repeat steps 1 through 3.
2. Press the Memory Button(12) and REPLACE MEMO? Shows on screen.
3. Press the Tone/Exit Button (21) to exit, or press the Memory Button (12) again
and the new call entry number replaces the current name/number in that memory
location. You will hear a confirmation tone.
Deleting Caller ID list entry
Use the Channel/Delete Button (20) to erase the name/number currently shown on
screen or entire Caller ID list.
Deleting the displayed entry
1. Make sure the phone is off (not in TALK mode).
2. Use the Caller ID/Volume (σand τ) Button (22) to display the desired Caller
ID entry.
3. Press the Channel/DeleteButton(20). The screen shows DELETE?
4. Press the Channel/DeleteButton (20) again to erase the displayed data. You
will hear confirmation tone. The screen shows DELETED. Then the next Caller
ID entry shows on screen.
Deleting entire Caller ID list
1. Make sure the phone is off (not in TALK mode).

2. Use the Caller ID/Volume (σandτ)Button(22) to display any Caller ID entry.
3. Press and hold the Channel/Delete Button(20) until the phone beeps and
DELETE ALL? Shows on the screen.
4. Press the Channel/Delete Button (20) again to erase the entire list. You will hear
confirmation tone and NO CALLS appears.
DIRECTORY
Store up to 10 names/numbers in the directory for quick dialing. The number can be
up to 24 digits. The name can be up to 15 characters. This directory feature is in
addition to the 40 Caller ID list.
Storing a name/number in the directory
1. Make sure the phone is off (not in TALK mode).
2. Press the Memory Button (12).
3. Press the desired memory location (0 through 9).
4. Press the Memory Button (12) again. The screen shows ENTER NAME.
Note: If you do not want to enter the name, skip step 5.
5. For example, to enter the name Alice Roy:
Press the 2key once for the letter A.
Press the 5key three times for the letter L.
Press the 4key three times for the letter I.
Press the 2key three times for the letter C.
Press the 3key twice for the letter E.
Press the 1key to insert a space between the letter E and R.
Continue to enter the letters of the last name.
Note: If you enter a wrong letter, press the Channel/Delete Button (20) to
backspace.
6. Press the Memory Button (12) to save the name. The screen shows ENTER TEL
NUMBER.
7. Use the number keypad to enter the telephone number you want to store (up to 24
digits).
8. Press the Memory Button (12) again to store the number. You will hear a
confirmation tone.
Changing a stored name/number
1. Repeat steps 1 through 7 in Storing a name/number in the directory.
2. Press the Memory Button (12) and REPLACE MEMO? Shows on screen.
3. Press the Tone/ExitButton(21) to replace the current number with a new

number. You will hear a confirmation tone.
Storing last-dialed number
1. Repeat steps 1 through 6 in Storing a name/number in the directory.
2. Press the Redial Button (23).
3. Press the Memory Button (12) to store the number. You will hear a confirmation
tone.
Making calls from the directory
1. Make sure the phone is off (not in TALK mode).
2. Press the Memory Button (12).
3. Use the Caller ID/Volume (σandτ)Button (22) to scroll through directory until
the desired name is shown.
4. Press the Talk Button (14). The number is dialed automatically.
-or -
1. Press the Talk Button(14).
2. Press the Memory Button(12).
3. Press number (0-9) for the desired memory location. The number is dialed
automatically.
Inserting a pause in the dialing sequence
Press the PauseButton (16) twice within one second to insert a delay in the dialing
sequence of a telephone number when a pause is needed to wait for a dial tone. For
example after you dial 9 for an outside line, or to wait for a computer access tone. P
shows on screen. Each pause counts as 1 digit in the dialing sequence.
Reviewing and deleting directory contents
1. Press the Memory Button(12), then use the Caller ID/Volume (σand τ)
Button(22) to view the directory.
2. While the desired entry is displayed, press the Channel/Delete Button (20). The
screen shows DELETE?
3. Press the Channel/DeleteButton (20) again to delete the entry. DELETED
shows on screen.
Chain dialing form the directory
Use this feature to make calls that require a sequence of numbers such as using a
calling card for a frequently called long distance number. You can dial each part of
the sequence from a different entry of the directory. The following example shows

how you can chain dial to make a call through a long distance service:
The Number for: Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is on.
2. Press the Memory Button(12) and then press 7.
3. When you hear the access tone, press the Memory Button(12) again and then
press 8.
4. At the next access tone, press the Memory Button (12) and then 9.
Tip:Wait for the access tones between pressing the Memory Button (12), or your
call might not go through.
CHANGING THE BATTERY
Battery replacement and handling
When the operating time becomes short even after a battery is recharged, please
replace the battery.
With normal usage, your battery should last about one year.
Note: Repeated short chargings may cause memory effect in the battery, which
reduces use time of the battery. It is recommended not to replace the handset to the
base unit after each call.
Caution
Use only the specified battery type (3.6V, 600mAh).
Do not remove the battery from the handset to charge it.
Never throw the battery into a fire, disassemble it, or heat it.
Do not remove or damage the battery casing.
Remove battery if storing the phone over 30 days.
(Drawing)
Make sure the telephone is off before you replace the battery.
1. Rotate the battery compartment cover counter-clockwise.

2. Disconnect the battery plug from the jack in the compartment and remove the
battery.
3. Insert the new battery and connect the cord into the jack.
4. Put the battery compartment cover back on.
5. Place handset on the base t charge.
Note: If the handset battery is removed for more than 5 minutes, the directory
memory and the Caller ID memory will be erased.
Charge the handset battery for 12 continuous hours prior to first use. The initial
uninterrupted battery charge is important for best performance.
Caution:To reduce the risk of fire or personal injury, use a 3.6V, 600 mAh battery.
Power failure
During the period that the power is off, you will not be able to make or receive calls
with the telephone.
After a power outage, place the handset in the base for about 20 seconds to reset the
digital security code.
LCD SCREEN MESSAGES
The following messages show the status of a call or the phone.
INCOMPLETE DATE
Caller information had been interrupted during transmission or the phone line is
excessively noisy.
ENTER NAME
Prompt telling you to enter the name for one of 10 directory locations.
ENTER TEL NUMBER
Prompt telling you to enter the telephone number for one of 10 directory locations.
DELETE?
Prompt asking if you want to erase an entry in the Caller ID list or directory.
DELETE ALL?

Prompt asking if you want to erase entire Caller ID list.
DELETED
Prompt confirming the Caller ID/Directory entry is erased.
END OF LIST
Indicates that there is no additional information in Caller ID list.
NEW
Indicates new caller(s) in the Caller ID list.
UNKNOW NAME/CALLER/NUMBER
The incoming call is from an area not serviced by Caller ID or the information was
not sent.
PAGING
The Page Button (3) is pressed on the base.
BLOCKED CALL
The caller has blocked name/number from transmission.
BLOCKED NAME
The caller’s name is blocked from transmission.
REPT
Repeat caller. Indicates that a new call from the same number was received more that
once.
NO DATA
No Caller ID information was received.
EMPTY
Indicates a memory location is vacant.
NO CALLS
No new calls received.
MESSAGE WAITING

This appears for 60 seconds when you have just received a new voice mail. This
message only appears if you subscribe to an answering service with your telephone
company.
MSG WAITING OFF
Appears when Voice Mail has been reviewed.
SOUND SIGNALS
Signal Meaning
A long warbling tone: Signals an incoming call (with ringer on)
Two long beeps: Confirmation tone
One short and one long beep: Page signal
One short beep every 7 seconds: Low battery warning
TROUBLESHOOTING
CALLER ID
No display on screen
Is battery fully charged? Try replacing the battery. Make sure the battery is
properly installed and connected.
Make sure that the phone is connected to a non-switched electrical outlet.
Disconnect the phone from the outlet and plug it in again.
Did you subscribe to Caller ID service from your local telephone company?
Caller ID error message
The phone displays this message if it detects anything other than valid Caller ID
information during the silent period after the first ring. This message indicates
the presence of noise on the line.
VoiceMail/In-use/Charge indicator flashes
When you subscribe to a voice mail service from your phone company, the Voice
Mail/In-use/Charge Indicator (4) on the base flashes when the phone is not in
use to indicate there is a voice mail waiting. It stops flashing after the voice mail
has been reviewed.
TELEPHONE
No dial tone
Check all connections:
-Is the AC/DC adaptor connected to a working outlet?

-Is the telephone line cord connected to the base and the wall jack?
Disconnect the base from the wall jack and connect another phone to the same
jack. If there is no dial tone in the second phone, the problem might be your
wiring or local service.
Is the handset out of range of the base?
Make sure the battery is properly charged (12 continuous hours).
Is the battery installed correctly?
Does the handset beep when you press the Talk Button(14)? The battery may
need to be charged.
Dial tone is OK, but cannot dial out
Make sure the tone/pulse setting is programmed correctly.
Handset does not ring
Make sure the Ringer On/Off Switch (19) on the handset is turned to ON
position.
You may have too many extension phones on your line. Try unplugging some
phones.
See solutions for No dial tone.
You experience static, noise or fading in and out
Change channels.
Is handset out of range? Move closer to the base.
Does the base need to be relocated?
Charge battery.
Make sure base is not plugged into an outlet with another household appliance.
Handse t beeps
Place handset in base for 20 seconds to reset the security code. If that doesn’t
work, charge battery for 12 continuous hours.
Clean charging contacts on handset and base with a soft cloth, or an eraser.
See solutions for No dial tone.
Replace battery.
Dialing from directory
Did you program the memory locations of directory?
Did you follow proper dialing sequence?
Make sure the tone/pulse setting is programmed correctly.
