Pontiac 2008 G6 User manual

Seats and Restraint Systems ........................... 1-1
Front Seats ............................................... 1-2
Rear Seats .............................................. 1-11
Safety Belts ............................................. 1-13
Child Restraints ....................................... 1-33
Airbag System ......................................... 1-59
Restraint System Check ............................ 1-74
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ...................................... 2-10
Windows ................................................. 2-15
Theft-Deterrent Systems ............................ 2-18
Starting and Operating Your Vehicle ........... 2-21
Mirrors .................................................... 2-37
OnStar
®
System ...................................... 2-41
Storage Areas ......................................... 2-44
Sunroof .................................................. 2-45
Retractable Hardtop .................................. 2-45
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-19
Warning Lights, Gages, and Indicators ........ 3-27
Driver Information Center (DIC) .................. 3-43
Audio System(s) ....................................... 3-52
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-25
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-4
Fuel ......................................................... 5-6
Checking Things Under the Hood ............... 5-12
Bulb Replacement .................................... 5-51
Windshield Wiper Blade Replacement ......... 5-59
Tires ...................................................... 5-60
Appearance Care ................................... 5-100
Vehicle Identification ............................... 5-109
Electrical System .................................... 5-109
Capacities and Specifications ................... 5-119
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance Information .................... 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-14
Vehicle Data Recording and Privacy ........... 7-16
Index ................................................................ 1
2008 Pontiac G6 Owner Manual M

GENERAL MOTORS, GM, the GM Emblem, PONTIAC,
the PONTIAC Emblem, and the name G6 are
registered trademarks of General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes
after that time without further notice. For vehicles first
sold in Canada, substitute the name “General Motors of
Canada Limited” for Pontiac Division whenever it
appears in this manual.
This manual describes features that may be available in
this model, but your vehicle may not have all of them.
For example, more than one entertainment system may
be offered or your vehicle may have been ordered
without a front passenger or rear seats.
Keep this manual in the vehicle for quick reference.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Propriétaires Canadiens
On peut obtenir un exemplaire de ce guide en français
auprès de concessionnaire ou à l’adresse suivante:
Helm Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Litho in U.S.A.
Part No. 15864180 A First Printing
©
2007 General Motors Corporation. All Rights Reserved.
ii

Using this Manual
Many people read the owner manual from beginning to
end when they first receive their new vehicle to learn
about the vehicle’s features and controls. Pictures
and words work together to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Safety Warnings and Symbols
There are a number of safety cautions in this book. A
box with the word CAUTION is used to tell about things
that could hurt you or others if you were to ignore the
warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
We tell you what the hazard is and what to do to help
avoid or reduce the hazard. Please read these cautions.
If you do not, you or others could be hurt.
A circle with a slash
through it is a safety
symbol which means “Do
Not,” “Do Not do this”
or “Do Not let this happen.”
iii

Vehicle Damage Warnings
You will also find notices in this manual.
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly.
The notice tells what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors or in
different words.
There are also warning labels on the vehicle which use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
iv

Front Seats ......................................................1-2
Manual Seats ................................................1-2
Power Seat ...................................................1-3
Manual Lumbar ..............................................1-3
Heated Seats .................................................1-4
Reclining Seatbacks ........................................1-4
Head Restraints .............................................1-7
Seatback Latches ...........................................1-8
Easy Entry Seat .............................................1-9
Power Lift Seat ............................................1-11
Rear Seats .....................................................1-11
60/40 Split Bench Seat (Sedan and Coupe) .....1-11
Safety Belts ...................................................1-13
Safety Belts: They Are for Everyone ................1-13
How to Wear Safety Belts Properly .................1-18
Lap-Shoulder Belt .........................................1-26
Safety Belt Use During Pregnancy ..................1-32
Safety Belt Extender .....................................1-32
Child Restraints .............................................1-33
Older Children ..............................................1-33
Infants and Young Children ............................1-36
Child Restraint Systems .................................1-39
Where to Put the Restraint .............................1-42
Lower Anchors and Tethers for Children
(LATCH) ..................................................1-44
Securing a Child Restraint in a Rear Seat
Position ...................................................1-53
Securing a Child Restraint in the Right Front
Seat Position ............................................1-56
Airbag System ...............................................1-59
Where Are the Airbags? ................................1-62
When Should an Airbag Inflate? .....................1-64
What Makes an Airbag Inflate? .......................1-65
How Does an Airbag Restrain? .......................1-66
What Will You See After an Airbag Inflates? .....1-66
Passenger Sensing System ............................1-68
Servicing Your Airbag-Equipped Vehicle ...........1-72
Adding Equipment to Your Airbag-Equipped
Vehicle ....................................................1-73
Restraint System Check ..................................1-74
Checking the Restraint Systems ......................1-74
Replacing Restraint System Parts After
a Crash ...................................................1-75
Section 1 Seats and Restraint Systems
1-1

Front Seats
Manual Seats
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving. Lift the bar located under the front of the seat to unlock
it. Slide the seat to where you want it and release
the bar. Try to move the seat with your body to be sure
the seat is locked in place.
1-2

Power Seat
If the vehicle has a power seat, the control used
to operate it is located on the outboard side of the
driver’s seat.
To adjust the seat:
•Move the seat forward or rearward by sliding the
control forward or rearward.
•Raise or lower the front part of the seat cushion by
moving the front of the control up or down.
•Raise or lower the rear part of the seat cushion by
moving the rear of the control up or down.
Manual Lumbar
If your vehicle has this feature, the handle is located on
the outboard side of the driver’s seat. Move the handle up
repeatedly to decrease lumbar support. Move the handle
down repeatedly to increase lumbar support.
1-3

Heated Seats
Your vehicle may have heated front seats.
The buttons are located on
the outboard side of the
driver’s and front
passenger’s seats.
Press the top of the switch to turn the feature on. The
seat will heat to the high setting. The indicator light
above the switch will be lit next to the number 2.
Press the top of the switch again to go to the low heat
setting. The indicator light will be lit next to the
number 1.
Press the bottom of the switch to turn the feature off.
The heated seat feature will turn off when the ignition is
turned off.
Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
Your seats have manual reclining seatbacks. The lever
used to operate them is located on the outboard
side of the seats.
1-4

To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position, then
release the lever to lock the seatback in place.
3. Push and pull on the seatback to make sure it is
locked.
To return the seatback to an upright position, do the
following:
1. Lift the lever fully without applying pressure to the
seatback and the seatback will return to the upright
position. Release the lever to lock the seatback
in place.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
2. Push and pull on the seatback to make sure it is
locked.
1-5

{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job because it
will not be against your body. Instead, it will be
in front of you. In a crash, you could go into it,
receiving neck or other injuries.
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there, not
at your pelvic bones. This could cause serious
internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
Do not have a seatback reclined if your vehicle is
moving.
1-6

Head Restraints
Adjust the head restraint so that the top of the restraint
is at the same height as the top of the occupant’s
head. This position reduces the chance of a neck injury
in a crash.
Pull the restraint up to
raise it. To lower the head
restraint, press the
button, located on the top
of the seatback, and
push the restraint down.
On sedans and coupes the rear seat head rests are
also adjustable.
On vehicles with a retractable hardtop the rear seat
head rests are not adjustable.
1-7

Seatback Latches
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving.
If your vehicle is a coupe or retractable hardtop model,
it has a seatback latch as part of the manual recline
lever. This feature provides easy access to the
rear seats. To operate the seatback latch, pull up on the
manual recline lever. The seatback will automatically
spring forward. To operate the latch from the rear seat,
pull back on the top of the manual recline lever.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
Lift the seatback up to return it to the upright position.
Push and pull on the seatback to make sure it is locked.
1-8

Easy Entry Seat
{CAUTION:
If the easy entry right front seat is not locked,
it can move. In a sudden stop or crash, the
person sitting there could be injured. After you
have used it, be sure to push rearward on an
easy entry seat to be sure it is locked.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
If your vehicle is a two-door model, the front passenger
seat can be moved to make it easier to get in and
out of the rear seat.
To use the easy entry seat, do the following:
1. Remove the safety belt from the headrest-mounted
guide.
1-9

2. Pull back on the top of the recliner lever. The
seatback will move forward. 3. Slide the seat forward.
4. Move the seat rearward until it locks into place after
the passenger enters the rear seat area.
5. Move the seatback to its original position and return
the front seat safety belt to the safety belt guide.
Make sure both the seat and seatback are locked.
1-10

Power Lift Seat
To adjust a power lift seat, press the top or bottom of
the power lift seat switch to raise or lower the seat.
Rear Seats
60/40 Split Bench Seat (Sedan and
Coupe)
Folding the Seatback
To fold down the rear seatback, do the following:
1. The handles that are used to lower the rear
seatbacks are located on the upper edge of
the trunk opening. Open the trunk. Pull the driver’s
side handle to open the larger side of the
seatback. Pull the passenger’s side handle to open
the smaller side of the seatback.
1-11

Notice: Folding a rear seat with the safety belts
still fastened may cause damage to the seat or the
safety belts. Always unbuckle the safety belts
and return them to their normal stowed position
before folding a rear seat.
2. Fold the seatback down from inside the vehicle.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
To return the seatback to the upright position, push up
the seatback until you hear a click. Then pull on the
seatback to make sure it is secure.
1-12

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she cannot
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle harder or be ejected
from it and be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passenger(s) are
restrained properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
Your vehicle has indicators as a reminder to buckle your
safety belts. See Safety Belt Reminders on page 3-30.
In most states and in all Canadian provinces, the
law requires wearing safety belts. Here is why:
You never know if you will be in a crash. If you do have
a crash, you do not know if it will be a serious one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person would not
survive. But most crashes are in between. In many of
them, people who buckle up can survive and sometimes
walk away. Without belts they could have been badly
hurt or killed.
After more than 40 years of safety belts in vehicles, the
facts are clear. In most crashes buckling up does
matter... a lot!
1-13

Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it is just a seat on
wheels.
Put someone on it.
1-14

Get it up to speed. Then stop the vehicle. The rider
does not stop. The person keeps going until stopped by something. In a real vehicle, it could be the windshield...
1-15

or the instrument panel... or the safety belts!
With safety belts, you slow down as the vehicle does.
You get more time to stop. You stop over more distance,
and your strongest bones take the forces. That is why
safety belts make such good sense.
1-16
