Porter&Charles Insert-24 User manual

Insert-24, Insert-30, Insert-36
Range Hood Instruction Manual
Thank you for the purchase of this product. Please read the
manual carefully before operating the appliance.

1 | P a g e
Contents
Important Safety Instructions 2
Introduction
3
Features
3
Installation
4-5
How to Use
Grounding Instruction
6
7
Safety Information
8
Trouble Shooting
9
Electrical Diagram
10
Specifications
11
Cleaning & Maintenance
12
Installation Diagram
13
Warranty
14

2 | P a g e
Important Safety Instructions
○Read and save these instructions
○Warning - To reduce the risk of fire or electric shock, do
not use this fan with any solid-state speed control device.
○ CAUTION: For general ventilating use only. Do not use
to exhaust hazardous or explosive materials and vapors.
○Warning - To reduce the risk of a range top grease fire:
Never leave surface units unattended at high settings.
Boil overs cause smoking and greasy spillovers that
may ignite. Heat oils slowly on low or medium settings.
Always turn hood ON when cooking at high heat or
when flambéing food (i.e. Crepes Suzette, Cherries
Jubilee, Peppercorn Beef Flambé)
Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filter.
Use proper pan size. Always use cookware appropriate
for the size of the surface element.
○Warning - To reduce the risk of injury to persons in the
event of a range top grease fire, observe the following:
Smother flames with a close-fitting lid, baking sheet, or
metal tray, and then turn off the burner. Be careful to
prevent burns. If the flames do not go out immediately,
evacuate and call the fire department.
Never pick up a flaming pan - you may be burned.
Do not use water, including wet dishcloths or towels a
violent steam explosion may result.
Use an extinguisher ONLY if: A) You know you have a
class ABC extinguisher, and you already know how to
operate it. B) The fire is small and contained in the area
where it started. C) The fire department is being called.
D) You can fight the fire with your back to an exit.

3 | P a g e
Introduction
oThis appliance has been manufactured with materials
and processes that respect the environment. We hope
that you will continue this important consideration in
the operation of this appliance and the disposal of the
packaging materials –thank you.
oThe installation work must be undertaken by a
qualified technician experienced in range hood
installation. Please connect the correct power rating
(see page 10)
oThe manufacturer disclaims all liability for any damage
or injury caused as a result of not following instructions
for installation contained in the following text
oThe appliance is not intended for use by young children
or infirm persons without supervision
oYoung children should be supervised to ensure that
they do not play with the appliance
oThe maximum number of burners covered by a range
hood should not exceed 5
oAny modifications to the appliance, electric wire and
plug is dangerous and voids the warranty
Features
oThis appliance is manufactured from top quality
materials, and offers superb streamlined effects
oWith high suction power and low noise, it is designed
to remove cooking fumes from your kitchen quietly
and effectively

4 | P a g e
Pic 1
Installation (duct is not supplied)
1. The range hood should be mounted
at a distance of 600mm from an
electric or induction cooktop, and
762mm above a gas cooktop for
safety and optimum performance. If
the instructions for installation of the
gas cooktop specify a greater
distance, this has to be taken into
account. (see pic 1) The exhaust air must
not be discharged into a chimney which is used for
exhausting fumes from other appliances burning gas or
other fuels
2. To install, drill 2 holes of Ø8mm on a sturdy wall and in
line with the hood
3. Insert expanding screws into the holes
4. Fix drilling template on the wall (see pic 2)
5. The appliance should be embedded into the wall unit
or another support. This process should be carried out
by 4 screws suitable for the kind of unit following the
instructions for the drilling of the holes as shown (see
pic 3)
6. Attach the duct to the one way valve, and connect it to
the kitchen outlet vent (see pic 4)
600 –762mm

5 | P a g e
7. Ensure that the wall the hood is to be installed on is
sufficiently sturdy to carry the weight of the hood. It
should be mounted level for best performance
8. Do not connect to a common vent with any other
appliances such as a gas heater, water heater,
washer/dryer, etc.
9. The duct should not be bent more than120° from the
one way valve outlet in the kitchen vent
10. Make sure that the electrical cord is not in contact with
sharp edges of the appliance
11. Be sure that the plug is accessible after installation
Pic 2
Pic 3
Pic 4
Pic 5

6 | P a g e
How to Use
3 speed adjustment (see pic 6)
oPush the Low button, and the motor will run at the
lowest speed
oPush the Mid button, and the motor will run at
medium speed
oPush the High button, and the motor will run at the
highest speed
oPush the Light button, and the two lighting lamps will
illuminate. Push it again and the lights will turn off
oPush the Stop button, and the motor will turn off
Pic 6

7 | P a g e
Grounding Instructions
oThis appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The
plug must be plugged into an outlet that is properly
installed and grounded.
oWarning - Improper grounding can result in a risk of
electric shock.
oConsult a qualified electrician if the grounding
instructions are not completely understood, or if doubt
exists as to whether the appliance is properly
grounded.
oDo not use an extension cord. If the power supply cord
is too short, having a qualified electrician install an
outlet near the appliance.
WARNING: TO REDUCE THE RISK OF FIRE, USE ONLY METAL
DUCTWORK.

8 | P a g e
Safety Information
oThere must be permanent and adequate ventilation of the
room when operating the range hood with appliances
burning gas or other fuels
oDo not check the status of the filters when the range hood
is operating –wait at least 30 minutes after switching off
to avoid scalding
oDo not touch the LED light within 30 minutes after
appliance use
oAvoid operating a gas cooktop when there is no pan on the
stove. It is a fire hazard and may cause damage to the hood
filters
oDisconnect the electrical plug prior to any maintenance
oThis appliance is not intended for use by young children
unless they have been adequately supervised by a
reasonable person to ensure that they can use the
appliance safely
oThe range hood is for home use only and is not suitable for
outdoor, barbeque, and other commercial applications
oThe range hood and its filter should be cleaned regularly
for best performance
oBefore cleaning, please confirm that the power is switched
off
oBuilding regulations concerning the discharge of exhaust
air have to be fulfilled
oDon’t cook with an open flame under the range hood
oFor any technical issues ensure that a suitably qualified
person handles any repairs or inspections

9 | P a g e
Trouble Shooting
If any problem occurs, please detach the plug from the
socket and contact Euro-Parts or a similarly qualified
person in order to avoid a hazard.
Problem
Cause
Solution
Light on, but
motor does not
work
The outlet valve is
blocked
Detach flue and duct
then turn on the hood
to check if the valves
open
The capacitor has
failed
Call for technical
service
The control switch
has broken
Call for technical
service
Light does not
work, motor
does not work
No power supply
Plug another appliance
into the socket to
confirm there is power
supply
Fuse has blown
Open up the plug and
replace he 13A fuse
Vibration
The propeller is
damaged or
unbalanced
Call for technical
service
The hood is not
installed correctly
Review the installation
instructions and check
the installation again
for loose screws,
brackets or
connections
Insufficient
suction effect
The distance
between the hood
and cooktop is too
great
Check that the
distance is between
600mm and 762mm
The filters are
saturated
Clean the filters from
grease residue and
replace after cleaning

10 | P a g e
Electrical Diagrams
Insert-24, Insert-30
Insert-36
115V, 60Hz
115V, 60Hz
L2
L2

11 | P a g e
Specifications
Insert-24
Power Supply
115V, 60Hz
Rated Input Power
97W
Lighting Power
1 x 2W
Motor Power
95W
Airflow
300 CFM
Outlet Diameter
150mm
Insert-30
Power Supply
115V, 60Hz
Rated Input Power
97W
Lighting Power
1 x 2W
Motor Power
95W
Airflow
300 CFM
Outlet Diameter
150mm
Insert-36
Power Supply
115V, 60Hz
Rated Input Power
99W
Lighting Power
2 x 2W
Motor Power
95W
Airflow
300 CFM
Outlet Diameter
150mm

12 | P a g e
Cleaning & Maintenance
1. Clean the surface of the hood every week with mild
soap or detergent. Avoid solvents, acid, alkali, scouring
pads or powder that could irreparably damage the
stainless steel surface
2. The grease filters may be washed using mild soap,
detergent or degreasing agents
3. The charcoal filters cannot be cleaned and must be
replaced generally after 6 months of use

13 | P a g e
Installation Diagram
600, 762, 900mm

14 | P a g e
Warranty
Porter & Charles Appliances are imported and distributed
in North America by Euro-Line Appliances Inc.
For more information visit www.euro-line-appliances.com
or contact:
2278 Speers Road
Oakville, ON L6L 2X8
Canada
1-800-421-6332 –Euro-Line Appliances Inc.
1-800-ELA-WEST –Euro-Line Appliances West
[e-mail]
All Porter & Charles Appliances are backed by a
comprehensive 2-year part and labour warranty.
Information on service and parts available from Euro-Parts
at 1-800-678-8352
