Poulan Pro PLN3516F User manual

NEW
NOTE : Illustration may differ from actual model due to design changes. Page:
PARTS LIST
1
Parts List No.
Date
MODEL
R
= New Part Number For This IPL
= Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
1. Screw (2 Pack)
2. Screw
3. Motor Cover
4. Assy - Electric Saw
5. Assy - Oil Tank Cap
6. Kit - Sprocket
7. Kit - Chain Catcher
8. Kit - Adjuster Wheel
9. Bar
10. Chain
11. Screw
12. Assy - Bar Clamp
13. Scabbard
Manual
WARNING
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by Qualified Service
Personnel.
Ref. Part No. Description Ref. Part No. Description
Not Shown
8
7
11 12
13
9
10
4
3
1
2
6
5
574607901
574623801
574608001
576180501
574630401
576180701
576180801
576180901
966051301
966051603
574630701
576181301
576181501
01/2801/10
952802358
115367826
PLN3516F
